  • Page 1: Product Reference Guide

    Gryphon™ I GD44XX/GBT4400 General Purpose Handheld Area Imager Bar Code Reader Product Reference Guide ...
  • Page 2 Should future revisions of this manual be published, you can acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the Datalogic website (www.scanning.data- logic.com) or provided on appropriate media.

  • Page 3: Table Of Contents

    About this Manual ......................................9 Overview ..................................................9 Manual Conventions ............................................10 References ........................................10 Technical Support ......................................10 Datalogic Website Support ..........................................10 Reseller Technical Support ..........................................10 Telephone Technical Support ..........................................10 About the Reader ......................................11 The BC40xx™ Radio Base ..................................... 12 Base LEDs .................................................12...
  • Page 4 Contents ACK NAK Timeout Value .......................................49 ACK NAK Retry Count ........................................49 ACK NAK Error Handling .......................................50 Indicate Transmission Failure .....................................50 Disable Character ..........................................51 Enable Character ..........................................51 Keyboard SETTINGS ................................53 Country Mode ..........................................54 Send Control Characters ......................................56 Wedge Quiet Interval ........................................57 Intercode Delay ..........................................57 Caps Lock State ..........................................58 Numlock .............................................58...
  • Page 5 Contents Aiming Pointer ..........................................99 Aiming Duration Timer ......................................100 Green Spot Duration ........................................100 Mobile Phone Mode ........................................101 Partial Label Reading Control ....................................101 Decode Negative Image ......................................102 Image Capture ..........................................102 MULTIPLE LABEL READING ..............................103 Multiple Labels per Frame ......................................103 Multiple Labels Ordering by Code Symbology ..............................
  • Page 6 Contents CODE 32 (ITAL PHARMACEUTICAL CODE) ..........................134 Code 32 Enable/Disable ......................................134 Code 32 Feature Setting Exceptions ..................................135 Code 32 Check Char Transmission ..................................135 Code 32 Start/Stop Character Transmission ..............................135 CODE 39 CIP (FRENCH PHARMACEUTICAL) ..........................136 Code 39 CIP Enable/Disable ..................................... 136 CODE 39 DANISH PPT ................................136 Code 39 Danish PPT Enable/Disable ..................................
  • Page 7 Contents Codabar Check Character Calculation .................................. 163 Codabar Check Character Transmission ................................164 Codabar Start/Stop Character Transmission ..............................164 Codabar Start/Stop Character Set ..................................165 Codabar Start/Stop Character Match ................................... 165 Codabar Quiet Zones ........................................166 Codabar Length Control ......................................166 Codabar Set Length 1 .........................................
  • Page 8 Contents 2D Normal/Inverse Symbol Control ......................................199 Aztec Code ........................................200 Aztec Code Enable / Disable .......................................... 200 Aztec Code Multiframe ............................................ 200 Aztec Code Length Control ........................................... 201 Aztec Code Set Length 1 ......................................201 Aztec Code Set Length 2 ......................................202 China Sensible Code ....................................203 China Sensible Code Enable / Disable .......................................
  • Page 9 Contents Automatic Configuration Update ..................................235 Copy Configuration to Scanner ....................................235 Copy Configuration to Base Station ..................................235 BATCH FEATURES ..................................236 Batch Mode ............................................ 236 Send Batch ............................................236 Erase Batch Memory ........................................237 RF Batch Mode Transmit Delay ....................................237 ACK TIMEOUT ....................................238 RF ADDRESS STAMPING ................................238 Source Radio Address Transmission ..................................
  • Page 10 Contents Error Codes ........................................288 Base Station Indications (GBT4400 Models ONLY) ..........................289 STANDARD DEFAULTS ................................291 Sample Barcodes ..................................303 KEYPAD ......................................307 SCANCODE TABLES ..................................309 Control Character Emulation ..................................309 Single Press and Release Keys ........................................309 Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE ....................310 Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode ......................312 Digital Interface ......................................314 IBM31xx 102-key ......................................315...

  • Page 11: Introduction

    Chapter 1 Introduction About this Manual This Product Reference Guide (PRG) is provided for users seeking advanced technical information, including connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other publications associated with this product are downloadable free of charge from the website listed on the back cover of this manual. Overview Chapter 1, (this chapter) presents information about manual conventions, and an overview of...

  • Page 12: Manual Conventions

    Telephone Technical Support If you do not have internet or email access, you may contact Datalogic technical support at (541) 349-8283 or check the back cover of your manual for more contact information. Gryphon™ I GD44XX/GBT4400...

  • Page 13: About This Manual

    - Model with Bluetooth options. Programming can alternatively be performed using the Datalogic Aladdin™ Configuration application which is downloadable from the Datalogic website listed on the back cover of this manual. This multi-platform utility program allows device configuration using a PC. It communicates to the device using a serial or USB cable and can also create configuration bar codes to print.

  • Page 14: Datalogic Website Support

    Beeper Indicators on page 88). The button can also be used to "force device connection" via the Datalogic Aladdin Software tool (available for free download from the Datalogic website). See the Aladdin Online Help for details. For the BT model, press quickly (less than one second) to initiate paging. Press and hold (longer than one second) to enable radio linking.

  • Page 15: Battery Safety

    To reinstall, charge and/or perform any other action on the battery, follow the instructions in this manual. Before installing the Battery, read “Battery Safety” on this and the following pages. Datalogic rec- ommends annual replacement of rechargeable battery packs to ensure maximum performance.

  • Page 16: Programming The Reader

    Datalogic Aladdin™ is a multi-platform utility program providing a quick and user-friendly configuration method via the RS-232/USB-COM interface. Aladdin is available on the CD- ROM provided with your product, and also from the Datalogic website. Aladdin allows you to program the reader by selecting configuration commands through a user-friendly graphical interface running on a PC.

  • Page 17: Setup

    Setup Unpacking Check carefully to ensure the reader and any accessories ordered are present and undamaged. If any damage occurred during shipment, contact Datalogic Technical Support. Information is shown on page KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping container.
  • Page 18 Setup Installing the Interface Cable For Corded versions, connect the reader cable by inserting the cable into the handle as shown in Figure 2. To remove it, insert a paper clip into the release aperture, then unplug the cable. Figure 2. Connect/disconnect the cable RS-232 Serial Connection Turn off power to the terminal/PC and connect the reader to the terminal/PC serial port via the RS-232 cable as shown in Figure 3.
  • Page 19 Installing the Interface Cable Keyboard Wedge Connection The Keyboard Wedge cable has a ‘Y’ connection from the reader. Connect the female to the male end from the keyboard and the remaining end at the keyboard port at the terminal/PC. Reference Figure 4. Figure 4.

  • Page 20: Installing The Interface Cable

    Setup Figure 6. Other Interface Connections or... or... Specific cables are required for connection to different hosts. The connec- tors illustrated above are examples only. Actual connectors may vary from those illustrated, but the steps to connect the reader remain the same. RF Models The power supply connects directly to the base (not on the cable's jack) for all configurations.

  • Page 21: Changing The Base Station Position

    Configuring the Base Station Changing the Base Station Position The base station is configured by installing one of two sets of mechanical parts that come with the cordless kit. The default mounts (shown below) provide three options: vertical (wall) mounting, standing (45°), or horizontal mounting with a higher mechanical retention of the scanner.

  • Page 22: Configuring The Base Station

    Setup 3. The stand can now be repositioned in either horizontal or standing position. Horizontal Standing Connecting the Base Station Figure 7 shows how to connect the Base Station to a terminal, PC or other host device. Turn off the host before connection and consult the manual for that equipment (if necessary) before proceeding.
  • Page 23 Configuring the Base Station Figure 7. Connecting the Base Station Wall plug Connector I/F Cable AC/DC Adapter DC Power Cord Base Station Securing the DC Power Cord (Optional) The DC power cord for the adapter can be secured to the bottom of the base in order to maximize the mechanical retention of the cable itself.

  • Page 24: Connecting The Base Station

    Setup Figure 9. Arrows showing routing Host Connection: Verify before connection that the reader’s cable type is compatible with your host equipment. Most connections plug directly into the host device as shown in Figure 10. Keyboard Wedge interface cables have a ‘Y’ connection where its female end mates with the male end of the cable from the keyboard and the remaining end at the keyboard port on the terminal/PC.

  • Page 25: Connecting The Base When Security Pin Is Enabled

    4. Power up the host. The reader will link to the Base 5. When the host completely powers up, a new custom Security Pin Code may be sent to the reader and Base, depending on host configuration. Contact Datalogic Technical Support for more information.

  • Page 26: Linking The Reader To A Base Station

    Setup Linking the Reader to a Base Station RF Devices For RF devices, before configuring the interface it is necessary to link the handheld with the base. To link the handheld and the base, press the trigger to wake it and place it on the base. If the reader was previously linked to another base, you must first scan the Unlink action command before re-linking to the new base.

  • Page 27: Stand Alone Layouts

    Configuring the Base Station Linking to a PC in Client Mode (BT Master Mode) The reader can optionally be linked in client mode to a Bluetooth-enabled PC with the serial port profile. To do this, follow these steps: 1. Ensure the PC or terminal can network with Bluetooth devices and that it is powered on. 2.
  • Page 28 Setup Figure 13. Multiple Reader Layout Wireless models only (not valid for BT model) In stand alone systems, each base station is connected to a single Host. Figure 14. Multiple Stand Alone Layouts Mobile models only (not valid for BT model) Many stand alone connections can operate in the same physical area without interference, provided all readers and base stations in the system have different addresses.

  • Page 29: Interface Selection

    Interface Selection Interface Selection Upon completing the physical connection between the reader and its host, proceed to Table 1 starting on page 28 to select the interface type the reader is connected to (for example: RS-232, Keyboard Wedge, USB, etc.). Scan the appropriate bar code in that section to configure your system’s correct interface type.
  • Page 30 63 IBM-46xx Port 9B reader interface Select IBM-P9B USB-OEM FEATURES Set USB-OEM $P,HA45,P(CR) Interface USB-OEM Features (can be used for OPOS/UPOS/JavaPOS) starting on page 61 Select USB-OEM a. Download the correct USB Com driver from www.datalogic.com Gryphon™ I GD44XX/GBT4400...

  • Page 31: Interface Selection

    Interface Selection KEYBOARD FEATURES $P,HA2B,P(CR) USB Keyboard with alternate key encoding Select USB Alternate Keyboard $P,HA29,P(CR) AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding Select KBD-AT $P,HA11,P(CR) Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard Select KBD-AT-NK...
  • Page 32 Setup KEYBOARD — cont. FEATURES $P,HA15,P(CR) Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make only key- board Select KBD-IBM-M $P,HA16,P(CR) Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make break key- board Select KBD-IBM-MB Set KEYBOARD $P,HA1B,P(CR) WEDGE Keyboard Wedge for DIGITAL Termi- Interface...

  • Page 33: Customizing Configuration Settings

    Customizing Configuration Settings Customizing Configuration Settings Configure Interface Settings If after scanning the interface bar code from the previous table, your installation requires you to select options to further customize your reader, turn to the appropriate section for your interface type in "Configuration Parameters"...

  • Page 34: Resetting The Product Configuration To Defaults

    Setup Resetting the Product Configuration to Defaults Restore Custom Defaults If you aren’t sure what programming options are in your imager, or you’ve changed some options and want to restore the Custom Default Configuration that may have been saved in the scanner, scan the Restore Custom Default Configuration bar code below.

  • Page 35: Customizing Configuration Settings

    Replacing the Battery "Battery Safety" starting on page 13 Before replacing the Battery, read . Datalogic recommends annual replacement of rechargeable battery packs to ensure maximum performance. To change the battery of your reader, complete the following instructions. 1. With a screwdriver, unscrew the battery cover screw.
  • Page 36 Setup 4. Remove the old battery from its place (if present), and insert the new battery in the same position. 5. Replace the battery holder and three screws, plug in the connector, and return the contacts circuit to its previous location. When inserting the new battery into the handle, take care to position the battery and the connector as shown.

