General Information
1.3.10.2 Comm Antenna
The Apollo CNX80 requires a VHF comm antenna meeting the following specifications:
•
Standard 50Ω vertically polarized antenna with a VSWR < 2.5:1
•
TSO C37d, and TSO C38d
1.3.10.3 VHF Antenna
The Apollo CNX80 requires a VHF NAV antenna meeting the following specifications:
• Standard 50 Ω horizontally polarized antenna with a VSWR < 3:1
•
Capable of receiving VOR/LOC/GS (Such as: Comant Industries P/N CI 157P)
•
108.00 – 117.95 MHz (VOR/LOC)
•
328.60 – 335.4 MHz (GS)
•
TSO C34e, TSO C36e, and TSO C40c
1.3.11 S I
ERIAL NTERFACE
RS-232 Defined in Appendix B- Serial Interface Specifications
1.4 R
EGULATORY
1.4.1 TSO
AND
•
TSO-C34e, ILS Glide Slope Receiving Equipment Operating Within the Radio Frequency Range
of 328.6-335.4 Megahertz (MHz)
•
TSO-C36e, Airborne ILS Localizer Receiving Equipment Operating Within the Radio Frequency
Range of 108-112 Megahertz (MHz)
•
TSO-C37d, VHF Radio Communications Receiving Equipment Operating Within the Radio
Frequency Range 117.975 to 137.000 Megahertz
•
TSO-C38d, VHF Radio Communications Transmitting Equipment Operating Within the Radio
Frequency Range 117.975 to 137.000 Megahertz
•
TSO-C40c, VOR Receiving Equipment Operating Within the Radio Frequency Range of 108-
117.95 Megahertz (MHz)
•
TSO-C113, Airborne Multipurpose Electronic Displays
•
TSO-C128, Devices That Prevent Blocked Channels Used in Two-Way Radio Communications
Due to Unintentional Transmission
•
TSO-C146a, Stand-Alone Airborne Navigation Equipment using the Global Positioning System
(GPS) Augmented by the Wide Area Augmentation System (WAAS)
•
AC 20-67B, Airborne VHF Communications Equipment Installations
•
AC43.13-1B, Acceptable Methods, Techniques and Practices - Aircraft Inspection and Repair
•
AC43.13-2A, Acceptable Methods, Techniques and Practices - Aircraft Alterations
Unauthorized changes or modifications to the CNX80 may void the compliance to required
regulations and authorization for continued equipment usage.
1-14
C
OMPLIANCE
A C
DVISORY IRCULAR
560-0982-00 Rev D
R
EFERENCES
NOTE
