  • Page 1: Technical Reference

    SY-5EMA Super 7 Mainboard ************************************************ ® Pentium Class CPU supported ETEQ82C663 PCI/AGP Mainboard ATX Form Factor ************************************************ User's Guide & Technical Reference...

  • Page 2: About This Guide

    It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.

  • Page 3: Table Of Contents

    Table of Contents SY-5EMA Table of Contents SY-5EMA MAINBOARD LAYOUT ............1 CHAPTER 1 INTRODUCTION............2 KEY FEATURES ............2 HANDLING THE MAINBOARD........5 ELECTROSTATIC DISCHARGE PRECAUTIONS..5 CHAPTER 2 HARDWARE SETUP ............ 6 PREPARATIONS ............6 UNPACKING THE MAINBOARD.......7 INSTALLATION GUIDE..........8 CHAPTER 3 BIOS SETUP UTILITY ..........

  • Page 4: Sy-5Ema Mainboard Layout

    Mainboard Features SY-5EMA SY-5EMA Mainboard Layout JP30 PS/2 Mouse PS/2 KB Connector Connector P .B. SRAM USB1 USB2 64Kx64 P .B. SRAM 64Kx64 (Optional) TAG 32Kx8 IDE 2 IDE 1 ETEQ EQ82C6638 JP44 JP44 SIMM1 DIMM 2 Header SIMM2 DIMM 1 AGP Slot PCI Slot #1 FDC37C669Q...

  • Page 5: Chapter 1 Introduction

    Introduction SY-5EMA Chapter 1 INTRODUCTION The SY-5EMA AGP/PCI mainboard is a high-performance ATX form-factor system board. SY-5EMA uses the ETEQ82C663 PCI ® Chipset technology and supports Pentium class processors. This mainboard is fully compatible with industry standards and adds many technical enhancements. 1-1 KEY FEATURES Ø...
  • Page 6 Introduction SY-5EMA System memory: 8MB to 640MB with EDO/SDRAM SY-5EMA PLATFORM FEATURES Board Size 4-layer PCB, 19x30.5cm(7.5”x12”), ATX Form Factor ® Socket 7 Socket for Pentium class CPUs with Host Bus frequency of 66/100MH; Supports: Ø ® Intel Pentium Processors P54C/P55C (100-233MHz) Ø...
  • Page 7 Introduction SY-5EMA HDD_LED 2-pin IDE Device LED Connector PWRBT ATX Power On/Off Switch 2-pin Connector CPU Voltage Smart-Detect CMOS Clear Jumper CPU bus clock frequency Jumper JP9, JP10 SDRAM frequency Jumpers JP30 CPU Voltage Selection Jumper JP44 WOL (Wake-On-LAN) 3-pin Connector CPU frequency Settings Jumper BACK-PANEL FEATURES 1 x Onboard 26-pin Female Parallel Printer Port...

  • Page 8: Handling The Mainboard

    Introduction SY-5EMA 1-2 HANDLING THE MAINBOARD To avoid damage to your mainboard, follow these simple rules while unpacking: Ø Before handling the mainboard, ground yourself by grasping an unpainted portion of the system's metal chassis. Ø Remove the mainboard from its anti-static packaging. Hold the mainboard by the edges and avoid touching its components.

  • Page 9: Chapter 2 Hardware Setup

    Hardware Setup SY-5EMA Chapter 2 HARDWARE SETUP Congratulations on your purchase of SY-5EMA Super 7 Mainboard. You are about to install and connect your new mainboard. Note: Do not unpack the mainboard from its protective anti-static packaging until you have made the following preparations.

  • Page 10: Unpacking The Mainboard

    Hardware Setup SY-5EMA 2-2 Unpacking the Mainboard When unpacking the mainboard, check for the following items: Ø The SY-5EMA ETEQ82C663 PCI/AGP Mainboard Ø This Quick Start Guide * Ø The Installation CD-ROM * Ø One IDE Device Flat Cable Ø One Floppy Disk Drive Flat Cable * If your board comes with a driver disc and a paper manual, the Quick Start Guide and the CD-ROM are not included in the package.

