Headlight beam level control

Left−hand drive vehicles
Right−hand drive vehicles
To adjust the headlight beam level, turn
the dial.
The following list shows examples of prop-
er dial settings. For loading conditions oth-
er than those listed, adjust the dial posi-
tion so that the beam level is the same
as the one obtained according to the list
when only the driver is in the vehicle. The
higher the number of the dial position, the
lower the headlight beam level.
Always keep the headlight beam at the
proper level, or your headlights may
dazzle other road users.
RAV4_EE
LIGHTS, WIPERS AND DEFOGGER
ALA30R−AWFXYW,
ALA30L−AWFXYW,
ACA30L−AWMXKW, ACA30L−AWMGKW,
ACA30L−AWPXKW
ACA30L−AWPGKW models
Loading condition
Driver only
Driver +
front passenger
Full passengers (including
driver)
Full passengers (including
driver) + full luggage loading
to the luggage compartment
Driver + full luggage loading
Others
Four−
Dial
wheel
position
drive
models
Loading
condition
Driver only
Driver +
front passenger
Full passengers
1.5
(including
driver)
Full passengers
(including
2.5
driver) + full
luggage loading
to the luggage
compartment
Driver + full
luggage loading
*
: See "Model code" on page x for de-
tails.
181
ALA30R−AWFGYW,
ALA30L−AWFGYW,
and
*
Dial position
0
0
1.5
3
4
Two− Two−
wheel wheel
drive drive
models models
with with
3ZR−FAE 2AD−FTV
engine and
2AD−FHV
engines
0 0 0
0
0 0
1.5 1.5
3 2.5
3 3.5 3.5
