STOVE GAS 4B
DGS170 (8100016500)
DGS172 (8100017700)
Users Manual
PERMIT NUMBERS
1037-48/1-RSA-12-A
1037-51/1-RSA-12-A
069498
Advertisement
Table of Contents
Related Manuals for Defy DGS170
Summary of Contents for Defy DGS170
- Page 1 PERMIT NUMBERS 1037-48/1-RSA-12-A 1037-51/1-RSA-12-A STOVE GAS 4B DGS170 (8100016500) DGS172 (8100017700) Users Manual Record in the space below the listed information for future reference. SERIAL NUMBER………………………………………………………………………………….. DATE OF PURCHASE……………………………………………………………………………... PURCHASED FROM……………………………………………………………………………….. …………………………………………………………………………………………………………. The manufacturer strives for continuous improvement. For this reason, the text and illustrations in this manual are subject to change without notice.
- Page 2 Dear Customer, Your new Defy appliance was manufactured in a state of the art facility and has passed the strictest quality control procedures. Please read this manual carefully before installing and using your hob for the first time and then store it within easy reach for future reference. Safety instructions must be strictly followed.
-
Page 3: Table Of Contents
Table of contents 6 How to operate the oven 1 General information General information on baking & roasting 19 Overview Technical specifications How to use the gas oven Identification table How to operate the gas grill Package contents 7 Maintenance and care General information 2 Important safety instructions General safety... -
Page 4: General Information
1 General Information Overview Tray Top lid Front door Burner plate Lower part Control panel Handle Wire shelf The manufacturer strives for continuous improvement. For this reason, technical specifications, text and illustrations in this manual are subject to change without notice. -
Page 5: Technical Specifications
Technical specifications GENERAL External dimensions (height / width / depth) 940 mm / 595 mm / 690 mm Gas type / pressure LPG - G 30/2.8-3.0 kPa Total gas consumption 10.5 kW Burners Rear left Normal burner Power 2000 W Front left Rapid burner Power... -
Page 6: Important Safety Instructions
2 Important safety instructions This section contains safety Do not operate the appliance if • instructions that will help you it is defective or has any visible avoid risk of injury and damage. damage. All warranties will become void if Do not carry out any repairs or •... - Page 7 Do not place any flammable Make sure that the function • • materials close to the appliance knobs are switched off after as the sides may become hot every use. during use. When using Gas, ensure that • Do not place baking trays, the room is well ventilated.
-
Page 8: Safety For Children
Safety when working with gas Safety for children Any work carried out on gas Packaging materials are • • equipment and systems may dangerous to children. Keep only be done by authorised packaging materials in a safe qualified persons who are place out of reach of children. -
Page 9: If You Smell Gas
If odour persists contact your • Good combustion is required in • nearest Defy Service Centre for gas appliances. In case of assistance. incomplete combustion, carbon If you still smell gas leave the • monoxide (CO) might develop. -
Page 10: Action To Be Taken In Event Of A Burn Back
To turn off the control knob to the do this, turn off the fuse at affected burner, and consult the home. nearest Defy service technician, Ensure that the fuse rating is who will advise you. • compatible with the appliance. -
Page 11: Installation
3 Installation Installation is the buyer’s responsibility. The • The appliance can be used with cabinets on either manufacturer accepts no liability for this service. Any side but in order to have a minimum distance of action that the manufacturer has to take as a result of 400mm above hotplate level allow a side an erroneous installation will not be covered by the clearance of 65mm between the appliance and... -
Page 12: Important Information
IMPORTANT INFORMATION FOR THE INSTALLER. Ventilation Room size opening This appliance may only be installed by a gas installer registered with the South African qualification and Smaller than 5 m min. 100 cm certification committee (SAQCC). The appliance must to 10 m min. -
Page 13: Anti Tilt Mechanism
WARNING: in order to prevent tipping of the appliance, this stabilizing means must be installed. Refer to the instruction for installation. Anti-Tilt mechanism “A” 1 x Stability chain • “B” 1 x Stability hook with • anchor sleeve “A” is factory fitted at the rear •... -
Page 14: Electrical Installation
Electrical installation Gas connection This appliance must be earthed and the manufacturer and the seller do not accept responsibility for any DANGER Risk of explosion or damage due to incorrect installation or electrical poisoning by unprofessional connection. installation. This appliance must not be connected through an The appliance may be connected to earth leakage system. -
Page 15: Leakage Control
Leakage control at the connection point DANGER Risk of • Ensure that the control knobs on the control panel explosion and are in the OFF position. • Open the valve on the Gas bottle. suffocation! LPG • Using a small paint brush, apply some soapy bottles must not be water to all the connections. -
Page 16: Gas Conversion
Gas conversion Reduced gas flow rate setting for taps DANGER Risk of 1. Ignite the burner that is to be adjusted and turn the explosion or poisoning knob to the reduced position. 2. Remove the knob from the gas tap. by unprofessional 3. -
Page 17: Package Information
First cleaning of the appliance Check the general appearance of your The surface of the appliance may be appliance for any damages that might damaged by some detergents or cleaning materials. Do not use have occurred during transportation. aggressive detergents, cleaning powder, Do not place other items on the top of cream or any sharp objects. -
Page 18: Using The Hob
5 Using the hob General information about cooking Using the hobs DANGER 1 Normal burner 18–20 cm Risk of fire by overheated oil! 2 Auxiliary burner 12–16 cm When heating oil, do not leave it unattended. The above list denotes the recommended diameters Never try to extinguish a fire with of pots to be used on related burners. -
Page 19: How To Operate The Oven
6 How to operate the oven General information on baking & roasting 3. Press ignition button and release it again. 4. Keep the gas oven control knob pressed for 3 to WARNING: Hot surfaces may cause 5 seconds. burns! Do not touch the hot surfaces of »... -
Page 20: Maintenance And Care
Cleaning • If required, the cleaning of the valves should only Cleaning the Exterior be carried out by a qualified Defy technician. i.e. Use a damp soapy cloth and avoid the use of • Burner not functioning correctly. -
Page 21: Cleaning The Oven
This may be done using a Gas Jet Cleaning Kit which may be • purchased from your nearest Defy Service Centre. The kit comprises of a sliding T-bar (A) a socket (B) and a •... -
Page 22: Troubleshooting
8 Troubleshooting Problem solving guide—before calling for technical support Oven emits steam when it is in use: It is normal that steam escapes during operation. This is not a fault. Water drops occur during cooking: Steam that arises during cooking can condense and form water droplets when it comes into contact with cold surfaces of the appliance. -
Page 23: Service Centres
0082 Nosso Show Room Tel: 012 377 8300 Av: da Industrias, Parcela No.735 * 735A Pretoria.Service@defy.co.za Machava, Maputo OTHER AREAS ARE SERVICED BY OVER 200 AUTHORISED SERVICE AGENTS. PLEASE CONSULT THE NEAREST REGIONAL DEFY SERVICE CENTRE FOR DETAILS. Page 23... -
Page 24: Warranty
10 Warranty This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