  • Page 11: Installation Guide

    Hardware Setup SY-5EMA 2-3 Installation Guide We will now begin the installation of the mainboard. Please follow the step-by-step procedure designed to lead you to a complete and correct installation. Step 1. CPU Installation ® Follow these instructions to install your Pentium class processor correctly.
  • Page 12 Hardware Setup SY-5EMA Follow these steps to install the CPU in the Socket 7: Lift the socket handle up to a vertical position. Align the blunt edge of the CPU with the matching pinhole distinctive edge on the socket. Seat the processor in the socket completely and without forcing. Then close the socket handle to secure the CPU in place.
  • Page 13 Hardware Setup SY-5EMA Step 3. CPU Voltage Setting (JP30 & JP4) CPU Voltage CPU Voltage Smart-Detect Please verify the correct voltage with your dealer before installation. Use the following tables to set JP30 to the proper "Voltage Value", according to the specifications marked on your CPU: This mainboard comes with pre-configured setting of CPU voltage.
  • Page 14 Hardware Setup SY-5EMA Note: For Dual voltage CPUs, JP4 must be set to enable. And at the same time make sure that the voltage setting of JP30 is correct. Incorrect setting may damage CPU. Those processors may come in various voltages on different markets.
  • Page 15 Hardware Setup SY-5EMA Voltage Settings for Various Processors Processor Voltage Value: JP30 Voltage Setting Intel P54C - P100 VCORE:3.3V Intel P54C - P133 VI/O:3.3V Intel P54C - P166 VCORE:3.5V Intel P54C - P200 VI/O:3.5V Intel P55C - P166 VCORE:2.8V Intel P55C - P200 VI/O:3.3V Intel P55C - P233 AMD K5 - PR100...
  • Page 16 Hardware Setup SY-5EMA Voltage Settings for Various Processors (continued) Processor Voltage Value: JP30 Voltage Setting Cyrix 6x86(L) PR166+ The Cyrix 6x86(L) come in several versions Cyrix 6x86(L) PR200+ with different voltages. Please ask your dealer for the correct voltage. Cyrix 6x86MX-PR166* Cyrix 6x86MX-PR200* Cyrix 6x86MX-PR233* VCORE:2.9V...
  • Page 17 Hardware Setup SY-5EMA Step 4. CPU Frequency Setting (SW1) Host Bus Frequency Frequency Multiplier ® The SY-5EMA mainboard is designed to support most Pentium class processors currently on the market. Jumpers SW1 is used to configure the mainboard frequency parameters to match the working frequency of your CPU.
  • Page 18 Hardware Setup SY-5EMA CPU FREQUENCY SETTING (SW1) Configure the SW1 jumpers to the settings that match your CPU speed. Refer to the following tables to set the Frequency Multiplier and Host Bus Frequency of your CPU: Frequency Multiplier Host Bus Frequency Host Bus Multiplier Frequency...
  • Page 19 Hardware Setup SY-5EMA Please refer to the following table that gives you the correct frequency settings for the specific brand and model of CPU you are installing on this mainboard. ® Frequency Settings for Intel Processors Processor Frequency Ratio Frequency Setting Clock Clock Clock...

