6
Parts List
Ersatzteilliste
Parts List
En
Parts # Qty Description
6132
20
PLASTIC STRAP (SMALL/BLACK)
6163
5
SERVO TAPE 20x100mm
6819
5
SILICONE O-RING P-3 (RED)
6917
1
PINION GEAR 17 TOOTH (48 PITCH)
75106
20
BODY CLIP (6mm/BLACK)
75115
4
BALL STUD 4.3x10.3mm (2mm SOCKET)
75116
4
BALL STUD 4.3x13mm (2mm SOCKET)
88010
2
SHOCK SPRING 14x29x1.4mm 8coils (Black/175Nf)
102846
10
TP. BUTTON HEAD SCREW M2x5mm
102847
6
TP. BUTTON HEAD SCREW M3x20mm
102848
6
TP. BUTTON HEAD SCREW M3x25mm
102849
10
BUTTON HEAD SCREW M3x10mm
102814
1
MAIN CHASSIS
102815
1
FRONT CHASSIS (HIGH NOSE TYPE)
102816
1
FRONT UPPER ARM
102817
1
BATTERY HOLDER SET
102818
1
MOTOR MOUNT SET
102819
1
SERVO SAVER / FRICTION PLATE SET
102820
1
SHOCK PARTS / ROD END SET
102821
1
STEERING KNUCKLE SET
102822
1
SPUR GEAR / DIFF GEAR SET (75T/87T/48P)
102823
8
PLASTIC BUSHING SET (FORMULA TEN)
102824
4
FT01 WHEEL SET (Front / Rear)
102828
1
ALUMINUM GEAR DIFF HUB (ORANGE)
102829
1
ALUMINUM WHEEL HUB RIGHT (ORANGE)
102830
1
ALUMINUM WHEEL HUB LEFT (ORANGE)
102831
1
REAR AXLE SHAFT 6.3x130mm (STEEL)
102833
2
FRONT AXLE SHAFT 5x28mm
102834
1
KING PIN 3.1x31.5mm / SUSPENSION BALL SET
102835
1
T-BAR 1.5mm
102836
2
FT01 SLICK TIRE D COMPOUND (FRONT/62x32mm)
102837
2
FT01 SLICK TIRE D COMPOUND (REAR/62x37mm)
102838
1
TOP DECK (FRP/2.0mm)
B010
2
BALL BEARING 1/4x3/8 in. FLANGED
Z150
1
ANTENNA PIPE SET
Z155
1
DIFFERENTIAL LUBE (SILICONE)
Z156
1
GRAY DIFFERENTIAL LUBE (FOR DIFF SMALL BALLS)
Z224
10
WASHER M3x8mm
Z242
20
E CLIP E2mm
Z264
10
PIN 2x10mm SILVER
Z420
12
CAP HEAD SCREW M2.6x6mm
Z527
6
FLAT HEAD SCREW M3x10mm
Z552
10
TP. BUTTON HEAD SCREW M3x10mm
Z561
6
TP. FLANGED SCREW M3x10mm
Z576
10
TP. FLAT HEAD SCREW M3x8mm
Z579
12
TP. FLAT HEAD SCREW M3x15mm
Z676
4
LOCK NUT M3 THIN TYPE
Z684
4
FLANGED LOCK NUT M4
Z700
6
SET SCREW M3x3mm
Z710
4
SET SCREW M3x22mm
Z901
1
ALLEN WRENCH 1.5mm
Z904
1
ALLEN WRENCH 2.0mm
Z950
1
CROSS WRENCH (SMALL)
Pièces détachées
パーツリスト
Ersatzteileliste
De
Nummer Anzahl Beschreibung
6132
20
KABELBINDER (KLEIN/SCHWARZ)
6163
5
DOPPELSEITIGES KLEBEBAND 20x100mm
