Toshiba Satellite E300 series User Manual

Hide thumbs Also See for Satellite E300 series:
Table of Contents

Advertisement

Quick Links

User's Manual
Satellite E300/E305 Series

Advertisement

Table of Contents
loading

Related Manuals for Toshiba Satellite E300 series

Summary of Contents for Toshiba Satellite E300 series

  • Page 1 User’s Manual Satellite E300/E305 Series...

  • Page 2: Table Of Contents

    Table of Contents Copyright..........v Disclaimer .
  • Page 3 Optical disc drives ........3-6 TOSHIBA VIDEO PLAYER ....... . . 3-16 Using WinDVD BD for TOSHIBA .
  • Page 4 Legal Footnotes Appendix C Non-applicable Icons ........C-1 CPU .

  • Page 5: Copyright

    Intel Corporation. Windows, Microsoft and Windows logo are registered trademarks of Microsoft Corporation. Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license. Memory Stick, Memory Stick Duo, Memory Stick PRO, Memory Stick PRO Duo and Memory Stick Micro are trademarks or registered trademarks of Sony Corporation.

  • Page 6: Fcc Information

    Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s external monitor port, Universal Serial Bus...

  • Page 7: Video Standard Notice

    Note that Canadian Department of Communications (DOC) regulations provide, that changes or modifications not expressly approved by TOSHIBA Corporation could void your authority to operate this equipment. This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

  • Page 8: Following Information Is Only Valid For Eu-Member States

    For more detailed information about the collection and recycling programmes available in your country, please visit our website (http://eu.computers.toshiba-europe.com) or contact your local city office or the shop where you purchased the product. Disposal of batteries and/or accumulators...

  • Page 9: Reach - Compliance Statement

    The new European Union (EU) chemical regulation, REACH (Registration, Evaluation, Authorization and Restriction of Chemicals), entered into force on 1 June 2007. Toshiba will meet all REACH requirements and is committed to provide our customers with information about the chemical substances in our products according to REACH regulation.

  • Page 10: Precautions

    Hitachi-LG Data Storage, Inc. 22-23,KAIGAN 3-CHOME, MINATO-KU,TOKYO,108-0022 JAPAN *1 “Panasonic Communications Co., Ltd.” or “Panasonic System Networks Co., Ltd.” 1. Panasonic Communications ■ DVD Super Multi with Double Layer Recording UJ8A0 ■ BD-Writer UJ240 2. HITACHI-LG Data Storage ■ BD-Combo CT30F Precautions CAUTION: This appliance contains a laser system and is classified as a...

  • Page 11: Preface

    Preface Congratulations on your purchase of this computer. This powerful notebook computer provides excellent expansion capability, includes multimedia functionality, and is designed to provide years of reliable, high-performance computing. This manual tells how to set up and begin using your computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
  • Page 12 Key operation Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, CTRL + C means you must hold down CTRL and at the same time press C.

  • Page 13: General Precautions

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.

  • Page 14: Creating A Computer-Friendly Environment

    Creating a computer-friendly environment Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer. Leave enough space around the computer and other equipment to provide adequate ventilation.

  • Page 15: Pressure Or Impact Damage

    Pressure or impact damage Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Mobile phones Please be aware that the use of mobile phones can interfere with the audio system.

  • Page 16: Equipment Checklist

    Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA. Equipment checklist Carefully unpack your computer, taking care to save the box and packaging materials for future use.
  • Page 17 Getting Started Software ® The following Windows operating system and utility software are pre- installed. ■ Windows 7 ■ TOSHIBA Recovery Media Creator ■ TOSHIBA VIDEO PLAYER ■ TOSHIBA Assist ■ TOSHIBA ConfigFree™ ■ TOSHIBA HDD Protection ■ TOSHIBA Disc Creator ■...

  • Page 18: Connecting The Ac Adaptor

    Getting Started ■ Use a virus-check program and make sure it is updated regularly. ■ Never format storage media without checking its content - formatting destroys all stored data. ■ It is a good idea to periodically back up the internal hard disk drive or other main storage device to external media.
  • Page 19 ■ Always use the TOSHIBA AC adaptor that was included with your computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury.

  • Page 20: Opening The Display

    Getting Started 1. Connect the power cord to the AC adaptor. Figure 1-1 Connecting the power cord to the AC adaptor (2-pin plug) Figure 1-2 Connecting the power cord to the AC adaptor (3-pin plug) Either a 2-pin or 3-pin adaptor/cord will be included with the computer depending on the model.
  • Page 21 Getting Started While holding down the palm rest with one hand so that the main body of the computer is not raised, slowly lift the display panel - this will allow the angle of the display panel to be adjusted to provide optimum clarity. 1.

  • Page 22: Turning On The Power

    Getting Started Turning on the power This section describes how to turn on the power - the Power indicator will then indicate the status. Please refer to the Monitoring of power condition section in Chapter 5, Power and Power-Up Modes for more information. ■...

  • Page 23: Sleep Mode

    Getting Started 1. If you have entered data, either save it to the hard disk drive or to other storage media. 2. Make sure all disk/disc activity has stopped before removing the CD/DVD/BD or floppy diskette. ■ Make sure the HDD/ODD indicator is off. If you turn off the power while a disk (disc) is being accessed, you may lose data or damage the disk.
  • Page 24 Getting Started ■ When the AC adaptor is connected, the computer will go into Sleep Mode according to the settings in the Power Options (to access it, Start → Control Panel → System and Security → Power Options). ■ To restore the operation of the computer from Sleep Mode, press and hold the power button or any key on the keyboard for a short amount of time.