  • Page 20: Hardware Setup

    Hardware Setup SY-5EMA Frequency Settings for AMD ™ Processors Processor Frequency Ratio Frequency Setting Clock Clock Clock Setting: SW1 AMD K5 - PR100 1.5 x 66MHz 66MHz 33MHz 1 2 3 4 5 6 AMD K5 - PR133 2.0 x 66MHz 66MHz 33MHz 1 2 3 4 5 6...
  • Page 21 Hardware Setup SY-5EMA Frequency Settings for Cyrix ™ Processors Processor Frequency Ratio Frequency Setting Clock Clock Clock Setting: SW1 Cyrix 6x86 - PR166+ 2.0 x 66MHz 66MHz 33MHz 1 2 3 4 5 6 Cyrix 6x86 - PR200+ 2.0 x 75MHz 75MHz 37.5MHz 1 2 3 4 5 6...
  • Page 22 Hardware Setup SY-5EMA Frequency Settings for Cyrix ™ Processors (Continued) Processor Frequency Ratio Frequency Setting Clock Clock Clock Setting: SW1 Cyrix M II - 350** 3.0 x 100MHz 66MHz 33MHz 1 2 3 4 5 6 ** Set the proper CPU frequency according to the marking on the CPU. Over specification is not guaranteed.
  • Page 23 Hardware Setup SY-5EMA Step 5. Set JP8,JP9,JP10 for SDRAM frequency JP8 is used to indicate the frequency of the CPU bus clock to the ETEQ chipset. JP9 and JP10 are used to determine that the SDRAM is running at the frequency of the CPU bus clock or the AGP clock. CPU BUS AGP BUS JP10...
  • Page 24 Hardware Setup SY-5EMA Step 6. DRAM Module Installation This mainboard supports two strips of 72-pin 5V FPM/EDO DRAM (SIMM) from 4 to 64 MB and two strips 168-pin 3.3V/5V Unbuffered DIMM modules from 8 to 256 MB. The mainboard requires SIMM modules of at least 70ns access time.
  • Page 25 Hardware Setup SY-5EMA Your board comes with tow DIMM sockets and two SIMM sockets, providing support for up to 512MB of main memory using DIMM modules from 8MB to 256MB;SIMM modules from 4MB to 64MB. For 66MHz host bus CPUs use 12ns or faster DIMM modules; for 83MHz or faster host bus CPUs use 8ns modules.
  • Page 26 Hardware Setup SY-5EMA Step 9. Front Panel Connections HDD LED Speaker Turbo Keylock PWRBT Power Reset Plug the computer case's front panel devices to the corresponding connectors on the mainboard. 1. Power LED & KeyLock Plug the Power LED cable into the 5-pin Keylock connector. Some systems may feature a KeyLock function with a front panel switch for enabling or disabling the keyboard.
  • Page 27 Hardware Setup SY-5EMA 3. Speaker Attach the 4-pin PC speaker cable from the case to the Speaker connector on the mainboard. 4. Turbo LED Connecting the 2-pin Turbo LED cable to the corresponding Turbo LED connector will cause the LED to light whenever the system is in Turbo mode.
  • Page 28 Hardware Setup SY-5EMA Step 10. Back Panel Connections All external devices such as the keyboard, printer, PS/2 mouse, modem, USB, can be plugged directly onto the mainboard back panel. Only after you have fixed and locked the mainboard to the computer case can you start connecting the external peripheral devices.
  • Page 29 Hardware Setup SY-5EMA 1. Onboard Serial Port COM1,COM2 External peripherals that use serial transmission scheme include: serial mouse, and modem. Plug the serial device cables directly into the COM1or COM2 9-pin male connector located at the rear panel of the mainboard. 2.
  • Page 30 Hardware Setup SY-5EMA Wake-On-LAN (WOL) Attach the 3-pin connector from the LAN card which supports the Wake-On-LAN (WOL) function to the JP44 connector on the mainboard. This WOL function lets users wake up the connected computer through the LAN card. Please install according to the following pin assignment: Wake-On-LAN JP44 Pin Assignment...
  • Page 31 Hardware Setup SY-5EMA Step 11. CPU Cooling Fan Installation After you have seated the CPU cooling fan properly on the processor, attach the 3-pin fan cable to the CPUFAN connector on the mainboard. To avoid damage to the system, install according to the following pin assignment: CPU Cooling Fan CPUFAN Pin Assignment...

