SpeedDome
Programmable Dome
Camera
Quick Reference Guide
RASO and RASI Series
Contents
About this Guide.................................................... 1
Dome Features...................................................... 2
Controlling the Zoom Setting................................. 2
Systems............................................................ 3
Supported Dome Commands................................ 4
Declarations .......................................................... 6
© Sensormatic 2004
RASO AND RASI SERIES SPEEDDOME OPTIMA
QUICK REFERENCE GUIDE
Optima
®
About this Guide
This Quick Reference Guide explains the functions
supported by the SpeedDome Optima
programmable dome camera. It is intended to
supplement information included in the operator's
manual for your video controller or matrix switching
system.
If you need assistance...
Contact your American Dynamics representative.
1 of 6
8000-2692-13, REV. B1
Advertisement
Related Manuals for American Dynamics RASO series
Summary of Contents for American Dynamics RASO series
-
Page 1: Table Of Contents
Quick Reference Guide system. If you need assistance... Contact your American Dynamics representative. RASO and RASI Series Contents About this Guide............ 1 Dome Features............2 Controlling the Zoom Setting......... 2 Supported Controllers and Matrix Switching Systems............ -
Page 2: Dome Features
Table 1: Protocols and supported features Dome Features Feature SensorNet RS-422 Manchester The SpeedDome Optima programmable dome Maximum 96 (a) 96 (a) Presets camera provides the following features: Maximum • 22X optical zoom/4X digital zoom Patterns (88X maximum total zoom). Resume Auto Focus •... -
Page 3: Supported Controllers And Matrix Switching Systems
Supported Controllers and Matrix Switching Systems SpeedDome Optima may be used with the following controllers and matrix switching systems. See notes below for specific limitations or restrictions. VM16 / AD2150 / ADTT16 VM32 / AD32 AD2350 MegaPower AD1650 AD168 AD2050 MegaPower (1, 2) (1, 2) -
Page 4: Supported Dome Commands
Supported AD Keyboards Dome Function Keyboard Command Go to Pattern #2 18 Call Shot For systems using AD keyboards, the following keys are used when Set Preset or Call Preset is Go to Pattern #3 19 Call Shot referenced: Run Pattern #1 21 Call Shot Run Pattern #2 22 Call Shot... - Page 5 AD168 Matrix Switcher/ MegaPower 48 Matrix Switcher/ Controller System Controller System See Supported AD Keyboards for button names See Supported AD Keyboards for button names used on specific keyboards. used on specific keyboards. Dome Function Keyboard Command Dome Function Keyboard Command Define Pattern # 1 121 - F2 Define Pattern # 1...
-
Page 6: Declarations
Run Pattern 3 72 Call Preset Reset Dome 65 Set Preset Thank you for using American Dynamics products. We support our products through an extensive and worldwide network of dealers. The Resume Auto Focus / Auto 66 Call Preset dealer, through whom you originally purchased this product, is your Iris point of contact if you have a need for service or support.
