- Page 1 Instruction manual Unitor Welding Inverter UWI 203 TP MMA (Stick) / TIG welder Revision date: 23 09 2014 Page 1 of 24...
-
Page 2: Table Of Contents
CONTENTS 1. GENERAL DESCRIPTION 2. TECHNICAL DATA 3. INSTALLATION 4. FRONT AND BACK PANEL 5. WELDING 6. ROUTINE MAINTENANCE 7. TROUBLESHOOTING 8. WIRING DIAGRAM 9. COMPONENTS AND SPARES 10. ACCESSORIES 11. SAFETY INSTRUCTIONS DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL INCLUDING THE SAFETY INSTRUCTIONS Revision date: 23 09 2014 Page 2 of 24... -
Page 3: General Description
Total Protection function with indicator light prevents damage to the machine if one phase in the power supply falls out IDENTIFY COMPONENTS Unitor Welding Inverter UWI 203 TP, product number 191- 203203 is delivered with Carrying strap mounted on the machine 1 pce... -
Page 4: Technical Data
2 TECHNICAL DATA Type of welding machine Three-phase static transformer rectifier frequency converter, DC output. Processes MMA (Stick electrode / SMAW) TIG (GTAW) Safety Marking Suitable for use in areas with increased electric shock hazard X: Duty cycle Duty Cycle is percentage of 10 minutes that unit can weld at rated load without overheating. It refers to a 40°C environmental temperature. - Page 5 = No-load voltage Also called open circuit voltage, is the maximum voltage (excluded any stabilization voltage or arc ignition) found between the output outlets when the welding machine is not welding. This is the voltage a welder can be exposed to between electrode holder and work piece. = rated reduced no-load voltage No-load voltage of a welding power source fitted with a voltage reducing device = Arc voltage...
-
Page 6: Installation
Select a suitable location The UWI 203 TP inverter welder has an IP23S rating. Locate the welder in a dry location where there is free circulation of clean air into the louvers in the back and out the front of the unit. -
Page 7: Front And Back Panel
4 FRONT AND BACK PANEL Description 1. Power on warning. Green light when the machine is connected and switched on. 2. Thermal protection activated. Yellow light indicates that the protection thermostat has cut the output. Do not switch the machine off. The fan will be running and the thermostat resets automatically when the machine has cooled down sufficiently. -
Page 8: Welding
5 WELDING MMA (SMAW stick electrode) welding 1 Electrode Select MMA welding (selector switch up). 2 Workpiece Connect ground (return) cable with good contact to 3 Arc the work piece. Select polarity and amperage as recommended for the electrode and start arc as follows: Drag electrode across work piece like striking a Match and lift electrode slightly after touching work. -
Page 9: Routine Maintenance
6 ROUTINE MAINTENANCE Checkpoint Action Interval Primary plug Check connections 3 months or more and socket and stretch relief often if needed Check for damage and replace if 3 months or more Primary cable necessary often if needed Primary cable Check for damage 3 months or more stretch relief... -
Page 10: Troubleshooting
7 TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTION REASON Mains fuses blown Machine is not plugged in Broken primary cable Primary power No output, no warning does not reach the Cable connection to machine is loose light, fan not running machine Machine not switched on On/off switch damaged Voltage protection Too high or too low input voltage, should be... -
Page 11: Wiring Diagram
8 WIRING DIAGRAM Revision date: 23 09 2014 Page 11 of 24... -
Page 12: Components And Spares
9 COMPONENTS AND SPARES Revision date: 23 09 2014 Page 12 of 24... - Page 13 022.0002.0190 Led wiring Spare part kit for UWI-203TP includes power board, necessary additional components and complete instructions for replacement Order no191-203205 For ordering spares please state: Model: UWI 203 TP Serial no: …………. Pos no: …………. Code: .…………. Revision date: 23 09 2014...
-
Page 14: Accessories
10 ACCESSORIES Cable Extensions Welding cable 35mm² (max 20m extension is recommended), per m 195 175836 Cable connector DIX 70 male – female for welding cable extension 195 632893 Stick Welding Accessories for UWI 203 AutoVision Welding Face Shield with Adjustable Shade 9 To 13 196 709519 Face shield with handle and filter shade 11 glass 196 619098... - Page 15 TIG torch T-200 Order number 197-200000 Pos. Order number Unit Product description 197-551192 Short back-cap 197-551200 Long back-cap 197-613767 Heat shield 197-551168 Collet 1.6mm 197-551150 Collet 2.4mm 197-551184 Collet body 1.6 mm 197-551176 CoIlet body 2.4 mm 197-551135 Alumina nozzle 6 197-551127 Alumina nozzle 7 197-674710...
-
Page 16: Safety Instructions
11 SAFETY INSTRUCTIONS Arc Welding Hazards The safety information given below is only a summary of the more complete safety information found in the Safety Standards listed in Section 1-5. Read and follow all Safety Standards. Only qualified persons should install, operate, maintain, and repair this unit. During operation, keep everybody, especially children, away. - Page 17 FUMES AND GASES can be hazardous. Welding produces fumes and gases. Breathing these fumes and gases can be hazardous to your health. Keep your head out of the fumes. Do not breathe the fumes. If inside, ventilate the area and/or use exhaust at the arc to remove welding fumes and gases. If ventilation is poor, use an approved air-supplied respirator.
- Page 18 HOT PARTS can cause severe burns. Do not touch hot parts bare handed. Allow cooling period before working on gun or torch. MAGNETIC FIELDS can affect pacemakers. Pacemaker wearers keep away. Wearers should consult their doctor before going near arc welding, gouging, or spot welding operations.
- Page 19 MOVING PARTS can cause injury. Keep away from moving parts such as fans. Keep all doors, panels, covers, and guards closed and securely in place. H.F. RADIATION can cause interference. High-frequency (H.F.) can interfere with radio navigation, safety services, computers, and communications equipment.
- Page 20 ECLARATION OF CONFORMITY ₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪ ₪ UNITOR WELDING We hereby state that the machine type INVERTER UWI-203 TP ₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪ ₪ 2004/108/ 2006/95/ is in compliance with the directives 2011/65/ ₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪ ₪ 60974-1 and that the following standards apply 60974-10 ₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪₪ ₪...
