Jeep 2009 Commander Owner's Manual page 433

1 — Low Beam Bulb
2 — High Beam Bulb
3 — Front Park/Turn Signal Bulb
MAINTAINING YOUR VEHICLE 431
4. Turn the socket on the bottom of the front lamp unit
housing 1/4 turn counterclockwise to unlock it.
5. Pull the socket and bulb straight out from the opening
in the housing.
6. Disconnect the electrical connector.
7. Pull the base of the bulb straight out of the socket.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
7
