Installation Guide
2. Place the Access Point against the wall, ensuring the Access Point's Motorola Solutions "bat wings" logo
is in the correct orientation.
3. Mark the screw hole locations on a vertical axis using the ear's mounting holes.
4. At each point, drill a hole in the wall and insert the anchor.
NOTE
5. Place the Access Point on the anchor. Insert screws through the Access Point's mounting ears and into the
anchor.
6. If required, install and attach a Kensington security cable (customer supplied) to the unit's lock port.
7. Attach an Ethernet cable from the Access Point to a controller with an 802.3af-compatible power source
or use the PWRS-14000-148R power supply to supply power to the AP-6522E (once fully cabled).
8. Attach appropriate antennas to the connectors.
9. Attach an Ethernet cable from the Access Point to a controller with an 802.3af compatible power source.
10. Verify the Access Point is receiving power by observing that the LEDs are lit or flashing.
CAUTION

2.6.3 Wall Mount Procedure - Existing Access Point Replacement

An existing external antenna model AP300 (WSAP-5100-100) or external antenna model AP650 (AP-0650-660X0)
Access Point, installed on a wall (plenum installation), can be placed by an AP-6522E. Simply remove the existing
legacy model Access Point from its mounting screws, leave the mounting hardware in place and install the new
external antenna model AP-6522E directly on to the existing mounting hardware. The cabling procedure for such a
replacement is as described in the previous section.
When pre-drilling a hole the recommended hole size is 2.8mm (0.11in.).
If not using a 802.3af capable controller to power the AP-6522E,
ensure only the AP-6522E's designated power supply
(PWRS-14000-148R) is used to supply power to the Access Point.
Using an incorrectly rated power supply could damage the unit and
void the product warranty. Do not actually connect to the power
source until the cabling portion of the installation is complete.
15