  • Page 25: Hibernation Mode

    Getting Started Sleep Mode limitations Sleep Mode will not function under the following conditions: ■ Power is turned back on immediately after shutting down. ■ Memory circuits are exposed to static electricity or electrical noise. Hibernation Mode The Hibernation Mode feature saves the contents of memory to the hard disk drive when the computer is turned off so that the next time when it is turned on, the previous state is restored.

  • Page 26: Restarting The Computer

    Getting Started 4. Enable the desired Hibernation Mode settings for When I press the power button and When I close the lid. 5. Click the Save changes button. Data save in Hibernation Mode When you turn off the power in Hibernation Mode, the computer will take a moment to save the current data in memory to the hard disk drive.

  • Page 27: Chapter 2 The Grand Tour

    Chapter 2 The Grand Tour This chapter identifies the various components of the computer - it is recommended that you become familiar with each before you operate the computer. Legal Footnote (Non-applicable Icons) For more information regarding Non-applicable Icons, please refer to the Legal Footnotes section in Appendix C.
  • Page 28 The Grand Tour Stereo speakers The speakers emit sound generated by your software as well as audio alarms, such as low battery condition, generated by the system. Memory media slot This slot lets you insert an SD™/SDHC™/ SDXC™ memory card, miniSD™/microSD™ Card, Memory Stick™...

  • Page 29: Left Side

    The Grand Tour Left side The following figure shows the computer’s left side. 1. DC IN 19V jack 4. Universal Serial Bus (USB 3.0) port 2. LAN jack 5. Optical disc drive 3. Universal Serial Bus (USB 2.0) port Product appearance may vary depending on the model you have purchased. Figure 2-2 The left side of the computer DC IN 19V jack The AC adaptor connects to this jack in order to...

  • Page 30: Right Side

    The Grand Tour Right side The following figure shows the computer’s right side. 1. Headphone jack 5. External monitor port 2. Microphone jack 6. Cooling vents 3. Universal Serial Bus (USB 2.0) port 7. Security lock slot 4. HDMI port Product appearance may vary depending on the model you have purchased.

  • Page 31: Underside

    The Grand Tour HDMI port HDMI port can be connected with Type A connector HDMI cable. HDMI cable can transmit video and audio signals. In addition, it can send and receive control signals. External monitor This port provides 15-pin, analog VGA port. This port port allows you to connect an external monitor to the computer.
  • Page 32 The Grand Tour Battery release latch Slide and hold this latch into its “Unlock” position in order to release the battery pack for removal. For more detailed information on removing the battery pack please refer to Chapter 5, Power and Power-Up Modes.

  • Page 33: Front With The Display Open

    The Grand Tour Front with the display open This section shows the computer with the display panel open. In order to open the display, lift the display panel up and position it at a comfortable viewing angle for you. Figure 2-5 The front of the computer with the display panel open 1.
  • Page 34 You can use it for video chatting or video conferences using a communication tool such as Windows Live Messenger. TOSHIBA Web Camera Application will help you to add various video effects to your video or photograph.
  • Page 35 The Grand Tour Display Power Saving Technology Intel chipset model may include the Display Power Saving Technology feature that can save the computer's power consumption by optimizing picture contrast on the internal LCD. This feature can be used if the computer is: ■...
  • Page 36 Utility. This button changes “On” and “Off” of eco Mode. When eco Mode is “On”, the icon turns green. When eco Mode is “Off”, the icon turns gray. The TOSHIBA eco Utility is not supported by ® Windows XP operating system.

  • Page 37: Internal Hardware Components

    The processor type varies depending on model. To check which type of processor is included in your model, open the TOSHIBA PC Diagnostic Tool Utility by clicking Start → All Programs → TOSHIBA → Utilities → PC Diagnostic Tool.
  • Page 38 The Grand Tour Legal Footnote (Memory (Main System)) For more information regarding Memory (Main System), please refer to the Legal Footnotes section in Appendix C. Graphics controller The graphics controller maximizes display performance. Legal Footnote (Graphics Processor Unit (“GPU”)) For more information regarding Graphics Processor Unit (“GPU”), please refer to the Legal Footnotes section in Appendix C.

  • Page 39: Chapter 3 Operating Basics

    Chapter 3 Operating Basics This chapter describes the basic operations of your computer, highlights the precautions that should be taken when using it. The Touch Pad To use the Touch Pad, simply touch and move your fingertip across it in the direction you want the on-screen pointer to go.

  • Page 40: The Keyboard

    Operating Basics You can also tap the Touch Pad to perform functions similar to those of the left button on a standard mouse. Click: Tap once Double-click: Tap twice Drag and drop: Tap to select the item(s) you want to move, leave your finger on the Touch Pad after the second tap and then move the item(s) to their new destination.

  • Page 41: Function Keys

    Operating Basics 1. CAPS LOCK indicator Figure 3-3 CAPS LOCK indicator CAPS LOCK This indicator glows green when letter keys are locked into their uppercase format. Function keys The function keys (not to be confused with the special FN key) are the twelve keys at the top of your keyboard - these keys function differently from other keys.

  • Page 42: Hot Key Functions

    FN + 1 and FN + 2 functions are supported by applications such as Microsoft Internet Explorer, Microsoft Office, Windows Media ® ® Player and Adobe ® Reader ® ■ Hot keys feature will be not available if you uninstall TOSHIBA Flash Cards. User’s Manual...

  • Page 43: Fn Sticky Key

    Off Indicators and keyboard backlight are always turned off. FN Sticky key You can use the TOSHIBA Accessibility Utility to make the FN key sticky, that is, you can press it once, release it, and then press an “F Number” key.

