Hunter 44360 Set & $ave Installation And Operation Manual

Programmable thermostat
Hide thumbs
Table of Contents

Advertisement

Quick Links

Set & $ave
Programmable Thermostat
installation and
operation manual
Model 44360
42710-01 8-17-06

Advertisement

Table of Contents
loading

Related Manuals for Hunter 44360 Set & $ave

Summary of Contents for Hunter 44360 Set & $ave

  • Page 1 Set & $ave Programmable Thermostat installation and operation manual Model 44360 42710-01 8-17-06...
  • Page 3 Table of Contents Important Information..........5 Tools ................6 Uninstalling the Existing Unit ........7 Installing the Thermostat ........... 12 installing the wall plate ........12 connecting the wires ........16 attaching the thermostat ........18 Settings ..............22 Methods of Operation ..........26 manual operation ..........
  • Page 4 Please read this manual before beginning installation and save this booklet for complete operation instructions. The Hunter Technical Support Group is available from 7 am to 7 pm CST. They may be reached toll-free at 1-888-830-1326.

  • Page 5: Important Information

    important information This thermostat is designed to work on the following heating and cooling systems: Gas – Standing Pilot Gas – Electronic Ignition Gas – Fired Boilers Gas – Millivolt Systems Oil – Fired Boilers Oil – Fired Furnace Electric Furnace Electric Air Conditioning Single-Stage Heat Pumps This thermostat is not designed for multi-stage heat pump...
  • Page 6 tools This thermostat includes two #8 slotted screws and two wall anchors for mounting. To install your new thermostat, you will need the following supplies: Flat-head screwdriver ..................... Small Phillips-head screwdriver ..................... Hammer ..................... Electric drill and 3/16” bit ..................... Two 1.5 Volt (AA) size alkaline batteries .....................
  • Page 7 NOTICE! Do not disconnect the wires from the existing thermostat before reading these instructions. The wires must be labeled prior to removal to ensure proper reconnection.

  • Page 9: Uninstalling The Existing Unit

    uninstalling the existing unit 1. Turn the system power OFF from the existing thermostat. Turn the power to the HVAC system OFF at the main power panel or at the furnace. (Failure to turn off the power to the existing thermostat before removal could damage your system.) 2.

  • Page 10: Wire Labels

    wire labels if your existing label the wire thermostat is marked... with this sticker: RH / R / VR / 4 24 Volt RC / VC 24 Volt cool air conditioning Y / C* / M / O compressor W / H / B heating G / F heat pump...
  • Page 11 uninstalling the existing unit, cont. 4. Using the provided stickers, label each wire according to the Wire Labels chart. (If the terminals are not labeled, contact a qualified HVAC technician.) note: wire colors do not always comply with standards, so wire color should be ignored. refer to the existing terminal designation for proper identification.

  • Page 13: Installing The Thermostat

    2. Position the new wall plate on the wall and pull the labeled wires through the opening. 3. If the existing holes do not match those on the Hunter wall plate, or if there are no existing holes, visually level the wall...
  • Page 15 installing the thermostat, cont. 4. Remove the wall plate and drill two 3/16” holes where marked. 5. Tap the plastic anchors into the holes until they are flush with the wall. ( Do not use plastic anchors if you encounter a stud in the wall.) 6.
  • Page 16 G RC RH Y/0 W/B Y1 Terminal Shield...
  • Page 17 installing the thermostat, cont. CONNECTING THE WIRES 1. Loosen, but do not remove, the terminal screws. Jumper note: a jumper wire has been provided, connecting the rc G RC RH Y W and rh terminals for systems that do not provide both an rh and rc wire.
  • Page 18 Thermostat Cover ENABLE RECOVERY HEAT DISABLE System Switch SYSTEM TYPE Switch FAN OPTION W/B Y/O RH...
  • Page 19 installing the thermostat, cont. ATTACHING THE THERMOSTAT Lift the thermostat cover and set the switch to SYSTEM switch to AUTO 1. Fan option - Locate the switch on the back of the HE/HG thermostat. Set the switch to (default) for gas furnace and oil burners.
  • Page 20 front cover...
  • Page 21 installing the thermostat, cont. 4. Place the top of the thermostat over the two tabs on the wall plate. Press the thermostat onto the wall plate and press to snap the bottom tab into place. note: Do not force the thermostat onto the wall plate, as the terminal pins may be damaged.
  • Page 22 reset...
  • Page 23 settings The default setting of the thermostat is Fahrenheit (F (notice: changing this setting will reset the thermostat to factorY Default programs.) To change to Celsius (C 1. Press and hold the button. 2. Use a paperclip to press the button.
  • Page 24 program day/time...
  • Page 25 settings, cont. The default for this thermostat setting is in a 12 hour format. You can change the format to 24 hour format by pressing Day/ and then Time Program the am/pm indicator will be off when the thermostat is in 24 hour mode.
  • Page 26 HEAT...

  • Page 27: Methods Of Operation

    methoDs of operation This thermostat gives you the ability to program up to 4 custom temperature settings per day or utilize pre-programmed settings. For manual operation instructions, see pages 28-31. To utilize the pre-programmed settings, see pages 32-33. To create custom programs, see pages 34-37.
  • Page 28 HEAT...
  • Page 29 methoDs of operation, cont. 1. MANUAL OPERATION Many people prefer to operate their thermostats manually, adjusting settings as needed. You can either temporarily override the settings for the current program, or permanently override all settings and adjust temperatures manually. If you want to only override the current program: 1.
  • Page 30 HOLD system heat cool hold /return...
  • Page 31 methoDs of operation, cont. MANUAL OPERATION, CONT. If you want to permanently override all settings and adjust the thermostat manually: 1. Press until the Hold icon appears. Hold/Return 2. Press and hold for one second to enter Manual Down Override mode. (Release the button when the display flashes.) 3.

