ULTRA FLAME
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPOURS AND LIQUIDS IN THE
Manufactured by :
DROLET STOVES & FIREPLACES INC.
1700 Leon Harmel
Quebec, Qc (Canada)
G1N 4R9
DIRECT VENT GAS STOVE
INSTALLATION AND OPERATING INSTRUCTIONS
FOR YOUR SAFETY
VICINITY OF THIS OR ANY OTHER APPLIANCE
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. OPEN WINDOWS
2. TURN OFF MAIN GAS SUPPLY
3. DON'T TOUCH ELECTRICAL SWITCHES
4. EXTINGUISH ANY OPEN FLAME
5. IMMEDIATELY CALL YOUR GAS SUPPLIER
Tested by :
WARNOCK HERSEY
Rev 07/96 45046A
Advertisement
Table of Contents
Related Manuals for Drolet ULTRA FLAME DIRECT VENT GAS STOVE
Summary of Contents for Drolet ULTRA FLAME DIRECT VENT GAS STOVE
- Page 1 3. DON'T TOUCH ELECTRICAL SWITCHES 4. EXTINGUISH ANY OPEN FLAME 5. IMMEDIATELY CALL YOUR GAS SUPPLIER Manufactured by : Tested by : DROLET STOVES & FIREPLACES INC. 1700 Leon Harmel Quebec, Qc (Canada) G1N 4R9 WARNOCK HERSEY Rev 07/96 45046A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS : TABLE OF CONTENTS : ................... 2 GENERAL INFORMATION : ..................3 WARNING ........................4 SPECIFICATIONS : ....................5 TOP, FRONT AND SIDE VIEWS : ................6 INSTALLATION: SAFETY NOTICE : ..................7 POSITIONING THE STOVE : ................ 7 VENT TERMINAL LOCATION : .............. -
Page 3: General Information
GENERAL INFORMATION : The ULTRA FLAME DIRECT VENT GAS STOVE is a high-efficiency free-standing gas appliance with a maximum input rating of 30 000 Btu/h with natural gas or 26,000 Btu/h with propane. It features a thermostatic modulating valve and a constant pilot. This means that the flame will vary in height according to room temperature. -
Page 4: Warning
WARNING INSTALLATION SHOULD BE DONE BY A QUALIFIED INSTALLER. DO NOT BURN WOOD OR ANY OTHER MATERIAL IN THIS APPLIANCE. HOT WHEN IN OPERATION. KEEP CHILDREN, FURNITURE, CLOTHING AND FLAMMABLE MATERIAL AWAY FROM THE APPLIANCE. ADVISE ADULTS AND CHILDREN TO THE HAZARD OF HIGH SURFACE TEMPERATURES AND THAT THEY SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. -
Page 5: Specifications
SPECIFICATIONS : Dimensions : height : 29-3/16" width : 26-5/16" depth : 19-5/8" 18-3/16" x 15-31/32" 1400 o F clear ceramic Glass : front sides 5-1/16" x 15-31/32" 1400 o F clear ceramic Fuel : Natural Gas Propane Input : 30 000 26 000 Btu/h... -
Page 6: Top, Front And Side Views
TOP, FRONT AND SIDE VIEWS : INSTALLATION: 26-5/16" 13-5/32" 8" 5" 19-5/8" Top view 26-5/16" 17-1/2" 19-5/8" 2-5/8" 6-1/8" 18-7/8" 13-5/8" 29-3/16" 10-5/16" 18-1/4" 24-1/8" Front view Side view... -
Page 7: Installation
INSTALLATION SAFETY NOTICE : Improper installation may result in a house fire. Follow installation directions. Installation must be in accordance with local building codes and with current CAN/CGA B149.1 & B149.2 installation codes for gas appliances. INSTALLATION SHOULD BE DONE BY A QUALIFIED INSTALLER. THIS GAS FIREPLACE MUST BE VENTED OUTSIDE. - Page 8 L9002.TIF A = 12" Clearance above grade, veranda, porch, deck or balcony B = 12" Clearance to window or door that may be opened C = 12" Clearance to permanently closed window D = 18" Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (60 cm) from the centre-line of terminal (straight out or corner installation)
-
Page 9: Clearances
A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings * Only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the floor * As specified in CGA B149 Installation Codes (1991) NOTE: Local codes or Regulations may require different clearances In addition, the following restrictions also apply. -
Page 10: Installation Of The Unit
Clearance between the stove and any combustible material must also be respected while installing your appliance. Clearance to the floor is 0". Clearance between wall and the pipe is 1". Do not install pipe in an enclosed area or through an insulated wall without a radiation shield ( no E-5710) INSTALLATION OF THE UNIT •... - Page 11 CONNECT THE POWER LINE TO THE SAME WIRES THE CORD WAS CONNECTED TO (P) JUNCTION BOX SPEED CONTROL • If you prefer to use the six-foot cord supplied, just connect it to a 120V outlet. • Move the ULTRA FLAME to the desired position and secure in place with four screws. •...
-
Page 12: Venting Kits
VENTING KITS Once the position of the stove and the termination cap are fixed, you should select the venting kit appropriate for your needs. First floor installations require either a STRAIGHT OUT kit or a CORNER kit while basement installations must be done with a BASEMENT kit. Please note that the BASEMENT kit can also be used on first (or higher) floors and it is possible to use up to 25' of pipe with a distant installation. -
Page 13: Basement Installation
• Add a spring spacer. Spring spacer must be located opposite to the joints of the outside pipe to prevent puncturing of the inside pipe when screwing two sections of the outside pipe together. • Add sections of 8" diameter pipe and cut it to be flush with the outside face of exterior wall, and install them to the 45°... - Page 14 VENTING KITS Straight out Corner VENT TERMINAL VENT TERMINAL RADIATION SHIELD RADIATION SHIELD 60" MAX 45 ELBOW -min 1" -max 60" VENT PIPES Basement 10-1/2" X 10-1/2" OPENING CUT TO LENGTH...