  • Page 44: Optical Disc Drives

    Operating Basics 3. Click Apply. The selected application will be launched the next time you press that button. Should you want to delete the information related to a specific button, click Factory Default. 4. Click OK. Windows special keys The keyboard provides two keys that have special functions in Windows, the Windows Start Button key activates the Start menu while the application key has the same function as the secondary (right) mouse button.

  • Page 45: Using Optical Disc Drives

    Operating Basics Using optical disc drives The full-size drive provides high-performance execution of disc based programs. You can run either 12 cm (4.72”) or 8 cm (3.15”) discs without an adaptor. When the computer is accessing a disc, an indicator on the drive glows.
  • Page 46 Operating Basics When the disc tray is fully opened, the edge of the computer will extend slightly over the disc tray. Therefore, you will need to turn the disc at an angle when you place it in the disc tray. After seating the disc, however, make sure it lies flat.

  • Page 47: Writable Discs

    TOSHIBA Disc Creator and Corel Digital Studio are provided as writing software with this computer. Corel Digital Studio can be used to write files in video format. TOSHIBA Disc Creator can be used to write data. You can use the DVD Super Multi drive or BD-Combo drive to write data to either CD-R, CD-RW, DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer), DVD+RW, DVD-RAM or DVD-R (Dual Layer) discs.

  • Page 48: Important Message

    RAM, BD-R, BD-R (Dual Layer), BD-RE or BD-RE (Dual Layer) media, however, it must be noted that disc quality can affect write or rewrite success rates. Please also be aware that in no event does TOSHIBA guarantee the operation, quality or performance of any disc.
  • Page 49 Operating Basics DVD-R: DVD Specifications for Recordable Disc for General Version 2.0 TAIYO YUDEN Co.,Ltd. (for 8x and 16x speed media) MITSUBISHI KAGAKU MEDIA CO., LTD. (for 8x and 16x speed media) Hitachi Maxell,Ltd. (for 8x and 16x speed media) DVD-R (Dual Layer): MITSUBISHI KAGAKU MEDIA CO., LTD.

  • Page 50: When Writing Or Rewriting

    ■ Keep mobile phones and other wireless communication devices away from the computer. TOSHIBA Disc Creator Please be aware of the following limitations when you use the TOSHIBA Disc Creator: ■ DVD Video cannot be created using TOSHIBA Disc Creator.
  • Page 51 TOSHIBA Disc Creator cannot record in packet format. ■ You might not be able to use the “Disc Backup” function of TOSHIBA Disc Creator to back up a DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW disc that was made with other software on a different optical media recorder.

  • Page 52: Data Verification

    Simplified steps for making a Labelflash DVD: 1. Insert a Labelflash disc in optical disc drive. Set PRINTING SIDE for underside. 2. Click Start → All Programs → Corel Digital Studio for TOSHIBA → Corel Digital Studio for TOSHIBA → Create. 3. Click Create Disc Label.

  • Page 53: Important Information For Use

    ■ Opening the Corel Digital Studio Manual Start → All Programs → Corel Digital Studio for TOSHIBA → User Manual → Corel Digital Studio User Manual Important information for use Note the following limitations when you write Video DVD or Blu-ray disc movie, file convert or playback files: 1.

  • Page 54: Toshiba Video Player

    Some BD-Combo drives for personal computers or other Blu-ray disc players may not be able to read BD-R/RE discs. TOSHIBA VIDEO PLAYER Please be aware of the following limitations when you use the TOSHIBA VIDEO PLAYER: Notes on use ■...
  • Page 55 Center” to play DVD. Display Devices & Audio ■ “TOSHIBA VIDEO PLAYER” will only run when “Colors” is set to “True color (32 bit)”. Click Start → Control Panel → Appearance and Personalization → Display → Adjust resolution, click “Advanced settings”, select “Monitor”...
  • Page 56 2D home video and other 2D contents you created, in 3D according to your personal preferences. ■ The “TOSHIBA VIDEO PLAYER” is set by default in the 2D format. By pressing the 2Dto3D conversion function button, you decide to activate the 2Dto3D conversion function and therefore decide to watch your 2D content in 3D.
  • Page 57 When a DVD-Video disc is set in the DVD drive (for models with DVD Super Multi drive), the following application selection screen may appear. If this occurs, select Play DVD movie (using TOSHIBA VIDEO PLAYER), to launch the TOSHIBA VIDEO PLAYER. Figure 3-7 Application selection screen User’s Manual...

  • Page 58: Using Windvd Bd For Toshiba

    Operating Basics 2. Select Start → All Programs → TOSHIBA VIDEO PLAYER → TOSHIBA VIDEO PLAYER to start “TOSHIBA VIDEO PLAYER”. Operating TOSHIBA VIDEO PLAYER Notes on Using “TOSHIBA VIDEO PLAYER”. ■ Screen display and available features may vary amongst DVD-Videos and scenes.
  • Page 59 This product does not play HD DVD discs. Blu-ray discs with high- definition content are required for HD viewing. 3D playback feature WinDVD BD for TOSHIBA supports the playback of Blu-ray 3D discs on external 3D display/TV using HDMI 1.4. Before playback Blu-ray 3D discs, configure the 3D Playback.
  • Page 60 Starting WinDVD BD for TOSHIBA Use the following procedure to start “WinDVD BD for TOSHIBA”. 1. When a Blu-ray disc is set in the BD drive, WinDVD BD for TOSHIBA starts automatically. 2. Select Start → All Programs → Corel → Corel WinDVD BD to start “WinDVD BD for TOSHIBA”.

