Page 1: Spare Parts List
Instruction manual & spare parts list Unitor Welding Inverter UWW-161 TP Multi Process MIG-MAG-MMA-TIG TP (total protection) version, from serial number 111194 Revision date: 23 09 2014 Page 1 of 32... - Page 2 ECLARATION OF CONFORMITY ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪ ₪...
-
Page 3: Table Of Contents
CONTENTS 1. GENERAL DESCRIPTION 2. IDENTIFY COMPONENTS TECHNICAL DATA 4. INSTALLATION 5. FRONT PANEL 6. SPOOL COMPARTMENT 7. WIRE LOADING 8. OPERATING INSTRUCTIONS 9. WIRE WELDING CONSUMABLE SPARES 10. WIRE WELDING ACCESSORIES 11. SHIELDING GAS ACCESSORIES 12. TIG ACCESSORIES 13. MAINTENANCE 14. -
Page 4: General Description
UWW-161 TP is easy to transport, only 12kg weight and it is specifically designed for light fabrication, maintenance and repair work on board. -
Page 5: Identify Components
2 IDENTIFY COMPONENTS UWW-161 TP complete, product number 193-161161 is delivered with Primary cable, 2.5m with plug (fitted on machine) 1 piece Gas hose socket with nut and hose clamp 1 set Product number 161165 Drive roll V groove, 0.6-0.8mm (fitted in machine) -
Page 6: Technical Data
3 TECHNICAL DATA The unique serial number for the machine will be printed here. Always give serial number when ordering spares or in other communication with WSS concerning your machine. Type of welding machine One-phase static transformer rectifier frequency converter, DC output. Processes MMA (Stick MIG/MAG (Metal Inert Gas/Metal Active Gas) - Page 7 X: Duty cycle Duty Cycle is percentage of 10 minutes that unit can weld at rated load without overheating. It refers to a 40°C environmental temperature. If unit overheats a thermal switch stops the output, the warning light for over-temperature is lit and the cooling fan continues to run. Wait fifteen minutes for unit to cool.
-
Page 8: Installation
4 INSTALLATION Only qualified personnel should perform this installation. Only personnel that have read and understood this Manual should install and operate this equipment. The machine must only be plugged into a receptacle which is grounded per applicable electrical codes. Note 1 The power switch is to be in the OFF position when installing work cable and torch and when connecting power cord to input power. - Page 9 POLARITY SELECTION In the picture below the cable supplying current to the Euro-connector is connected to the machine plus- connection. The cable to return current (ground clamp) then has to be connected to the machine minus- connection to the right in the picture. This means the machine is set for welding with electrode plus polarity from the Euro-connector to the right, which is the normal setting for MIG/MAG welding.
-
Page 10: Front Panel
5 FRONT PANEL 1. Wire speed adjustment. See separate table under OPERATION for relation between wire speed and approximate welding current. This adjustment is only active when one of the wire welding modes are selected 2. When this LED is lit, it means that the thermal cut-out for overheating of the machine has triggered and there is no welding current. - Page 11 7. This knob is active in the MIG/MAG mode only and allows selection between two arc types. When the led above the knob is lit a softer welding arc for MIG brazing is obtained. When the led is dark the normal, slightly crisper or harder arc is obtained. 8.
-
Page 12: Spool Compartment
6 SPOOL COMPARTMENT Gas post-flows pot-meter the gas post-flow for MIG Fuse for the auxiliary transformer and TIG can be adjusted from 0-3 seconds. It must providing current to the wire feed be long enough to ensure sufficient cooling of the motor: 800mA 250V slow fuse. -
Page 13: Wire Loading
7 WIRE LOADING Release the spring loaded pressure arm (1) rotate the roll arm (2) up from the wire feed drive roll (3). Ensure that the groove size in the feeding position on the drive roll matches the wire type and size. Place the wire spool in place on the wire spool spindle (4). -
Page 14: Operating Instructions
12. Set wire speed and voltage in accordance with the wire specifications and proceed with the welding. 13. When finished, close the gas cylinder and press the trigger shortly to vent off gas pressure in hoses and machine before switching off and unplugging. Examples on parameter settings Unitor Wire Wire size Groove type Wire... -
Page 15: Wire Welding Consumable Spares
9 WIRE WELDING CONSUMABLE SPARES Application area Product Description WIRE FEED DRIVE ROLLS 160003 Drive roll V-groove 0,6-0,8 160004 Drive roll U-groove 0,8-1,0 160005 Drive roll V-groove knurled 1,0-1,2 WIRE FEED LINERS 590075 Non iron liner * 0,6-1.2 613746 Steel liner** 0,6-1,2 CONTACT TIPS 711986... -
Page 16: Shielding Gas Accessories
11 SHIELDING GAS ACCESSORIES Regulator with flow adjustment 0-32 l/min 197 510010 for Argon and Mixed gas Regulator with flow adjustment 0-32 l/min 193 510012 for CO2 shielding gas Gas hose ¼” black, for shielding gas 176 576157 Hose clamps, one ear for ¼” hose, non- 401 729442 protruding stainless, bag of 10 pcs Pinching tool for ear clamps... -
Page 17: Maintenance
Spares 1 197-551192 pcs Short back-cap 2 197-551200 pcs Long back-cap 3 197-613767 pcs Heat shield 4 197-551168 pcs Collet 1.6mm 4 197-551150 pcs Collet 2.4mm 5 197-551184 pcs Collet body 1.6 mm 5 197-551176 pcs CoIlet body 2.4 mm 6 197-551135 pcs Alumina nozzle 6 6 197-551127 pcs Alumina nozzle 7 7 197-674710 pck Tungsten electrode (10 pcs) 1.6 mm... -
Page 18: Troubleshooting
14 TROUBLESHOOTING PROBLEM CAUSE SOLUTION − No current to the machine. • Make sure that power is available at the socket you − Voltage reaches the plug in to and that the power supply cable is intact. • Unplug the machine and make sure that when the machine switch but there is The machine no voltage after the... - Page 19 PROBLEM CAUSE SOLUTION Check for a short circuit at the DINSE plug with a diode tester. A short Unplug the machine. Remove the snubber board: circuit may be caused by : • check with a diode tester the status of the transil on the −...
