- Page 1 CS 2260WH CS 2260 CS 2258 Operator ′ ′ ′ ′ s manual English Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
-
Page 2: Key To Symbols
KEY TO SYMBOLS Symbols on the machine: Chain oil fill. WARNING! Chain saws can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. Adjustment of the oil pump. Please read the operator’s manual carefully and make sure you understand the instructions before using the If your machine bears this symbol it... -
Page 3: Symbols In The Operator's Manual
KEY TO SYMBOLS Symbols in the operator’s manual: Switch off the engine by moving the stop switch to the STOP position before carrying out any checks or maintenance. CAUTION! The start/ stop switch automatically returns to run position. In order to prevent unintentional starting, the spark plug cap must be removed from the spark plug when assembling, checking... -
Page 4: Table Of Contents
CONTENTS Contents TECHNICAL DATA Technical data ............37 KEY TO SYMBOLS Guide bar and chain combinations ....... 38 Symbols on the machine: ........2 Saw chain filing and file gauges ......38 Symbols in the operator’s manual: ......3 EC-declaration of conformity ......... 39 CONTENTS Contents ............... -
Page 5: Introduction
If you will sell this machine, make sure that the buyer will get the operator ′ s manual. Good luck on using your Jonsered machine! Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice. English – 5... -
Page 6: What Is What
WHAT IS WHAT? What is what on the chain saw? Front handle 16 Decompression valve Cylinder cover 17 Switch for heated handle (CS 2260WH) Air purge 18 Throttle lockout Rear handle 19 Right hand guard Information and warning decal 20 Throttle trigger... -
Page 7: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Before using a new chain saw WARNING! Never allow children to use or be in the vicinity of the machine. As the • Please read this manual carefully. machine is equipped with a spring- • Check that the cutting equipment is correctly fitted and loaded stop switch and can be started by adjusted. -
Page 8: Always Use Common Sense
GENERAL SAFETY PRECAUTIONS Always use common sense • Gloves with saw protection • Trousers with saw protection It is not possible to cover every conceivable situation you • Boots with saw protection, steel toe-cap and non-slip can face when using a chain saw. Always exercise care sole and use your common sense. - Page 9 GENERAL SAFETY PRECAUTIONS Take care when using your saw and make sure the • To release the chain brake pull the front hand guard kickback zone of the bar never touches any object. backwards, towards the front handle. • The chain brake (A) can either be activated manually •...
-
Page 10: Chain Catcher
GENERAL SAFETY PRECAUTIONS of the front hand guard, the chain brake can only be control (B). When you release the handle the throttle activated by the inertia action. control and the throttle lockout both move back to their original positions. This arrangement means that the throttle control is automatically locked at the idle setting. -
Page 11: Cutting Equipment
GENERAL SAFETY PRECAUTIONS WARNING! Overexposure to vibration CAUTION! The muffler gets very hot during and after can lead to circulatory damage or nerve use. This also applies during idling. Be aware of the fire damage in people who have impaired hazard, especially when working near flammable circulation. - Page 12 GENERAL SAFETY PRECAUTIONS Cutting equipment designed to reduce • Chain pitch (inches). The spacing between the drive links of the chain must match the spacing of the teeth kickback on the bar tip sprocket and drive sprocket. WARNING! Faulty cutting equipment or the wrong combination of bar and saw chain increases the risk of kickback! Only use the bar/saw chain combinations...
-
Page 13: Sharpening Your Chain And Adjusting Depth Gauge Setting
GENERAL SAFETY PRECAUTIONS Sharpening your chain and adjusting Sharpening cutting teeth depth gauge setting General information on sharpening cutting teeth • Never use a blunt chain. When the chain is blunt you To sharpen cutting teeth you will need a round file and a have to exert more pressure to force the bar through file gauge. -
Page 14: Tensioning The Chain
GENERAL SAFETY PRECAUTIONS Tension the chain as tightly as possible, but not so tight WARNING! The risk of kickback is that you cannot pull it round freely by hand. increased if the depth gauge setting is too large! Adjustment of depth gauge setting •... - Page 15 GENERAL SAFETY PRECAUTIONS Never use waste oil! Using waste oil can be dangerous • Check that the bar tip sprocket turns freely and that to you and damage the machine and environment. the lubricating hole in the tip sprocket is not blocked. Clean and lubricate if necessary.
- Page 16 GENERAL SAFETY PRECAUTIONS We recommend you compare the existing chain with a WARNING! Most chain saw accidents new chain to decide how badly the existing chain is worn. happen when the chain touches the When the length of the cutting teeth has worn down to operator.
-
Page 17: Assembly
ASSEMBLY Fitting the bar and chain underside of the bar. See instructions under the heading Tensioning the chain. WARNING! Always wear gloves, when working with the chain. Check that the chain brake is in disengaged position by The chain is correctly tensioned when it does not sag from moving the front hand guard towards the front handle. -
Page 18: Fuel Handling Fuel
When working with continuous high revs (e.g. limbing) good adhesion characteristics. a higher octane is recommended. Environment fuel JONSERED recommends the use of alkylate fuel, either Aspen two-stroke fuel or environmental fuel for four-stroke engines blended with two-stroke oil as set out below. Running-in Avoid running at a too high speed for extended periods during the first 10 hours. -
Page 19: Fueling
FUEL HANDLING Fueling Fuel safety • Never refuel the machine while the engine is running. • Make sure there is plenty of ventilation when refuelling or mixing fuel (petrol and 2-stroke oil). • Move the machine at least 3 m from the refuelling point before starting it. -
Page 20: Starting And Stopping
STARTING AND STOPPING Starting and stopping Push down the red choke control as soon as the engine fires which can be heard through a "puff" sound. Keep on pulling the cord powerfully until the engine starts. WARNING! Note the following before starting: Warm engine Start position (1): Set the start/stop switch in the choke... -
Page 21: Starting And Stopping
STARTING AND STOPPING should use this grip. Use a firm grip with thumbs and WARNING! Long term inhalation of the fingers encircling the chain saw handles. engine’s exhaust fumes, chain oil mist and dust from sawdust can represent a health risk. •... -
Page 22: Working Techniques
WORKING TECHNIQUES Before use: • To ensure that people, animals or other things cannot affect your control of the machine. • To make sure that none of the above might come within reach of your saw or be injured by falling trees. CAUTION! Follow the instructions above, but do not use a chain saw in a situation where you cannot call for help in case of an accident. - Page 23 WORKING TECHNIQUES right-handed or left-handed. This grip minimises the You must have a steady stance in order to have full effect of kickback and lets you keep the chain saw control over the chain saw. Never work standing on a under control.
