Page 1: Lexmark C750
Lexmark C750 Setup Guide August 2001 www.lexmark.com... -
Page 2: Fcc Emissions Information
This product is designed, tested, and approved to meet strict global safety standards with the use of specific Lexmark components. The safety features of some parts may not always be obvious. Lexmark is not responsible for the use of other replacement parts. •... -
Page 3: Table Of Contents
Introduction ........v About your printer ........v Other sources of information . - Page 4 Local printing ........40 Turning on the printer .......41 Printing a network setup page .
-
Page 5: Introduction
There are several different configuration options for your printer. Launch the Lexmark C750 Publications CD and click Printer Overview for information about configuration options. -
Page 6: Other Sources Of Information
It also provides general information for administrators. The information on the Lexmark C750 Publications CD is also available on Lexmark’s Web site at www.lexmark.com/publications. Quick Reference and... -
Page 7: Step 1: Unpack The Printer
(54 in.) 30 cm (12 in.) 51 cm (20 in.) Select a location for your Lexmark™ C750 printer: — Leave enough room to open the printer trays, covers, and doors; access options; and allow for proper ventilation. — Provide the proper... - Page 8 Make sure you have the following items: — Printer with one 500-sheet tray — Power cord — Four print cartridges (preinstalled) — Setup Guide with a Lexmark C750 Publications CD — Quick Reference card, Clearing Jams card, and printer pocket — Drivers CD...
-
Page 9: Step 2: Set Up The Printer And Paper Handling Options
Topic Installing a 2000-sheet drawer Installing a 500-sheet drawer Installing a duplex unit Positioning the printer Installing an output expander Installing a 5-bin mailbox Set up the printer and paper handling options Go to page... -
Page 10: Installing A 2000-Sheet Drawer
Warning! duplex unit, you must install one 500-sheet drawer between the duplex unit and the 2000-sheet drawer. Set up the printer and paper handling options Installing a 2000-sheet drawer If you have an optional Your printer supports one optional 2000-sheet drawer. -
Page 11: Installing A 500-Sheet Drawer
Your printer supports up to three additional 500-sheet drawers. However, if you install a 2000-sheet drawer, you can only add one additional 500-sheet drawer. Unpack the 500-sheet drawer and remove any packing material. Set up the printer and paper handling options... - Page 12 Set up the printer and paper handling options Place the drawer in the location you have chosen for your printer or install it on another drawer: Align the holes in the 500-sheet drawer with the positioning posts on the lower drawer.
-
Page 13: Installing A Duplex Unit
Lower the duplex unit into place. Make sure it is seated securely on the drawer. Continue with “Positioning the printer” on page 8. Set up the printer and paper handling options... -
Page 14: Positioning The Printer
CAUTION! (105 lb) and requires at least two people to lift it safely. Set up the printer and paper handling options The printer weighs 47.7 kg Once you have selected a location and set up any optional drawers or a duplex unit, you are ready to position the printer. - Page 15 Make sure the printer is seated securely on the option. Remove any tape or packing material from the outside of the printer. Set up the printer and paper handling options...
-
Page 16: Installing An Output Expander
Do not use it as a shelf; excess weight may cause it to disengage from the output expander. Set up the printer and paper handling options Installing an output expander The output expander tray is... - Page 17 Align the mounting brackets on the bottom of the output expander with the slots in the top of the printer. Lower the output expander into place. Attach the printer top cover to the output expander. Set up the printer and paper handling options...
-
Page 18: Installing A 5-Bin Mailbox
After you unpack the mailbox, install it immediately. Otherwise, the edges of the mounting brackets could damage tabletops or fabrics. Set up the printer and paper handling options Installing a Your printer supports a 5-bin mailbox 5-bin mailbox that lets you collate and stack up to 500 sheets of paper. - Page 19 Remove the printer top cover. Align the mounting brackets on the bottom of the mailbox with the slots in the top of the printer. Lower the mailbox into place. Set up the printer and paper handling options...
- Page 20 Set up the printer and paper handling options Attach the printer top cover to the mailbox. Attach the mailbox paper bail to the top cover.
-
Page 21: Step 3: Set Up The Print Supplies
This step describes how to prepare the print cartridges and remove the packing materials inside the printer. To avoid damage, do not turn on the printer until you have completed this step and removed all packing materials. Setting up the Open the printer front cover. - Page 22 Handle Handhold Set up the print supplies Remove the packing material on top of the cartridges. Remove the print cartridges. For each cartridge: Pull up slightly on the handhold. Pull the cartridge straight out and use the handle to lift it off the guides.
- Page 23 Gently but firmly pull the material up and out of the printer. Make sure you also remove the packing material covering the top of the transfer belt. Set up the print supplies...