  • Page 32: Atx Power

    Hardware Setup SY-5EMA Step 13. ATX Power Supply Plug the connector from the power directly into the 20-pin male ATX PW connector on the mainboard, as shown in the following figure. ATX Power Warning: Follow these precautions to preserve your mainboard from any remnant currents when connecting to ATX power supply: Turn off the power supply and unplug the power cord...
  • Page 33 Hardware Setup SY-5EMA Please install the ATX power according to the following pin assignment: ATX Power 5VSB PW-0K Ø Pay special care to the directionality. PS-ON 3.3V -12V 3.3V 3.3V Step 14. CPU Voltage Smart-Detect (JP4) This Mainboard automatically detects and adjusts the CPU voltage to the proper value for Intel P54C/P55C and Cyrix 6x86(L) CPUs.
  • Page 34 Hardware Setup SY-5EMA Step 15. CMOS Clearing (JP5) After you have turned off your computer, clear the CMOS memory by momentarily shorting pins 2-3 on jumper JP5, for a few seconds. Then restore JP5 to the initial 1-2 jumper setting in order to recover and retain the default settings.
  • Page 35 Hardware Setup SY-5EMA Step 17. CACHE CONFIGURATION This mainboard has a built-in 512KB(5EMA/5) or 1MB(5EMA) Level 2 Pipelined Burst cache onboard to improve the system performance. The cache size and RAM locations are specified as follows: Cacheable Cache Size Cache RAM TAG RAM Range 512 KB...
  • Page 36 Hardware Setup SY-5EMA 3. The BIOS Setup screen appears: ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP SUPERVISOR PASSWORD CHIPSET FEATURES SETUP USER PASSWORD POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION PNP/PCI CONFIGURATION SAVE &...

  • Page 37: Chapter 3 Bios Setup Utility

    BIOS Setup Utility SY-5EMA Chapter 3 BIOS SETUP UTILITY This mainboard's BIOS setup program uses the ROM PCI/ISA BIOS program from Award Software Inc. To enter the Award BIOS program's Main Menu: 1. Turn on or reboot the system. 2. After the diagnostic checks, press the [Del] key to enter the Award BIOS Setup Utility.

  • Page 38: Save And Exit Setup

    BIOS Setup Utility SY-5EMA Hot Keys: Function keys give you access to a group of commands throughout the BIOS utility. Function Command Description Help Gives the list of options available for each item. Color Change the color of the display window. Shift F2 Old values Restore the old values.

  • Page 39: Standard Cmos Setup

    BIOS Setup Utility SY-5EMA 3-1 STANDARD CMOS SETUP Select the [STANDARD CMOS SETUP] option from the Main Menu and press [Enter] key. ROM PCI/ISA BIOS STANDARD CMOS SETUP AWARD SOFTWARE, INC. Date (mm:dd:yy) : Fri, May 29 1998 Time (hh:mm:ss) : 9 : 42 : 43 HARD DISKS TYPE...
  • Page 40 BIOS Setup Utility SY-5EMA 3-1.2 Hard Disks Type & Mode Choose the type and mode for the hard disks that you have already installed. Primary Setting Description Note (Secondary) Master & Slave Type Auto BIOS detects hard disk type Default automatically.
  • Page 41 BIOS Setup Utility SY-5EMA 3-1.4 Video Select the video mode: EGA/VGA (Default), CGA 40, CGA 80, Mono (Monochrome). 3-1.5 Halt On When the BIOS detects system errors, this function will stop the system. Select which type of error will cause the system halt: All Errors (Default), No Errors, All But Diskette, All But Keyboard, All But Disk/Key.

  • Page 42: Bios Features Setup

    BIOS Setup Utility SY-5EMA 3-2 BIOS FEATURES SETUP Select the [BIOS FEATURES SETUP] option from the Main Menu and press [Enter] key. ROM PCI/ISA BIOS BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow...
  • Page 43 BIOS Setup Utility SY-5EMA 3-2.1 Virus Warning Setting Description Note Virus Warning Disabled Default Enabled Enable this option to protect the boot sectors and partition tables of your hard disk. Any attempt to write to them will the system to halt and display a warning message.
  • Page 44 BIOS Setup Utility SY-5EMA 3-2.3 System Boot Control Settings System Boot Setting Description Note Control Settings Quick Power On Disabled Self Test Enabled Provides a fast POTS at Default boot-up. Boot Sequence A, C, SCSI Choose the boot sequence adapted to C, A, SCSI your needs, for example: C, CD-ROM, A...
  • Page 45 BIOS Setup Utility SY-5EMA System Boot Control Settings (continued) System Boot Setting Description Note Control Settings Gate A20 Option Normal Fast Allows RAM access Default above 1MB using the fast gate A20 line. Memory Parity Enabled This allows to perform a Default Check/ ECC redundancy check on the...
  • Page 46 BIOS Setup Utility SY-5EMA 3-2.5 Other Control Options Other Control Setting Description Note Options Security Setup Use this feature to prevent Default Option Unauthorized system boot-up or use of BIOS Setup. “Setup”, If a password is set, the password prompt only appears if you attempt to enter the Setup program.
  • Page 47 BIOS Setup Utility SY-5EMA Other Control Options (Continued) Other Control Setting Description Note Options Video or Disabled Adapter BIOS Enabled Default Shadow The BIOS is shadowed in a 16K segment if it is enabled and if it has BIOS present. These 16 segments can be shadowed from ROM to RAM.

