Lexmark™ C720
Color Laser Printer
Machine Type 5024-001
Parts Catalog Guide
Lexmark and Lexmark with diamond
design are trademarks of Lexmark
International, Inc., registered in the
United States and/or other countries.

Advertisement

loading

Related Manuals for Lexmark 5024-001

Summary of Contents for Lexmark 5024-001

  • Page 1 Lexmark™ C720 Color Laser Printer Machine Type 5024-001 Parts Catalog Guide Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.

  • Page 2: How To Use This Parts Catalog

    5024-001 Parts Catalog How to Use this Parts Catalog • SIMILAR ASSEMBLIES: If two assemblies contain a majority of identical parts, they are shown on the same list. Common parts are shown by one index number. Parts peculiar to one or the other of the assemblies are listed separately and identified by description.
  • Page 4 5024-001 Assembly 1: Part Number 1 - 1 12G7004 12G7005 12G7006 12G7007 12G7008 1339517 1339518 Units Description Toner Cartridge -Y (Supply, customer order only) Toner Cartridge -M (Supply, customer order only) Toner Cartridge -C (Supply, customer order only) Toner Cartridge -K...
  • Page 6 5024-001 Assembly 1 (cont.): Part Number 1 - 16 1339520 1339524 1339528 1339529 1339530 1339531 1339532 1339533 1339534 12G7010 12G7232 12G7011 12G7012 12G7013 12G7014 12G7159 12G7160 12G7341 12G7340 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information. Then go to Assembly 6 for parts ordering information.
  • Page 8 5024-001 Assembly 2: Part Number 2 - 1 12G7015 12G7016 12G7017 12G7018 12G7019 12G7020 12G7021 12G7022 12G7023 12G7024 12G7025 12G7026 12G7027 12G7028 12G7029 12G7030 12G7031 12G7032 12G7033 12G7034 12G7035 12G7036 12G7037 12G7038 Units Description Top Cover Assembly (includes 35) Side Cover (R)
  • Page 10 5024-001 Assembly 2 (cont.): Part Number 2 - 27 12G7039 12G7037 12G7360 12G7041 12G7042 12G7043 12G7044 12G7161 12G7162 12G7163 12G7164 12G7165 12G7166 12G7167 12G7168 12G7169 12G7170 12G7171 12G7172 12G7173 12G7174 12G7036 12G7175 12G7176 Units Description Paper Exit Roller Paper sensor (PFUL)
  • Page 12 5024-001 Assembly 2 (cont.): Part Number 2 - 50 12G7177 12G7178 12G7179 12G7180 12G7070 12G7341 12G7340 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information. Then go to Assembly 6 for parts ordering information.
  • Page 14 5024-001 Assembly 3: Part Number 3 - 1 12G7045 12G7046 12G7047 12G7048 12G7049 12G7049 12G7051 12G7052 12G7053 12G7054 12G7055 12G7056 12G7057 12G7058 12G7059 12G7060 12G7061 12G7062 12G7063 12G7064 12G7065 12G7037 12G7067 12G7068 Units Description Paper Feeding Clutch (PCLU) Registration Clutch (RECL)
  • Page 16 5024-001 Assembly 3 (cont.): Part Number 3 - 25 12G7069 12G7070 12G7073 12G7074 12G7075 12G7076 12G7077 12G7078 12G7079 12G7079 12G7081 12G7082 12G7083 12G7084 12G7181 12G7182 12G7183 12G7184 12G7185 12G7341 12G7340 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information.
  • Page 18 5024-001 Assembly 4: Part Units Number 4 - 1 12G7098 12G7099 12G7100 12G7037 12G7037 12G7103 12G7104 12G7186 12G7187 12G7188 12G7341 12G7340 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information. Then go to Assembly 6 for parts ordering information.
  • Page 19 5024-001 Assembly 5: Controller RIP Card 7-18 Service Manual...
  • Page 20 5024-001 Assembly 5: Controller RIP Card Part Number 5 - 1 12G7227 12G7226 12G7228 99A1752 99A1755 12G7229 12G7231 99A0459 11G0962 12G7230 Note: The standard and network models have listed memory. See Assembly 7 for part number information. Units Description Controller RIP Card...
  • Page 21 5024-001 Assembly 6: Printer Cable Harness Sets 7-20 Service Manual...
  • Page 22 5024-001 Assembly 6: Printer Cable Harness Sets Part Units Number 6 - 1 12G7342 12G7343 12G7344 12G7345 12G7346 12G7347 12G7348 12G7349 12G7350 12G7351 12G7352 12G7353 12G7354 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information.
  • Page 23 5024-001 Assembly 7: Miscellaneous (No illustration) 7-22 Service Manual...
  • Page 24 5024-001 Assembly 7: Miscellaneous Part Number 12G1704 13A0297 13A0296 99A0459 99A0545 12G1696 12G1697 99A1830 99A1752 99A1753 99A1754 99A1755 99A1756 99A1773 99A1757 99A1758 99A1759 99A1774 99A0560 99A0923 99A0467 7366394 7366417 7366413 7366409 Units Description Card Assembly, SIMM IPDS/SCS/TNE Cable, Coax Cable, Twinax Hard Disk, 2.1GB...
  • Page 25 5024-001 Assembly 8: Lower Feed Unit 7-24 Service Manual...
  • Page 26 5024-001 Assembly 8: Lower Feed Unit Part Number 8 - 1 12G7037 12G7043 12G7045 12G7098 12G7099 12G7121 12G7122 12G7123 12G7124 12G7144 12G7224 12G7145 12G7146 12G7147 12G7148 12G7149 12G7150 12G7151 12G7152 12G7153 12G7154 12G7155 12G7156 12G7135 Units Description Paper Sensor (PEL)
  • Page 27 5024-001 Assembly 8 (cont.): Lower Feed Unit (cont.) 7-26 Service Manual...
  • Page 28 5024-001 Assembly 8 (cont.): Lower Feed Unit (cont.) Part Number 12G7135 12G7136 12G7137 12G7139 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information. Then go to the assembly for parts ordering information.
  • Page 29 5024-001 Assembly 9: Duplex Unit 7-28 Service Manual...
  • Page 30 5024-001 Assembly 9: Duplex Unit Part Number 9 - 1 12G7105 12G7106 12G7107 12G7108 12G7109 12G7110 12G7111 12G7112 12G7113 12G7114 12G7115 12G7116 12G7138 12G7117 12G7140 12G7141 12G7070 12G7143 12G7125 12G7118 12G7119 Units Description Cover Top (C) Assembly Cover Top (L)
  • Page 31 5024-001 Assembly 9 (cont.): Duplex Unit (cont.) 7-30 Service Manual...
  • Page 32 5024-001 Assembly 9: Duplex Unit Part Number 9 - 23 12G7120 12G7139 12G7126 12G7127 12G7128 12G7129 12G7130 12G7131 12G7132 12G7133 12G7134 12G7136 12G7138 12G7135 12G7136 12G7137 12G7139 Note: Reference the foldout wiring diagram, in the back of this manual, for cable replacement detailed information. Then go to the assembly for parts ordering information.
  • Page 33 5024-001 7-32 Service Manual...