-
Page 15: Distant Installation
5" LOCKING BAND SCREWS 8"RIGID AIR INLET PIPE 5" FLEXIBLE FLUE PIPE 4" FOR BASEMENT OR DISTANT INSTALLATION DISTANT INSTALLATION It is possible to use up to 25 feet of pipe and a wall vent terminal or roof vent terminal ( no E5700 ) However, the following restrictions must be applied. -
Page 16: Venting System
L9001.TIF VENTING SYSTEM... -
Page 17: Vent Terminal Straight Out And Corner Installation
VENT TERMINAL STRAIGHT OUT AND CORNER INSTALLATION Seal with RTV silicone between 8" diameter pipe and radiation shield inside and outside the building to prevent air passage. Install the vent terminal as shown. Insert the wall plate inside the 8" pipe and screw it to the wall using the six #10 2-1/2" wood screws supplied. Place the 5" locking band around the inner connector and insert the exhaust pipe. -
Page 18: Vent Terminal, Roof Installation
VENT TERMINAL, ROOF INSTALLATION • Here are the distance requirements for roof terminal installation. • Clearance between combustible wall and vent pipe must be 2" and a radiation shield must be use to cross and insulated wall. • If vent terminal is more then 5 feet above the roof use roof braces to secure the whole assembly INSTALLATION OF SIDE PANELS AND PEDESTAL •... - Page 19 NUTS Pedestal cover : Slide the pedestal cover over the pedestal from the front. Place the back cover on the pedestal cover and secure with the supplied screws. PEDESTAL COVER BACK COVER SCREWS • The paint on your stove will produce light smoke and fumes when heated for the first time. We recommend you light the stove and let it burn for at least an hour while providing good ventilation in the room.
-
Page 20: Glass Front Removal, Cleaning And Installation
GLASS FRONT REMOVAL, CLEANING AND INSTALLATION GLASS FRONT ASSEMBLY SIDE PANELS CLAMPS (OPEN POSITION) DECORATIVE GOLD TRIMS Removal : - Let the stove cool down for at least one hour. - Remove the decorative gold trim from the stove. - Open both side panels. - Open the four clamps. - Page 21 There should be no gap between the venturi tube and the orifice assembly. Of there is any, it should be filled with silicone washer available from Drolet Stoves & Fireplaces inc. WARNING : NEVER OPERATE THE GAS STOVE WITHOUT HAVING THE ORIFICE PROPERLY INSERTED IN THE VENTURI TUBE.
-
Page 22: Log Installation
LOG INSTALLATION : Remove the glass front as described on page 20. Install the longer log in back of the firebox with locating grooves on top. Install the 14" log in the front of the firebox and to the right. Make sure the log is pushed against the metal retainer on the burner face. -
Page 23: Ember Kit Installation
EMBER KIT INSTALLATION : Threesmall plastic bags are supplied with your unit. One of the bags contains vermiculite to simulate ashes in the fire box, another contains lava rock to simulate coals and the last one is filled with rock wool fibre which, when glowing red, resembles hot embers. (follow instruction on the next drawing) Place some vermiculite and some lava rocks at the bottom of the fire box and on top of the burner plate. -
Page 24: Refractory Panels Installation
REFRACTORY PANELS INSTALLATION: Remove the glass front assembly. Remove the logs from the firebox. Place the back refractory against the back of the firebox. Install the two side refractory panels by sliding them between the firebox sides and the baffle plate. Put the logs back in place. -
Page 25: Operating Instructions
OPERATING INSTRUCTIONS LIGHTING INSTRUCTIONS: Open the pedestal cover front panel to reach the control. Turn the gas valve knob to the "OFF" position and wait 5 minutes. Turn the gas valve knob to "PILOT". Depress and hold the knob while lighting the pilot by pressing the pilot igniter button (RED button right of the valve). -
Page 26: Shutdown Instructions
NOTE : This valve is equipped with a modulating thermostat that will automatically adjust flame height according to room temperature. As room temperature approaches the value set by the knob ( anywhere between HI and LOW on the knob ), the flame will decrease in height. -
Page 27: Maintenance Instructions
MAINTENANCE INSTRUCTIONS : TURN OFF THE GAS WITH THE SHUTDOWN VALVE AND THE ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. The venting system and the gas stove should be inspected at least once a year. Remove the glass front and the logs and clean them if necessary. The control compartment, air circulating passages, firebox, logs and burner should be cleaned at least once a year by vacuuming or brushing. -
Page 28: Optional Parts
OPTIONAL PARTS ITEM DESCRIPTION Pedestal and side panels almond enamel Pedestal and side panels black enamel Pedestal and side panels black painted Decorative refractory kit Gold plated door trims REPLACEMENT PARTS ITEM DESCRIPTION 4 Log kit Burner assembly Burner orifice, ( natural gas or propane ) Pilot assembly, ( natural gas or propane ) S.I.T. -
Page 29: Limited 5-Year Warranty
During the first year of the limited warranty, DROLET STOVES AND FIREPLACES INC. will provide free replacement parts for the fireplace gas stove except for the glass assembly.
