Page 1: Video Splitter
Video Splitter USER MANUAL VS-132... -
Page 2: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Package Contents
Copyright © 1999–2008 ATEN International Co., Ltd. Manual Part No. PAPE-1153-200G Manual Date: 2008-11-27 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 3 -... - Page 4 Overview The VS-132 Video Splitter is a boosting device to duplicate the video signal from one source to two outputs, and is ideal for any monitor using analog signals. The VS-132 also extends the transmission distance up to 65 m (210 feet) making it excellent for public broadcast systems.
- Page 5 Features One video input to two video outputs Cascadable to three levels – provides up to 8 video signals Supports up to 350 MHz bandwidth Long Distance Transmission – up to 65 m (210 ft) High video quality – 1920 x 1440 DDC, DDC2, DDC2B Compatible (Port 1 only*) Supports XGA, VGA, SVGA, and multisync monitors Note: If you connect a DDC type monitor to Video Out 1, all...
-
Page 6: Hardware Requirements
Hardware Requirements One or more XGA, SVGA, VGA, and/or multisync compatible analog monitor(s) with standard PC high density cables having 15 pin D type male connectors. Computer with one XGA, SVGA, VGA, and/or multisync analog video port with a standard PC 15 pin D type female connector. -
Page 7: Front View
Video Out Your monitors (or cascaded video splitters) plug Ports in here. Video In Port The cable that links the VS-132 to the computer's video port plugs in here. Gain Switch To boost the video signal when the computer is located at some distance from the unit, slide the switch to the High position. -
Page 8: Standalone Installation
Installation Standalone Installation Setting up the Video Splitter is simply a matter of plugging in the cables. Refer to the diagram as you follow the step-by-step directions below: 1. Make sure that the computer and monitors you are using for the installation are all powered Off. - Page 9 Cascading To provide video display for more monitors, additional VS-132s can be cascaded. Use a high density HDB-15 male/female video extender cable (Part No. 2L-2401), to connect any available Video Out port on the higher level Video Splitter to the Video In port of the lower level Video Splitter.
-
Page 10: Specifications
Specifications Function VS-132 Display Connections Connectors Video In 1 x HDB-15 Male Video Out 2 x HDB-15 Female Power 1 x DC Jack LEDs 1 x Signal Indicator 1 Power Indicator Video 1920 x 1440 @80 Hz Cable Distance Up to 65 m (210 ft.) Power Consumption AC 9V, 120mA (max.)
