Summary of Contents for Regency GLADIATOR GL3
- Page 1 Style that revolves around you. • C • EILING WNER'S ANUAL • G • LADIATOR (GL3) with DC motor 01/10 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS: 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
-
Page 3: Important Safety Precautions
MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting. -
Page 4: Unpacking Your Fan
1. Fan blades (5) (Model: TB60-xx, packed in separate box.) (CAUTION: This GLADIATOR (GL3) Ceiling Fan must only be used with the Models "TB60-xx, W154, W354 and 56" Décor Match " Blades, it is not ® intended to be used with any other REGENCY Fan blades.) 2. Hanging bracket 3. Ceiling canopy 4. -
Page 5: Hanging Bracket
REPARATION Parts identification on assembled fan Canopy Collar Cover Downrod Blade Motor Housing Detachable Blade Switch Housing PREPARATION: Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box. - Page 6 NSTALLING THE 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Loosen the two set screws and remove the downrod pin and cotter pin from the top coupling of the motor assembly. 3.
- Page 7 NSTALLING THE WARNING: To avoid damaging the blade arms and blades, do not install them onto fan until fan is fastened to ceiling. 1. Lift ball/downrod/fan into hanging bracket opening. NOTE: The tab opposite hanging bracket opening should fit in slot on ball. Slot Fig.
-
Page 8: Finishing The Installation
INISHING THE NSTALLATION 1. Tuck connections neatly into ceiling outlet box. Ceiling Fan 2. Slide the canopy up to ceiling and over the 2 screws on Outlet Box the hanger bracket. Rotate canopy clockwise. Next, while Hanger Bracket holding the canopy with one hand, slide the canopy screw cover plate over the screws and rotate clockwise Screws until tight. -
Page 9: Switch Housing
NSTALLATION OF ETACHABLE WITCH OUSING OUNTING 1. Remove one of the three screws on the mounting hub located on the fan motor. 2. Loosen the other two screws. 3. Install detachable switch housing mounting hub to mounting hub. 4. Pass the 2 light wires through the center hole of the detachable switch housing mounting hub. 5. - Page 10 3. Attach the switch housing to the switch housing hub. 4. Align the side screws with keyhole slots on edge of switch housing and tighten the side screws. 5. Turn the power on. Your Regency Ceiling Fan is now ready to enjoy! Detachable Switch Housing...
-
Page 11: Operating Your Transmitter
PERATING RANSMITTER Your DC brushless motor is equipped with a automatically learned type remote control. Restore power to ceiling fan and test the transmitter as below for proper operation: Install one 23A/12V battery (included). To prevent damage to transmitter, remove the battery if not used for long periods of time (Fig. 10) A. - Page 12 Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans. NOTE: NOTE: To operate the reverse function on this fan, press the button while the fan is running. Warm Weather (forward): A DOWNWARD airflow creates a cooling effect as shown in Figure 12.
-
Page 13: Troubleshooting
Make sure these are tight and the ball is completely seated in the bracket. HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfan.com 10/07 Regency Ceiling Fans...