  • Page 37: Configuration Using Bar Codes

    Chapter 3 Configuration Using Bar Codes This and following sections provide programming bar codes to configure your reader by changing the default settings. For details about additional methods of programming, see "Configuration Methods" on page You must first enable your reader to read bar codes in order to use this Setup, starting on page 15 section.
  • Page 38 Enter/Exit Programming Mode To program features: 1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each pro- gramming page, when applicable. 2. Scan the bar code to set the desired programming feature. You may need to cover unused bar codes on the page, and possibly the facing page, to ensure that the reader reads only the bar code you intend to scan.

  • Page 39: Global Interface Features

    Enter/Exit Programming Mode GLOBAL INTERFACE FEATURES The following interface features are configurable by all interface types. Host Commands — Obey/Ignore This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will ignore all host commands except for those necessary for: •...
  • Page 40 Enter/Exit Programming Mode NOTES Gryphon™ I GD44XX/GBT4400...

  • Page 41: Rs-232 Only Interface

    RS-232 ONLY INTERFACE on page 40 on page 41 on page 41 ARITY on page 42 ANDSHAKING ONTROL on page 43 Use the programming bar codes in this section if modifications to the standard RS-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in the next section, "RS-232/USB-Com Interfaces"...
  • Page 42 Enter/Exit Programming Mode Baud Rate page 247 for information on this feature. $CR2BA00(CR) Baud Rate = 1200 $CR2BA01(CR) Baud Rate = 2400 $CR2BA02(CR) Baud Rate = 4800 $CR2BA03(CR) DEFAULT Baud Rate = 9600 $CR2BA04(CR) Baud Rate = 19,200 $CR2BA05(CR) Baud Rate = 38,400 $CR2BA06(CR) Baud Rate = 57,600 $CR2BA07(CR)
  • Page 43 Enter/Exit Programming Mode Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data. $CR2DA00(CR) 7 Data Bits $CR2DA01(CR) DEFAULT 8 Data Bits Stop Bits Set the number of stop bits to match host device requirements. See page 247 for more information on this feature.
  • Page 44 Enter/Exit Programming Mode Parity This feature specifies parity required for sending and receiving data. Select the parity type according to host device requirements. See page 247 for more information. $CR2PA00(CR) DEFAULT Parity = None $CR2PA01(CR) Parity = Even $CR2PA02(CR) Parity = Odd Gryphon™...

  • Page 45: Handshaking Control

    Enter/Exit Programming Mode Handshaking Control page 248 for more information about this feature. $CR2HC00(CR) DEFAULT Handshaking Control = RTS $CR2HC01(CR) Handshaking Control = RTS/CTS $CR2HC02(CR) Handshaking Control = RTS/XON/XOFF $CR2HC03(CR) Handshaking Control = RTS On/CTS $CR2HC04(CR) Handshaking Control = RTS/CTS Scan Control Product Reference Guide...

  • Page 46: Rs-232/Usb-Com Interfaces

    RS-232/USB-COM INTERFACES NTERCHARACTER ELAY on page 45 ASCII BEL on page 46 OT ON on page 46 ACK NAK O PTIONS on page 47 ACK C HARACTER on page 48 NAK C HARACTER on page 48 ACK NAK T IMEOUT ALUE on page 49 ACK NAK R...

  • Page 47: Intercharacter Delay

    Enter/Exit Programming Mode Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. page 257 for more information.
  • Page 48 Enter/Exit Programming Mode Beep On ASCII BEL When this parameter is enabled, the reader issues a beep when a <BEL> character is detected on the RS-232 serial line. <BEL> is issued to gain a user's attention to an illegal entry or other important event.
  • Page 49 Enter/Exit Programming Mode ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol.  page 249 for more information. $CR2AE00(CR) DEFAULT ACK/NAK Protocol = Disable ACK/NAK $CR2AE01(CR) ACK/NAK Protocol = Enable for label transmission $CR2AE02(CR) ACK/NAK Protocol = Enable for host-command acknowledge...

  • Page 50: Ack Character

    Enter/Exit Programming Mode ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See page 250 for more information. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.

  • Page 51: Ack Nak Options

    Enter/Exit Programming Mode ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. page 252 for more information on setting this feature.

  • Page 52: Ack Nak Error Handling

    Enter/Exit Programming Mode ACK NAK Error Handling This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK character from the host. $CR2EH00(CR) DEFAULT ACK NAK Error Handling = Ignore Errors Detected $CR2EH01(CR) ACK NAK Error Handling = Process Error as Valid ACK Character $CR2EH02(CR)

  • Page 53: Disable Character

    Enter/Exit Programming Mode Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
  • Page 54 Enter/Exit Programming Mode NOTES Gryphon™ I GD44XX/GBT4400...

  • Page 55: Keyboard Settings

    KEYBOARD SETTINGS OUNTRY on page 54 ONTROL HARACTERS on page 56 EDGE UIET NTERVAL on page 57 NTERCODE ELAY on page 57 TATE on page 58 UMLOCK on page 59 USB K EYBOARD PEED on page 59 USB K EYBOARD UMERIC EYPAD on page 61...

  • Page 56: Country Mode

    Enter/Exit Programming Mode Country Mode This feature specifies the country/language supported by the keyboard. Several languages are supported: $CKBCO00(CR) DEFAULT Country Mode = U.S. $CKBCO01(CR) Country Mode = Belgium $CKBCO02(CR) Country Mode = Britain $CKBCO03(CR) Supports only the interfaces listed in the Country Mode feature description.
  • Page 57 Enter/Exit Programming Mode Country Mode (Continued) $CKBCO06(CR) Country Mode = Italy $CKBCO0C(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Japanese 106-key $CKBCO07(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Norway $CKBCO08(CR) Supports only the interfaces listed in the Country...

  • Page 58: Send Control Characters

    Enter/Exit Programming Mode Send Control Characters This feature Specifies how the reader transmits ASCII control characters to the host. Reference Appendix E, Scancode Tables for more information about control characters. Options are as follows: Control Character 00 : Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located from 0x80 to 0xA1.

  • Page 59: Wedge Quiet Interval

    Enter/Exit Programming Mode Wedge Quiet Interval Specifies amount of time to look for keyboard activity before scanner breaks keyboard connection in order to transmit data to host. The selectable range for this setting is 00 to 990 milliseconds (00-0x63 by 01) in increments of ten milliseconds. See page 256 in “References”...

  • Page 60: Caps Lock State

    Enter/Exit Programming Mode 00 = No Wedge Intercode Delay DEFAULT Caps Lock State This option specifies the format in which the reader sends character data. This does not apply when an alternate key encoding keyboard is selected. $CKBCL00(CR) DEFAULT Caps Lock State = Caps Lock OFF $CKBCL01(CR) Caps Lock State = Caps Lock ON $CKBCL02(CR)

  • Page 61: Usb Keyboard Speed

    Enter/Exit Programming Mode USB Keyboard Speed This option specifies the USB poll rate for a USB keyboard. This feature applies ONLY to the USB Keyboard interface. $CKBSP01(CR) DEFAULT USB Keyboard Speed = 1ms $CKBSP02(CR) USB Keyboard Speed = 2ms $CKBSP03(CR) USB Keyboard Speed = 3ms $CKBSP04(CR) USB Keyboard Speed = 4ms...

  • Page 62: Usb Keyboard Numeric Keypad

    Enter/Exit Programming Mode USB Keyboard Speed — continued $CKBSP07(CR) USB Keyboard Speed = 7ms $CKBSP08(CR) USB Keyboard Speed = 8ms $CKBSP09(CR) USB Keyboard Speed = 9ms $CKBSP0A(CR) USB Keyboard Speed = 10ms USB Keyboard Numeric Keypad This option Controls whether numeric characters will be sent using standard keys or the numeric keypad.
  • Page 63 Product Reference Guide...
  • Page 64 Gryphon™ I GD44XX/GBT4400...

  • Page 65: Usb-Oem Interface

    USB-OEM INTERFACE USB-OEM D EVICE SAGE on page 62 NTERFACE PTIONS on page 62 Feature settings for USB interfaces differ depending upon which host type the reader will be connected with. Use the feature settings in this chapter and "IBM 46XX Interface" on page 63 to specifically configure for the USB-OEM interface.

  • Page 66: Usb-Oem Device Usage

    Enter/Exit Programming Mode USB-OEM Device Usage The USB-OEM protocol allows for the reader to be identified as one of two different types of barcode scanners. Depending on what other scanners you may already have connected to a USB-OEM POS, you may need to change this setting to enable all devices to communicate. Options are: •...

  • Page 67: Ibm 46Xx Interface

    IBM 46XX INTERFACE UMBER OF ESETS on page 64 39 F RANSMIT ABELS IN ORMAT on page 66 NTERFACE PTIONS on page 66 Use the bar codes in this section to configure programmable features for available IBM 46XX interfaces. Reference Appendix B, for a listing of standard factory settings.

  • Page 68: 46Xx Number Of Host Resets

    Enter/Exit Programming Mode 46xx Number of Host Resets Specifies how many consecutive resets are processed before the reader starts a five-second period to allow the user to enter Programming Mode and configure the reader. The configurable range for this feature is 1 to 15 resets. $CIBHR01(CR) 46xx Number of Host Resets = 1 $CIBHR02(CR)
  • Page 69 Enter/Exit Programming Mode 46xx Number of Host Resets — cont. $CIBHR08(CR) 46xx Number of Host Resets = 8 $CIBHR09(CR) 46xx Number of Host Resets = 9 $CIBHR0A(CR) 46xx Number of Host Resets = 10 $CIBHR0B(CR) 46xx Number of Host Resets = 11 $CIBHR0C(CR) 46xx Number of Host Resets = 12 $CIBHR0D(CR)

  • Page 70: Transmit Labels In Code 39 Format

    Enter/Exit Programming Mode Transmit Labels in Code 39 Format This feature enable/disables translation to Code 39 before transmitting label data to an IBM- 46XX or a USB-OEM host. Only the symbology identifier is modified for the translation. The data is not converted to Code 39 or verified to be valid for Code 39. Options are: IBM Standard Format: Send labels in standard IBM format.

  • Page 71: Wand Emulation Interface

    WAND EMULATION INTERFACE This feature is valid only for the GBT4400 model. IGNAL PEED on page 68 OLARITY on page 68 TATE on page 69 RANSMIT OISE on page 69 ABEL YMBOLOGY ONVERSION on page 70 This chapter provides feature/settings configuration for the Wand Emulation interface. Reference Appendix B, for a listing of standard factory settings.

  • Page 72: Wand Signal Speed

    Enter/Exit Programming Mode Wand Signal Speed This feature specifies the speed of the Wand output signal per nominal bar or space. Choices are: • 330 microseconds • 660 microseconds $CWASP00(CR) Wand Signal Speed = 330ms $CWASP01(CR) DEFAULT Wand Signal Speed = 660ms Wand Polarity This option specifies the polarity of the Wand output signal.

  • Page 73: Wand Idle State

    Enter/Exit Programming Mode Wand Idle State This feature specifies the level of the Wand output signal when the reader is idle. TTL logic levels: 0V <= Low <= 0.7V 2.4V <= High <= 5.25V $CWAID00(CR) Wand Idle State = Low $CWAID01(CR) DEFAULT Wand Idle State = High...

  • Page 74: Label Symbology Conversion

    Enter/Exit Programming Mode Label Symbology Conversion When this feature is enabled for the Wand Emulation interface, all bar code labels are converted to a single symbology. Options are: • No conversion • Convert to Code 39 symbology • Convert to Code 39 Full ASCII •...

  • Page 75: Data Format

    DATA FORMAT LOBAL REFIX UFFIX on page 72 AIM ID LOBAL on page 73 ABEL starting on page 76 • Label ID: Pre-Loaded Sets • Individually Set Label ID • Label ID Control • Label ID Symbology Selection • 1D Symbologies •...