  • Page 32: Default Programs Chart

    Default programs chart 10 pm Program 4 Heat : 60 F (16 Cool : 82 F (28 Program 3 Heat : 68 F (20 Cool : 78 F (26 6 am Program 1 Heat : 68 F (20 Cool : 78 F (26 4 pm 8 am...
  • Page 33 methoDs of operation, cont. 2. DEFAULT PROGRAMS This thermostat meets ENERGY STAR guidelines for energy efficiency. By using the pre-programmed settings, this thermostat can save you money by optimizing energy usage in heating and cooling. Refer to the Default Programs Chart for detailed information about the pre-programmed settings.
  • Page 34 system heat program cool hold /return...
  • Page 35 methoDs of operation, cont. 3. CREATING CUSTOM PROGRAMS • Program times can be set in 10 minute increments. • Program temperature can be set in increments of 1 F (1 • After 15 seconds of inactivity during programming, the thermostat will return to Normal Display mode. •...
  • Page 36 T W TH F SA SU HEAT COOL system heat program cool hold /return...
  • Page 37 methoDs of operation, cont. 3. Press to change the hour. Press to save Down Program the hour and adjust the minute setting. 4. Press to change the minute. Press Down Program save the minute setting and adjust the temperature. 5. Press to change the temperature.
  • Page 38 FILTER filter...

  • Page 39: Icons And Features

    icons anD features 1. INDIGLO night-light - will backlight the display for easy ® viewing in the dark. Press any button to illuminate the light. (If no button is pressed after 5 seconds, the backlight will turn off.) note: if the thermostat shows a low battery warning, the backlight will not operate.
  • Page 40 HEAT COOL system heat cool reset...
  • Page 41 icons anD features, cont. 3. Span setting mode – allows you to adjust the system ON/OFF cycle rate. The default setting is 2 (the system cycles ON or OFF when the temperature is within 1 F (0.5 C) above and below the set temperature.) The span setting can be adjusted if your system is cycling too fast or too slowly.
  • Page 42 COOL STAGE 1 STAGE 2...
  • Page 43 icons anD features, cont. 4. Low battery warning – indicates two stages of battery power shortage. When the batteries are detected as weak, the icon will flash until new AA alkaline batteries are installed (Stage 1). If the batteries become too weak for normal operation, the thermostat enters the second battery power shortage mode (Stage 2).
  • Page 44 hold /return...
  • Page 45 icons anD features, cont. 5. Auto recovery – allows heating and cooling systems to gradually recover from an energy-saving setpoint temperature to a comfort setpoint temperature. Auto recovery calculates the time needed to adjust the temperature to the next program setting. When the thermostat is in Auto Recovery mode, the display will flash alternating messages of RECO and the time.
  • Page 47 icons anD features, cont. 6. Error mode – indicates an unexpected battery problem. The screen will flash an ERR message and shut your system off until the batteries are replaced with new AA alkaline batteries. You must Reset and reprogram the thermostat after replacing the batteries if the thermostat has entered Error mode.
  • Page 48 HOME TODAY...
  • Page 49 icons anD features, cont. 8. Home Today – overrides the programmed settings during a time you would not normally be home. Pressing Home Today during the first or second programs of the day will override the programs until the fourth program begins. The thermostat will then go back into Normal mode.
  • Page 50 Usage Today...
  • Page 51 icons anD features, cont. 9. Energy – calculates energy usage. Press to display the total operation time for heat and air conditioning for today, yesterday, last week, or Total. Monitoring energy usage allows you to optimize energy savings. Press to cycle through Today, Yesterday, This Week, Energy and Total (up to 999 hours and 59 minutes).

  • Page 52: Important Features

    important features 1. Temperature Range 99 o F 30 o F 45 o F 95 o F (37 o C) (7 o C) (35 o C) Out of Range Out of Range Program Range "LO" "HI" Display Range < 30 o F >...

  • Page 53: Troubleshooting

    troubleshooting 1. My display will not come on. 1 a. Check batteries and battery connections. 1 b. Reset the thermostat....................2. The auto fan feature will not operate properly. 2 a. Remove the thermostat from the wall plate and set the HG/HE switch to the correct position.
  • Page 54 troubleshooting 5. My heating or cooling will not turn on or off. 5 a. Check the Heat/Cool function switch to ensure it is set to the desired position. 5 b. Wait. There may be as much as a 4-minute delay before the system turns on or off to protect the compressor.
  • Page 55 troubleshooting 7. My system continues to operate when the thermostat is in the off position. 7 a. Replace unit. 7 b. Check your system for proper wiring....................8. The LCD screen permanently reads HI, LO, or ERR. 8 a. Replace unit....................
  • Page 56 Yes. Visit http://www.hunterfan.com for more information....................Can’t I just call someone? Sure. The Hunter Technical Support Group is available from 7 am to 7 pm CST M-F and 8 am to 5 pm Saturday. They may be reached toll-free at 1-888-830- 1326.