- Page 20 PROBLEM CAUSE SOLUTION Unplug the machine. The delayed fuse 5x20 800 mA on − Primary fuse of the the back of the machine must be replaced. auxiliary transformer is • Check the connection of the motor feeding wire on the damaged The wire feeding front panel and after that check the continuity between...
- Page 21 PICTURE 3 PICTURE 4 To check the inverter, carry out the following measurements with a diode tester: Should there be a short-circuit on one of these measurements or an “OL” instead of a numeric value, the power board must be replaced. PICTURE 5 The varistor is a blue disc near the ground wire of the power board.
- Page 22 PICTURE 6 To check the mosfet of the switching power supply unit, carry out the following measurements: Should there be a short-circuit on one of these measurements or an “OL” instead of a numeric value, the power board must be replaced. PICTURE 7 Digital multimeter.
-
Page 23: Wiring Diagram
15 WIRING DIAGRAM Revision date: 23 09 2014 Page 23 of 32... -
Page 24: Components And Spares
16 COMPONENTS AND SPARES Spare part kit for UWI-150TP and UWW-161TP includes power board, necessary additional components and complete instructions for replacement. Order no.: 191-150161 For ordering spares please state: Model: UWW-161 TP Serial no: ………....…. Pos no: …………..... ………....…. - Page 25 CODE DESCRIPTION CODE DESCRIPTION 005.0001.0008 BELT 011.0010.0003 COIL BEARIN PLATE 011.0001.0188 UPPER COVER 011.0006.0050 SPOOL SUPPORT 015.0001.0001 HEAT SINK L=107mm 040.0006.1420 FUSE CARRIER 015.0001.0002 HEAT SINK L=50mm 050.0001.0043 DOUBLER OVERCUT BOARD 012.0001.0000 INTERNAL FRAMEWORKS 011.0010.0006 SWITCH PROTECTION PLATE 050.0011.0001 POWER BOARD 010.0006.0034 REAR PLASTIC PANEL 046.0002.0006...
-
Page 26: Safety Instructions
17 SAFETY INSTRUCTIONS Arc Welding Hazards The safety information given below is only a summary of the more complete safety information found in the Safety Standards listed in Section 1-5. Read and follow all Safety Standards. Only qualified persons should install, operate, maintain, and repair this unit. During operation, keep everybody, especially children, away. - Page 27 ARC RAYS can burn eyes and skin. Arc rays from the welding process produce intense visible and invisible (ultraviolet and infrared) rays that can burn eyes and skin. Sparks fly off from the weld. Wear a welding helmet fitted with a proper shade of filter to protect your face and eyes when welding or watching.
- Page 28 Additional precautions for installation, operation, and maintenance Do not install or place unit on, over, or near combustible surfaces. Do not install unit near flammables. Do not overload building wiring − be sure power supply system is properly sized, rated, and protected to handle this unit.
- Page 29 Principal Safety Standards (US) Safety in Welding, Cutting, and Allied Processes, ANSI Standard Z49.1, from American Welding Society, 550 N.W. LeJeune Rd, Miami FL 33126 (phone: 305-443-9353, website: www.aws.org ) . Recommended Safe Practices for the Preparation for Welding and Cutting of Containers and Piping, American Welding Society Standard AWS F4.1, from American Welding Society, 550 N.W.
- Page 30 18 NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Revision date: 23 09 2014 Page 30 of 32...
- Page 31 USE THE UNITOR WELDING HANDBOOK FOR MARITIME WELDERS You can download it here http://www.wilhelmsen.com/services/maritime/companies/buss/DocLit/PorductLiterature/Pages/Maintenanceandrepair.aspx …or contact Wilhelmsen Ships Service for a paper copy Revision date: 23 09 2014 Page 31 of 32...
