This manual contains supplementary instructions regarding the use of the computer. It explains the cases
where the operation of the computer differs from that in the Operating Instructions.
NOTE
Windows NT
:
Information for Microsoft Windows NT
Windows 2000
: Information for Microsoft Windows
Windows NT
The following functions are not supported with Windows NT. Ignore the description in the "Operating
Instructions" about the following functions.
Windows 2000
The following functions are not supported with Windows 2000. Ignore the description in the "Operating
Instructions" about the following functions.
Read Me First
Ignore the item of "System File Checker".
First-time Operation
Replace the inclusion for the following.
Windows 2000
Replace the "NOTE" for the following.
NOTE
The power saving mode ([Power Schemes] in [Control Panel] - [Power Options]) is factory set, so if there is no input
from a key, the touch pad, the touchscreen or an external mouse (when one is connected) for a certain interval of time,
the power to the LCD and hard disk is shut down. The LCD will resume operation when the touch pad, the
touchscreen or an external mouse (when one is connected) is used or a key is pressed.
The power to the LCD may be turned off while Windows is setting up or even when an application software is
being installed. In this case, because it is conceivable that a selection dialog box will be shown, do not press the
Space or
instead, press a key unrelated to the direct triggering of a selection, like the
In addition, when the computer is left alone, it automatically enters the standby or hibernation mode (
"Standby/Hibernation Functions"). The computer will resume by sliding the power switch.
Display Rotation Tool
USB Devices
Infrared Data Communications
Smart Boot
Panasonic Hand Writing
Smart Boot
Product Recovery
CD-ROM...............1
Enter
key to attempt to resume from this condition as doing so may trigger a selection, but
Supplementary Instructions
Model No.
®
Workstation Version 4.0 users.
®
2000 Professional users.
"OPERATING INSTRUCTIONS
"OPERATING INSTRUCTIONS (page 7)"
"OPERATING INSTRUCTIONS
"OPERATING INSTRUCTIONS (page 9)"
Product Recovery
CD-ROM...............3
"OPERATING INSTRUCTIONS (page 10)"
Personal Computer
CF-37
(page 3)
(page 9)
Shift
key.
®
Series
"
"
1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CF-37 Series

Summary of Contents for Panasonic CF-37 Series

  • Page 1 Infrared Data Communications Smart Boot Windows 2000 The following functions are not supported with Windows 2000. Ignore the description in the “Operating Instructions” about the following functions. Panasonic Hand Writing Smart Boot Read Me First “OPERATING INSTRUCTIONS ” (page 3) Ignore the item of “System File Checker”.

  • Page 2: Select The Operating System

    Add the following step before the step 7 “OPERATING INSTRUCTIONS (page 11)” Select the Operating System Windows NT and Windows 2000 are preinstalled on this computer. After one of them is selected with the following procedure, only that OS can be used. At the screen for the agreement of the selection of the OS, select [Y].
  • Page 3 Windows 2000 CAUTION Do not press any key or use the touch pad or the touchscreen until [Windows 2000 Profes- sional Setup] is displayed. At the [Welcome to the Windows 2000 Setup Wizard], then press [Next]. NOTE Moving the cursor ( ) or clicking buttons can be performed with the touch pad. ( “Operating Instructions”...
  • Page 4 Windows NT Add the following steps after step 7. “OPERATING INSTRUCTIONS (page 11)” ® Install the Acrobat Reader 4.0 NOTE Acrobat ® Reader is necessary to view the Reference Manual, which explains detailed opera- tional procedures concerning your computer. Logon the computer by the administrator. At the [Welcome to Windows NT], select [Close].
  • Page 5 “OPERATING INSTRUCTIONS (page 12)” Prepare 2HD floppy disks and make sure they are not in the write-protected state, then select [Start] - [Programs] - [Panasonic] - [Create Backup Disk] and follow the on-screen instructions. Place a label identifying the contents on each disk.

  • Page 6: Starting Up/Shutting Down

    Reference Manual “OPERATING INSTRUCTIONS ” (page 14) Add the following “NOTE”. “OPERATING INSTRUCTIONS (page 14)” NOTE There might be missing characters and underlined parts in the Reference Manual. In such cases, printing out the contents will enable you to view the pages properly. Windows 2000 Replace the first “NOTE”...

  • Page 7: Restarting Your Computer

    Should this happen, allow the computer to cool down then switch the power on again. If the computer still does not power on, contact Panasonic Technical Support. If the computer has not been used for a long period of time, it may produce an unusual sound at start up.

  • Page 8: Dealing With Problems (Summary)

    Check to see if a fully charged battery is properly installed. Remove the battery pack and disconnect the AC adapter, then connect them again. is displayed Input your password. If you have forgotten it, contact Panasonic Technical Support. [POST Startup Error(s)] is “Operating Instructions” page 17...

  • Page 9: Battery Indicator

    The battery pack or recharging function may be defective. Quickly remove the battery pack and disconnect the AC adapter, then connect them again. If the problem persists, contact Panasonic Technical Support. After the AC adapter is con- Unable to charge because of an improper temperature range. ( “Operating Instructions”...

  • Page 10: Reference Manual

    [File] - [Open]. For the Reference Manual, this procedure does not need to be followed. The Reference Manual can be opened by selecting [Reference Manual] in [Start] - [Pro- grams] - [Panasonic] - [On-Line Manuals]. Network Unable to connect to a net-...

  • Page 11: Reinstalling Software

    NOTE If you have not created the BACKUP DISK, you can create by selecting [Create BACKUP DISK] in [Start] - [Pro- grams] - [Panasonic]. If you can not create this disk, contact Panasonic Technical Support. Important Save all important data. If reinstallation is carried out, all data existing prior to the installation will be lost. The reinstallation will return the computer to close to the conditions at time of purchase.
  • Page 12 10 At the confirmation message , press Y . The operations of “format” and “restore” for the hard disk start automatically. (The operations take about one hour.) Windows 2000 When “Insert media 2” is displayed, insert Product Re- covery CD-ROM 2, then “Insert the next media” is dis- played, insert Product Recovery CD-ROM 3 into the CD- ROM drive and immediately select [OK].

  • Page 13: Specifications

    Specifications “OPERATING INSTRUCTIONS ” (page 25) The following has been changed. “OPERATING INSTRUCTIONS (page 25)” Windows NT Model No. CF-37NDEDDCM Internal Modem Data:56 kbps (V.90 & K56flex) FAX:14.4 kbps Internal LAN IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX Software Operating System Microsoft ®...

  • Page 14: Usb Devices

    USB Devices “REFERENCE MANUAL ” (page 43) Windows NT When using the USB FDD, install the USB FDD driver by the following procedure. “REFERENCE MANUAL (page 43)” Installing the USB FDD driver Select [Start] - [Run], input [C:\UTIL\DRIVERS\USBFD\UFD105.EXE], then select [OK]. At the [Setup Complete], select [Yes, I want to restart my computer now], then select [Finish].
  • Page 16 UA0601-0 Printed in U.S.A. DFQX5271ZAU...