  • Page 76: Global Prefix/Suffix

    Enter/Exit Programming Mode Global Prefix/Suffix Global Prefix/Suffix This option sets up to 20 characters each from the set of ASCII characters or any hex value from 00 to FF. The characters may be added as a prefix (in a position before the bar code data, also called a header) and/or as a suffix (in a position following the bar code data, also called a footer).

  • Page 77: Global Aim Id

    Global AIM ID Enter/Exit Programming Mode Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. See Table 2 on page 3-73 for a listing of AIM IDs.
  • Page 78 Enter/Exit Programming Mode Global AIM ID DATABAR EXPANDED COMPOSITE DATABAR LIMITED DATABAR LIMITED COMPOSITE DATA MATRIX EAN128 EAN128 COMPOSITE EAN13 EAN13 P2 EAN13 P5 EAN13 COMPOSITE EAN8 EAN8 P2 EAN8 P5 EAN8 COMPOSITE FOLLET 2OF5 I2OF5 IATA INDUSTRIAL 2OF5 INDUSTRIAL 2OF5 ISBN ISBT128 CONCAT ISSN...

  • Page 79: Set Aim Id Individually For Gs1-128

    Global AIM ID Enter/Exit Programming Mode Set AIM ID Individually for GS1-128 This feature configures a Label ID individually for the GS1-128 symbology and the programming for this works the same way as Label ID. See Label ID: Set Individually Per Symbology, starting on page 266 for detailed instructions on setting this feature.

  • Page 80: Label Id

    Enter/Exit Programming Mode Label ID Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01- 0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.

  • Page 81: Individually Set Label Id

    Label ID Enter/Exit Programming Mode Individually Set Label ID This feature configures a Label ID individually for a single symbology. See Label ID: Set Individually Per Symbology, starting on page 266 for detailed instructions on setting this feature. Label ID Control This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given symbology type.

  • Page 82: Label Id Symbology Selection − 1D Symbologies

    Enter/Exit Programming Mode Label ID Label ID Symbology Selection 1D Symbologies − This option selects the symbology for which a Label ID is to be configured. See "Label ID" on page 76 or page 263 in “References” for more detailed instructions. $CP3ID $CACID Set ABC Codabar Label ID Character(s)

  • Page 83: Label Id Symbology Selection − 1D Symbologies

    Label ID Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies $CXCID $C8BID Set EAN 8 Label ID Character(s) Set GS1 DataBar Expanded Composite Label ID Character(s) $C8MID $CU8ID Set EAN 8 Composite Label ID Character(s) Set GS1-128 Label ID Character(s) $CUMID $C82ID Set EAN 8 P2 Label ID Character(s)
  • Page 84 Enter/Exit Programming Mode Label ID Label ID Symbology Selection − 1D Symbologies $CLPID $CIAID Set IATA Industrial 2 of 5 Label ID Character(s) Set LaPoste Code 39 Label ID Character(s) $CPMID $CMSID Set IMB Postal Code Label ID Character(s) Set MSI Label ID Character(s) $CU2ID $CC7ID Set Industrial 2 of 5 Label ID Character(s)
  • Page 85 Label ID Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies $CPZID $CAMID Set PZN Code Label ID Character(s) Set UPC-A Composite Label ID Character(s) $CPRID $CA2ID Set Royal Postal Code Label ID Character(s) Set UPC-A P2 Label ID Character(s) $CS2ID $CA5ID Set Standard 2 of 5 Label ID Character(s)

  • Page 86: Label Id Symbology Selection

    Enter/Exit Programming Mode Label ID Label ID Symbology Selection 2D Symbologies − $CAZID $CMXID Set Aztec Label ID Character(s) Set Maxicode Label ID Character(s) $CCSID $CP4ID Set China Sensible Label ID Character(s) Set PDF 417 Label ID Character(s) $CCFID $CMIID Set Codablock F Label ID Character(s) Set Micro PDF 417 Label ID Character(s) $CDMID...

  • Page 87: Advanced Formatting: User Label Edit

    Label ID Enter/Exit Programming Mode Advanced Formatting: User Label Edit Advanced formatting is available to create user label edit scripts. See the Datalogic Aladdin configuration application or contact Technical Support. Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case.

  • Page 88: Character Conversion

    Enter/Exit Programming Mode Label ID Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done.

  • Page 89: Reading Parameters

    READING PARAMETERS OUBLE IMEOUT on page 86 CANNING CTIVE on page 97 EEPER NDICATORS on page 88 TAND LLUMINATION ONTROL on page 97 OWER LERT on page 88 LASH on page 98 HEN TO NDICATE on page 88 LASH on page 98 on page 89 IMING OINTER...

  • Page 90: Double Read Timeout

    Enter/Exit Programming Mode Double Read Timeout Double Read Timeout prevents a double read of the same label by setting the minimum time allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the specified timeout, the second read is ignored.
  • Page 91 Enter/Exit Programming Mode Double Read Timeout — continued $CSNDR50(CR) Double Read Timeout = 0.8 Second $CSNDR5A(CR) Double Read Timeout = 0.9 Second $CSNDR64(CR) Double Read Timeout = 1 Second Product Reference Guide...

  • Page 92: Led And Beeper Indicators

    Enter/Exit Programming Mode LED AND BEEPER INDICATORS Power On Alert Disables or enables the indication (from the Beeper) that the reader is receiving power. $CBPPU00(CR) Power On Alert = Disable (No Audible Indication) $CBPPU01(CR) DEFAULT Power On Alert = Four Beeps Good Read: When to Indicate This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a bar code.

  • Page 93: Good Read Beep Type

    Enter/Exit Programming Mode Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound. $CBPTY00(CR) DEFAULT Good Read Beep Type = Mono $CBPTY01(CR) Good Read Beep Type = Bitonal Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below.

  • Page 94: Good Read Beep Length

    Enter/Exit Programming Mode Good Read Beep Length $CBPLE06(CR) Good Read Beep Length = 60 msec $CBPLE08(CR) DEFAULT Good Read Beep Length = 80 msec $CBPLE0A(CR) Good Read Beep Length = 100 msec $CBPLE0C(CR) Good Read Beep Length = 120 msec $CBPLE0E(CR) Good Read Beep Length = 140 msec $CBPLE10(CR)

  • Page 95: Good Read Beep Volume

    Enter/Exit Programming Mode Good Read Beep Volume Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels. $CBPVO00CR) Good Read Beep Volume = Beeper Off $CBPVO01CR) Good Read Beep Volume = Low $CBPVO02CR) Good Read Beep Volume = Medium $CBPVO03CR) DEFAULT Good Read Beep Volume = High...

  • Page 96: Good Read Led Duration

    Enter/Exit Programming Mode Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 milliseconds (0.001 to 2.55 seconds) in 100ms increments.

  • Page 97: Scanning Features

    Enter/Exit Programming Mode SCANNING FEATURES Scan Mode Selects the reader’s scan operating mode. See page 271 in “References” for descriptions. $CSNRM00(CR) DEFAULT Scan Mode = Trigger Single $CSNRM01(CR) Scan Mode = Trigger Hold Multiple $CSNRM Scan Mode = Trigger Pulse Multiple $CSNRM03(CR Scan Mode = Flashing $CSNRM04(CR)

  • Page 98: Stand Operation

    Enter/Exit Programming Mode Stand Operation Specifies the behavior of the reader when stationary in a stand. There are two conditions which cause the reader to switch to Stand Mode: 1. The reader is configured to switch to Stand Mode when stationary. 2.

  • Page 99: Pick Mode

    Enter/Exit Programming Mode Pick Mode Specifies the ability of the reader to decode labels only when they are close to the center of the aiming pattern. This allows the reader to accurately target labels when they are placed close together, such as on a pick sheet. This feature is not compatible with Multiple Labels Reading in a Volume.

  • Page 100: High Motion Immunity

    Enter/Exit Programming Mode High Motion Immunity This option enables/disables the ability of the reader to activate immunity to label motion when in Stand Mode. $CMOSI00(CR) DEFAULT High Motion Immunity = Disable $CMOSI01(CR) High Motion Immunity = Enable Stand Mode Illumination Off Time Specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode.

  • Page 101: Scanning Active Time

    Enter/Exit Programming Mode Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. See page 273 in “References”...

  • Page 102: Flash On Time

    Enter/Exit Programming Mode Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See page 275 in “References” for detailed information on setting this feature. To configure this feature, scan the ENTER/EXIT PRO- $CSNFN GRAMMING MODE barcode above, then the barcode at...

  • Page 103: Aiming Pointer

    Enter/Exit Programming Mode Aiming Pointer Enables/disables the aiming pointer for all symbologies. $CTAAP00(CR) Aiming Pointer = Disable $CTAAP01(CR) DEFAULT Aiming Pointer = Enable Product Reference Guide...

  • Page 104: Aiming Duration Timer

    Enter/Exit Programming Mode Aiming Duration Timer Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode.The range for this setting is from 1 to 255 seconds in 1-second increments. See page 274 in “References”...

  • Page 105: Mobile Phone Mode

    Enter/Exit Programming Mode Mobile Phone Mode This mode is useful for scanning bar codes displayed on a mobile phone. Other options for this feature can be configured using the Datalogic Aladdin application. $CSNPE00(CR) Mobile Phone Mode = Disable $CSNPE01(CR) DEFAULT...

  • Page 106: Decode Negative Image

    Decode Negative Image = Disable $P,CIPVR01,P(CR) Decode Negative Image = Enable Image Capture For information and a list of options for Image Capture, use the Datalogic Aladdin configuration application, available for free download from the Datalogic Scanning website. Gryphon™ I GD44XX/GBT4400...

  • Page 107: Multiple Label Reading

    Enter/Exit Programming Mode MULTIPLE LABEL READING In standard (default) mode, when the reader’s aiming system is activated (by a trigger pull, motion or other method depending on the mode), it then acquires and processes each image in the area in front of it (the Volume). In this case, the scanner stops processing the image once it decodes a label.

  • Page 108: Multiple Labels Ordering By Code Symbology

    Enter/Exit Programming Mode Multiple Labels Ordering by Code Symbology This feature allows you to specify the order multiple labels are transmitted by symbology type, when Multiple Labels per Frame is enabled. See page 277 in “References” for detailed information on setting this feature. To configure this feature, scan the ENTER/EXIT PRO- $CSNMS GRAMMING MODE barcode above, then the barcode at...

  • Page 109: 1D Symbologies

    1D SYMBOLOGIES 1D Code Selection The reader supports the following 1D symbologies (bar code types). See "2D Symbologies" starting on page 197 for 2D bar codes. Symbology-dependent options are included in each chapter. • Disable All Symbologies, page 106 • GS1-128, page 144 •...

  • Page 110: Disable All Symbologies

    Enter/Exit Programming Mode 1D Code Selection DISABLE ALL SYMBOLOGIES Use this feature to disable all symbologies. 1. Scan the ENTER/EXIT PROGRAMMING Mode bar code. 2. Scan the Disable All Symbologies bar code. 3. Complete the programming sequence by scanning the ENTER/EXIT PROGRAM- MING bar code.

  • Page 111: Code Ean/Upc

    1D Code Selection Enter/Exit Programming Mode CODE EAN/UPC Coupon Control This feature is used to control the reader’s method of processing coupon labels. $CCPLC00(CR) Coupon Control = Allow all coupon bar codes to be decoded $CCPLC01(CR) DEFAULT Coupon Control = Enable only UPCA coupon decoding $CCPLC02(CR) Coupon Control = Enable only GS1 DataBar™...

  • Page 112: Upc-A

    Enter/Exit Programming Mode 1D Code Selection UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the reader will not read UPC-A bar codes. $CABEN00(CR) UPC-A = Disable $CABEN01(CR) DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data.

  • Page 113: Expand Upc-A To Ean-13

    1D Code Selection Enter/Exit Programming Mode Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CAB3B00(CR) DEFAULT UPC-A to EAN-13 = Don’t Expand $CAB3B01(CR) UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission...

  • Page 114: Upc-A 2D Component

    Enter/Exit Programming Mode 1D Code Selection UPC-A 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $CAB2D00(CR) DEFAULT EAN-13 2D Component = Disable (2D component not required) $CAB2D01(CR) EAN-13 2D Component = 2D component must be decoded...