  • Page 48: Chipset Features Setup

    BIOS Setup Utility SY-5EMA 3-3 CHIPSET FEATURES SETUP Caution: Change these settings only if you are already familiar with the Chipset. The [CHIPSET FEATURES SETUP] option changes the values of the chipset registers. These registers control the system options in the computer.
  • Page 49 BIOS Setup Utility SY-5EMA CHIPSET FEATURES SETUP CHIPSET Setting Description Note FEATURES Bank 0/1 DRAM FP/EDO Use the default setting Default Timing 70ns Bank 2/3 DRAM Normal Choose DRAM Timing. Timing Medium Bank 4/5 DRAM Fast, Timing Turbo DRAM Read Disabled Pipeline Enabled...
  • Page 50 BIOS Setup Utility SY-5EMA CHIPSET FEATURES SETUP (Continued) CHIPSET Setting Description Note FEATURES AGP Aperture AGP could use the DRAM Default Size 4-256M as its video RAM. Choose the JDRAM size that you wish to allocate as video RAM. AGP-2X Mode Disabled Default Enabled...

  • Page 51: Power Management Setup

    BIOS Setup Utility SY-5EMA 3-4 POWER MANAGEMENT SETUP The [POWER MANAGEMENT SETUP] sets the system's power saving functions. ROM PCI/ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Primary INTR : ON ACPI function : Disabled IRQ3 (COM2) : Primary Power Management : User Define IRQ4 (COM1) : Primary...
  • Page 52 BIOS Setup Utility SY-5EMA 3-4.1 Power Management Controls Power Setting Description Note Management Controls ACPI Disabled Default function Enabled Enabled if you use Windows 98 and want to use ACPI Power User Define Lets you define the HDD and Management system power down times.
  • Page 53 BIOS Setup Utility SY-5EMA 3-4.2 PM Timers PM Timers Setting Description Note HDD Power Disable Default Down Some older 1-15Min When the set time has model HDDs elapsed, BIOS sends a may not support command to the HDD to this advanced power down.
  • Page 54 BIOS Setup Utility SY-5EMA 3-4.3 PM Events PM Events Setting Description Note Enabled the power managemnet. Default LPT & COM LPT/COM Enabled the power Default management timer. NONE HDD & FDD Enabled the power Default management timers when the event is detected on the Hard Disk Drive and Floppy Disk Drive device.
  • Page 55 BIOS Setup Utility SY-5EMA PM Events (Continued) PM Events Setting Description Note IRQ# Primary IRQ3(COM2), IRQ4(COM1), IRQ5(LPT2), IRQ6(Floppy Disk), IRQ7(LPT1), IRQ12(PS/2 mouse), IRQ13(Coprocessor), IRQ14(HardDsik) Secondary IRQ9(IRQ2 Redir), IRQ10( Reserved), IRQ11(Reserved) Disabled IRQ8 (RTC Alarm), IRQ15 (Reserved)

  • Page 56: Pnp/Pci Configuration Setup

    BIOS Setup Utility SY-5EMA 3-5 PNP/PCI CONFIGURATION SETUP This option sets the mainboard's PCI Slots. ROM PCI/ISA BIOS PNP/PCI CONFIGURATION SETUP AWARD SOFTWARE, INC. : No CPU to PCI Write Buffer : Enabled PNP OS Installed : Manual PCI Master Broken Timer : Disabled Resources Controlled By : Disabled...
  • Page 57 BIOS Setup Utility SY-5EMA 3-5.1 PNP/PCI Configuration Controls PNP/PCI Setting Description Note Controls PNP OS Use the default setting Disabled Installed Resources Manual BIOS does not manage PCI/ISA Controlled By PnP card IRQ assignment. Requires to assign IRQ-# and DMA-# to PCI or ISA PnP manually.
  • Page 58 BIOS Setup Utility SY-5EMA 3-5.2 PNP/PCI Configuration Setup PNP/PCI Setting Description Note Setup If [Resources Controlled By] is set to [Manual] IRQ-3,4,5,7,9,10, IRQ-# and PCI/ISA PnP Choose IRQ-# and 11,12,14,15 DMA-# DMA-# assigned to DMA-0,1,3,5,6,7 assigned to: PCI/ISA PnP card. IRQ-3,4,5,7,9,10, Legacy ISA Choose IRQ-# and 11,12,14,15...

