Supplementary Instructions for Windows
This manual contains supplementary instructions regarding the use of the computer. It explains the cases
where the operation of the computer differs from that in the Operating Instructions.
<For CF-37VB6BAEM model only>
For U.S.A.
FCC Regulation Notice for modem
This equipment contains a FCC approved modem.
Manufacturer of modem: 3Com Corporation
Model No. 3CN3AC1556
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
First-time Operation
Replace the inclusion for the following.
Windows 95 System Pack .... 1
Windows
®
95 Book
Product Recovery CD-ROM
Perform the following after step 1.
Write down the Product Key
CAUTION
The Product Key is necessary during the Setup procedure for Windows (
write down the alphanumeric Product Key, which is written on the "Certificate of Authenticity"
listed on the cover of the Windows book (that comes with this computer) or on the bottom panel of
the computer, in the margin of the manual.
Replace the first "NOTE" for the following. "OPERATING INSTRUCTIONS (page 10)"
NOTE
The power saving mode ([Power Scheme] in [Control Panel] - [Power Management]) is factory set, so if there is no
input from a key, the touch pad, the touchscreen or an external mouse (when one is connected) for a certain
interval of time, the power to the LCD and hard disk is shut down.
The LCD will resume operation when the touch pad or the touchscreen is used, or a key or an external
mouse is pressed.
The power to the LCD may be turned off while Windows is setting up or even when an application software is
being installed. In this case, because it is conceivable that a selection dialog box will be shown, do not press
the Enter key to attempt to resume from this condition as doing so may trigger a selection, but instead,
press a key unrelated to the direct triggering of a selection, like the
*With Windows 98, "Suspend" is called "Standby".
Registration Card
"OPERATING INSTRUCTIONS
"OPERATING INSTRUCTIONS
Windows
®
Book......1
Personal Computer
CF-37
Product Recovery
Driver Update
CD.............1
CD-ROM.....1
page 2,3), so be sure to
key.
Shift
®
98
®
Series
"
(page 3)
"
(page 9)
1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CF-37 Series

Summary of Contents for Panasonic CF-37 Series

  • Page 1 ® Personal Computer Supplementary Instructions for Windows ® CF-37 Series This manual contains supplementary instructions regarding the use of the computer. It explains the cases where the operation of the computer differs from that in the Operating Instructions. <For CF-37VB6BAEM model only> For U.S.A.
  • Page 2 Replace the step 6 for the following. “OPERATING INSTRUCTIONS (page 11)” Setup Windows 98 <For CF-37VB62AEM model> Select settings for your region and your keyboard layout, then press [Next]. (for U.S.A.: United States 101) NOTE Moving the cursor ( ) or clicking buttons can be performed with the touch pad, a key or the touchscreen.
  • Page 3 <For CF-37VB6BAEM model> At the [Add New Hardware Wizard], set the Driver Update CD in the CD-ROM drive. Press [Next]. Select [Search for the best driver for your device.], then press [Next]. Input [L:\WIN98\LAN] for [Specify allocation], then press [Next]. If [Location of driver L:\WIN98\LAN\NET556N5.INF] is displayed, press [Next].

  • Page 4: Starting Up/Shutting Down

    Replace the "NOTE" for the following. “OPERATING INSTRUCTIONS (page 12)” NOTE When using the files in the following folders available on the retail version of the Windows CD-ROM, it is necessary to run a separate file decompression program. \tsclient \tools To uncompress the file, it is necessary to have approximately 80 MB of free disk space available on the hard disk.

  • Page 5: Dealing With Problems

    Dealing with Problems “OPERATING INSTRUCTIONS ” (page 19) The following has been changed. Starting Up When the previous item is Press F9 in the Setup Utility ( "Setup Utility"). This will restore the Setup not the cause Utility's settings to their default values (except the password settings). In the MS-DOS mode, run SCANDISK to check the hard disk.
  • Page 6 <For CF-37VB6BAEM model only> Modem “REFERENCE MANUAL ” (page 45) Replace the step 2 for the following and the step 3 is not needed. Select [Dialing Properties] in [Start] - [Settings] - [Control Panel] - [Modems] Select the country in [Dialing Properties] - [My Locations] - [I am in]. Input the necessary information (items such as the phone system) and then press [Close].

  • Page 7: Connecting To The Lan

    The following has been added. <For CF-37VB6BAEM model only> Connecting to the LAN This model has an internal LAN port. CAUTION Do not insert a telephone line connector (including a PBX internal phone) into the LAN port. Doing so may cause fire or electric shock. LAN Port <For CF-37VB6BAEM model only>...

  • Page 8: Setup Utility

    <For CF-37VB6BAEM model only> Setup Utility “REFERENCE MANUAL ” (page 47) Replace the advanced menu for the following. “REFERENCE MANUAL (page 49)” Plug & Play: [Disable] Serial Port A:* [Auto] Serial Port B:* [Auto] Device: [Touchscreen] Parallel Port:* [Auto] Mode: [Bi-directional] Internal Modem/LAN: [Enable]...