  • Page 61: Wireless Communications

    Operating Basics Wireless communications The computer’s wireless communication function supports some wireless communication devices. Only some models are equipped with both Wireless LAN and Bluetooth functions. ■ Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a microwave oven or in areas subject to radio interference or magnetic fields.

  • Page 62: Card Specifications

    ■ TOSHIBA is not liable for the loss of data due to eavesdropping or illegal access through the wireless LAN and the damage thereof. Card Specifications Form Factor PCI Express Mini Card ■...

  • Page 63: Radio Characteristics

    Operating Basics Radio Characteristics Radio Characteristics of Wireless LAN module may vary according to: ■ Country/region where the product was purchased ■ Type of product Wireless communication is often subject to local radio regulations. Although Wireless LAN and wireless networking products have been designed for operation in the license-free 2.4GHz and 5GHz band, local radio regulations may impose a number of limitations to the use of wireless communication equipment.

  • Page 64: Lan

    This Bluetooth Stack is based on the Bluetooth Version 1.1/1.2/2.0+EDR/2.1+EDR/3.0/3.0+HS specification. However, TOSHIBA cannot confirm the compatibility between any computing products and/or other electronic devices that use Bluetooth, other than TOSHIBA notebook computers. Release Notes related to the Bluetooth Stack for Windows by TOSHIBA 1.

  • Page 65: Lan Cable Types

    Operating Basics ■ The Wake-up on LAN function consumes power even when the system is off. Leave the AC adaptor connected while using this feature. ■ The Link speed (10/100 megabits per second) changes automatically depending on the network conditions (connected device, cable or noise and so on).

  • Page 66: Optional Devices

    Operating Basics Connecting the LAN cable To connect the LAN cable, follow the steps as detailed below: ■ Connect the AC adaptor before connecting the LAN cable. The AC adaptor must remain connected during LAN use. If you disconnect the AC Adaptor while the computer is accessing a LAN, the system may hang up.

  • Page 67: Peripheral Devices

    Other ■ Security lock ■ Optional TOSHIBA accessories Memory media slot The computer is equipped with a memory media slot that can accommodate some kinds of memory media with various memory capacities so that you can easily transfer data from devices, such as digital cameras and Personal Digital Assistants.

  • Page 68: Memory Media

    Operating Basics microSD card adaptor and microSD card Secure Digital (SD) Card MultiMediaCard xD picture card Memory Stick (MMC) Figure 3-9 Examples of memory media Memory media This section provides the important safety precautions in order to handle your memory media. Points to note about the SD/SDHC/SDXC memory card SD/SDHC/SDXC memory cards comply with SDMI (Secure Digital Music Initiative), which is a technology adopted to prevent unlawful copy or...

  • Page 69: Memory Card Care

    Operating Basics Formatting an SD/SDHC/SDXC memory card SD/SDHC/SDXC memory cards are sold already formatted in conformity to specific standards. If you reformat an SD/SDHC/SDXC memory card, be sure to reformat it with a device such as digital camera or digital audio player that uses the SD/SDHC/SDXC memory cards, not with the format command provided within Windows.

  • Page 70: Inserting A Memory Media

    Operating Basics Inserting a memory media The following instructions apply to all types of supported media devices. To insert a memory media, follow the steps as detailed below: 1. Turn the memory media so that the contacts (metal areas) are face down.

  • Page 71: External Monitor

    Operating Basics ■ Make sure the data transfer is completed before you remove the memory media or shut down the computer. If you remove the memory media or turn off the power while the computer is accessing the memory media, you may lose data or damage the media. ■...
  • Page 72 Operating Basics Please refer to the The Keyboard section for further details on using hot keys to change the display setting. Do not disconnect the external monitor while in Sleep or Hibernation Mode. Turn off the computer before disconnecting the external monitor. When displaying desktop at external analog monitor, desktop is sometimes displayed on the center of the monitor with black bars around desktop (with small size).

  • Page 73: Settings For Display Video On Hdmi

    Operating Basics ■ When you connect a television or external monitor to the HDMI port and the display output device is set to HDMI. When you unplug the HDMI cable and re-plug it in please wait at least 5 seconds before you replug the HDMI cable again.

  • Page 74: Optional Toshiba Accessories

    1333) can easily be installed in the computer. ■ Use only memory modules approved by TOSHIBA. ■ Contact a TOSHIBA Authorized Service Provider to install or remove memory modules. ■ Do not try to install or remove memory modules by yourself.

  • Page 75: Sound System

    Operating Basics Sound System This section describes some of the audio control functions. Volume Mixer The Volume Mixer utility lets you control the audio volume for playback of devices and applications under Windows. ■ To launch the Volume Mixer utility, right click on the speaker icon on the Taskbar, and select Open Volume Mixer from the sub menu.

  • Page 76: Video Mode

    Operating Basics Starting SmartAudio Application To launch the SmartAudio, click Start → Control Panel → Hardware and Sound → SmartAudio. Opening SmartAudio Help Clicking “?” in the top right corner of the SmartAudio window will open the Help file in your selected language, or in English if your selected language is not supported.

  • Page 77: Computer Handling

    Operating Basics Computer Handling This section explains computer handling and maintenance. Cleaning the computer To help ensure long, trouble-free operation, keep the computer free of dust and dirt, and use care with all liquids around it. ■ Be careful not to spill liquids into the computer. If the computer does get wet, turn the power off immediately and let the computer dry completely - in these circumstance you should get the computer inspected by an authorized service provider in order to assess the scope of any...