  • Page 59: Load Setup Defaults

    BIOS Setup Utility SY-5EMA 3-6 LOAD SETUP DEFAULTS Select the [LOAD SETUP DEFAULTS] option from the Main Menu to load the system values you have previously saved. This option is recommended if you need to reset the system setup and to retrieve the old values.

  • Page 60: Integrated Peripherals

    BIOS Setup Utility SY-5EMA 3-8 INTEGRATED PERIPHERALS Caution: Change these settings only if you are already familiar with the Chipset. The [INTEGRATED PERIPHERALS] option changes the values of the chipset registers. These registers control the system options in the computer. The following screen shows default settings.
  • Page 61 BIOS Setup Utility SY-5EMA 3-8.1 IDE Device Controls IDE Controls Setting Description Note Onchip IDE Primary Disabled Use the On-board IDE Channel Channel Enabled Default Onchip IDE Second Disabled Turn off the On-board Channel IDE Channel Enabled Default IDE Prefetch Mode Disabled Enabled Enable to enhance...
  • Page 62 BIOS Setup Utility SY-5EMA 3-8.2 FDC Controls FDC Controls Setting Description Note Onboard FDC Disabled Turn off the on-board controller floppy controller Enabled Use the on-board Default floppy controller 3-8.3 Onboard Serial Ports Onboard Serial Setting Description Note Ports Onboard UART 1 Disabled Onboard UART 2 3F8/IRQ4...
  • Page 63 BIOS Setup Utility SY-5EMA 3-8.4 Onboard Parallel Ports IR Pins Controls Setting Description Note IR Duplex mode Half Select the IR mode Default your IR module Full supports Use IR Pins IR-RX2TX2 Default IR-RX TX 3-8.5 Onboard Parallel Ports Onboard Parallel Setting Description Note...

  • Page 64: Supervisor Password

    BIOS Setup Utility SY-5EMA 3-9 SUPERVISOR PASSWORD Based on the setting you have made in the [Security Option] of the [BIOS FEATURES SETUP] section, the password prevents access to the system or the setup program by unauthorized users. Follow this procedure to set a new password or disable the password: Choose [BIOS FEATURES SETUP] in the Main Menu and press [Enter].

  • Page 65: User Password

    BIOS Setup Utility SY-5EMA Enter your new password and press [Enter]. The following message appears, prompting to confirm the new password: Confirm Password: Re-enter your password and then press [Enter] to exit to the Main Menu. This diagram outlines the password selection procedure: ↔...

  • Page 66: Ide Hdd Auto Detection

    BIOS Setup Utility SY-5EMA 3-11 IDE HDD AUTO DETECTION This Main Menu function automatically detects the hard disk type and configures the STANDARD CMOS SETUP accordingly. ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR...

  • Page 67: Chapter 4 Drivers Installation

    HTML format with information on SOYO Mainboards and other products. Step 1. Insert the SOYO CD into the CD-ROM drive The SOYO CD will auto-run, and the SOYO CD Start Up Menu will display as shown below. (SOYO CD Start Up Program Menu) The SOYO CD Start Up Program automatically detects which SOYO Mainboard you own and displays the corresponding model name.
  • Page 68 We recommend you to install all drivers, and to do so in the right sequence (top to bottom). If you want to see all the drivers available on the SOYO –CD, click the Display all drivers on the SOYO CD button. Do NOT install drivers that are not suitable for you board, otherwise your system may crash.
  • Page 69 SOYO CD and install the next driver. Note: Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system...
