- Page 1 Style that revolves around you. • C • EILING WNER'S ANUAL • P • ROFESSIONAL ERIES REVISED NOVEMBER 2007 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 Regency extends the following warranty to the original purchaser of a Regency Ceiling Fan. 1. If any part of your Regency ceiling fan motor fails at any time during the lifetime of the original purchaser due to a defect in material or workmanship, we will provide a replacement part free of charge, when the defective fan is returned to our corporate service department.
- Page 3 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning. 2. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.
-
Page 4: Important Safety Precautions
MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting. -
Page 5: Unpacking Your Fan
NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged. 2. -
Page 6: Installing The Mounting Bracket
REPARATION Parts identification on assembled fan Canopy Downrod Blade Motor Housing Blade Light Kit REPARATION Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box. - Page 7 NSTALLING NSTALLATION This fan has two installation options: #1 HUGGER MOUNTING The HUGGER method is preferred if maximum headroom is required. The ceiling must be horizontal, not sloped. Blades will be approximately 8˝ from the ceiling. Air flow will be reduced when the fan is installed using the HUGGER method.
- Page 8 NSTALLING THE UGGER TYLE #1: H NSTALLATION PTION UGGER TYLE OUNTING NOTE: The S hook is to be used for hugger style mounting. 1. Remove the plastic trim ring from the canopy to expose the 6 mounting holes. The downrod, ball and cotter pin will not be used for this mounting (Fig.
- Page 9 – D NSTALLING THE OWNROD STYLE #2: D NSTALLATION PTION OWNROD STYLE MOUNTING 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin; remove ball.
- Page 10 – D NSTALLING THE OWNROD STYLE #2: D NSTALLATION PTION OWNROD STYLE MOUNTING CONT 1. Lift ball/downrod/fan into hanger bracket opening. NOTE: The tab opposite hanger bracket opening should fit in slot on ball. 2. Make wire connections, (refer to section titled “Electrical Connections”). 3.
-
Page 11: Electrical Connections
LECTRICAL ONNECTIONS Be sure electricity is turned off at the main power box before wiring LECTRICAL ONNECTIONS 1. Four wires are connected to the fan. Black – this is the “hot” power to run fan. White – this is the “common” power to run fan and light. Blue –... -
Page 12: Blade Attachment
LADE TTACHMENT LADE TTACHMENT 1. Place fiber washer on screw. Insert this assembly through the blade and start the screw into the blade arm. Repeat this procedure without tightening the screw until all 3 screws have been started into the blade arm (Fig. 1). NOTE: Fans that have painted finishes are packed with gaskets that can be used between the blade arm and blade to help prevent a clicking noise that may develop if blade screws loosen over time. - Page 13 5. Align the side screws with keyhole slots on edge of switch housing and tighten the side screws. 6. Turn the power on. Your Regency Ceiling Fan is now ready to enjoy! Switch Housing Hub Opening for...
- Page 14 NSTALLATION OF IGHT NOTE: Before installing the switch housing to the fan, the light fixture should be installed onto the switch housing. 1. Remove the plug on the bottom of the switch housing so the light fixture can be connected. 2.
-
Page 15: Operation
PERATION Turn on the power and check operation of the fan. The fan is controlled by the use of the pull chain as follows: one pull = high speed two pulls = medium speed three pulls = low speed four pulls = off For proper functions, ensure that the chain is pulled down fully and released each time. -
Page 16: Troubleshooting
ARE AND LEANING Periodic cleaning of your new ceiling fan is about the only maintenance that is needed. Only use a soft brush or lint free cloth to avoid scratching the finish. DO NOT use water when cleaning your ceiling fan. It could damage the motor or the wood blades and/or create the possibility of electrical shock. - Page 17 HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfan.com 7/06 Regency Ceiling Fans...