  • Page 115: Upc-E Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data. $CEBCT00(CR) UPC-E Check Character Transmission = Don’t Send $CEBCT01(CR) DEFAULT UPC-E Check Character Transmission = Send UPC-E 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.

  • Page 116: Expand Upc-E To Ean-13

    Enter/Exit Programming Mode 1D Code Selection Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CEB3B00(CR) DEFAULT UPC-E to EAN-13 = Don’t Expand $CEB3B01(CR) UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A...

  • Page 117: Upc-E Number System Character Transmission

    1D Code Selection Enter/Exit Programming Mode UPC-E Number System Character Transmission This feature enables/disables transmission of the UPC-E system number character. $CEBNS00(CR) UPC-E Number System Character = Do not transmit $CEBNS01(CR) DEFAULT UPC-E Number System Character = Transmit GTIN FORMATTING This feature enables/disables the ability to convert UPC-E, UPC-A, EAN 8, and EAN 13 labels into the GTIN 14-character format.

  • Page 118: Ean 13 (Jan 13)

    Enter/Exit Programming Mode 1D Code Selection EAN 13 (JAN 13) The following options apply to the EAN 13 (Jan 13) symbology. EAN 13 Enable/Disable When disabled, the reader will not read EAN 13/JAN 13 bar codes. $C3BEN00(CR) EAN 13 = Disable $C3BEN01(CR) DEFAULT EAN 13 = Enable...

  • Page 119: Ean-13 Flag 1 Character

    1D Code Selection Enter/Exit Programming Mode EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character is the first character of the label. $C3BF100(CR) EAN-13 Flag 1 Char= Don’t transmit $C3BF101(CR) DEFAULT EAN-13 Flag 1 Char= Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels.

  • Page 120: Ean-13 2D Component

    Enter/Exit Programming Mode 1D Code Selection EAN-13 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $C3B2D00(CR) DEFAULT EAN-13 2D Component = Disable (2D component not required) $C3B2D01(CR) EAN-13 2D Component = 2D component must be decoded...

  • Page 121: Ean 8 (Jan 8)

    1D Code Selection Enter/Exit Programming Mode EAN 8 (JAN 8) The following options apply to the EAN 8 (Jan 8) symbology. EAN 8 Enable/Disable When disabled, the reader will not read EAN 8/JAN 8 bar codes. $C8BEN00(CR) EAN 8 = Disable $C8BEN01(CR) DEFAULT EAN 8 = Enable...

  • Page 122: Expand Ean 8 To Ean 13

    Enter/Exit Programming Mode 1D Code Selection Expand EAN 8 to EAN 13 Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13. $C8B3B00(CR) DEFAULT Expand EAN 8 to EAN 13 = Disable $C8B3B01(CR) Expand EAN 8 to EAN 13 = Enable EAN 8 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.

  • Page 123: Upc/Ean Global Settings

    1D Code Selection Enter/Exit Programming Mode UPC/EAN GLOBAL SETTINGS This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 symbologies, and affects all of these unless otherwise marked for each feature description. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits. $CPWEN00(CR) DEFAULT Price Weight Check = Disabled...

  • Page 124: Upc/Ean Quiet Zones

    Enter/Exit Programming Mode 1D Code Selection UPC/EAN Quiet Zones This feature specifies the number of quiet zones for UPC/EAN labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label.

  • Page 125: Add-Ons

    1D Code Selection Enter/Exit Programming Mode ADD-ONS Contact Customer Support for advanced programming of optional and conditional add-ons. Optional Add-ons The reader can be enabled to optionally read the following add-ons (supplementals): If a UPC/EAN base label and an add-on are both decoded, the reader will transmit the base label and add-on.

  • Page 126: Optional Add-On Timer

    Enter/Exit Programming Mode 1D Code Selection Optional Add-On Timer This option sets the time the reader will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled. (Also see "Optional GS1-128 Add-On Timer" on page 125.) $CADOT01(CR) Optional Add-on Timer = 10ms...
  • Page 127 1D Code Selection Enter/Exit Programming Mode Optional Add-On Timer — cont. $CADOT06(CR) Optional Add-on Timer = 60ms $CADOT07(CR) DEFAULT Optional Add-on Timer = 70ms $CADOT0A(CR) Optional Add-on Timer = 100ms $CADOT0C(CR) Optional Add-on Timer = 120ms $CADOT0E(CR) Optional Add-on Timer = 140ms $CADOT10(CR) Optional Add-on Timer = 160ms Product Reference Guide...
  • Page 128 Enter/Exit Programming Mode 1D Code Selection Optional Add-On Timer — cont. $CADOT12(CR) Optional Add-on Timer = 180ms $CADOT14(CR) Optional Add-on Timer = 200ms $CADOT16(CR) Optional Add-on Timer = 220ms $CADOT18(CR) Optional Add-on Timer = 240ms $CADOT1A(CR) Optional Add-on Timer = 260ms $CADOT1C(CR) Optional Add-on Timer = 280ms $CADOT1E(CR)

  • Page 129: Optional Gs1-128 Add-On Timer

    1D Code Selection Enter/Exit Programming Mode Optional GS1-128 Add-On Timer This option sets the timer expiration value to read the added part after reading the linear EAN/ UPC part. For UPC/EAN add-ons other than those of that type, see "Optional Add-On Timer"...
  • Page 130 Enter/Exit Programming Mode 1D Code Selection Optional GS1-128 Add-On Timer — cont. $CADUT06(CR) Optional GS1-128 Add-On Timer = 60ms $CADUT07(CR) Optional GS1-128 Add-On Timer = 70ms $CADUT0A(CR) Optional GS1-128 Add-On Timer = 100ms $CADUT0C(CR) Optional GS1-128 Add-On Timer = 120ms $CADUT0E(CR) Optional GS1-128 Add-On Timer = 140ms $CADUT10(CR)
  • Page 131 1D Code Selection Enter/Exit Programming Mode Optional GS1-128 Add-On Timer — cont. $CADUT12(CR) Optional GS1-128 Add-On Timer = 180ms $CADUT14(CR) Optional GS1-128 Add-On Timer = 200ms $CADUT16(CR) Optional GS1-128 Add-On Timer = 220ms $CADUT18(CR) Optional GS1-128 Add-On Timer = 240ms $CADUT1A(CR) Optional GS1-128 Add-On Timer = 260ms $CADUT1C(CR)

  • Page 132: Code 39

    Enter/Exit Programming Mode 1D Code Selection CODE 39 The following options apply to the Code 39 symbology. Code 39 Enable/Disable $CC3EN00(CR) Code 39 = Disable $CC3EN01(CR) DEFAULT Code 39 = Enable Code 39 Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Code 39 check character.

  • Page 133: Code 39 Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode Code 39 Check Character Calculation — cont. $CC3CC04(CR) Code 39 Check Character Calculation = Enable Italian Post Check $CC3CC08(CR) Code 39 Check Character Calculation = Enable Daimler Chrysler Check Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data.

  • Page 134: Code 39 Start/Stop Character Transmission

    Enter/Exit Programming Mode 1D Code Selection Code 39 Start/Stop Character Transmission Enable this option to enable/disable transmission of Code 39 start and stop characters $CC3SS00(CR) DEFAULT Code 39 Start/Stop Character Transmission = Don’t Transmit $CC3SS01(CR) Code 39 Start/Stop Character Transmission = Transmit Code 39 Full ASCII Enables/disables the translation of Code 39 characters to Code 39 full-ASCII characters.

  • Page 135: Code 39 Quiet Zones

    1D Code Selection Enter/Exit Programming Mode Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label. $CC3LO02(CR) Code 39 Quiet Zones = Quiet Zones on two sides $CC3LO03(CR)

  • Page 136: Code 39 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Code 39 Set Length 1 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 137: Code 39 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Code 39 Set Length 2 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 138: Trioptic Code

    Enter/Exit Programming Mode 1D Code Selection TRIOPTIC CODE The following options apply to the Trioptic symbology. Trioptic Code Enable/Disable $CCTEN00(CR) DEFAULT Trioptic Code = Disable $CCTEN01(CR) Trioptic Code = Enable CODE 32 (ITAL PHARMACEUTICAL CODE) The following options apply to the Code 32 (Italian Pharmaceutical Code) symbology. Code 32 Enable/Disable When disabled, the reader will not read Code 32 bar codes.

  • Page 139: Code 32 Feature Setting Exceptions

    1D Code Selection Enter/Exit Programming Mode Code 32 Feature Setting Exceptions The following features are set for Code 32 by using these Code 39 settings: "Code 39 Quiet Zones" on page 131 "Code 39 Length Control" on page 131 "Trioptic Code" on page 134 Code 32 Check Char Transmission Enable this option to transmit the check character along with Code 32 bar code data.

  • Page 140: Code 39 Cip (French Pharmaceutical)

    Enter/Exit Programming Mode 1D Code Selection CODE 39 CIP (FRENCH PHARMACEUTICAL) The following options apply to the Code 39 CIP symbology. Code 39 CIP Enable/Disable Enables/Disables ability of the reader to decode Code 39 CIP labels. $CCCEN00(CR) DEFAULT Code 39 CIP = Disable $CCCEN01(CR) Code 39 CIP = Enable CODE 39 DANISH PPT...

  • Page 141: Code 39 Laposte

    1D Code Selection Enter/Exit Programming Mode CODE 39 LAPOSTE The following options apply to the Code 39 LaPoste symbology. Code 39 LaPoste Enable/Disable Enables/disables the ability of the scanner to decode Code39 La Poste labels. $CLPEN00(CR) DEFAULT Code 39 LaPoste = Disable $CLPEN01(CR) Code 39 LaPoste = Enable CODE 39 PZN...

  • Page 142: Code 128

    Enter/Exit Programming Mode 1D Code Selection CODE 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable When disabled, the reader will not read Code 128 bar codes. $CC8EN00(CR) Code 128 = Disable $CC8EN01(CR) DEFAULT Code 128 = Enable Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels.

  • Page 143: Code 128 Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode Code 128 Check Character Transmission Enable this option to transmit the check character along with Code 128 bar code data. $CC8CT00(CR) DEFAULT Code 128 Check Character Transmission = Don’t Send $CC8CT01(CR) Code 128 Check Character Transmission = Send Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.

  • Page 144: Code 128 Sub-Code Exchange Transmission

    Enter/Exit Programming Mode 1D Code Selection Code 128 Sub-Code Exchange Transmission Enables/disables the transmission of “Sub-Code Exchange” characters (NOT transmitted by standard decoding). $CC8SC00(CR) DEFAULT Code 128 Sub-Code Exchange Transmission = Disable $CC8SC01(CR) Code 128 Sub-Code Exchange Transmission = Enable Code 128 Quiet Zones This feature specifies the number of quiet zones for Code 128 labels.

  • Page 145: Code 128 Length Control

    1D Code Selection Enter/Exit Programming Mode Code 128 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 128 symbology. See page 259 for more information. $CC8LC00(CR) DEFAULT Code 128 Length Control = Variable Length $CC8LC01(CR) Code 128 Length Control = Fixed Length Product Reference Guide...

  • Page 146: Code 128 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Code 128 Set Length 1 Specifies one of the bar code lengths for Code 128 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 147: Code 128 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Code 128 Set Length 2 This feature specifies one of the bar code lengths for Code 128 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 148: Gs1-128

    Enter/Exit Programming Mode 1D Code Selection GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS-128, GS1-128, GTIN-128, UCC-128, EAN-128.) GS1-128 Enable This option enables/disables the ability of the reader to translate GS1-128 labels to the GS1-128 data format.

  • Page 149: Code Isbt 128

    1D Code Selection Enter/Exit Programming Mode CODE ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Use this option to enable/disable ISBT128 concatenation of 2 labels. $CI8CE00(CR) DEFAULT ISBN 128 Concatenation = Disable $CI8CE01(CR) ISBN 128 Concatenation = Enable ISBT 128 Force Concatenation When enabled, this feature forces concatenation for ISBT.

