- Page 1 Style that revolves around you. • C • EILING WNER'S ANUAL • V • ANTAGE with DC motor 12/14 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS: 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
-
Page 3: Important Safety Precautions
MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting. -
Page 4: Unpacking Your Fan
NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged. 2. -
Page 5: Hanging Bracket
REPARATION Parts identification on assembled fan Canopy Blade Collar Cover Downrod Motor Housing Blade Light Cover PREPARATION: Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box. - Page 6 NSTALLING THE 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Loosen the two set screws and remove the downrod pin and cotter pin from the top coupling of the motor assembly. 3.
- Page 7 NSTALLING THE WARNING: To avoid damaging the blade arms and blades, do not install them onto fan until fan is fastened to ceiling. 1. Lift ball/downrod/fan into hanging bracket opening. NOTE: The tab opposite hanging bracket opening should fit Slot in slot on ball.
-
Page 8: Blade Attachment
INISHING THE NSTALLATION NSTALLING THE 1. Tuck connections neatly into ceiling outlet box. 2. Slide the canopy up to mounting bracket and place the Ceiling Fan key hole on the canopy over the screw on the mounting Outlet Box bracket, turn canopy until it locks in place at the narrow Hanger section of the key holes. -
Page 9: Glass Shade
NSTALLING THE IGHT IT AND LASS HADE Step1. Remove one of the three screws on the mounting hub located on the fan motor. (Fig. 1) Step 2. While holding the LED light kit under your fan, make the polarized plug connections: (Fig. 1) - Red to white - Black to black NOTE: If you do not plan to install the LED light kit with... -
Page 10: Operating Your Transmitter
PERATING RANSMITTER Your DC brushless motor is equipped with a automatically learned type remote control. Restore power to ceiling fan and test the transmitter as below for proper operation: Install one 23A/12V battery (included). To prevent damage to transmitter, remove the battery if not used for long periods of time (Fig. 1) A. - Page 11 This receiver provides the following protective function: 1. Lock Rotor Position: The DC motor has a built-in safety against a stalled or locked rotor condition (stalled blade rotation). If there is an obstruction or fault with the motor, the current monitoring function will automatically turn power off to the motor after 30 seconds.
- Page 12 NSTALLING THE RANSMITTER OLDER 1. Remove the cover from the holder. Cover 2. Attach the holder with the two screws provided. Holder 3. Replace the cover into holder. Screws Fig. 14 ARE AND LEANING Periodically it may be necessary to re-tighten blade to blade arm screws or blade arm to motor screws to prevent clicking or humming sound during operation.
-
Page 13: Troubleshooting
Make sure these are tight and the ball is completely seated in the bracket. HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfan.com 12/14 Regency Ceiling Fans...
