Gryphon™ I GBT4130
General Purpose Handheld Linear Imager Barcode Reader
with B
® W
LUETOOTH
IRELESS
CORDLESS COMMUNICATIONS
Protocol - Bluetooth 2.0 Certified Class 2
Radio Frequency - 2.4 GHz
Radio Range (Open Air) - 30.0 m / 98.4 ft
DECODING CAPABILITY
1D / LINEAR CODES - Auto discriminates all standard 1D codes including
GS1 DataBar™ linear codes
BATTERY
Battery Type - Lithium-Ion, 2100 mAh
Full Charge Time – up to 22 Hours w/ USB Host Power from full discharge - 4 Hours w/ optional external power adapter
Reads per Full Charge - 33,000
As with other types of batteries, Lithium-Ion (LI) batteries will lose capacity over time. Capacity deterioration is noticeable after one
year of service whether the battery is in use or not. It is difficult to precisely predict the finite life of a LI battery, but cell
manufacturers rate them at 500 charge cycles. In other words, the batteries should be expected to take 500 full discharge / charge
cycles before needing replacement. This number is higher if partial discharging / recharging is adhered to rather than full / deep
discharging.
The typical manufacturer advertised useful life of LI batteries is one to three years, depending on usage and number of charges, etc.,
after which they should be removed from service, especially in mission critical applications. Do not continue to use a battery that is
showing excessive loss of capacity, it should be properly recycled / disposed of and replaced. For most applications, batteries should
be replaced after one year of service to maintain customer satisfaction and minimize safety concerns.
CRADLE INDICATOR LEDS
Battery Charging (Red) - Charge Completed (Green) - Power/Data (Yellow)
WARRANTY
3-Year Factory Warranty (Scanner & Base only – battery & cable 90 days) – www.scanning.datalogic.com
DATALOGIC WEBSITE SUPPORT
The Datalogic website is the complete source for technical support and information for Datalogic products. The site offers
product support, registration, warranty information, product manuals, product tech notes, software updates, demos and
instructions for returning products for repair.
TELEPHONE & TECHNICAL SUPPORT
If you do not have internet or email access, you may contact Datalogic technical support at (541)349-8283 or check the back
cover of your manual for more contact information.
UNPACKING
Check carefully to ensure the Reader, Base, Cable, Mounting Accessories and Quick Reference Guide are present and
undamaged. If any damage has occurred in shipment or if items appear to be missing, contact Technical Support
immediately. This unit does not need nor does it ship with a power adapter. The Lithium Ion battery is factory installed.
Should the unit require service, it must be returned in its original shipping container with all its original contents.
PDS Tech Support 800.286.8929 option 2
T
ECHNOLOGY
Datalogic Scanning, Inc. - USA
959 Terry Street
Eugene, OR 97402
(541) 683-5700
KEEP THE PACKAGING
Datalogic Tech Support 541.349.8283
Page 1 of 8
