You can change your printer setting by using your application software, your Lexmark printer
driver, the printer operator panel, or the remote operator panel available from MarkVision.
Note: Printer settings selected from a software application or driver override
default settings selected from the operator panel.
If there is a printer feature you cannot control from the application or printer driver, use the
printer operator panel or the remote operator panel available from MarkVision. Changing a
printer setting from the operator panel or from MarkVision makes that setting the user default
for all subsequent jobs sent to the printer. In most cases, settings you change from the
application or driver apply only to the job you are preparing to send to the printer.
For more information, click one of the following headings:
•
Understanding the operator panel
•
Changing menu settings
•
Locking the menus
•
Using the MarkVision remote operator panel
•
Using the operator panel
www.lexmark.com
Changing printer settings
Lexmark C720
1

Advertisement

loading

Related Manuals for Lexmark C720

Summary of Contents for Lexmark C720

  • Page 1 Changing printer settings Printing You can change your printer setting by using your application software, your Lexmark printer driver, the printer operator panel, or the remote operator panel available from MarkVision. Using color Note: Printer settings selected from a software application or driver override default settings selected from the operator panel.

  • Page 2: Understanding The Operator Panel

    • Off The printer power is off. • On The printer power is on and the printer is cur- rently idle. Index • Flashing The printer power is on and the printer is busy or awaiting operator intervention. www.lexmark.com Lexmark C720...
  • Page 3 • Enter a number 5 as part of a PIN for confidential or print and hold printing. If you’ve changed printer settings from the operator panel, cleared a Troubleshooting paper jam, or changed a supply item, press to resume printing. Administration Index www.lexmark.com Lexmark C720...
  • Page 4 • Display the Job Menu or the Supplies Menu while the printer is busy. Maintenance • Enter a number 1 or 2 as part of a PIN for confidential or print and hold printing. Troubleshooting Administration Index www.lexmark.com Lexmark C720...
  • Page 5 • Back up to the previous level of the menu structure without selecting a new menu item or value. Administration • Enter a number 4 as part of a PIN for confidential or print and hold printing. Index www.lexmark.com Lexmark C720...
  • Page 6 For example, if you need to load paper in a tray while a job is printing, Maintenance press and wait for the printer motors to idle before removing the Stop tray. Reinsert the loaded tray, and then press Troubleshooting Administration Index www.lexmark.com Lexmark C720...

  • Page 7: Changing Menu Settings

    Using printer menus for the menus and their menu items. Maintenance Press to display the list of items for the selected menu. Select Press until the item you want appears on the second line. Menu> <Menu Troubleshooting Administration Index www.lexmark.com Lexmark C720...
  • Page 8 A numerical value that you can increase or decrease Maintenance Press to scroll through the list of values. Menu> <Menu Note: Press if you need to go back to previous menus or menu items Return without changing the current setting. Troubleshooting Administration Index www.lexmark.com Lexmark C720...
  • Page 9 The previous list of menu items appears. Paper handling Note: User default settings remain in effect until you save new settings or restore factory defaults. Press when you have finished changing menu settings. Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C720...

  • Page 10: Locking The Menus

    > or < , until appears on the second line. Menu Menu Exit Config Menu Press Select Index To unlock the menus, repeat steps 1-9. However, select when it appears on the Enable second line, instead of Disable www.lexmark.com Lexmark C720...
  • Page 11 Using Administration this option eliminates the time required to scroll through the various menu items and values when using the operator panel and its two-line display. For additional information see Introducing MarkVision. Index www.lexmark.com Lexmark C720...
