- Page 1 4-Port True 4K HDMI Switch with Dual Output VS482B User Manual www.aten.com...
-
Page 2: Emc Information
VS482B User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
VS482B User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988... -
Page 4: Package Contents
VS482B User Manual Package Contents 1 VS482B 4-Port True 4K HDMI Switch with Dual Output 1 IR Remote Control Unit 1 Power Adapter 1 Mounting kit 1 User Instructions* Note: 1. Make sure that all the components are present and in good order. -
Page 5: Table Of Contents
VS482B Installation ........ - Page 6 VS482B User Manual Standby/Power Commands ....... . 18 Switch Mode Commands ........19 EDID Commands .
-
Page 7: About This Manual
VS482B User Manual About this Manual This User Manual is provided to help you get the most from your VS482B system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. -
Page 8: Conventions
For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... -
Page 9: Introduction
Chapter 1 Introduction Overview The ATEN VS482B Switch is an ideal solution for application requiring superior video resolution of True 4K when connecting 4 HDMI A/V sources to 2 HDMI displays. Complying with HDMI 2.0 standards, the switch’s Audio Return Channel (ARC) function allows users to send audio without having to attach a separate audio cable. -
Page 10: Features
HDR supported HDMI 2.0 (3D, Audio Return Channel, Deep Color); HDCP 2.2 compliant Supports Auto Switch – the VS482B automatically switches to a newly plugged-in source Audio Return Channel (ARC) function – connects an HDMI cable to the... -
Page 11: Requirements
Contact your dealer to purchase the correct cable sets. 2. If you wish to utilize the VS482B’s high-end serial controller function, you will also need to purchase an appropriate RS-232 cable. -
Page 12: Components
VS482B User Manual Components VS482B Front View Component Description Port LEDs The selected port’s LED (green) lights up to indicate that the port is selected. ARC LED The LED (blue) lights up when the ARC function is enabled. Power Pushbutton Press this button to turn on / off the switch. -
Page 13: Vs482B Rear View
Chapter 1. Introduction VS482B Rear View Component Description Power Jack The power adapter cable plugs in here. IR EXT (Extender) Connect the IR Extender to this port. Port Note: The IR receiver can be purchased separately. RS-232 Serial Port This is the serial remote port for input source selection and high-end system control, including firmware upgrade. -
Page 14: Ir Remote Control
VS482B User Manual IR Remote Control Component Description Up / Down / Left / Press the Up / Down / Left / Right button to cycle Right Arrows through the OSD menu/selection. Setup Press this to confirm the selection on the OSD screen. -
Page 15: Hardware Setup
3. Make sure that all devices you will be installing are properly grounded. Rack Mounting For convenience and flexibility, the VS482B can be mounted on system racks. To rack mount a unit do the following: 1. Using the screws provided in the Mounting Kit, screw the mounting... -
Page 16: Grounding
To prevent damage to your installation it is important that all devices are properly grounded. 1. Use a grounding wire to ground the VS482B by connecting one end of the wire to the grounding terminal, and the other end of the wire to a suitable grounded object. -
Page 17: Installation
Chapter 2. Hardware Setup Installation Installation of the VS482B is simply a matter of plugging in the appropriate cables. VS482B Installation To install the switch, refer to the installation diagram below as you perform the following steps: 1. Connect your audio devices (such as speakers or AVRs) to the Stereo Audio Out Ports or Digital Audio Out Ports. -
Page 18: Installing The Rs-232 Controller
In order to use the RS-232 serial interface to attach a high-end controller (such as a PC) to the VS482B, use a serial cable such as a modem cable. The end connecting to the VS482B should have a 9-pin male connector. Connect this to the serial interface on the rear of the VS482B. -
Page 19: Operation
RS-232 serial interface, and system settings via OSD menu. Note: 1. Whenever the VS482B is powered on and there is no video input source connected, it automatically selects Port 1 as the active port (i.e., the Port 1 LED lights up). -
Page 20: Switch Mode
In addition, the Go To function, which can be turned On or Off via RS-232 commands, enables the VS482B to switch to the next port with a powered on source device when the current input source is off. Refer to Switch Mode... -
Page 21: Audio Return Channel (Arc)
HDMI Displays The audio/video coming from the HDMI sources (Blu-ray, DVD, etc.) are received by the VS482B and then passed on to the HDMI displays (TV, projector or AVR). However if the HDMI audio or video is coming from the TV (through a... -
Page 22: Enabling Arc
ARC feature is enabled or disabled. See ARC Commands, page 24 for more information. In the following diagram, audio from the TV goes to the VS482B through the ARC Input port, and is then passed on to the AVR via the HDMI cable or the audio devices connected to the HDMI output ports. -
Page 23: Ir Command Code
Chapter 3. Operation IR Command Code Carry Frequency: 38KHz IR Protocol: NEC Customer Code: 00FD Data Code: Function Data Code Left Down Right Setup Port 1 Port 2 Port 3 Port 4 MENU Info HDMI MUTE... -
Page 24: Rs-232 Serial Interface
VS482B User Manual RS-232 Serial Interface The VS482B’s built-in bi-directional RS-232 serial interface allows system control through a high-end controller, PC, and/or home automation / home theater software package. Configuring the Serial Port The controller’s serial port should be configured as follows:... - Page 25 Chapter 3. Operation Port number Description 01-04 port (default is 01) Control Description Turn on the display Turn off the display Next Port Previous Port The following table shows the available command list: Command Input Port Control Enter Description [Enter] Switch Input Port [Enter] Turn on (Display out) [Enter] Turn off (No output) [Enter] Switch to the next input...
