Page 1: Operating Instructions
Aconda 9272 Aconda 9372 Aconda 9281 HD Aconda 9381 HD Neu für 3.Auflage: S11, 14, 16, 17, 18, 19, 24 BAQ2550H_31308_020_3_GB2 Operating Instructions. 07.05.2004, 10:58 Uhr... -
Page 2: Table Of Contents
Video mode Operating additional equipment 18 – 20 Logging in and connecting AV equipment Video playback Loewe video recorders and direct operation of Loewe DVD players What to do if … 21 – 22 Technical data Mechanical data Electrical data... -
Page 3: Remote Control - Tv Functions
Remote control – TV functions Indicator: Operate VCR Indicator: operate DVD Direct operation select for VCR/DVD/TV PIP operation on/off Video operation with video operating line on/off Call up menu /in the menu: back Teletext mode on/off Select programme up/down /in the menu: select up/down Personal teletext pages on/off Set picture format... -
Page 4: Control Panel
Control panel Open control panel Channel up/down Video input AVS Headphones socket /In a menu: adjust Standby indicator (CVBS) Audio input (white=left, Video input AVS To display Operating red= right) (Y/C, CVBS) menu indicator On/Off key V IN AV-S AUDIO —... -
Page 5: Rear Connections
AUDIO IN AV2/RGB AUDIO VHF/UHF SUBWOOFER STAND Connection for Connection for subwoofer in the stand, Loewe active loudspeaker systems special subwoofer or Home Automation Dolby digital module 07.05.2004, 10:58 Uhr Digital tone inputs Dolby digital module Digital tone output Dolby digital module... -
Page 6: Welcome
With the remote control, you can operate three Loewe units, this TV, a Loewe video recorder and a Loewe DVD player. BAQ2550H_31308_020_3_GB2 TV equipment This operating manual describes the maximum equipment. -
Page 7: For Your Own Safety
For your own safety For your own safety and in order to avoid unnecessarily damaging your TV set, please read and observe the following safety instructions: • This TV set is designed exclusively for receiving and reproducing audio and visual (AV) signals. - Page 8 BAQ2550H_31308_020_3_GB2 We recommend you to use only original parts, e.g. Loewe racks and stands. If the TV set is placed on a console with castors, move the console carefully because the console and the TV could tip over.
-
Page 9: Initial Installation
You then see a list of the stored stations in which you can mark your favorites. Finally log in your video recorders, decoders, Loewe audio system and Home Automation with the connection wizard and connect these to the TV set according to the illustrated connection plan. -
Page 10: Daily Handling
Daily handling Switching on/off Your TV set is equipped with an eco-standby power supply unit. The power consumption drops to low power in standby mode. If you want to save even more energy, switch the set off with the On/Off switch. However, please note that EPG data are then lost and timer recordings programmed on the TV set will not be carried out. -
Page 11: General Menu Operation
Daily handling General menu operation With the TV and picture menus, we show you how to navigate within the menus. Which buttons you can use for operation is shown at the bottom of the appropriate menu. Call the TV menu TV menu Mark Standard settings... -
Page 12: Modes Of Operation
TV. If it is a question about the operation, you have direct access to the operat- ing function from the index. Loewe TV sets are supplied in different models with different equipment. You can find out what equipment your TV has under the menu item ”Technical spec. -
Page 13: Picture In Picture
Modes of operation Picture in Picture (PIP) Standard PIP functions: In standard PIP, a PIP picture is displayed in the current TV picture. The frame round the PIP picture is initially green in standard PIP. Show/hide PIP picture PIP picture as still frame The frame around the PIP picture must be green. -
Page 14: Epg Mode
Modes of operation EPG mode EPG is the electronic program guide for TV programs. With this system, you can easily find the stations that interest you (sorted according to time, day, topics and programs). You can memorize stations and station recordings. A wizard is activated the first time you use EPG (not with DVB) which guides you through the necessary settings. -
Page 15: Radio Mode
Modes of operation EPG settings If you want to change the provider or want to have other programs evaluated, you can do this in the EPG menu. Provider search EPG on/off Call EPG menu EPG menu List of memorized stations Select provider/program Favorite programs Select personal topics... -
Page 16: Teletext Mode
Modes of operation Teletext mode Teletext transmits information such as News, Weather, Sport, Program Previews and Subtitles. Teletext on/off 1OO 1OO ARD-Text O1.O7.O1 1O:3O:42 ARD-Text Teletext im Ersten Letzte Meldung: Libyscher Botschafter in London schließt Entschädigung für Lockerbie-Opfer nicht mehr aus Fußball: Rolf Hüssmann soll neuer Sportdirektor beim VfB Stuttgart... -
Page 17: Video Mode
Loewe VCRs also have Digital Link, a system for controlling Loewe VCRs via the Euro-AV cable. If the Loewe VCR only has Digital Link, the TV tuner is used for recording. If you have installed your Loewe VCR in a concealed place, you can operate the Loewe VCR with the remote control. -
Page 18: Operating Additional Equipment
Logging in equipment You have already logged in and connected all connected devices (video recorders, camcorders, DVD player, DVD recorder, Loewe audio system, Pay-TV decoders, Loewe home automation, door intercom) with the connection wizard when you put it into operation for the first time. If you... -
Page 19: Video Playback
TV menu). Then the VCR picture is shown on the current station slot as in Digital Link Plus VCR’s. 2. You can also control logged-in Loewe VCRs and DVD players with the video menu bar. See page 17 for more details. - Page 20 Operating Loewe video recorders and Loewe DVD players directly You can switch over the remote control of the TV set to operate Loewe video recorders and Loewe DVD players. These devices can be operated directly or, in the case of equipment installed in a concealed place, by the TV set.
- Page 21 The ”Stations” item in the TV menu and the ”Automatic station search” item in the main information cannot be called Control of the Loewe VCR with the video control bar and the timer does not work or does not work properly...
- Page 22 (decoder, TV or Autom.), see instructions of the decoder. a) Change the setting to ”TV”. b) Either a dummy plug with bridges, Loewe Concertos, the transmitter for the home automation or a subwoofer must be plugged into the cubic socket.
-
Page 23: Technical Data
IR-Link OUT Jack 2,5 mm RC5/RC6 OUT D-Sub 15-pole 9-pole cube socket active loudspeaker systems Mini-DIN 9 pole Turning foot Mini-DIN 8-pole Service or Loewe audio systems Cinch Centre OUT Centre Signal Cinch Subwoofer OUT LFE Signal Cinch Surround OUT Cinch Dig. -
Page 24: Accessories Available
Accessories available Racks Ask your dealer, he will be able to offer you the right rack from the Loewe range to suit your TV set. Loewe audio systems and active loudspeaker systems A combination of a Loewe TV set, a Loewe... -
Page 25: Service Addresses