  • Page 150: Isbt 128 Concatenation Mode

    Enter/Exit Programming Mode 1D Code Selection ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic. ISBT 128 Concate- This option is only valid when ISBT 128 Concatenation is enabled (see " nation" on page 145 $CI8CM00CR) DEFAULT ISBT 128 Concatenation Mode = Static $CI8CM01CR) ISBT 128 Concatenation Mode = Dynamic...

  • Page 151: Isbt 128 Dynamic Concatenation Timeout

    $CI8DT64(CR) ISBT 128 Dynamic Concatenation Timeout = 1 second ISBT 128 Advanced Concatenation Options To set up pairs of label types for concatenation, use the Datalogic Aladdin configuration page 10 application or contact Datalogic Technical Support, as described on Product Reference Guide...

  • Page 152: Interleaved 2 Of 5 (I 2 Of 5)

    Enter/Exit Programming Mode 1D Code Selection INTERLEAVED 2 OF 5 (I 2 OF 5) The following options apply to the I 2 of 5 symbology. I 2 of 5 Enable/Disable When disabled, the reader will not read I 2 of 5 bar codes. $CI2EN00(CR) DEFAULT I 2 of 5 = Disable...

  • Page 153: I 2 Of 5 Check Character Calculation

    1D Code Selection Enter/Exit Programming Mode I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character. Combinations of these settings are possible via the Aladdin configuration utility, or contact Technical Support.

  • Page 154: I 2 Of 5 Check Character Transmission

    Enter/Exit Programming Mode 1D Code Selection I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data. $CI2CT00(CR) I 2 of 5 Check Character Transmission = Don’t Send $CI2CT01(CR) DEFAULT I 2 of 5 Check Character Transmission = Send...

  • Page 155: I 2 Of 5 Set Length 1

    1D Code Selection Enter/Exit Programming Mode I 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 156: I 2 Of 5 Set Length 2

    Enter/Exit Programming Mode 1D Code Selection I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 157: Interleaved 2 Of 5 Cip Hr

    1D Code Selection Enter/Exit Programming Mode INTERLEAVED 2 OF 5 CIP HR The following options apply to the Interleaved 2 of 5 CIP HR symbology. Interleaved 2 of 5 CIP HR Enable/Disable Enables/Disables ability of reader to decode Interleaved 2 of 5 CIP HR labels. $CCHEN00(CR) DEFAULT Interleaved 2 of 5 CIP HR = Disable...

  • Page 158: Standard 2 Of 5

    Enter/Exit Programming Mode 1D Code Selection STANDARD 2 OF 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the reader will not read Standard 2 of 5 bar codes. $C2SEN00(CR) DEFAULT Standard 2 of 5 = Disable $C2SEN01(CR)

  • Page 159: Standard 2 Of 5 Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check character. $CS2CT00(CR) Standard 2 of 5 Check Character Transmission = Don’t Send $CS2CT01(CR) DEFAULT Standard 2 of 5 Check Character Transmission = Send Standard 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Standard 2 of 5 symbology.

  • Page 160: Standard 2 Of 5 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length...

  • Page 161: Standard 2 Of 5 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Standard 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length...

  • Page 162: Industrial 2 Of 5

    Enter/Exit Programming Mode 1D Code Selection INDUSTRIAL 2 OF 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Industrial 2 of 5 labels. $CU2EN00(CR) DEFAULT Industrial 2 of 5 = Disable $CU2EN01(CR) Industrial 2 of 5 = Enable Industrial 2 of 5 Check Character Calculation...

  • Page 163: Industrial 2 Of 5 Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. $CU2CT00(CR) Industrial 2 of 5 Check Character Transmission = Disable $CU2CT01(CR) DEFAULT Industrial 2 of 5 Check Character Transmission = Enable Industrial 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Industrial 2 of 5 symbology.

  • Page 164: Industrial 2 Of 5 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length...

  • Page 165: Industrial 2 Of 5 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Industrial 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length...

  • Page 166: Code Iata

    Enter/Exit Programming Mode 1D Code Selection CODE IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the reader to decode IATA labels. $CIAEN00(CR) DEFAULT IATA = Disable $CIAEN01(CR) IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.

  • Page 167: Codabar

    1D Code Selection Enter/Exit Programming Mode CODABAR The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the reader will not read Codabar bar codes. $CCBEN00(CR) DEFAULT Codabar = Disable $CCBEN01(CR) Codabar = Enable Codabar Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Codabar check character.

  • Page 168: Codabar Check Character Transmission

    Enter/Exit Programming Mode 1D Code Selection Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. $CCBCT00(CR) Codabar Check Character Transmission = Don’t Send $CCBCT01(CR) DEFAULT Codabar Check Character Transmission = Send Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters $CCBSS00(CR)

  • Page 169: Codabar Start/Stop Character Set

    1D Code Selection Enter/Exit Programming Mode Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters $CCBSC00(CR) Codabar Check Character Set = ABCD/TN*E $CCBSC01(CR) Codabar Check Character Set = ABCD/ABCD $CCBSC02(CR) Codabar Check Character Set = abcd/tn*e $CCBSC03(CR) DEFAULT Codabar Check Character Set = abcd/abcd...

  • Page 170: Codabar Quiet Zones

    Enter/Exit Programming Mode 1D Code Selection Codabar Quiet Zones Specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label. $CCBLO02(CR) Codabar Quiet Zones = Quiet Zones on two sides $CCBLO03(CR)

  • Page 171: Codabar Set Length 1

    1D Code Selection Enter/Exit Programming Mode Codabar Set Length 1 This feature specifies one of the bar code lengths for Codabar Length ControlCodabar Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 172: Codabar Set Length 2

    Enter/Exit Programming Mode 1D Code Selection Codabar Set Length 2 This feature specifies one of the bar code lengths for Codabar Length ControlCodabar Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 173: Abc Codabar

    1D Code Selection Enter/Exit Programming Mode ABC CODABAR The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of reader to decode ABC Codabar labels. $CCBAB00(CR) DEFAULT ABC Codabar = Disable $CCBAB01(CR) ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic.

  • Page 174: Abc Codabar Dynamic Concatenation Timeout

    Enter/Exit Programming Mode 1D Code Selection ABC Codabar Dynamic Concatenation Timeout Specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode. $CCBDT05(CR) ABC Codabar Dynamic Concatenation Timeout = 50 msec $CCBDT0A(CR) ABC Codabar Dynamic Concatenation Timeout = 100 msec $CCBDT14(CR) DEFAULT...

  • Page 175: Abc Codabar Force Concatenation

    1D Code Selection Enter/Exit Programming Mode ABC Codabar Force Concatenation Forces labels starting or ending with D to be concatenated. $CCBFC00(CR) DEFAULT ABC Codabar Force Concatenation = Disable $CCBFC01(CR) ABC Codabar Force Concatenation = Enable Product Reference Guide...

  • Page 176: Code 11

    Enter/Exit Programming Mode 1D Code Selection CODE 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the reader will not read Code 11 bar codes. $CC1EN00(CR) DEFAULT Code 11 = Disable $CC1EN01(CR) Code 11 = Enable Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.

  • Page 177: Code 11 Check Character Transmission

    1D Code Selection Enter/Exit Programming Mode Code 11 Check Character Transmission This feature enables/disables transmission of an optional Code 11 check character. $CC1CT00(CR) Code 11 Check Character Transmission = Don’t Send $CC1CT01(CR) DEFAULT Code 11 Check Character Transmission = Send Code 11 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 11 symbology.

  • Page 178: Code 11 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Code 11 Set Length 1 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 179: Code 11 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Code 11 Set Length 2 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 180: Gs1 Databar™ Omnidirectional

    Enter/Exit Programming Mode 1D Code Selection GS1 DATABAR™ OMNIDIRECTIONAL The following options apply to the GS1 DataBar™ Omnidirectional (formerly RSS-14) symbology. GS1 DataBar™ Omnidirectional Enable/Disable When disabled, the reader will not read GS1 DataBar™ Omnidirectional bar codes. $C4BEN00(CR) DEFAULT GS1 DataBar™ Omnidirectional = Disable $C4BEN01(CR) GS1 DataBar™...

  • Page 181: Gs1 Databar™ Omnidirectional 2D Component

    1D Code Selection Enter/Exit Programming Mode GS1 DataBar™ Omnidirectional 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. $C4B2D00(CR) DEFAULT GS1 DataBar™ Omnidirectional 2D Component = Disable (2D component not required) $C4B2D01(CR) GS1 DataBar™...

  • Page 182: Gs1 Databar™ Expanded Gs1-128 Emulation

    Enter/Exit Programming Mode 1D Code Selection GS1 DataBar™ Expanded GS1-128 Emulation When enabled, GS1 DataBar™ Expanded bar codes will be translated to the GS1-128 label data format. $CXBU800(CR) DEFAULT GS1 DataBar™ Expanded GS1-128 Emulation = Disable $CXBU801(CR) GS1 DataBar™ Expanded GS1-128 Emulation = Enable GS1 DataBar™...

  • Page 183: Gs1 Databar™ Expanded Length Control

    1D Code Selection Enter/Exit Programming Mode GS1 DataBar™ Expanded Length Control This feature specifies either variable length decoding or fixed length decoding for the GS1 DataBar™ Expanded symbology. Variable Length: For variable-length decoding, a minimum length may be set. Fixed Length: For fixed-length decoding, two different lengths may be set.

  • Page 184: Gs1 Databar™ Expanded Set Length 1

    Enter/Exit Programming Mode 1D Code Selection GS1 DataBar™ Expanded Set Length 1 This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 185: Gs1 Databar™ Expanded Set Length 2

    1D Code Selection Enter/Exit Programming Mode GS1 DataBar™ Expanded Set Length 2 This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 186: Gs1 Databar™ Limited

    Enter/Exit Programming Mode 1D Code Selection GS1 DATABAR™ LIMITED The following options apply to the GS1 DataBar™ Limited (formerly RSS Limited) symbology. GS1 DataBar™ Limited Enable/Disable When disabled, the reader will not read GS1 DataBar™ Limited bar codes. $CLBEN00(CR) DEFAULT GS1 DataBar™...

  • Page 187: Gs1 Databar™ Limited 2D Component

    1D Code Selection Enter/Exit Programming Mode GS1 DataBar™ Limited 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. $CLB2D00(CR) DEFAULT GS1 DataBar™ Limited 2D Component = Disable (2D component not required) $CLB2D01(CR) GS1 DataBar™...

  • Page 188: Code 93 Check Character Calculation

    Enter/Exit Programming Mode 1D Code Selection Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character. $CC9CC00(CR) Code 93 Check Character Calculation = Disable $CC9CC01(CR) Code 93 Check Character Calculation = Enable Check C $CC9CC02(CR) Code 93 Check Character Calculation = Enable Check K $CC9CC03(CR)

  • Page 189: Code 93 Length Control

    1D Code Selection Enter/Exit Programming Mode Code 93 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 93 symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.

  • Page 190: Code 93 Set Length 1

    Enter/Exit Programming Mode 1D Code Selection Code 93 Set Length 1 Specifies one of the bar code lengths for Code 93 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 191: Code 93 Set Length 2

    1D Code Selection Enter/Exit Programming Mode Code 93 Set Length 2 This feature specifies one of the bar code lengths for Code 93 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 192: Code 93 Quiet Zones

    Enter/Exit Programming Mode 1D Code Selection Code 93 Quiet Zones Enables/disables quiet zones for Code 93. $CC9LO02(CR) Code 93 Quiet Zones = Quiet Zones on two sides $CC9LO03(CR) DEFAULT Code 93 Quiet Zones = Small Quiet Zones on two sides The following options apply to the MSI symbology.

  • Page 193: Msi Check Character Calculation

    1D Code Selection Enter/Exit Programming Mode MSI Check Character Calculation Enables/Disables calculation and verification of an optional MSI check character. $CMSCC00(CR) MSI Check Character Calculation = Disable $CMSCC01(CR) DEFAULT MSI Check Character Calculation = Enable Mod10 $CMSCC02(CR) MSI Check Character Calculation = Enable Mod11/10 $CMSCC03(CR) MSI Check Character Calculation = Enable Mod10/10 MSI Check Character Transmission...

