Introduction Congratulations on the purchase of this quality Defy gas stove. We trust that you will enjoy many years of trouble free use. Please read these instructions carefully before using the stove. This book will provide you with information on how to operate and care for your stove in order that you gain the maximum benefit from it.
• Extinguish all naked flames. • Do not operate any electrical appliances. • Ventilate the area. • Check for leaks as detailed on page 6 of this manual. • If odour persists contact your nearest Defy Service Centre for assistance. PAGE 3 OF16...
Installation Good ventilation is essential for the safe operation of the stove. Do not install the stove in a room below ground level unless it is open to ground level on at least one side. Prolonged extensive use of the stove may call for additional ventilation, for example an open window or dedicated extraction fan that exhausts to the outside.
Gas installation The necessary installation including gas and electrical connections must be carried out by qualified personnel in accordance with current and local regulations, since an installation by an unqualified person may constitute a hazard. The manufacturer declines liability for injury to persons or damage caused due to non compliance with these provisions.
Safety compliance with local requirements. Installer’s details are to be filled in on page 16 of this book Permanent installation. Important information for the user. The appliance may only be installed by a registered LP Gas installer. All registered installers are issued with a card carrying their registration number. Ask to be shown this card before allowing the installation to commence and make a note of the installer QCC number on page 16 of this book.
If the burn back occurs again, turn off the control valve to the affected burner, and consult the nearest Defy Service Centre for assistance . Do not use the appliance again until a service technician has declared it safe to do so.
JET CLEANING KIT This may be done using a Gas Jet Cleaning Kit which may be • purchased from your nearest Defy Service Centre. The kit comprises of a sliding T-bar (A) a socket (B) and a • ‘Classic pin’ (C).
Cleaning and Maintenance Switch off the gas supply before cleaning any part of the stove. Allow the stove to cool down before cleaning Never use steel wool or similar, sharp objects, vinegar or lemon to clean any part of the stove.
Buff to shine. Stubborn stains and Use a little Ceran cleaning Repeat several times rather discolouration paste. (available from Defy than resorting to a single Service Centres) aggressive cleaning method. Rinse and dry. Grease and fat splatter.
Specifications 4 BURNER MODEL 5 BURNER MODEL WIDTH 510 mm 760 mm HEIGHT 900 mm 900 mm DEPTH 650 mm 650 mm WEIGHT 28.87 Kg 35.68 Kg OVEN CAPACITY 62.3 L 97 L ENERGY RATING SMALL BURNER 1.7 kW 1.7 kW MEDIUM BURNER 2.0 kW 2.0 kW...
Problem solving guide —before calling for technical support Problem Possible cause The burners or oven The gas hose is twisted, bent or kinked. • will not light The burners are dirty or wet. • The gas cylinder is empty. • The burner caps are not fitted properly.
Defy Service Centres If you have followed the instructions and still have a problem, contact the nearest Defy Service Centre. They will be able to advise you on any aspect of the product or send a qualified technician to repair it.
Warranty This certificate is issued by DEFY APPLIANCES LIMITED manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
TO YOU?......................... or future reference, record the listed information in the space below. The Serial number may be found at the back of the stove SERIAL No DATE OF PURCHASE PURCHASED FROM Please register your product at www.defy.co.za PAGE 16 OF16...
