SHINDAIWA OWNER'S/OPERATOR'S MANUAL
MULTIPURPOSE
POWERBROOM TOOL
Model 80264
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.

Advertisement

Table of Contents
loading

Related Manuals for Shindaiwa 80264 PowerBroom

Summary of Contents for Shindaiwa 80264 PowerBroom

  • Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL MULTIPURPOSE POWERBROOM TOOL Model 80264 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.

  • Page 2: Table Of Contents

    The Shindaiwa Multipurpose PowerBroom™ Tool has been designed and built to deliver superior performance and reliability without compromise to quality, comfort, safety or durability. As an owner/operator, you’ll soon discover for yourself why Shindaiwa is simply in a class by itself! IMPORTANT! The information contained in these instructions describes machines available at the time of publication.

  • Page 3: Safety Labels

    This Shindaiwa PowerBroom tool is specifically designed for use on the Shindaiwa Multipurpose Tool Carrier. Instal- lation and/or use on any other model, brand or type of power tool is not approved by Shindaiwa. Attempts to use on non-approved models can damage the equipment and cause accidents, serious injury or death.

  • Page 4: General Safety Instructions

    The Properly Equipped Operator Work Safely: Be Aware of the Work- Always wear appropriate hear- ing Environment ing protection. Always wear eye protec- tion such as goggles or ■ Be careful when operating on a slope safety glasses. or on slippery terrain, especially dur- ing rainy weather.

  • Page 5: Assembly

    Use Good Judgment WARNING! Always wear eye protection to shield against thrown objects. Always protect yourself from hazards such as thorny brush and flying debris by wearing gloves and close fitting cloth- ing that covers arms and legs. Never wear shorts. Don’t wear loose clothing or items such as jewelry that could get caught in machinery or underbrush.
  • Page 6 Assembly: 1. Remove drum assembly (A) from drum axle (C) on clamping bolt side of gear case. 2. Loosen clamping bolt on gear case (D) and remove locating screw (E). 3. Install tube guard (F) onto outer shaft tube. NOTE Assure that locating hole of internal collar aligns with locat- ing hole in gear case.

  • Page 7: Checking Unit Condition

    Checking Unit Condition NEVER operate the unit with the protective devices (ignition switch, etc.) re- moved! Use only authorized Shindaiwa parts and accessories with your Shindaiwa Multipurpose Tool. Do not make modifications to your machine without the written approval of Shindaiwa.

  • Page 8: Operation

    Figure 10 Operation Starting and Fueling For detailed instructions on general safety procedures, fueling, starting, and stopping the Shindaiwa Multipurpose Tool Car- rier, refer to the appropriate Owner’s Manual for your model machine. WARNING! KEEP CLEAR of drum assemblies during starting operations! The drums may rotate during startup.

  • Page 9: Operating Techniques

    Operating Techniques Sweeping Windrows Operate the PowerBroom at or near full throttle with its sweeper fins resting on the work surface. IMPORTANT! It is both tiring and unnecessary to lift or hold the fins from the work surface dur- ing sweeping. When sweeping narrow areas such as sidewalks, the PowerBroom can be used to throw material directly ahead of the operator.

  • Page 10: Maintenance

    IMPORTANT! For detailed maintenance information about your Multipurpose Tool Carrier, consult the owner's manual that was provided with it. If it has been lost or misplaced, contact Shindaiwa for a replacement. NOTE: Using non-standard replacement parts could invalidate your Shindaiwa warranty.

  • Page 11: Troubleshooting Guide

    Troubleshooting Guide Symptom Possible Cause Remedy Excessive vibration Warped or damaged drums or belts. Inspect and replace drum or belt as required. Loose gear case. Tighten gear case securely. Bent main shaft/worn or Inspect and replace as necessary. damaged bushings. Drums will not rotate.

  • Page 12: Servicing Information

    Service of this product during the warranty period must be performed by an Authorized Shindaiwa Service Dealer. For the name and address of the Authorized Shindaiwa Service Dealer nearest you, ask your retailer or call: 1-877- 986-7783. Dealer information is also available on WWW.SHINDAIWA.COM. When presenting your unit for Warranty service/repairs, proof of purchase is required.