  • Page 78: Heat Dispersal

    Operating Basics ■ Never transport your computer with any cards installed - this may cause damage to either the computer and/or the card resulting in product failure. ■ Always use a suitable carry case when transporting the computer. ■ When carrying your computer, be sure to hold it securely so that it does not fall or hit anything.

  • Page 79: Chapter 4 Utilities & Advanced Usage

    The TOSHIBA Accessibility utility provides support to movement impaired users when they Accessibility need to use the TOSHIBA Hot-key functions. In use, the utility allows you to make the FN key 'sticky', that is you can press it once, release it, and they press one of the “Function”...
  • Page 80 To access this utility, click Start → All Programs → TOSHIBA VIDEO PLAYER → TOSHIBA VIDEO PLAYER. For details on how to use TOSHIBA VIDEO PLAYER, see the help file. ■ Frame dropping, audio skipping or out of synch audio and video may occur during playback of some DVD Video titles.
  • Page 81 TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities that improve the ease and control of communication devices and network connections, help in the...
  • Page 82 Alert Utility the Disk Drive operating status and execute the system backup. To access the utility, click Start → All Programs → TOSHIBA → Utilities → HDD SSD Alert. TOSHIBA Service This application allows your computer to Station automatically search for TOSHIBA software...

  • Page 83: Special Features

    Chapter 4, Utilities & Advanced Usage. Special features The following features are either unique to TOSHIBA computers or are advanced features which make the computer more convenient to use. Access each function using the following procedures. *1 To access the Power Options, click Start → Control Panel → System and Security →...
  • Page 84 Utilities & Advanced Usage eco button Press this button to launch the TOSHBIA eco Utility. This button changes “On” and “Off” of eco Mode. When eco Mode is “On”, the icon turns green. When eco Mode is “Off”, the icon turns gray.
  • Page 85 Hard Disk Drive (HDD) Protection section for more details. ■ The TOSHIBA HDD Protection function does not guarantee that the hard disk drive will not be damaged. ■ During audio/video playback, when the computer detects a shock or vibration and the hard disk drive's head is parked, the playback might be temporarily interrupted.

  • Page 86: Using The Toshiba Sleep Utility

    Using the TOSHIBA Sleep Utility The TOSHIBA Sleep Utility is used for changing settings of the following function(s): ■ Sleep and Charge ■...

  • Page 87: Sleep And Music

    Utilities & Advanced Usage ■ When Sleep and Charge function is enabled, USB bus power (DC5V) will be supplied to compatible ports even when the power of the computer is turned OFF. USB bus power (DC5V) is similarly supplied to the external devices which are connected to the compatible ports.

  • Page 88: Starting The Toshiba Sleep Utility

    ■ Use the “Sleep and Music” feature with the display open. Starting the TOSHIBA Sleep Utility To start the utility, click Start → All Programs → TOSHIBA → Utilities → Sleep Utility. Enabling Sleep and Charge This utility can be used to enable and disable the Sleep and Charge function.

  • Page 89: Using Toshiba Web Camera Application

    You can enable Sleep and Music by selecting the “Enable Sleep and Music” check box and clicking the Apply button. There is no “Sleep and Music” option in the “TOSHIBA Sleep Utility” screen if your computer does not have this function.

  • Page 90: Using The Toshiba Face Recognition

    Video Quality. Using the TOSHIBA Face Recognition TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. The user can thus avoid having to enter a password or the like, which makes the login process easier.
  • Page 91 Toshiba does not guarantee that the face recognition utility will accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of the face recognition software or utility.
  • Page 92 How to launch the help file For further information on this utility, please refer to help file. 1. To launch the help file, click Start → All Programs → TOSHIBA → Utilities → Face Recognition Help. Windows Logon via TOSHIBA Face Recognition This section explains how to login to Windows with TOSHIBA Face Recognition.

  • Page 93: Hw Setup

    TOSHIBA HW Setup allows you to configure settings for General, Password, Display, Boot Priority, Keyboard, USB, LAN. If the supervisor password is set, access to the TOSHIBA HW Setup program can be prevented when the user password is used to log on to the computer.

  • Page 94: User Password

    Utilities & Advanced Usage Accessing HW Setup To start the utility, click the Windows Start button, point to All Programs, click TOSHIBA, click Utilities, and select HWSetup icon. HW Setup window The HW Setup window contains the following tabs: General, Password, Display, Boot Priority, Keyboard, USB, LAN and SATA.

  • Page 95: Power On Display

    Utilities & Advanced Usage 2. Click the OK button. The following message appears, allowing you to verify the password. Verify Password: 3. If character strings match, the password is registered click OK button. If they do not match, the following message appears. You must repeat from step 1.

  • Page 96: Boot Priority

    Utilities & Advanced Usage Boot Priority Boot Priority Options This option sets the priority for booting the computer. The Boot Priority Options setting will be like the following. You can override the settings and manually select a boot device by pressing one of the following keys while the computer is booting: Selects the USB diskette drive.
  • Page 97 Utilities & Advanced Usage 2. Use the up/down cursor keys to select boot device you want and press ENTER. ■ If a supervisor password is set, the menu above does not appear when you use the user password to start the computer. ■...

  • Page 98: Function Button

    Utilities & Advanced Usage Regarding Wake-up on LAN from sleep or hibernation, you must check the “Allow the device to wake the computer” check box within the LAN Device properties” (This feafure does not effect the Wake-up on LAN from sleep or hibernation).