  • Page 194: Msi Length Control

    Enter/Exit Programming Mode 1D Code Selection MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbology. For variable length decoding, a minimum and maximum length may be Variable Length: set. For fixed length decoding, two different lengths may be set. Fixed Length: $CMSLC00(CR) DEFAULT...

  • Page 195: Msi Set Length 1

    1D Code Selection Enter/Exit Programming Mode MSI Set Length 1 This feature specifies one of the bar code lengths for . Length 1 is the MSI Length Control minimum label length if in Mode, or the first fixed length if in Variable Length Fixed Mode.

  • Page 196: Msi Set Length 2

    Enter/Exit Programming Mode 1D Code Selection MSI Set Length 2 This feature specifies one of the bar code lengths for . Length 2 is the MSI Length Control maximum label length if in Mode, or the second fixed length if in Variable Length Fixed Mode.

  • Page 197: Plessey

    1D Code Selection Enter/Exit Programming Mode PLESSEY The following options apply to the Plessey symbology. Plessey Enable/Disable Enables/Disables ability of reader to decode Plessey labels. $CPLEN00CR) DEFAULT Plessey = Disable $CPLEN01CR) Plessey = Enable Plessey Check Character Calculation Enables/Disables calculation and verification of an optional Plessey check character. $CPLCC00(CR) Plessey Check Character Calculation = Disable $CPLCC01(CR)

  • Page 198: Plessey Check Character Transmission

    Enter/Exit Programming Mode 1D Code Selection Plessey Check Character Transmission Enables/disables transmission of an MSI check character. $CPLCT00(CR) Plessey Check Character Transmission = Disable $CPLCT01(CR) DEFAULT Plessey Check Character Transmission = Enable Plessey Length Control This feature specifies either variable length decoding or fixed length decoding for the Plessey symbology.

  • Page 199: Plessey Set Length 1

    1D Code Selection Enter/Exit Programming Mode Plessey Set Length 1 This feature specifies one of the bar code lengths for Plessey Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 200: Plessey Set Length 2

    Enter/Exit Programming Mode 1D Code Selection Plessey Set Length 2 This feature specifies one of the bar code lengths for Plessey Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 201: 2D Symbologies

    2D SYMBOLOGIES 2D Global Features • 2D Maximum Decoding Time, page 198 • 2D Normal/Inverse Symbol Control, page 199 • 2D Structured Append, page 199 2D Symbologies The reader supports the following 2D symbologies (bar code types). Symbology-dependent options for each symbology are included in this chapter. See "1D Code Selection"...

  • Page 202: 2D Maximum Decoding Time

    Enter/Exit Programming Mode 2D Global Features 2D Maximum Decoding Time This feature specifies the maximum amount of time the software will spend attempting to decode a 2D label. The selectable range is 10 milliseconds to 2.55 milliseconds. $CDETM0A(CR) 2D Maximum Decoding Time = 100 msec $CDETM32(CR) 2D Maximum Decoding Time = 200 msec $CDETM23(CR)

  • Page 203: 2D Structured Append

    2D Global Features Enter/Exit Programming Mode 2D Structured Append Enables/disables ability of reader to append multiple 2D Codes labels in a structured format. The structured append property is globally applied to the following symbologies, if these are enabled: • Data Matrix •...

  • Page 204: Aztec Code

    Enter/Exit Programming Mode Aztec Code Aztec Code Aztec Code Enable / Disable Enables/disables the ability of the reader to decode Aztec Code labels. $CAZEN00(CR) DEFAULT Aztec Code = Disable $CAZEN01(CR) Aztec Code = Enable Aztec Code Multiframe Enables/disables ability of reader to decode an Aztec Code label using multiple frames. $CAZMF00(CR) Aztec Code Multiframe = Disable $CAZMF01(CR)

  • Page 205: Aztec Code Length Control

    Aztec Code Enter/Exit Programming Mode Aztec Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CAZLC00(CR) DEFAULT Aztec Code Length Control = Variable Length...

  • Page 206: Aztec Code Set Length 2

    Enter/Exit Programming Mode Aztec Code Aztec Code Set Length 2 This feature specifies one of the bar code lengths for Aztec Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 207: China Sensible Code

    China Sensible Code Enter/Exit Programming Mode China Sensible Code China Sensible Code Enable / Disable Enables/disables the ability of the reader to decode China Sensible Code labels. $CCSEN00(CR) DEFAULT China Sensible Code = Disable $CCSEN01(CR) China Sensible Code = Enable China Sensible Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.

  • Page 208: China Sensible Code Set Length 1

    Enter/Exit Programming Mode China Sensible Code China Sensible Code Set Length 1 Specifies one of the bar code lengths for China Sensible Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 209: China Sensible Code Set Length 2

    China Sensible Code Enter/Exit Programming Mode China Sensible Code Set Length 2 This feature specifies one of the bar code lengths for China Sensible Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 210: Data Matrix

    Enter/Exit Programming Mode Data Matrix Data Matrix Data Matrix Enable / Disable Enables/disables ability of reader to decode Data Matrix labels. $CDMEN00(CR) Data Matrix = Disable $CDMEN01(CR) DEFAULT Data Matrix = Enable Data Matrix Square/Rectangular Style Specifies the options available when reading Data Matrix with different form factors. Choices are: •...

  • Page 211: Data Matrix Length Control

    Data Matrix Enter/Exit Programming Mode Data Matrix Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CDMLC00(CR) DEFAULT Data Matrix Length Control = Variable Length...

  • Page 212: Data Matrix Set Length 2

    Enter/Exit Programming Mode Data Matrix Data Matrix Set Length 2 This feature specifies one of the bar code lengths for Data Matrix Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 213: Maxicode

    Maxicode Enter/Exit Programming Mode Maxicode Maxicode Enable / Disable Enables/disables ability of reader to decode Maxicode labels. $CMXEN00(CR) DEFAULT Maxicode = Disable $CMXEN01(CR) Maxicode = Enable Maxicode Primary Message Transmission Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable.

  • Page 214: Maxicode Length Control

    Enter/Exit Programming Mode Maxicode Maxicode Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CMXLC00(CR) DEFAULT Maxicode Length Control = Variable Length...

  • Page 215: Maxicode Set Length 2

    Maxicode Enter/Exit Programming Mode Maxicode Set Length 2 This feature specifies one of the bar code lengths for Maxicode Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 216: Pdf417

    Enter/Exit Programming Mode PDF417 PDF417 PDF417 Enable / Disable Enables/disables the ability of the reader to decode PDF417 labels. $CP4EN00(CR) PDF417 = Disable $CP4EN01(CR) DEFAULT PDF417 = Enable PDF417 Multiframe Enables/disables the ability of the reader to decode a PDF 417 label using multiple frames. $CP4MF00(CR) DEFAULT PDF417 Multiframe = Disable...

  • Page 217: Pdf417 Length Control

    PDF417 Enter/Exit Programming Mode PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CP4LC00(CR) DEFAULT PDF417 Length Control = Variable Length...

  • Page 218: Pdf417 Set Length 2

    Enter/Exit Programming Mode PDF417 PDF417 Set Length 2 This feature specifies one of the bar code lengths for PDF417 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 219: Micro Pdf417

    Micro PDF417 Enter/Exit Programming Mode Micro PDF417 Micro PDF417 Enable / Disable Enables/disables the ability of the reader to decode Micro PDF417 labels $CMIEN00(CR) DEFAULT Micro PDF417 = Disable $CMIEN01(CR) Micro PDF417 = Enable Micro PDF417 Code 128 GS1-128 Emulation Specifies which AIM ID to use for MicroPDF labels when doing Code 128 or GS1-128 emulation.

  • Page 220: Micro Pdf417 Length Control

    Enter/Exit Programming Mode Micro PDF417 Micro PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CMILC00(CR) DEFAULT Micro PDF417 Length Control = Variable Length...

  • Page 221: Micro Pdf417 Set Length 2

    Micro PDF417 Enter/Exit Programming Mode Micro PDF417 Set Length 2 This feature specifies one of the bar code lengths for Micro PDF417 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length includes the barcode’s data characters only.

  • Page 222: Qr Code

    Enter/Exit Programming Mode QR Code QR Code QR Code Enable / Disable Enables/disables the ability of the reader to decode QR Code labels $CQREN00(CR) QR Code = Disable $CQREN01(CR) DEFAULT QR Code = Enable QR Code Multiframe Enables/disables the ability of the reader to decode a QR Code label using multiple frames. $CQRMF00(CR) DEFAULT QR Code Multiframe = Disable...

  • Page 223: Qr Code Length Control

    QR Code Enter/Exit Programming Mode QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CQRLC00(CR) DEFAULT QR Code Length Control = Variable Length...

  • Page 224: Qr Code Set Length 2

    Enter/Exit Programming Mode QR Code QR Code Set Length 2 This feature specifies one of the bar code lengths for QR Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 225: Micro Qr Code

    Micro QR Code Enter/Exit Programming Mode Micro QR Code Micro QR Code Enable/Disable Enables/disables the ability of the reader to decode Micro QR Code labels MQEN00 DEFAULT Micro QR Code = Disable MQEN01 Micro QR Code = Enable Micro QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.

  • Page 226: Micro Qr Code Set Length 1

    Enter/Exit Programming Mode Micro QR Code Micro QR Code Set Length 1 Specifies one of the bar code lengths for Micro QR Code Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.

  • Page 227: Micro Qr Code Set Length 2

    Micro QR Code Enter/Exit Programming Mode Micro QR Code Set Length 2 This feature specifies one of the bar code lengths for Micro QR Code Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.

  • Page 228: Ucc Composite

    Enter/Exit Programming Mode UCC Composite UCC Composite UCC Composite Enable / Disable Enables/disables the ability of the reader to decode the stacked part of a UCC Composite label. Global This feature is not effective when Global AIM IDs are enabled (see " AIM ID"...

  • Page 229: Ucc Optional Composite Timer

    UCC Composite UCC Optional Composite Timer Specifies the amount of time the system will wait for the stacked part of a UCC Composite label before transmitting the linear label without an add-on. $CCMOT00(CR) DEFAULT UCC Optional Composite Timer = Timer Disabled $CCMOT01(CR) UCC Optional Composite Timer = 100msec $CCMOT02(CR)

  • Page 230: Postal Code Selection

    Postal Code Selection Enables/disables the ability of the scanner to decode labels of a specific postal symbology. • Disable All Postal Codes • Australia Post • Postnet • Japan Post • Planet • • Royal Mail • Sweden Post • •...

  • Page 231: Postnet Bb Control

    Postal Code Selection Postal Code Selection — cont. $CPOEN06(CR) Postal Code Selection = Enable Japan Post $CPOEN07(CR) Postal Code Selection = Enable IMB $CPOEN08(CR) Postal Code Selection = Enable Sweden Post $CPOEN09(CR) Postal Code Selection = Enable Portugal Post Postnet BB Control Controls the ability of the scanner to decode B and B' fields of Postnet labels.
  • Page 232 NOTES Gryphon™ I GD44XX/GBT4400...

  • Page 233: Wireless Features

    WIRELESS FEATURES This section provides options and programming related to the reader’s wireless communication features. Reference Appendix B, for a listing of standard factory settings. IRELESS EEPER EATURES starting on page 230 IMEOUT starting on page 238 RF A • Good Transmission Beep DDRESS TAMPING...

  • Page 234: Wireless Beeper Features

    Enter/Exit Programming Mode WIRELESS BEEPER FEATURES Several options are available to configure beeper behavior for RF operation. Good Transmission Beep Enables/disables the Good Transmission Beep indication. When enabled, a beep occurs when a Label is correctly transmitted to the base. $CBTAB00(CR) Good Transmission Beep = Disable $CBTAB01(CR)

  • Page 235: Beep Duration

    Enter/Exit Programming Mode Beep Duration This feature controls the duration of radio-specific beep indications. $CBTBD06(CR) Beep Duration = 60 msec $CBTBD08(CR) DEFAULT Beep Duration = 80 msec $CBTBD0A(CR) Beep Duration = 100 msec $CBTBD0C(CR) Beep Duration = 120 msec $CBTBD0E(CR) Beep Duration = 140 msec $CBTBD10(CR) Beep Duration = 160 msec...

