Clarion DB265MP Service Manual

Clarion DB265MP Service Manual

Cd/mp3 receiver
Hide thumbs Also See for DB265MP:

Advertisement

(DB265MP)

SPECIFICATIONS

FM tuner section
Frequency range:
87.9MHz to 107.9MHz
(PE-2793B-A)
87.0MHz to 108.0MHz
(PE-2793K-A/B)
Usable sensitivity:
11dBf
50dB quieting sensitivity:
17dBf
Alternate channel selectivity: 75dB
Stereo separation:
35dB(1k Hz)
Frequency response:
30Hz to 15kHz (+3/-3dB)
AM tuner section
Frequency range:
530kHz to 1710kHz
( PE-2793B-A)
531kHz to 1629kHz
(PE-2793K-A/B)
Usable sensitivity:
25 uV
CD player section
System:
Compact disc digital audio sys tem
Usable discs:
Compact disc
10Hz to 20kHz(+1/ -1dB )
Frequency response:
Signal to Noise Ratio:
100dB(1 kHz)
Dynamic range:
95dB(1kHz)
Harmonic distortion:
0.01%
MP3
Decode Format:
MPEG 1, 2 and 2.5-layer 3
Sampling rate(kHz):
MPEG-1:
MPEG-2:
MPEG-2.5: 11.025, 12
Bit-rate(kbps):
8, 16, 24, 32, 40, 48, 56, 64, 80, 96, 112,
128, 144, 160, 192, 224, 256, 320, VBR
CD-ROM Format:
ISO9660 level 1, 2, Joliet or Romeo
Folder Level Limit:
No limitation
Folder Support:
128
File Support:
254
Folder Name:
Maximum 16 characters
File Name:
Maximun 28 characters
Xiamen Clarion Electrical Enterprise Co., Ltd
8/F., Xiamen Mail Processing Centre, No.275 Lujiang Road, Xiamen, China
Tel:+86-592-2389080 Fax:+86-592-2389089
Clarion Co., Ltd.
50 Kamitoda , Toda-shi, Saitama 335-8511 Japan
Service Manual
32, 44.1, 48
16, 22.05, 24
CD/MP3 Receiver
Model
(PE-2793B-A for U.S.A)
Model
(PE-2793K-A/B for Other Countries)
Audio section
Maximum power output:
Bass control action:
Treble control action:
Line output level:
General
Power supply voltage:
Current consumption:
Speaker impedance:
Weight:
Dimensions(mm):
NOTE
*
We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
*
Specifications and design are subject to change without
notice for further improvement.
Use only compact discs bearing the
*
Some CDs recorded in CD-R/CD-RW mode may not be usable.
COMPONENTS
PE-2793B-A/PE-2793K-A/B
1.
Source unit
2.
Mounting bracket
3.
Mounting bracket
4. Remote control unit
(PE-2793K-A/B)
5. Battery(CR2025)
(PE-2793K-A/B)
6.
DCP case(PE-2793K-A/B)
7.
Escutcheon(OUT-ES)
8.
Extension lead
9.
Parts bag
9-1.
Removal key
9-2.
Rubber
par(PE-2793B-A)
9-3.
Screw(M5X8)
-1-
Published by Service Dept.
298-6313-00 DEC.2005P
Printed in P.R.C.
45Wx4
+14 /-14dB (100Hz)
+14/-14dB (10kHz)
1.8V(with A/C 1kHz, 10kohm)
14.4V DC(10.8 to 15.6V allowable),
negative ground
Less than 15A
4ohm(4ohm to 8ohm allowable)
Source unit
1.1kg
Source unit
178(W)x50(H)x152(D)mm
mark.
1
300-4976-00
1
300-8088-00
1
RCB-176-200
1
1
335-7542-00
1
370-6216-01
1
854-6349-59
1
1
331-2497-00
2
345-5900-00
1
716-0496-51
1
DB265MP/DB266MP
