Rear side

33. Handle
34. IDT
™ system

Top parts

35. Pre-tension disk for threading and bobbin
winding
36. Bobbin winder thread guide
37. Thread guide
38. Bobbin winder thread guides
39. Bobbin winder thread cutter
40. Bobbin winder spindle
41. Auxiliary spool pin
42. Spool caps
43. Spool pin
44. Thread tension disk
45. Take-up lever
The accessory tray features special compartments
for presser feet and bobbins, plus space for needles
and other accessories. Store the accessories in the
tray so they are easily accessible.
46. Space for accessories
47. Removable tray for presser feet
48. Removable bobbin holder
38
35 36 37
45 44 43
46
47
48
33
34
39 40
42 41