  • Page 236: Beep Volume

    Enter/Exit Programming Mode Beep Volume Selects the beeper volume (loudness) of radio-specific beep indications. There are three selectable volume levels. $CBTBV00(CR) Beep Volume = Low $CBTBV01(CR) Beep Volume = Medium $CBTBV02(CR) DEFAULT Beep Volume = High Disconnect Beep Enables/disables the beep indication that a handheld has become connected or disconnected from a Base Station.

  • Page 237: Docking Beep

    Enter/Exit Programming Mode Docking Beep Enables/disables a beep indication when the handheld is placed in the Base Station. $CBTCB00(CR) Docking Beep = Disable $CBTCB01(CR) DEFAULT Docking Beep = Enable Leash Alarm This setting specifies the number of seconds to sound the Leash Mode beeps (three per second) when the handheld goes out of range.
  • Page 238 Enter/Exit Programming Mode Leash Alarm — cont. $CBTLB03(CR) Leash Alarm = 3 Seconds $CBTLB04(CR) Leash Alarm = 4 Seconds $CBTLB05(CR) Leash Alarm = 5 Seconds $CBTLB0A(CR) Leash Alarm = 10 Seconds $CBTLB19(CR) Leash Alarm = 25 Seconds $CBTLB1E(CR) Leash Alarm = 30 Seconds Gryphon™...

  • Page 239: Configuration Updates

    Enter/Exit Programming Mode CONFIGURATION UPDATES page 279 in “References” for detailed information and examples of these features. Automatic Configuration Update When this feature is enabled, a reader and its linked Base Station can automatically ensure they stay in sync with regard to application hardware and/or configuration. See page 279 for more in- formation on this feature.

  • Page 240: Batch Features

    Enter/Exit Programming Mode BATCH FEATURES Batch Mode This option specifies whether to store labels in the handheld while disconnected from the base. Options are as follows: • Disabled — The handheld will not store/batch labels. • Automatic — The handheld will store labels to RAM when the handheld goes out of range and is disconnected from the remote device.

  • Page 241: Erase Batch Memory

    Enter/Exit Programming Mode Erase Batch Memory Use this bar code to erase any labels stored in batch memory. Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunction with this bar code. Erase Batch Memory RF Batch Mode Transmit Delay Specifies the delay in 10 msec increments between transmitting labels stored in batch memory.

  • Page 242: Ack Timeout

    Enter/Exit Programming Mode ACK TIMEOUT This option designates wait time in 200-millisecond ticks for an ACK of a transmitted packet (Tack). The selectable timeout range is 200 to 51,000 milliseconds (01-0xFF) in 200 millisecond increments. A setting of 00 causes the system to wait forever. page 252 for more information on setting this feature.

  • Page 243: Source Radio Address Delimiter Character

    Enter/Exit Programming Mode Source Radio Address Delimiter Character This option specifies the delimiter character to be placed between the label data and radio address when address stamping is enabled. This feature only applies if "Source Radio Address Transmission" on page 238 is enabled. To configure this feature, scan the ENTER/EXIT PRO- $CBTAD GRAMMING MODE barcode above, then the barcode at...

  • Page 244: Link Timeout

    Enter/Exit Programming Mode Link Timeout This feature specifies the wait time in one-second ticks for response from the remote. The selectable timeout range is 01 to 40 (01-0x28) seconds in one second increments. page 252 for more information on setting this feature. To configure this feature, scan the ENTER/EXIT $CBTLT PROGRAMMING MODE barcode above, then the...

  • Page 245: Bluetooth-Only Features

    The Host can be set up to specify a custom security PIN code when a scanner attempts to connect. For more information about this feature, contact Datalogic Technical Support. The Gryphon GBT4400 can be set up to require a PIN code when connecting to the host.

  • Page 246: Bt Pin Code

    Enter/Exit Programming Mode BT PIN Code After enabling Security Mode (see "BT Security Mode" on page 241), specify whether you want to set a 4-digit or a 16-digit PIN Code. page 280 for detailed information and examples for setting this feature. Select PIN Code Length $CBTPC\r Select 4-character BT PIN Code...

  • Page 247: Other Bt Features

    Enter/Exit Programming Mode OTHER BT FEATURES BT Poll Rate This feature specifies the time between BT polls. $CBTST00(CR) BT Poll Rate = Maximum BT Poll Rate $CBTST01(CR) BT Poll Rate = 10 ms $CBTST02(CR) DEFAULT BT Poll Rate = 20 ms $CBTST05(CR) BT Poll Rate = 50 ms $CBTST0A(CR)

  • Page 248: Powerdown Timeout

    Enter/Exit Programming Mode Powerdown Timeout The Powerdown Timeout feature sets the time for automatically switching the unit off when the imager has been idle. $CSLPS00(CR) Powerdown Timeout = Disable $CSLPS01(CR) Powerdown Timeout = 10 minutes $CSLPS02(CR) Powerdown Timeout = 20 minutes R)$CSLPS03(CR Powerdown Timeout = 30 minutes $CSLPS06(CR)

  • Page 249: Motion Features

    MOTION FEATURES OTION IMING ONTROL on page 245 OTION ENSITIVITY on page 246 OTIONLESS IMEOUT on page 246 Use this chapter to configure motion settings for the handheld. Reference Appendix B for a listing of standard factory settings. Motion Aiming Control Configures the ability of the scanner to Enable/Disable the Aiming system when motion is detected.

  • Page 250: Motion Sensitivity

    Enter/Exit Programming Mode Motion Sensitivity Defines discrete set of levels for scanner motion sensitivity when in handheld use. $CMOSY00(CR) Motion Sensitivity = Low $CMOSY01(CR) DEFAULT Motion Sensitivity = Medium $CMOSY02(CR) Motion Sensitivity = High Motionless Timeout Specifies the waiting time in 100 millisecond ticks to assume that the reader is in a motionless condition.

  • Page 251: References

    Chapter 4 References This section contains explanations and examples of selected bar code features. See the Configuration section for the actual bar code labels used to configure the reader. RS-232 Parameters RS-232 Only Baud Rate Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to match the baud rate setting of the host device.

  • Page 252: Rs-232/Usb Com Parameters

    References Handshaking Control The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). Handshaking Control includes the following options: • RTS — RTS is asserted during transmissions. CTS is ignored. •...
  • Page 253 RS-232 Parameters Table 25. Intercharacter Delay Setting Examples STEP ACTION EXAMPLES Desired Setting 50ms 150ms 600ms 850ms Divide by 10 (pad with leading zeroes to yield two-digits) Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT INTERCHARACTER DELAY SETTING Scan Two Characters From ‘0’...
  • Page 254 References ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
  • Page 255 RS-232 Parameters NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
  • Page 256 References ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. To set this value: 1.
  • Page 257 RS-232 Parameters ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries.
  • Page 258 References Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
  • Page 259 RS-232 Parameters Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.

  • Page 260: Keyboard Interface

    References Keyboard Interface Wedge Quiet Interval Specifies the amount of time the reader looks for keyboard activity before it breaks the keyboard connection in order to transmit data to host. The range is from 0 to 990ms in 10ms increments. This feature applies ONLY to the Keyboard Wedge interface.

  • Page 261: Intercharacter Delay

    Keyboard Interface Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. This feature applies ONLY to the Keyboard Wedge interface.

  • Page 262: Intercode Delay

    References Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. Follow these instructions to set this feature: 1. Determine the desired setting. 2. Pad the number with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc 3.

  • Page 263: Symbologies

    Symbologies Symbologies Set Length Length Control allows you to select either variable length decoding or fixed length decoding for the specified symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. Set Length 1 This feature specifies one of the bar code lengths for Length Control.

  • Page 264: Data Editing

    ID code will be transmitted before the scanned bar code data. 00 - 20 Characters (ASCII) Additional advanced editing is available. See the Advanced formatting features in the Datalogic Aladdin configuration software, or contact Technical Support page 10 (as described on ) for more information.

  • Page 265: Global Prefix/Suffix

    Data Editing Please Keep In Mind... • Modifying a message string is not a mandatory requirement. Data editing is a sophisti- cated feature allowing highly customizable output for advanced users. Factory default set- tings for data editing is typically set to NONE. •...

  • Page 266: Global Aim Id

    References Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: •...

  • Page 267: Label Id

    Data Editing Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01- 0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
  • Page 268 References USA Label ID set EU Label ID set Symbology Default Default Default Default Character ASCII Character ASCII DATABAR 14 COMPOSITE 523400 523400 DATABAR EXPANDED 525800 740000 DATABAR EXPANDED COMPOSITE 525800 525800 DATABAR LIMITED 524C00 760000 DATABAR LIMITED COMPOSITE 524C00 524C00 DATA MATRIX 446D00...
  • Page 269 Data Editing USA Label ID set EU Label ID set Symbology Default Default Default Default Character ASCII Character ASCII 400000 5A0000 NW7 CODABAR 244E00 244E00 PDF417 500000 720000 PLESSEY 610000 610000 POSTAL AUSTRALIAN 244B00 244B00 POSTAL IMB 245600 245600 POSTAL JAPANESE 245200 245200 POSTAL KIX...
  • Page 270 References Label ID: Set Individually Per Symbology To configure a Label ID individually for a single symbology: 1. Go to page 77 and scan the ENTER/EXIT bar code. 2. Select Label ID position as either BEFORE (Enable as Prefix) or AFTER (Enable as suf- fix) by scanning the appropriate bar code in the section "Label ID Control"...
  • Page 271 Data Editing Table 36 . Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT bar code (Scanner enters Programming Mode) Determine placement of the Label ID characters BEFORE or AFTER with regard to scanned Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix data using...

  • Page 272: Character Conversion

    References Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done.

  • Page 273: Reading Parameters

    Reading Parameters Reading Parameters Label Gone Timeout This feature sets the time after the last label segment is seen before the reader prepares for a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds (2.55 seconds) in 10ms increments.

  • Page 274: Good Read Led Duration

    References Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 milliseconds (0.001 to 2.55 seconds) in 100ms increments.

  • Page 275: Scanning Features

    Scanning Features Scanning Features Scan Mode This mode is associated with typical handheld reader operation. Selects the scan operating mode for the reader. The following selections are valid for all models: Trigger Single: When the trigger is pulled, scanning is activated until one of the following occurs: Scanning Active Time has elapsed...

  • Page 276: Stand Mode Off Time

    References Stand Mode Off Time This feature specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds). Follow these instructions to set this feature: 1.

  • Page 277: Scanning Active Time

    Scanning Features Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.

  • Page 278: Aiming Duration Time

    References Aiming Duration Time Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.

  • Page 279: Flash On Time

    Scanning Features Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.

  • Page 280: Flash Off Time

    References Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.

  • Page 281: Multiple Labels Ordering By Code Symbology

    Scanning Features Multiple Labels Ordering by Code Symbology This feature Specifies the transmission ordering by symbology type, when Multiple Labels per Frame is enabled.Up to six symbologies can be selected. Zeroes must be added to pad the string to 12 characters if not using all six symbologies. The labels are ordered first as specified in the output mask.
  • Page 282 References Table 45 . Symbology Hex Values Value Symbology ID Value Symbology ID Don't care GTIN5 UPC-A GTIN8 UPC-E S2OF5 EAN8 PDF417 EAN13 CODE11 UPC2 IATA UPC5 MICRO_PDF C128_ADDON GS1 DataBar_LIM_ID EAN128 GS1 DataBar_LIM_COMP C128_PROGRAMMING_LABEL GS1 DataBar_Omnidirectional_COMP CODE128 GS1 DataBar_EXP_COMP FNC3_C128_LABEL GENERIC_DATA DATA MATRIX...

