Setting the FM/MW interval

The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for MW stations. The illustration shows the 50/9 kHz
zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
This product is not equipped with a span selector. However, it will be
adjusted to a 50 kHz FM (9 kHz MW) interval when shipped from the
factory.
Before using the unit, be sure to set it to the FM/MW tuning interval
(span) used in your area.
To change the FM/MW tuning interval:
1 Press the ON/STAND-BY button to turn the power on.
2 Press and hold down the TUNER (BAND) button, for 3 seconds.
3 The display will appear for 2 seconds and the new setting is acti-
vated.
Caution:
● When the unit is left for a few hours after the span has been
switched and the AC power lead disconnected, the FM span will
be automatically returned to 50 kHz (MW span to 9 kHz). If this
happens, set the span again.
● When the span is switched, all the memorised stations will be can-
celled.
Downloaded From Disc-Player.com Sharp Manuals
Listening to a cassette tape
(TAPE 1 or TAPE 2)
Before playback:
● For playback, use normal or low-noise tapes for
the best sound. (Metal or CrO tapes are not
recommended.)
● Do not use C-120 tapes or poor-quality tapes, as
they may cause malfunctions.
● Before loading a tape into the cassette compartment,
tighten the slack with a pen or a pencil.
Auto power off function:
In the stop mode of tape operation, the main unit enters the stand-
by mode after 15 minutes of inactivity.
or
04/1/28 CX-GD5200V_EN2.fm
GX-CD5200V
ENGLISH
E-30
