• Oil pressure warning lamp
• Oil Change Reminder Indicator (Diesel
only)
• Engine warning lamps
• Four-wheel drive indicator
• Four-wheel drive low (4L) indicator
• Electronic locking differential (ELD)
indicator
• Water-in-fuel indicator (Diesel only)
• Washer fluid level indicator
• DPF (Diesel Particulate Filter)
• Ice/Frost warning indicator

ABS warning lamp

If it illuminates when you are
driving, this indicates a
malfunction. You will continue
to have normal braking (without ABS).
Have the system checked by a properly
trained technician as soon as possible.

Vehicle immobilizer indicator

The immobilizer indicator will
blink if the key is removed from
the ignition or a wrong key is
inserted.

Brake system warning lamp

It illuminates when the parking
brake is engaged.
WARNING
Reduce your speed gradually and
stop your vehicle as soon as it is safe
to do so. Use your brakes with care.
Ranger (TKE) Vehicles Built From: 01-10-2014, DB39120609AD (CG3575en) enGBR, Edition date: 09/2014, First Printing
Instrument Cluster
If it illuminates when you are driving, check
that the parking brake is not engaged. If
the parking brake is not engaged, this
indicates a malfunction. Have the system
checked by a properly trained technician
immediately.

Ignition warning lamp

equipment. Have your vehicle checked by
an authorised dealer immediately.

Airbag warning lamp

Low fuel level warning lamp

The arrow adjacent to the fuel pump
symbol tells you on which side of your
vehicle the fuel filler cap is located.

Stability control (ESP) indicator

does not illuminate or illuminates
continuously while driving, this indicates a
malfunction. During a malfunction, the
system switches off. Have the system
checked by a properly trained technician
as soon as possible.
lamp will go out when you switch the
system back on or when you switch the
ignition off.
54
If it illuminates when driving, this
indicates a malfunction. Switch
off all unnecessary electrical
If it illuminates while driving, this
indicates a malfunction. Have
this checked as soon as possible.
If the low fuel level warning lamp
comes on, refuel as soon as
possible.
While driving, it flashes during
activation of the system. After
switching on the ignition, if it
If you switch ESP off, the
warning lamp will flash twice
and remain illuminated. The