  • Page 283: Rf Features

    RF Features RF Features Automatic Configuration Update When this feature is enabled, the base station and reader will keep their configurations synchronized. If a reader's configuration is altered by reading programming labels, this change is automatically transferred and updated in a linked base station. Likewise, if the base station's configuration is changed using Aladdin or by host commands, then the reader's configuration will automatically be updated if this feature is enabled.

  • Page 284: Bt-Only Features

    References BT-Only Features BT Pin Code This option specifies the 4-character or 16-character pin code to be used for authentication of the BT link. To set the pin code: 1. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode, then enable "BT Security Mode"...

  • Page 285: Technical Specifications

    Appendix A Technical Specifications Table contains Physical and Performance Characteristics, User Environment and Regulatory information. Table provides Standard Cable Pinouts. Table 48. Technical Specifications Item Description GD44XX GBT4400 Physical Characteristics Color White or Black Height 7.1”/181 mm Height 7.1”/181 mm Dimensions Length 3.9”/100 mm Length 3.9”/100 mm...
  • Page 286 Item Description Aiming Source Laser Class 2 Roll (Tilt) Angle Up to ± 180° Pitch Angle ± 40° Skew (Yaw) Angle ± 40° Field of View 40° Hx26° V Depth of Field (Typical) Symbology Standard Range (SR) Models High Density (HD) Models 5mil: 1.6”...
  • Page 287 2D / Stacked Codes Decode Capability The Gryphon I GBT4400 scanner is capable of decoding the following symbologies using multiple frames (i.e. Multi-Frame Decoding): PDF-417; QR Code; Aztec; Data Matrix; Inverse Data Matrix; Data Matrix is configurable for the following parameters:;...
  • Page 288 Item Description Regulatory Electrical Safety UL 60950, CSA C22.2 No. 60950, IEC 60950 GD44XX Models GBT Models Europe - CE; Australia - C-tick; Russia – North America (FCC) : Part 15 Class B; Can- GOST; USA/CANADA – FCC/IC; Japan – ada ( IC) : ICES-003 Class B;...

  • Page 289: Standard Cable Pinouts

    Standard Cable Pinouts Figure Figure 20 and Table provide standard pinout information for the interface cable. Figure 19. Standard Cable Pinouts: Handheld Bottom of Scanner Cable Strain Relief Pin 10 To Host Pin 1 Cable Cable Clip (Latch) Interface Cable Port Figure 20.
  • Page 290 Table 49. Standard Cable Pinouts — Handheld (GD44XX model) or Base Station (GBT4400 model) Side Keyboard RS-232 Wedge RTS (out) CLKIN (KBD side) DATAIN (KBD side) IBM_B CLKOUT (PC side) IBM_A DATAOUT (PC side) CTS (in) Gryphon™ I GD44XX/GBT4400...

  • Page 291: Led And Beeper Indications

    LED and Beeper Indications The reader’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. An optional “Green Spot” also performs useful functions. The tables below list these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or may not be turned on.

  • Page 292: Error Codes

    Table 51 . Programming Mode Indications Programming Mode - The following indications ONLY occur when the reader is in Programming Mode. Label Program- A valid programming label has Reader sounds four low fre- LED blinks continuously ming Mode Entry been scanned. quency beeps.

  • Page 293: Base Station Indications (Gbt4400 Models Only)

    Base Station Indications (GBT4400 Models ONLY) INDICATION LEDS Power-up Complete Yellow LED on Reader Disabled by the HOST or the communication Yellow LED blinking ~1Hz with HOST is not established Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec Programming Mode Yellow LED blinks quickly Configuration alignment with the handheld is in...
  • Page 294 NOTES Gryphon™ I GD44XX/GBT4400...

  • Page 295: Standard Defaults

    Appendix B Standard Defaults The most common configuration settings are listed in the “Default” column of the table below. Page references are also provided for feature descriptions and programming bar codes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features.
  • Page 296 Page Parameter Default Your Setting Number ACK NAK Retry Count 3 Retries ACK NAK Error Handling Ignore Errors Detected Indicate Transmission Failure Enable Disable Character ‘D’ Enable Character ‘E’ KEYBOARD WEDGE Country Mode U.S. Keyboard Send Control Characters Wedge Quiet Interval 100 ms Intercode Delay No Delay...
  • Page 297 Page Parameter Default Your Setting Number Data Format No Global Prefix Global Prefix/Suffix Global Suffix = 0x0D (CR) Global AIM ID Disable Set AIM ID Individually for GS1-128 Enable Label ID: Pre-Loaded Sets EU Set Individually Set Label ID Disable Case Conversion Disable Character Conversion...
  • Page 298 Page Parameter Default Your Setting Number Aiming Pointer Enable Aiming Off Aiming Duration Timer After Decoding Green Spot Duration 300 ms Mobile Phone Mode Enable Partial Label Reading Control Enable Decode Negative Image Disable Multiple Label Reading Multiple Labels per Frame Disable Multiple Labels Ordering by Code Symbology Random Order...
  • Page 299 Page Parameter Default Your Setting Number EAN 13 (Jan 13) EAN 13 Enable/Disable Enable EAN 13 Check Character Transmission Send EAN-13 Flag 1 Character Transmit EAN-13 ISBN Conversion Disable 2D Component Not EAN-13 2D Component Required ISSN ISSN Enable/Disable Disable EAN 8 EAN 8 Enable/Disable Enable...
  • Page 300 Page Parameter Default Your Setting Number Code 39 Set Length 2 Trioptic Code Trioptic Code Enable/Disable Disable Code 32 (Italian Pharmaceutical Code) Code 32 Enable/Disable Disable Code 32 Check Char Transmission Don’t Send Code 32 Start/Stop Character Transmission Don’t Transmit Code 39 CIP (French Pharmaceutical Code) Code 39 CIP Enable/Disable Disable...
  • Page 301 Page Parameter Default Your Setting Number ISBT 128 Concatenation Mode Static ISBT 128 Dynamic Concatenation Timeout 200 msec Interleaved 2 of 5 I 2 of 5 Enable/Disable Disable I 2 of 5 Check Character Calculation Disable I 2 of 5 Check Character Transmission Send I 2 of 5 Length Control Variable...
  • Page 302 Page Parameter Default Your Setting Number Codabar Codabar Enable/Disable Disable Codabar Check Character Calculation Don’t Calculate Codabar Check Character Transmission Send Codabar Start/Stop Character Transmission Transmit Codabar Start/Stop Character Set abcd/abcd Codabar Start/Stop Character Match Don’t Require Match Small Quiet Zones on Codabar Quiet Zones two sides Codabar Length Control...
  • Page 303 Page Parameter Default Your Setting Number GS1 DataBar™ Expanded Enable/Disable Disable GS1 DataBar™ Expanded GS1-128 Emulation Disable 2D component not GS1 DataBar™ Expanded 2D Component required GS1 DataBar™ Expanded Length Control Variable GS1 DataBar™ Expanded Set Length 1 GS1 DataBar™ Expanded Set Length 2 GS1 DataBar™...
  • Page 304 Page Parameter Default Your Setting Number Plessey Check Character Transmission Enable Plessey Length Control Variable Plessey Set Length 1 Plessey Set Length 2 CODE SELECTION - 2D SYMBOLOGIES 2D Maximum Decoding Time 350msec 2D Structured Append Disable 2D Normal/Inverse Symbol Control Normal Aztec Code Enable / Disable Disable...
  • Page 305 Page Parameter Default Your Setting Number PDF417 Set Length 1 PDF417 Set Length 2 2,710 Micro PDF417 Enable / Disable Disable Micro PDF AIM ID and Micro PDF417 Code 128 GS1-128 Emulation label type Micro PDF417 Length Control Variable Micro PDF417 Set Length 1 Micro PDF417 Set Length 2 0366 QR Code Enable / Disable...
  • Page 306 Page Parameter Default Your Setting Number RF Batch Mode Transmit Delay No Delay Ack Timeout Wait Forever Source Radio Address Transmission Do not include Source Radio Address Delimiter Character No Delimiter Character DIRECT RADIO AUTOLINK Unlink Label Required Link Timeout 2 Seconds Features for BT Models Only BT Security Mode...

  • Page 307: Sample Barcodes

    Appendix A Sample Barcodes The sample barcodes in this appendix are typical representations for their symbology types. 1D Bar Codes 12345 67890 UPC-A 3 4 5 67 8 9 0 1 2 3 4 0 EAN-13 123ABC Code 39 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 Code 128 12345678901231 Interleaved 2 of 5...
  • Page 308 Sample Barcodes Sample Barcodes — continued A020096020 Code 32 Codabar Code 93 Code 11 Gryphon™ I GD44XX/GBT4400...
  • Page 309 Sample Barcodes GS1 DataBar™ (RSS) GS1 DataBar™ GS1 DataBar™ variants must be enabled to read the barcodes below (see Omnidirectional on page 176 10293847560192837465019283746029478450366523 (GS1 DataBar™ Expanded Stacked) 1234890hjio9900mnb (GS1 DataBar™ Expanded) 08672345650916 (GS1 DataBar™ Limited) GS1 DataBar™-14 55432198673467 (GS1 DataBar™ Omnidirectional Truncated) 90876523412674 (GS1 DataBar™...

  • Page 310: D Bar Codes

    Sample Barcodes 2D Bar Codes Aztec Datmatrix China Sensible MaxiCode Test Message PDF 417 Micro PDF 417 Test Message Car Registration Micro QR Code QR Code Numbers UCC Composite Gryphon™ I GD44XX/GBT4400...

  • Page 311: Keypad

    Appendix D Keypad Use the bar codes in this appendix to enter numbers as you would select digits/characters from a keypad. Product Reference Guide...
  • Page 312 Gryphon™ I GD44XX/GBT4400...

  • Page 313: Scancode Tables

    Appendix E Scancode Tables Control Character Emulation Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms. Control Character 00 : Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located from 0x80 to 0xA1.

  • Page 314: Interface Type Pc At Ps/2, Usb-Keyboard Or Usb-Keyboard For Apple

    Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE Table 53. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+D C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W...
  • Page 315 Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE — cont. Table 54. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑ S+ Tab Enter Pg Up ...

  • Page 316: Interface Type Pc At Ps/2 Alt Mode Or Usb-Keyboard Alt Mode

    Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode Table 55. Scancode Set When Control Character is 00 or 01 Alt+000 Alt+001 Alt+002 Alt+003 Alt+004 Alt+005 Alt+006 Alt+007 Alt+010 Alt+011 Alt+012 Alt+014 Alt+015 Enter Alt+016 Alt+017 Alt+018 Alt+019 Alt+020 Alt+021 Alt+022...
  • Page 317 Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode — cont. Table 56. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑ S+ Tab Enter Pg Up ...

  • Page 318: Digital Interface

    Digital Interface Table 57. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...

  • Page 319: Ibm31Xx 102-Key

    IBM31xx 102-key Table 59. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...

  • Page 320: Ibm Xt

    IBM XT Table 61. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+H C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...

  • Page 321: Microsoft Windows Codepage 1252

    Microsoft Windows Codepage 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy components of Microsoft Windows in English and some other Western languages. Product Reference Guide...
  • Page 322 NOTES Gryphon™ I GD44XX/GBT4400...

  • Page 323: Ascii Chart

    ASCII Chart ASCII ASCII ASCII ASCII Hex No. Hex No. Hex No. Char. Char. Char. Char. ‘ “ & ’ < >...
  • Page 324 Telephone: 49 (0) 61 51/93 58-0 Telephone: (65) 6435-1311 germany.scanning@datalogic.com singapore.scanning@datalogic.com India Iberia Datalogic Scanning India Datalogic Scanning SAS Sucursal en España Telephone: 91- 22 - 64504739 Telephone: 34 91 746 28 60 india.scanning@datalogic.com spain.scanning@datalogic.com Italy United Kingdom Datalogic Scanning SpA Datalogic Scanning LTD Telephone: [39] (0) 39/62903.1...

Table of Contents