  • Page 99: Toshiba Pc Health Monitor

    Once enabled, you may disable the TOSHIBA PC Health Monitor at any time by uninstalling the software via Uninstall a program in the Control Panel. Doing so will automatically delete all collected information from the HDD.

  • Page 100: Using The Hard Disk Drive (Hdd) Protection

    & Acceptance screen. Please carefully read the information displayed. Selecting ACCEPT and clicking OK will enable the program. By enabling the TOSHIBA PC Health Monitor software, you agree with these terms and conditions and to the use and sharing of the collected information. Once...

  • Page 101: Taskbar Icon

    TOSHIBA HDD Protection is disabled. TOSHIBA HDD Protection Properties You can change the TOSHIBA HDD Protection settings by using the TOSHIBA HDD Protection Properties window. To open the window, click Start → All Programs → TOSHIBA → Utilities → HDD Protection Settings.

  • Page 102: System Recovery

    Intensely shaking the computer or other subjecting it to strong impacts may cause damage to the computer. Details To open the Details window, click the Setup Detail button in the TOSHIBA HDD Protection Properties window. Detection Level Amplification When the AC adaptor is disconnected or the lid is closed, HDD Detection assumes that the computer will be carried and sets the detection level to the maximum for 10 seconds.

  • Page 103: Creating Recovery Media

    Utilities & Advanced Usage See the Windows Help and Support content for more information about Startup Repair. The System Recovery Options can also be run manually to repair problems. The procedure is as follows. Follow the instructions shown on the on- screen menu.
  • Page 104 2. While holding down F12 ( ) key on the keyboard, turn on your computer - when the TOSHIBA Leading Innovation >>> logo screen appears, release the F12 ( ) key. 3. Use the up and down cursor key to select the appropriate option from the menu according to your actual recovery media.
  • Page 105 However, if you have already created a “Recovery Media”, you can use it to restore the recovery partition. If you have not created “Recovery Media”, please contact TOSHIBA support for assistance. Restoring the pre-installed software from the Recovery hard disk drive A portion of the total hard disk drive space is configured as a hidden recovery partition.

  • Page 106: Chapter 5 Power And Power-Up Modes

    Chapter 5 Power and Power-Up Modes The computer's power resources include the AC adaptor, battery pack and any internal batteries. This chapter provides details on making the most effective use of these resources, and includes information on charging and changing batteries, tips for saving battery power, and information on the different power-up modes.

  • Page 107: Monitoring Of Power Condition

    Power and Power-Up Modes Table 5-1 Power conditions Power on Power off (no operation) Battery fully • Operates • No charge adaptor charged • No charge • LED: white connected • LED: white Battery partially • Operates • Quick charge charged •...

  • Page 108: Battery

    Power and Power-Up Modes Flashing amber The battery charge is low, the AC adaptor must be connected in order to recharge the battery. Or, Indicates a problem with the power supply. You should initially try plugging the AC adaptor into another power outlet - if it still does not operate properly, you should contact your reseller or dealer.

  • Page 109: Battery Pack

    <F1> continue, <F2> to setup You can change the Real Time Clock settings by turning on the computer and then pressing the F2 ( ) key when the TOSHIBA Leading Innovation >>> screen appears. Please refer to Chapter 6 Troubleshooting for further information.

  • Page 110: Charging The Batteries

    ■ The computer's RTC battery is a Ni-MH battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed. Dispose of the battery as required by local ordinances or regulations.

  • Page 111: Battery Charging Notice

    Power and Power-Up Modes Battery charging notice The battery may not begin charging immediately under the following conditions: ■ The battery is extremely hot or cold (if the battery is extremely hot, it might not charge at all). To ensure the battery charges to its full capacity, you should charge it at room temperature of between 5°...

  • Page 112: Maximizing Battery Operating Time

    Power and Power-Up Modes Maximizing battery operating time A battery's usefulness depends on how long it can supply power on a single charge, while how long the charge lasts in a battery depends on: ■ Processor speed ■ Screen brightness ■...

  • Page 113: Replacing The Battery Pack

    Power and Power-Up Modes 4. Connect the AC adaptor to the DC IN 19V jack of the computer, and to a wall outlet that is supplying power. The DC IN/Battery indicator should glow amber, however, in the event that DC IN/Battery indicator does not glow this indicates that power is not being supplied - check the connections for the AC adaptor and the power cord.

  • Page 114: Power-Up Modes

    Power and Power-Up Modes 6. Slide and hold the battery release latch (2) to disengage the battery pack and then remove it from the computer (3). 1. Battery lock 3. Battery pack 2. Battery release latch Figure 5-1 Releasing the battery pack Installing the battery pack To install a battery pack, follow the steps as detailed below: Do not touch the battery release latch while holding the computer or the...

  • Page 115: Panel Power On/Off

    Power and Power-Up Modes Panel power on/off You can set up your computer so that power is turned off automatically when you close the display panel, and turned on again when you open it. Please note that this function is only available for Sleep Mode or Hibernation Mode, not for Shut Down Mode.

  • Page 116: Troubleshooting

    In reality many problems can be solved simply, but a few may require help from TOSHIBA Support - if you find you need to consult others, be prepared to describe the problem in as much detail as possible.

  • Page 117: Analyzing The Problem

    Always try to make detailed notes of your observations and keep them in a permanent error log - this will help you to describe your problems to TOSHIBA Support. In addition, if a problem recurs, the log you have made will help to identify the problem faster.

  • Page 118: If Something Goes Wrong

    Before using a peripheral device or application software that is not an authorized Toshiba part or product, make sure the device or software can be used with your computer. Use of incompatible devices may cause injury or may damage your computer.

