LC-5500(BELT)
EXERCISE BIKE
Console Assembly
AK51-00026-0001(R)
Seat
OK18-01265-0004
Seat w/Seatpost
AK17-00120-0003
Seatpost
AK17-00119-0003
Seat Pin w/Knob
OK17-01208-0000
Leg Levelers(2)
0017-00009-0795
Stabilizer Bar Assembly
SK18-00070-0000
Foot(2)
OK17-01033-0000
Overlay Bezel
AK51-00035-0001
Telemetry Receiver
SK40-00045-0001
Cover OK18-01360-0000
Decal OK49-01017-0000
Shroud w/Decal(LT)
AK17-00079-0011
Pedal w/Strap(RT)
AK17-00189-0001
1 of 2
GE09-00030-0100
SN: 634409 - up
Battery
0017-00003-0757
Console Case
OK36-01034-0006
Handlebar Assembly
AK18-00215-0000
Front Cap
OK18-01156-0001
Shroud w/Decal(RT)
AK18-00078-0011
Pedal w/Strap(LT)
AK17-00189-0002
Wheel & Bearing Assembly
SK18-00016-0000
Revision Date: 12/28/98
Previous
Page
Next
Page
1
2
Advertisement
Related Manuals for Life Fitness Exercise Bike LC-5500(BELT)
Exercise Bike Life Fitness Lifecycle LC5500 Owner's Manual
Exercise bike (39 pages)
Exercise Bike Life Fitness LC-5500 Parts List
Life fitness bicycle trainer parts list (3 pages)
Exercise Bike Life Fitness Exercise Bike LC5500 (RE) Parts List
Life fitness exercise bike parts list (2 pages)
Exercise Bike Life Fitness LC-5000 Parts List
Life fitness exercise bike parts list (3 pages)
Exercise Bike Life Fitness LC-5500R Parts List
Life fitness exercise bike installation manual (3 pages)
Exercise Bike Life Fitness Exercise Bike LC-5500HR Parts List
Life fitness exercise bike parts list (2 pages)
Exercise Bike Life Fitness LIFE CYCLE LC9100 Parts Manual
Life fitness cycle parts manual (14 pages)
Exercise Bike Life Fitness Lifecycle LC9500 Service Manual
Lifecycle upright bikes (152 pages)
Exercise Bike Life Fitness Essential LCRT8-0XXX-01 Parts List
Life fitness essential recumbent parts list (7 pages)
Exercise Bike Life Fitness Sport LCSR30-0XXX-01 Parts List
Life fitness recumbent bike parts list (7 pages)
Exercise Bike Life Fitness Lifecycle LC9100R Series Service Manual
Life fitness bike service manual (112 pages)
Exercise Bike Life Fitness LC9500R Service Manual
Lifecycle recumbent bikes (156 pages)
Exercise Bike Life Fitness LC85R Assembly Instructions Manual
Life fitnes exercise bike assembly instructions (8 pages)
Exercise Bike Life Fitness Lifestyle Exercise Bike LC8500 Operation Manual
Life fitness lifestyle exercise bike operation manual (33 pages)
Exercise Bike Life Fitness Exercise Bike Inspire Console 95C Lifecycle Operation Manual
Life fitness exercise bike inspire console operation manual (42 pages)
Exercise Bike Life Fitness LIFECYCLE 5500 Operation Manual
Life fitness exercise bike user manual (33 pages)
Summary of Contents for Life Fitness Exercise Bike LC-5500(BELT)
Page 1
LC-5500(BELT) EXERCISE BIKE Console Assembly AK51-00026-0001(R) Shroud w/Decal(LT) Seat AK17-00079-0011 OK18-01265-0004 Seat w/Seatpost AK17-00120-0003 Seatpost AK17-00119-0003 Seat Pin w/Knob OK17-01208-0000 Leg Levelers(2) 0017-00009-0795 Stabilizer Bar Assembly SK18-00070-0000 Foot(2) OK17-01033-0000 Overlay Bezel AK51-00035-0001 Telemetry Receiver SK40-00045-0001 Cover OK18-01360-0000 Decal OK49-01017-0000 Pedal w/Strap(RT) AK17-00189-0001 1 of 2 GE09-00030-0100...
Page 2
LC-5500(BELT) EXERCISE BIKE Upper Console Cable AK49-00024-0000 Lower Console Cable AK49-00017-0000 Poly V-Belt 0017-00009-0735 Idler Pulley OK46-01008-0003 Idler Arm Assembly AK46-00024-0002 Pulley w/Plate OK46-01007-0000 Power Grip Belt OK46-01009-0000 Tabbed Lockwasher OK18-01280-0000 Crank Locknut OK18-01059-0002 GE09-00030-0100 Crankarm OK18-01281-0000 Freewheel Pulley Assembly Crankarm Pulley Assembly SK17-00036-0000 AK46-00015-0000...