-
Page 26: Standby/Power Commands
VS482B User Manual Standby/Power Commands The Standby/Power feature enables the VS482B to enter power saving mode. The formula for Standby/Power commands is as follows: Standby + Control command [Enter] 1. For example, to disable the Standby/Power feature, input the following:... -
Page 27: Switch Mode Commands
Auto - Places priority on a selected port so that when a source is connected to the said port, the VS482B automatically switches to it, and the port can not be changed until the source is unplugged or auto switching mode is disabled with the default command. - Page 28 VS482B User Manual Control Description default No automatic switching operation next Priority is placed on the next port that has a new source connected to it (default) auto Priority is placed on a selected port goto on Switch to the next port with a...
-
Page 29: Edid Commands
Extended Display Identification Data (EDID) is a data format that contains a display's basic information and is used to communicate with the video source/ system. You can set up which EDID mode the VS482B uses with the following command: EDID Command + Control (port1 / auto / default) [Enter] 1. -
Page 30: Cec Commands
VS482B User Manual CEC Commands Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control. The formula for CEC mode selection commands is as follows: CEC Command + Control (Off / Auto / Port1) [Enter] 1. -
Page 31: Mute Commands
Chapter 3. Operation Mute Commands Enable or disable audio coming from the output port(s) using the following command: Mute Command + Control (On / Off) [Enter] 1. For example, to mute the audio, type the following: mute on [enter] The following tables show the possible values for the Mute string Command Description mute... -
Page 32: Arc Commands
VS482B User Manual ARC Commands Audio Return Channel (ARC) allows a source device (TV, STB, etc.) to send audio “upstream” to an audio/video receiver using only one HDMI cable. The formula for enabling/disabling ARC is as follows: ARC Command + Control (On / Off) [Enter] 1. -
Page 33: Echo
Echo on echo [Enter] Echo off Reset You can reset the VS482B to default factory settings. The formula for the Reset command is as follows: Reset Command [Enter] The following tables show the possible values for the Reset string Command... -
Page 34: Baud Rate Setting
VS482B User Manual Baud Rate Setting You can select the RS-232 Baud Rate you want the VS482B to use. Options are 9600, 19200 (default) 38400 and 115200. The formula for Baud Rate setting command is as follows: Baud Command + Control [Enter] 1. -
Page 35: Verification
Command incorrect - indicates that the command has the wrong format and/or values. Powering Off and Restarting If you power off the VS482B, follows these steps before powering it on again: 1. Power off the attached devices. 2. Unplug the power adapter cable from the VS482B. -
Page 36: Osd Menu
VS482B User Manual OSD Menu Use the MENU pushbutton on the remote control to view the OSD menu and cycle through the options in the order shown in the table below. See IR Remote Control, page 6 for details on how to use the remote control. -
Page 37: Input Setting Menu
Chapter 3. Operation Input Setting Menu Use this screen to select the video source device(s) for the HDMI input port(s). 1. Use the drop-down menu to select a video source device for HDMI 1 input port. Options are as follows. Note: The default value HDMI Device does not point to any device. -
Page 38: Audio Setting
Audio Setting Use this screen to configure the VS482B audio settings. 1. Use the drop-down menu to Enable or Disable ARC on the VS482B. See Audio Return Channel (ARC), page 13 for more details on this feature. 2. Use the drop-down menu to select which audio channel receiver the VS482B uses. -
Page 39: Osd Setting
Chapter 3. Operation OSD Setting Use this screen to configure the VS482B OSD settings. 1. Use the drop-down menu to select which display mode the VS482B uses to display information in the upper left corner of the screen. Options are as follows. - Page 40 VS482B User Manual 2. Select the visibility of the OSD menu when it is invoked. Press the menu button to enter the adjustment menu. Use the drop-down menu to select a value. The value 100 shows a fully visible and opaque OSD menu. The...