  • Page 119: Hardware And System Checklist

    Troubleshooting The computer will not start Make sure you attached the AC adaptor and power cord/cable properly or installed a charged battery. Press and hold the power button for at least 10 seconds. If you are using the AC adaptor, check that the wall outlet is working by plugging in another device, such as a lamp.

  • Page 120: Ac Power

    If the AC adaptor still does not power the computer, you should contact TOSHIBA Support. User’s Manual...
  • Page 121 However, if you do not believe the battery is at the end of its operating life, you should contact a TOSHIBA Support. Battery doesn’t power If you frequently recharge a partially charged...

  • Page 122: Real Time Clock

    RTC Power 1. Turn on the computer. Failure. Check system. 2. Press the F2 ( ) key when the TOSHIBA Then press [F2] Leading Innovation >>> screen key. appears - the BIOS setup application will load. 3. Set the date in the System Date field.

  • Page 123: Hard Disk Drive

    ROM/BD-ROM in the optical disc drive - if so remove it and try to start the computer again. If this has no effect, check the Boot Priority setting within the TOSHIBA HW Setup utility - please refer to the Boot Priority section in Chapter 4, Utilities &...

  • Page 124: Optical Disc Drive

    You cannot read a file Check to ensure the required file is actually on the memory media card that is inserted into the computer. If you are still unable to resolve the problem, contact TOSHIBA Support. User’s Manual...

  • Page 125: Pointing Device

    Troubleshooting Pointing device If you are using a USB mouse, you should also refer to both the device section in this chapter, and the documentation supplied with your mouse. Touch Pad Problem Procedure The Touch Pad does Check the Device Select settings. not work.

  • Page 126: Usb Mouse

    Touch Sensitivity. 8. Click OK button. 9. Click the OK button on Advanced feature setting screen. If you are still unable to resolve the problem, contact TOSHIBA Support. USB mouse Problem Procedure On-screen pointer does In this instance the system might be busy - Try...
  • Page 127 The elements of the mouse responsible for moves erratically detecting movement might be dirty - please refer to the documentation supplied with the mouse for instructions on how to clean it. If you are still unable to resolve the problem, contact TOSHIBA Support. User’s Manual 6-12...

  • Page 128: Usb Device

    Sleep and Charge function may be disabled. and Charge function”. Select the “Enable Sleep and Charge” check box in the TOSHIBA Sleep utility to enable this function. When there is a current overflow of the external device connected to the compatible port, USB bus power (DC5V) supply may be stopped for safety reasons.
  • Page 129 Troubleshooting Problem Procedure The battery depletes If Sleep and Charge function is enabled, the quickly even when I computer's battery will discharge during turned OFF the power hibernation or when the computer is turned off. of the computer. Connect the AC adaptor to the computer or disable the Sleep and Charge function.
  • Page 130 Chapter 3, Operating Basics for further information. Volume cannot be adjusted during Windows start up or shut down. If you are still unable to resolve the problem, contact TOSHIBA Support. External monitor Please also refer to Chapter 3, Operating Basics, and to the documentation supplied with your monitor for further information.

  • Page 131: Wireless Lan

    Display error occurs Check that the cable connecting the external monitor to the computer is firmly attached. If you are still unable to resolve the problem, contact TOSHIBA Support. Problem Procedure Cannot access LAN Check for a firm cable connection between the LAN jack and the LAN hub.

  • Page 132: Toshiba Support

    TOSHIBA Support. TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system so it is important that you investigate other sources of assistance first.

  • Page 133: Specifications

    Appendix A Specifications This appendix summarizes the computer’s technical specifications. Physical Dimensions 342 x 232 x 30.15/31.8 (battery part) Size millimeters (not including parts that extend beyond the main body). Environmental Requirements Conditions Ambient temperature Relative humidity Operating 5°C (41°F) to 35°C (95°F) 20% to 80% (noncondensing) Non-operating...

  • Page 134: Ac Power Cord And Connectors

    Appendix B AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Wire size: Minimum 0.75 mm...
  • Page 135 AC Power Cord and Connectors Denmark: DEMKO Norway: NEMKO Finland: FIMKO Sweden: SEMKO France: LCIE Switzerland: Germany: United Kingdom: In Europe, two conductors power cord must be VDE type, H05VVH2-F or H03VVH2-F and for three conductors power cord must be VDE type, H05VV-F.

  • Page 136: Legal Footnotes

    Appendix C Legal Footnotes This chapter states the Legal Footnotes information applicable to TOSHIBA computers. Non-applicable Icons Certain computer chassis are designed to accommodate all possible configurations for an entire product series. Therefore, please be aware that your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the computer chassis.

  • Page 137: Memory (Main System

    86°F) or >25°C (77°F) at high altitude (all temperature references are approximate and may vary depending on the specific computer model - please refer to your computer documentation or visit the Toshiba website at www.pcsupport.toshiba.com for details). CPU performance may also vary from specifications due to design configuration.

  • Page 138: Battery Life

    Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.

  • Page 139: Graphics Processor Unit ("Gpu

    Legal Footnotes Graphics Processor Unit (“GPU”) Graphics processor unit (“GPU”) performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

  • Page 140: Information For Wireless Devices

    The “Wi-Fi CERTIFIED™” logo is a certification mark of the Wi-Fi ® Alliance Bluetooth wireless technology Interoperability Bluetooth™ Cards from TOSHIBA are designed to be interoperable with any product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to: ■...