-
Page 24: Basic Cutting Technique
WORKING TECHNIQUES chain use only combinations that are recommended Is there a risk of kickback? by us. See instructions under the headings Cutting equipment and Technical data. Basic cutting technique WARNING! Never use a chain saw by holding it with one hand. A chain saw is Do the conditions and surrounding terrain affect how not safely controlled with one hand. -
Page 25: Tree Felling Technique
WORKING TECHNIQUES inadvertently getting a kickback, as well as increasing the Start by cutting from above (about 1/3 of the way through). risk of losing your balance while working. Finish by cutting from below so that the two cuts meet. Tree felling technique The log is lying on the ground. - Page 26 WORKING TECHNIQUES there is high accident risk. See instructions under the further forward in the terrain, where you would like the tree heading Freeing a tree that has fallen badly. to fall (2). Stand on the right-hand side of the tree, behind the saw, and cut with a pull stroke.
-
Page 27: Freeing A Tree That Has Fallen Badly
WORKING TECHNIQUES Finish the felling cut parallel with the directional cut line so Freeing a tree that has fallen badly that the distance between them is at least 1/10 of the Freeing a ”trapped tree” trunk diameter. The uncut section of the trunk is called the felling hinge. -
Page 28: How To Avoid Kickback
WORKING TECHNIQUES Continue to cut deeper until tree/limb bends and tension Kickback only occurs if the kickback zone of the bar is released. touches an object. Cut tree/limb from outside the bend, after tension has been released. Limbing How to avoid kickback WARNING! A majority of kickback accidents occur during limbing. -
Page 29: Maintenance
Carburettor adjustment demands special training. This is especially true of the machine’s safety equipment. If your machine fails any of Your Jonsered product has been designed and the checks described below we recommend that you manufactured to specifications that reduce harmful take it to your service workshop. -
Page 30: Throttle Lockout
MAINTENANCE Checking the inertia brake release Throttle lockout Place the chain saw, with the engine switched off, on a • Make sure the throttle control is locked at the idle stump or other stable surface. Release the front handle setting when the throttle lockout is released. and let the saw fall by its own weight, rotating around the rear handle towards the stump. -
Page 31: Muffler
MAINTENANCE Vibration damping system Regularly check that the muffler is securely attached to the machine. Regularly check the vibration damping units for cracks or deformation. Make sure the vibration damping units are securely attached to the engine unit and handle unit. Some mufflers are equipped with a special spark arrestor mesh. -
Page 32: Starter
MAINTENANCE Starter handle. Make a secure knot in the end of the starter cord. WARNING! When the recoil spring is wound up in the starter housing it is under tension and can, if handled carelessly, pop out and cause personal injury. -
Page 33: Air Filter
Lay the saw on its side with the clutch drum upwards. A JONSERED chain saw can be equipped with different types of air filter according to working conditions, weather, season, etc. Contact your dealer for advice. -
Page 34: Adjustment Of The Oil Pump
MAINTENANCE Lubrication involves grease being squirted into the centre Cylinder cover (directs cold air over the cylinder). of the crankshaft using a grease gun. Adjustment of the oil pump. Clean the cooling system with a brush once a week, more often in demanding conditions. -
Page 35: Heated Handles
MAINTENANCE Temperature 0° ° ° ° C or colder: Heated handles CS 2260WH On models with the model code WH, both the front handle bar and the rear handle are equipped with electrical heating coils. These are supplied with electricity from a The intermediate wall is designed so it can be adjusted for generator built into the chain saw. -
Page 36: Maintenance Schedule
MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. Daily maintenance Weekly maintenance Monthly maintenance Check the brake band on the chain On chain saws without a catalytic brake for wear. -
Page 37: Technical Data
TECHNICAL DATA Technical data CS 2258 CS 2260 CS 2260WH Engine Cylinder displacement, cm 59,8 59,8 59,8 Cylinder bore, mm Stroke, mm Idle speed, rpm 2800 2800 2800 Power, kW/ rpm 3,1/9600 3,5/9600 3,5/9600 Ignition system Spark plug NGK CMR6H... -
Page 38: Guide Bar And Chain Combinations
TECHNICAL DATA Guide bar and saw chain combinations The following cutting attachments are approved for the models Jonsered CS 2258, CS 2260 and CS 2260WH. Guide bar Saw chain Max. nose Length, drive Length, inch Pitch, inch Gauge, mm Type radius links (no.) -
Page 39: Contents Ec-Declaration Of Conformity
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares under sole responsibility that the chain saws for forest service Jonsered CS 2258, CS 2260 and CS 2260WH from 2011’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), are in conformity with the requirements of the COUNCIL’S DIRECTIVES:... - Page 44 Original instructions 1154275-26 ´®z+V;T¶6"¨ ´®z+V;T¶6"¨ 2011-12-07...
