Carrier 40UV050 Installation, Start-Up And Service Instructions Manual

Installation, Start-Up and Service Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . . .1
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
PREINSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpack and Inspect Units . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Protect Units From Damage . . . . . . . . . . . . . . . . . . . . . . . . .1
Prepare Jobsite for Unit Installation . . . . . . . . . . . . . . . . .1
Identify and Prepare Units . . . . . . . . . . . . . . . . . . . . . . . . . . .1
PHYSICAL DATA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Placing Vertical Units in Position . . . . . . . . . . . . . . . . . . . .2
Placing Horizontal Units in Position . . . . . . . . . . . . . . . . .2
Make Piping Connections . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Make Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . .8
Actuators (Field-Supplied). . . . . . . . . . . . . . . . . . . . . . . . . . .8
Make Duct Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Make Final Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-41
Preventing Excessive Condensation on Unit . . . . . . .25
Check Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Fan Motor Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Fan Shaft Ball Bearing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Clean Fan Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Clean or Replace Air Filters . . . . . . . . . . . . . . . . . . . . . . . .25
ECM Motor Removal and Reinstallation . . . . . . . . . . . .25
Blower Assembly Section Removal and
Reinstallation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Coil Assembly Removal and Reinstallation . . . . . . . . .30
Ball Bearing Replacement . . . . . . . . . . . . . . . . . . . . . . . . . .32
Sleeve Bearing Replacement . . . . . . . . . . . . . . . . . . . . . . .37
Blower Wheel Removal and Reinstallation. . . . . . . . . .39
Damper Section Removal and Reinstallation . . . . . . .40

SAFETY CONSIDERATIONS

Installation and servicing of this unit can be hazardous due
to system pressure, electrical components and equipment loca-
tion (such as a ceiling or elevated structure). Untrained person-
nel can perform the basic maintenance functions of replacing
filters. Only trained and qualified service personnel should per-
form all other operations.
When installing this unit, observe precautions in the litera-
ture, tags and labels attached to the equipment, and any other
safety precautions that may apply.
• Follow all safety codes.
• Wear safety glasses and work gloves.
• Use care in handling and installing this accessory.
• Use quenching cloth for all brazing operations.
• Have fire extinguisher available for all brazing
operations.
Before performing service or maintenance operations, turn
off main power switch to the unit. Electrical shock could
cause personal injury.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 534-095
Book 3
Tab 2a
Page
Printed in U.S.A. Form 40UV,UH-7SI
40UV,UH050-200
Unit Ventilators

INTRODUCTION

This document contains general installation instructions for
the 40UV,UH unit ventilators. Refer to the 40UV,UH Unit Ven-
tilators with Product Integrated Controls (PIC) Installation,
Start-Up and Service instructions manual for specific PIC
control instructions. Refer to the unit wiring diagram or to
specific manufacturer literature for any other type of factory-
mounted controls.
See submittal drawings for unit configurations, dimensions,
clearances, and pipe connections. Refer to unit wiring label for
all electrical connections; follow NEC (National Electrical
Code) and local codes.

PREINSTALLATION

Unpack and Inspect Units -

from all units. Check the shipment against shipping order. If
shipment is damaged or incomplete, file claim with transporta-
tion company and advise Carrier immediately.

Protect Units From Damage -

ranty, protect units against adverse weather, theft, vandalism,
and debris on jobsite. Do not allow foreign material to fall into
drain pan. Prevent dust and debris from being deposited on
motor and fan wheels.
If the equipment is stored for any length of time before in-
stallation, it should remain in its shipping container in a clean,
dry, and climate controlled area.

Prepare Jobsite for Unit Installation -

time and to reduce the possibility of costly errors, set up a com-
plete sample installation in a typical room at jobsite. Check all
critical dimensions such as pipe, wire, and duct connection
requirements. Refer to job drawings and product dimension
drawings as required. Instruct all trades in their part of the
installation.

Identify and Prepare Units

1. Be sure power requirements match available power
source. Refer to the unit nameplate and wiring diagram.
2. Remove front (40UV) or bottom (40UH) access panels
from the unit. Retain the
panels for reinstallation later.
3. Rotate the fan shaft by hand to ensure that fans are
unrestricted and can rotate freely. Check for shipping
damage and fan obstructions.
PHYSICAL DATA
Component weight data of 40UV,UH units is provided in
Table 1.
Pg 1
Remove shipping wraps
To maintain war-
To save
5 / -in. socket head fasteners and
32
5-05 Replaces: 40UV,UH-2SI