-
Page 41: System Setting
2. Use the drop-down menu to select how the video source’s CEC is applied. See Verification, page 27 for more details. 3. Set this to On to have the VS482B return to default settings when it is reset. Otherwise, select Off. - Page 42 VS482B User Manual This Page Intentionally Left Blank...
-
Page 43: The Firmware Upgrade Utility
Introduction The purpose of the Windows-based Firmware Upgrade Utility is to provide an easy process for upgrading the VS482B. The program comes as part of a Firmware Upgrade Package that is specific for each device. As new firmware versions become available, new firmware upgrade packages are posted on our website. -
Page 44: Preparation
Preparation To prepare for the firmware upgrade, do the following: 1. Use an RS-232 cable to connect a COM port on your computer to the RS- 232 Serial Port of your VS482B. VS482B 2. Unplug the VS482B’s power adapter. 3. Hold-down front panel pushbutton 1 and plug the power adapter into the VS482B to power the unit. -
Page 45: Starting The Upgrade
Chapter 4. The Firmware Upgrade Utility Starting the Upgrade To upgrade the firmware: 1. Run the downloaded firmware upgrade package file either by double- clicking the file icon, or by opening a command line and entering the full path to it. The Firmware Upgrade Utility welcome screen appears: Note: The screens shown in this section are for reference only. - Page 46 VS482B User Manual 3. Click Next to continue. The Firmware Upgrade Utility main screen appears. The devices capable of being upgraded are listed in the Device List panel: 4. Click Next to perform the upgrade. The Port LEDs 1, 3, and 4 will flash while the upgrade is in process.
-
Page 47: Upgrade Succeeded
Chapter 4. The Firmware Upgrade Utility Upgrade Succeeded After the upgrade has completed, all port LEDs will stop flashing and a screen appears to inform you that the procedure was successful: Click Finish to close the Firmware Upgrade Utility. Upgrade Failed If the Upgrade Succeeded screen doesn't appear, it means that the upgrade failed to complete successfully. -
Page 48: Firmware Upgrade Recovery
VS482B User Manual Firmware Upgrade Recovery There are three conditions that call for firmware upgrade recovery: When a firmware upgrade is manually aborted. When the mainboard firmware upgrade fails. When the I/O firmware upgrade fails. To perform a firmware upgrade recovery, do the following: 1. -
Page 49: Safety Instructions
Appendix Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. This product is for indoor use only. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 50 VS482B User Manual Never push objects of any kind into or through cabinet slots. They may touch dangerous voltage points or short out parts resulting in a risk of fire or electrical shock. Do not attempt to service the device yourself. Refer all servicing to qualified service personnel.
-
Page 51: Rack Mounting
Appendix Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack. -
Page 52: Technical Support
VS482B User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://support.aten.com For telephone support, see Telephone Support, page iii: North America Email Support support@aten-usa.com Online Technical Troubleshooting http://www.aten-usa.com/support Support Documentation Software Updates... -
Page 53: Specifications
Appendix Specifications Function VS482B Display Connections Connectors Video Input Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Max. 3 m (4096 x 2160 @ 60Hz, 4:4:4) Distance Video Output Interfaces 2 x HDMI Type A Female (Black) Impedance 100 Ώ... - Page 54 VS482B User Manual Function VS482B Video Max. Data Rate 18 Gbps (6Gbps Per Lane) Max. Pixel Clock 600 MHz Compliance HDMI 2.0 (3D, Audio Return Channel, Deep Color) HDCP 2.2 Consumer Electronic Control (CEC) Max. Resolution 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) Max.
-
Page 55: Limited Warranty
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