- Page 24 Set up the print supplies Open the front access door and pull the plastic shim out of the printer. Reinstall the print cartridges. For each cartridge: Shake the cartridge in all directions to distribute the toner. Turn the cartridge over so that...
- Page 25 Warning! Failure to remove the packing material from the print cartridges damages the printer. Warning! Do not touch the photoconductor drum on the bottom of the print cartridge. Remove the plastic packing material from the photoconductor drum. Discard the packing material.
- Page 26 Warning! close completely, reopen the cover and press in firmly on the cartridges to make sure they are fully seated. Set up the print supplies If the front cover does not Slide the cartridge in as far as it will go. The cartridge lowers into place.
-
Page 27: Attaching An Adhesive Operator Panel Overlay
What do I do next? Task Install memory and option cards Load paper If English is not your preferred language and your printer shipped with an adhesive operator panel overlay, attach the overlay that has the appropriately translated button names: Locate the adhesive overlay packaged with your printer. -
Page 28: Step 4: Install Memory And Option Cards
Step 4: Install memory and option cards CAUTION! or option cards sometime after setting up the printer, turn the printer off and unplug the power cord and any other cables before continuing. Removing the system board access cover Install memory and option cards... - Page 29 Hard disk connector Option card Firmware card connector connector To install a... Memory card Firmware card Hard disk Option card Memory and flash memory card connectors Use the following table to locate the instructions you need. Go to page... Install memory and option cards...
-
Page 30: Installing A Memory Card
Note: Memory options designed for other Lexmark printers may not work with your printer. Warning! memory cards are easily damaged by static electricity. Touch something metal on the printer before you touch a memory card. Connection points Notch Install memory and option cards... -
Page 31: Installing A Firmware Card
If an option card has been installed, you must remove it before installing the firmware card. If you have a Lexmark C750in, an ImageQuick™ firmware card is already installed. Remove the system board access cover (see page 22). -
Page 32: Installing A Hard Disk
Installing a hard disk Warning! damaged by static electricity. Touch something metal on the printer before you touch a disk. Ribbon cable Install memory and option cards Hard disks are easily Hard disk Mounting plate Follow the instructions in this section to install an optional hard disk. - Page 33 Press the ribbon cable connector into the connector on the system board. Flip the hard disk over, and then press the three posts on the mounting plate into the holes on the system board. The hard disk snaps into place. Install memory and option cards...
-
Page 34: Installing An Option Card
Installing an option card Function Adds an Ethernet or Token-Ring port so you can connect your printer to a network. Install a MarkNet™ N2501e or N2401e internal print server if you received either of these cards as part of a multifunction printer upgrade. - Page 35 Warning! Option cards are easily damaged by static electricity. Touch something metal on the printer before you touch an option card. Unpack the option card. Save the packing materials. Align the connector on the option card with the connector on the system board.
-
Page 36: Replacing The System Board Access Cover
Install memory and option cards After you have finished installing cards on the printer system board, you must replace the system board access cover. Align the slots at the top of the access cover with the screws near the top of the printer. -
Page 37: Step 5: Load Paper
Step 5: Load paper Source Paper sizes supported 500-sheet trays Letter, A4, A5, Legal, Executive, JIS B5, Folio Statement , Universal 2000-sheet tray Letter, A4, A5, Legal, Executive, JIS B5 Multipurpose Letter, A4, A5, Legal, feeder Executive, JIS B5, Folio Statement , Universal 7¾, 9, 10, DL, C5, B5,... -
Page 38: Loading The 500-Sheet Trays
Load paper Loading the 500-sheet trays Follow these instructions to load any of the 500-sheet trays. Remove the tray. Squeeze the front guide lever and slide the guide to the front of the tray. Squeeze the side guide lever and slide the guide to the correct position for the size paper you are loading. - Page 39 Maximum height guide Note: Do not exceed the maximum stack height indicated on the front guide. Overfilling the tray may cause jams. Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges of the stack on a level surface.
-
Page 40: Loading The 2000-Sheet Tray
Reinstall the tray. Make sure the tray is pushed completely into the printer. Follow these instructions to load a 2000-sheet tray. Do not load any print media other than paper in the 2000-sheet tray. - Page 41 Squeeze the side guide lever, lift the guide, and place it into the appropriate slot for the size paper you are loading. Squeeze the two front guide levers and slide the guide to the correct position for the size paper you are loading.
- Page 42 Straighten the edges of the stack on a level surface. Place the paper against the back left corner of the tray, print side down. Do not load bent or wrinkled paper. Close the tray. Make sure the tray is pushed completely into the printer.
-
Page 43: Loading The Multipurpose Feeder
The printer then prompts you to load the appropriate print media before it prints. Follow these instructions to load the multipurpose feeder. - Page 44 Note: Do not exceed the maximum stack height. Overfilling the feeder may cause jams. Load paper Arrange the stack of print media correctly for the size, type, and print method you are using. Place the print media, print side up, along the left side of the multipurpose feeder, and then push it in as far as it will go.
