X7502828700
12/14
SHINDAIWA OWNER'S/OPERATOR'S MANUAL
T282 TRIMMER
Minimize the risk of injury to yourself and others! Read this manual
and familiarize yourself with the contents. Always wear eye and
hearing protection when operating this unit.
WARNING!

Advertisement

Table of Contents
loading

Related Manuals for Shindaiwa T282

Summary of Contents for Shindaiwa T282

  • Page 1 SHINDAIWA OWNER’S/OPERATOR'S MANUAL T282 TRIMMER Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit. WARNING! X7502828700 12/14...

  • Page 2: Table Of Contents

    If you have questions regarding your power tool, or if you do not understand something in this manual, your Shindaiwa dealer will be glad to assist you. You may also contact Shindaiwa at the address printed on the back of this Manual.

  • Page 3: Safety

    WARNING: Surface can Make sure no one is 50 FEET a Shindaiwa approved be hot. Always wear gloves (15m within 15 m (50 feet) of handlebar or barrier. when handling this unit.
  • Page 4 Immediately replace damaged or missing information labels. New labels are available from your local authorized Shindaiwa dealer. The Properly Equipped Operator Wear hearing protection devices and a Always wear eye protection such as broad-brimmed hat or helmet.
  • Page 5 Be Aware of the Working Environment Reduce the risk of bystanders being Make sure struck by flying debris. Make sure no bystanders one is within 15 meters (50 feet)— or observers that’s about 16 paces of an operating outside the attachment.

  • Page 6: Product Description

    Bore x Stroke 35 x 30 mm (1.38 x 1.18 in.) Displacement 28.9 cc (1.7 cu. in.) 50:1 Shindaiwa Red Armor® ISO-L-EGD (ISO/CD 13738) and J.A.S.O. Fuel/Oil Ratio M345- FD, two-stroke, air-cooled engine oil. 750 ml (25.4 oz. Fuel Tank Capacity...

  • Page 7: Emission Control

    Outer Tube 1. Position front handle for comfortable operation and secure screw. Screw Cutting Attachment Shield 1. Insert the cutting attachment shield T282 between the outer tube and the cutting attachment mounting plate. NOTE: Outer Tube Socket-Head It may be necessary to loosen the...
  • Page 8 Adjust Throttle Lever Free Play The throttle lever free play should be approximately 4 - 6 mm (3/16 - 1/4 in.). Make sure that the throttle lever operates smoothly without binding. If it becomes necessary to adjust the lever free play, follow the procedures and illustrations that follow.

  • Page 9: Mixing Fuel

    2-Stroke Oil is strongly recommended as it meets this standard and is specifically formulated for use in all Shindaiwa 2-stroke engines. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345/FD certified oil will void the engine warranty.

  • Page 10: Filling The Fuel Tank

    Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline. 2. Add the proper amount of engine oil to gasoline. 3. Close container and shake to mix oil with gasoline. 4. Add remaining gasoline, close fuel container, and remix. IMPORTANT! Spilled fuel is a leading cause of hydrocarbon emissions.

  • Page 11: Starting The Engine

    Starting the Engine IMPORTANT! Engine ignition is controlled by a two position switch mounted on the throttle housing labeled, “I” for ON or START and “O” for OFF or STOP. WARNING! The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury.

  • Page 12: Stopping The Engine

    Starting the Engine (continued) 5. When the engine starts, slowly move the choke lever to the “OPEN” position. If the engine stops after the initial start, close the choke and restart. OPEN WARNING! Keep all parts of your body away from the rotating cutting attachment and hot surfaces.

  • Page 13: Checking Unit Condition

    Contact local fire authorities for laws or regulations regarding fire prevention requirements. Cutting grass with a trimmer head Your Shindaiwa unit may be equipped with one of several Shindaiwa trimmer head models, each with features for specific applications and/or operational requirements.

  • Page 14: Maintenance

    CONTROL SYSTEM AND MAY HAVE A BEARING ON THE OUTCOME OF A WARRANTY CLAIM. NOTE: Using non-standard replacement parts could invalidate your Shindaiwa warranty. WARNING! Before performing any maintenance, repair, or cleaning work on the unit, make sure the engine and cutting attachment are completely stopped.

  • Page 15: Spark Plug

    Muffler Spark Plug This unit must never be operated with a faulty or missing spark Keep the spark plug and wire connections tight and arrester or muffler. Make sure the muffler is well secured and in clean. good condition. A worn or damaged muffler is a fire hazard and Fasteners may also cause hearing loss.
  • Page 16 Remove the filler plug from the side of the gear case and press new grease into the gear case until old grease is pushed out. Use only lithium- base grease such as Shindaiwa Gear Case Lubricant or equivalent. grease ■...
  • Page 17 7. Gently tap the muffler on a wood surface to dislodge any loose carbon. 8. Reassemble the spark arrester, muffler and engine cover in the reverse order of disassembly. IMPORTANT! If you note excessive carbon buildup, consult with an authorized Shindaiwa servicing dealer.

  • Page 18: Carburetor Adjustment

    NOTE: Every unit is run at the factory and the carburetor is set in compliance with emission regulations. Carburetor adjustments, other than idle speed, must be performed by an authorized Shindaiwa dealer. WARNING! When carburetor adjustment is completed, the cutting attachment should not move at idle, otherwise serious personal injury may result.

  • Page 19: Long Term Storage

    2. Start and run the engine until it ■ stops running. Store the unit in a clean, dust-free Damage resulting from stale or area. contaminated fuel is not covered by 3. Repeat steps 1 and 2 until the the Shindaiwa warranty policy. engine will no longer start.

  • Page 20: Troubleshooting Guide

    ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. ENGINE DOES NOT START What To Check Possible Cause Remedy Consult with an authorized Shindaiwa servicing dealer. Faulty recoil starter. Does the engine crank? Fluid in the crankcase. Internal damage. Tighten and re-test.
  • Page 21 89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. Piston seizure. Consult with an authorized Shindaiwa servicing dealer. Faulty carburetor and/or diaphragm. Overheating condition. Consult with an authorized Shindaiwa Engine is knocking.
  • Page 22 Adjust idle. Check Specifi cations page for correct Idle set too high. Engine will not idle idle speed. down. Consult with an authorized Shindaiwa servicing Engine has an air leak. dealer. Adjust idle. Check Specifi cations page for correct idle Engine idle too high.

  • Page 23: Warranty Statement

    The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as pre- scribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your Shindaiwa unit to an authorized Shindaiwa servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made.
  • Page 24 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the Shindaiwa oil label and covered in your operator’s manual.

  • Page 25: Product Registration

    Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.

  • Page 26: Notes

    NOTES...
  • Page 27 NOTES...

  • Page 28: Servicing Information

    Genuine Shindaiwa Parts and Assemblies for your Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number, Type and Serial Number of the unit with you. You can find these numbers on the engine. For future reference, write them in the space provided below.