6819
5
SILIKON O-RING P-3 (ROT)
6917
1
Ritzel 17Z 48dp
75106
20
KAROSSERIEKLAMMERN (6mm/SCHWARZ)
75115
4
KUGELKOPF 4.3X10.3mm (2mm INBUS)
75116
4
KUGELKOPF 4.3x13mm (2mm INBUS)
88010
2
DAEMPFERFEDER 14x29x1.4mm 8WDG (SCHWARZ)
102846
10
FLACHKOPFSCHNEIDSCHRAUBE M2x5mm
102847
6
FLACHKOPFSCHNEIDSCHRAUBE M3x20mm
102848
6
FLACHKOPFSCHNEIDSCHRAUBE M3x25mm
102849
10
FLACHKOPFSCHRAUBE M3x10mm
102814
1
CHASSIS (FORMULA TEN)
102815
1
VORDERES CHASSIS (HOHE NASE TYP/FORMULA TEN)
102816
1
VORDERE, OBERE SCHWINGEN (FORMULA TEN)
102817
1
AKKUHALTER SET (FORMULA TEN)
102818
1
MOTORHALTER SET (FORMULA TEN)
102819
1
SERVO SAVER/REIBUNGSPLATTE SET (FORMULA TEN)
102820
1
DAEMPFERTEILE/KUGELPFANNEN SET (FORMULA TEN)
102821
1
LENKHEBEL SET (FORMULA TEN)
102822
1
HAUPTZAHNRAD/DIFF KEGELRAD SET (FORMULA TEN)
102823
8
PLASTIKLAGER SET (FORMULA TEN)
102824
4
FT01 FELGEN SET (JE 2ST VORNE, HINTEN)
102828
1
ALUMINIUM KEGEL DIFF AUFNAHME (ORANGE/FORMULA TEN)
102829
1
ALUMINIUM RADTRAEGER RECHTS (ORANGE/(FORMULA TEN)
102830
1
ALUMINIUM RADTRAEGER LINKS (ORANGE/FORMULA TEN)
102831
1
HINTERACHS-WELLE 6.3x130mm (STAHL/FORMULA TEN)
102833
2
RADACHSE VORNE 5x28mm (FORMULA TEN)
102834
1
KING PIN/AUFHAENGUNGS-KUGEL SET (FORMULA TEN)
102835
1
T-BAR 1.5mm (FORMULA TEN)
102836
2
FT01 SLICKREIFEN D MISCHUNG (VORNE/62x32mm)
102837
2
FT01 SLICKREIFEN D MISCHUNG (HINTEN/62x37mm)
102838
1
OBERDECK (FRP/2.0mm/FORMULA TEN)
B010
2
KUGELLAGER MIT FLANSCH 1/4x3/8 in.
Z150
1
ANTENNENROHRSET
Z155
1
DIFFERENTIAL FETT
Z156
1
GRAUES DIFFERENTIALFETT
Z224
10
UNTERLAGSCHEIBE M3x8mm
Z242
20
E-CLIP E2mm SILBER
Z264
10
STIFT 2x10mm SILBER
Z420
12
INBUSSCHRAUBE M2.6x6 SCHWARZ
Z527
6
SENKKOPFSCHRAUBE M3x10mm
Z552
10
FLACHKOPFSCHNEIDSCHRAUBE M3x10mm
Z561
6
SCHNEIDSCHRAUBE MIT FLANSCH M3x10mm
Z576
10
SENKKOPFSCHNEIDSCHRAUBE M3x8mm
Z579
12
SENKKOPFSCHNEIDSCHRAUBE M3x15mm
Z676
4
STOPPMUTTER M3 (FLACH)
Z684
4
STOPPMUTTER M4 MIT FLANSCH
Z700
6
MADENSCHRAUBE M3x3mm
Z710
4
MADENSCHRAUBE M3x22mm
Z901
1
INBUSSCHLUESSEL 1.5mm
Z904
1
INBUSSCHLUESSEL 2.0mm
Z950
1
KREUZSCHLUESSEL KLEIN
30