-
Page 45: Step 6: Attach Cables
Token-Ring, Ethernet 10BaseT, or Ethernet 100BaseTX networks (Category 5) use an RJ-45 connector. The Lexmark C750 can be attached to a network or locally (directly to a computer). You can attach your printer to a network using standard network cables. -
Page 46: Local Printing
Lexmark C750n, Lexmark C750in, or Lexmark C750dn, you need a 1284 A-C parallel cable, such as Lexmark part number 43H5171 (9.8 ft), or a USB cable such as Lexmark part number 12A2405 (2 m). If you have installed an optional Tri-Port Adapter, you can locally attach the printer with a serial cable. -
Page 47: Step 7: Verify Printer Setup
Remove the shipping paper from the left access door. Hold down the lever and pull the paper out. Plug one end of the printer power cord into the socket at the back of the printer and the other end into a properly grounded outlet. -
Page 48: Printing A Network Setup Page
Otherwise, go on to “Printing a menu settings page” on page 43. If the printer is attached to a network, print a network setup page to verify the network connection. This page also provides important information that helps you configure for network printing. -
Page 49: Printing A Menu Settings Page
Verify that the options you installed are correctly listed under “Installed Features.” If an option you installed is not listed, turn the printer off, unplug the power cord, and reinstall the option. Verify the amount of memory installed is correctly listed under “Printer Information.”... -
Page 50: Step 8: Configure For Tcp/Ip
2. If your network is not using DHCP, you must manually assign an IP address to the printer. One of the easiest ways is to use the operator panel: Press Menu until you see Network Menu, and then press Select. -
Page 51: Verifying The Ip Settings
See “Printing a network setup page” on page 42 if you need help. Ping the printer and verify that it responds. For example, at a command prompt on a network computer type “ping” followed by the new printer IP address: ping xxx.xxx.xxx.xx... -
Page 52: Step 9: Install Printer Drivers
Macintosh UNIX/Linux The following instructions explain how to install printer drivers on printers attached to a network. In Windows network environments, Lexmark printers can be configured for direct printing or for shared printing. Supported network printer ports • Microsoft IP port (Windows NT 4.0 and Windows 2000) •... - Page 53 You must create a printer object (icon) on the desktop of each network client using the LaserWriter 8 printer driver and the Lexmark C750 PPD file. Specific information about installing the printer on your AppleTalk network can be found in the online documentation on the drivers CD that shipped with your printer.
- Page 54 NetWare Install printer drivers You can find a Lexmark PPD Installer in the downloadable Web package available on the Lexmark Web site at www.lexmark.com. Depending upon which version of the drivers CD shipped with your printer, you may also find this software on the drivers CD. Launch the Lexmark PPD Installer and follow the instructions to install the PPDs.
-
Page 55: Local Printing
Non-NDPS (queue-based) For the latest information about Lexmark support for non-NDPS environments, click View Documentation on the drivers CD and look for information about network printer installation. Local printing In order to print, you must install a printer driver on the computer attached to the printer. - Page 56 Updated system and custom drivers are available on Lexmark’s Web site at www.lexmark.com. You must install the Lexmark C750 PPD and use it with the LaserWriter 8 printer driver or the Adobe PostScript driver. You can find the Lexmark C750 PPD and specific information about local printer installation on Macintosh computers on the drivers CD that shipped with your printer.
-
Page 57: Step 10: Distribute Information To Users
If you have a version of Acrobat capable of full text searching, we have created catalog entries to help you find the information you need. The type of helpful information provided on the Lexmark C750 Publications CD includes: •... -
Page 58: Distributing The Information
For printing instructions, launch the CD and then click Navigation. In addition to the Lexmark C750 Publications CD, your printer shipped with one or more quick reference cards. We recommend that you store these cards in their convenient printer pocket. You can attach the pocket to the printer or any flat surface near the printer. -
Page 59: Appendix: Statement Of Limited Warranty
• Is in good working order If this product does not function as warranted during the warranty period, contact a Remarketer or Lexmark for repair without charge. If this product is a feature or option, this statement applies only when that feature or option is used with the product for which it was designed. -
Page 60: Limitation Of Liability
Lexmark be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages. This is true even if you advise Lexmark or a Remarketer of the possibility of such damages. Lexmark is not liable for any claim by you based on a third party claim. - Page 61 This is a placeholder for the inside back cover.
- Page 62 P/N 10B2601 E.C. 2B0151 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. © 2001 Lexmark International, Inc. 740 West New Circle Road Lexington, Kentucky 40550 www.lexmark.com...