  • Page 141: Caution About Wireless Devices

    If you should experience any such problem, immediately turn off either one of your Bluetooth or Wireless LAN. Please visit http://www.pc.support.global.toshiba.com, if you have any questions about using Wireless LAN or Bluetooth Card from TOSHIBA. In Europe visit http://www.toshiba-europe.com/computers/tnt/bluetooth.htm Your Bluetooth product is not compatible with devices using Bluetooth Version 1.0B specifications.

  • Page 142: Radio Regulatory Information

    Information for Wireless Devices Radio Regulatory Information The Wireless device is must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. This product complies with the following radio frequency and safety standards.
  • Page 143 Information for Wireless Devices Russian Limited e.i.r.p 100mW. Permitted to use only Federation: for indoor applications, closed industrial and warehouse areas, and on board aircraft. 1. Permitted to use for local networks of aircraft crew service communications on board aircraft in area of the airport and at all stages of flight.
  • Page 144 Information for Wireless Devices Canada - Industry Canada (IC) This device complies with RSS 210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
  • Page 145 3. Contact an authorized TOSHIBA service provider if you have problems with interference caused by this product to Other Radio Stations. 2. Indication for Wireless LAN The indication shown below appears on this equipment.

  • Page 146: Device Authorization

    Information for Wireless Devices 3. Indication for Bluetooth The indication shown below appears on this equipment. (1) 2.4 : This equipment uses a frequency of 2.4 GHz. (2) FH : This equipment uses FH-SS modulation. (3) 1 : The interference range of this equipment is less than 10 m. : This equipment uses a frequency bandwidth from 2,400 MHz to 2,483.5 MHz.

  • Page 147: Radio Approvals For Wireless Devices

    Information for Wireless Devices The following restrictions apply: ■ Do not disassemble or modify the device. ■ Do not install the embedded wireless module into other device. When using the wireless device in any country or region, refer to the section Approved Countries/Regions for use in the online manual.
  • Page 148 Information for Wireless Devices Qatar Romania Saudi Arabia Serbia Singapore Slovak Republic Slovenia South Africa South Korea Spain Sri Lanka Sweden Switzerland Taiwan Thailand Turkey Ukraine Uruguay Venezuela Vietnam Yemen Zimbabwe ® Approved Countries/Regions for the Realtek RTL8188CE Wireless LAN 802.11n PCI-E NIC b/g/n Wireless LAN This equipment is approved to the radio standard by the countries/regions in the following table.
  • Page 149 Information for Wireless Devices Mozambique Namibia Netherlands New Zealand Norway Oman Pakistan Panama Papua New Paraguay Peru Philippines Guinea Poland Portugal Puerto Rico Qatar Romania Saudi Arabia Senegal Serbia Singapore Slovak Republic Slovenia South Africa South Korea Spain Sri Lanka Sweden Switzerland Taiwan...
  • Page 150 Information for Wireless Devices Germany Ghana Greece Guatemala Honduras Hong Kong Hungary Iceland India Indonesia Ireland Israel Italy Ivory Coast Japan Jordan Kazakhstan Kenya Kuwait Kyrgyzstan Latvia Lebanon Lesotho Liberia Liechtenstein Lithuania Luxembourg Libia Madagascar Malawi Malaysia Malta Mauritius Mexico Monaco Montenegro Morocco...
  • Page 151 Information for Wireless Devices ■ An ad-hoc mode is not available in 802.11n mode. ■ Available channel of Peer-to-peer connection by ad-hoc mode is Ch1- Ch11. ■ Connection with an access point by the Infrastructure mode is Ch1- Ch13. As of Dec. 2010 Australia Austria Austria...

  • Page 152: Glossary

    Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AC: Alternating current ANSI: American National Standards Institute AMT: Intel Active Management Technology ASCII: American Standard Code for Information Interchange BIOS: basic input/output system bps: bits per second CD: compact disc CD-ROM: Compact Disc Read-Only Memory...
  • Page 153 Glossary I/O: input/output IRQ: interrupt request KB: kilobyte LAN: local area network LCD: liquid crystal display LED: light emitting diode MB: megabyte MMC: multi media card OCR: optical character recognition (reader) PC: personal computer PCI: peripheral component interconnect RAM: random access memory RGB: red, green, and blue ROM: read only memory RTC: real time clock...
  • Page 154 Hard disk drive 2-11 replacing 5-8 automatic power off 4-6 Bluetooth 3-25 HDD Protection 4-22 Bluetooth Stack for Windows by HDD/ODD indicator 2-2 Toshiba 4-3 HDMI port 2-5 problems 6-16 Heat dispersal 3-40, 4-7 Boot Priority 4-18 Hibernation Mode 4-7 Hot keys 4-6...
  • Page 155 Memory card care 3-31 Real Time Clock 6-7 Memory SD/SDHC/SDXC Card 6-9 additional 3-36 Sound system 6-14 installing 3-33 TOSHIBA support 6-17 Memory media slot 2-2, 3-29 Touch Pad 6-10 using 3-29 USB device 6-13 Memory Stick 3-29 USB mouse 6-11...
  • Page 156 2-4 problems 6-14 Stereo speakers 2-2 TOSHIBA Assist 4-3 TOSHIBA ConfigFree 4-3 TOSHIBA Disc Creator 3-12, 4-4 TOSHIBA DVD-RAM Utility 4-4 TOSHIBA HDD Protection 4-7 TOSHIBA HDD/SSD Alert Utility 4-4 TOSHIBA PC Diagnostic Tool 4-1 TOSHIBA Service Station 4-4...

This manual is also suitable for:

Satellite e305 series

Table of Contents
