Summary of Contents for Chauvet Hurricane 1101
- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What Is Included ..........................3 Unpacking Instructions ........................3 Claims ............................... 3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance .......................... 4 Safety Notes ............................. 4 2. -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with Chauvet within 7 days of delivery. Text Convention Meaning 1—512... -
Page 4: Product At A Glance
Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. FCQ (Fog Cleaner Quart) was specifically developed by Chauvet to clean your Hurricane™ 1101. Make sure you use FCQ regularly, no longer than 90 days between cleanings, to increase the life of your fogger. -
Page 5: Introduction
2. I NTRODUCTION Overview Manual Fog Button Safety Loop Fog Fluid Tank Low Fluid Indicator Fluid Level Indicator Manual Controller Socket Wireless Controller Socket Power In Fuse Holder Rear Panel View Hurricane 1101 User Manual Rev. 1 Page 5 of 5... -
Page 6: Dimensions
Dimensions 7 in 180 mm 8.8 in 222 mm 4.8 in 124 mm 9.3 in 9.6 in 235 mm 243 mm 9.9 in 251 mm 7 in 180 mm Page 6 of 6 Hurricane™ 1101 User Manual Rev. 1... -
Page 7: Setup
3. S ETUP AC Power This Hurricane 1101 has a fixed voltage power supply and it can work with an input voltage of either 120 VAC, 60 Hz or 230 VAC, 50 Hz, depending on the specific model. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Mounting
Mounting Clamp Safety Cable (such as CLP-15 clamp (works with CH-05 from Chauvet) from Chauvet) Fog Fluid Tank Mounting Bracket Safety... -
Page 9: Operation
4. O PERATION Remote or The Hurricane™ 1101 can be operated manually, or with the included manual fog controller. Two other optional remote controls are also available: a timer remote (FC-T) Manual and a wireless remote (FC-W). The Manual button is located on the rear of the unit. Operation See the product Overview. -
Page 10: Technical Information
NFORMATION Fogger Do not allow the fogger to become clogged. After every 40 hours of continuous operation, use CHAUVET® Fog Cleaner Quart (FCQ) through the system to prevent the Maintenance accumulation of particulate matter in the heating element. The recommended cleaning procedure is as follows. -
Page 11: General Troubleshooting
Turn off the product for 5 seconds, and then turn it No output or short output back on. Repeat as necessary. Note: After more than 10 attempts, contact Customer Service. Clean thoroughly with CHAUVET® FCQ. For full Incorrect fluid instructions, see Fogger Maintenance. Refill with CHAUVET®... -
Page 12: Technical Specifications
7. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 9.9 in (252 mm) 9.6 in (243 mm) 8.8 in (222 mm) 7.4 lb (3.4 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Supply Type Range Voltage Selection Power... -
Page 13: Returns
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Hurricane 1101 User Manual Rev. -
Page 14: Contact Us
(954) 577-4455 Email: tech@chauvetlighting.com Fax: (954) 929-5560 Toll free: (800) 762-1084 World Wide Web www.chauvetlighting.com UNITED KINGDOM AND IRELAND - Chauvet Europe Ltd. General Information Technical Support Address: Unit 1C Email: uktech@chauvetlighting.com Brookhill Road Industrial Estate Pinxton, Nottingham, UK World Wide Web www.chauvetlighting.co.uk...
