Table of Contents Introduction Child Safety Installing child seats ........19 Booster seats .
Page 3 Table of Contents Locks Locking and unlocking ........69 SecuriCode™...
Page 4: Table Of Contents
Table of Contents Instrument Cluster Gauges..........104 Warning lamps and indicators .
Page 5 Table of Contents Fuel and Refueling Fuel quality .........185 Refueling .
Page 6: Table Of Contents
Table of Contents Driving Aids Blind Spot Information System (BLIS) with Cross Traffic Alert (CTA) ..........230 Steering .
Page 7 Table of Contents Maintenance General information ........290 Opening and closing the hood .
Page 8: Table Of Contents
Table of Contents Wheels and Tires Tire care ......... . .326 Tire Pressure Monitoring System (TPMS) .
Page 9 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2014...
Page 10: Introduction
Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
Page 11 Introduction SYMBOL GLOSSARY These are some of the symbols you may see on your vehicle. Symbol Description Symbol Description Symbol Description Safety alert See Owner’s Anti-lock Manual braking system Avoid Battery Battery acid smoking, flames, or sparks Brake fluid – Brake system Cabin air filter...
Page 12 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 13 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 14 If you do not want Ford or its vendors to receive this information, do not activate the service. For more information, see Traffic, Directions and Information, Terms and Conditions.
Page 15 Introduction FORD CREDIT (U.S. ONLY) Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business. For your convenience, we offer a number of ways to contact us, as well as help manage your account.
Page 16 Do not use this vehicle for snowplowing. Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package.
Page 17 Introduction MOBILE COMMUNICATIONS EQUIPMENT Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 18: Child Safety
NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle.
Page 19 Child Safety Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Infants or Children weighing 40 lb (18 kg) or Use a child safety seat toddlers less (generally age four or younger). (sometimes called an infant carrier, convertible seat, or toddler seat).
Page 20: Installing Child Seats
Child Safety INSTALLING CHILD SEATS Child Seats Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers or children weighing 40 pounds (18 kilograms) or less (generally age four or younger). Using Lap and Shoulder Belts WARNING: Airbags can kill or injure a child in a child seat.
Page 21 Child Safety • Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling. • Place the vehicle seat upon which the child seat will be installed in the upright position.
Page 22 Child Safety 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 23 There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed.
Page 24 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Using Tether Straps in this chapter.
Page 25 Child Safety The LATCH anchors are located at the rear section of the rear seat between the cushion and seatback, below the locator symbols on the seatback. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. The locator symbols are on round plastic buttons for the center seat and on rectangular tags for the outboard seats.
Page 26 Child Safety Using Tether Straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap, or to obtain a longer tether strap if the tether strap on your safety seat does not reach the appropriate top tether...
Page 27 Child Safety If you install a child seat with rigid LATCH attachments, and have attached the top tether strap to the proper top tether anchor, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it.
Page 28 Child Safety 3. Grasp the tether strap and position it to the seat frame. 4. Rotate the tether strap, and clip the tether strap to the anchor on the seat frame. 5. Rotate the tether strap clip. 6. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
Page 29 Child Safety Third row center seating position 1. Route the child safety seat tether strap over the back of the seat. 2. Locate the anchor webbing loop for the seating position. • You may need to pull back the top of the hinged panel along the bottom of the seat back to access the tether anchor.
Page 30: Booster Seats
If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. BOOSTER SEATS WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces...
Page 31 Child Safety • Does the lap belt rest low across the hips? • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Always use booster seats in conjunction with your vehicle lap and shoulder belt.
Page 32 Child Safety Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 33: Child Seat Positioning
Child Safety CHILD SEAT POSITIONING WARNING: Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back.
Page 34 Child Safety WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. WARNING: To avoid risk of injury, do not leave children or pets unattended in your vehicle.
Page 35: Child Safety Locks
Child Safety CHILD SAFETY LOCKS When these locks are set, the rear doors cannot be opened from the inside. The childproof locks are located on the rear edge of each rear door and must be set separately for each door. Move the lock control up to engage the childproof lock.
Page 36: Safety Belts
Safety Belts PRINCIPLES OF OPERATION WARNING: Always drive and ride with your seat back upright and the lap belt snug and low across the hips. WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained. WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 37 Safety Belts WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. WARNING: Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather;...
Page 38: Fastening The Safety Belts
Safety Belts FASTENING THE SAFETY BELTS The front outboard and rear safety restraints in your vehicle are combination lap and shoulder belts. 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
Page 39 Safety Belts Pregnant women should always wear their safety belts. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow. The shoulder belt should be positioned to cross the middle of the shoulder and the center of the chest.
Page 40 Safety Belts Automatic Locking Mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to Use the Automatic Locking Mode This mode should be used any time a child safety seat, except a booster, is installed in passenger front or rear seating positions.
Page 41: Safety Belt Height Adjustment
Safety Belts SAFETY BELT HEIGHT ADJUSTMENT WARNING: Position the safety belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the seat belt and increase the risk of injury in a crash. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder.
Page 42: Safety Belt Warning Light And Indicator Chime
Safety Belts To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide (the portion of the belt between the latch tongue and the D-ring, not the portion where the belt exits from the quarter trim panel). 2.
Page 43: Safety Belt-Minder
Safety Belts SAFETY BELT-MINDER™ This feature supplements the safety belt warning function by providing additional reminders that intermittently sound a tone and illuminate the safety belt warning light when you are in the driver seat and the safety belt is unbuckled. If...
Page 44: Child Restraint And Safety Belt Maintenance
Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced. However, if the crash was minor and an authorized dealer finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Page 45: Supplementary Restraints System
Supplementary Restraints System PRINCIPLES OF OPERATION WARNING: Airbags do not inflate slowly or gently, and the risk of injury from a deploying airbag is the greatest close to the trim covering the airbag module. WARNING: All occupants of your vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided.
Page 46 Supplementary Restraints System The airbags are a supplemental restraint system and are designed to work with the safety belts to help protect the driver and right front passenger from certain upper body injuries. Airbags do not inflate slowly; there is a risk of injury from a deploying airbag. Note: You will hear a loud bang and see a cloud of harmless powdery residue if an airbag deploys.
Page 47 Supplementary Restraints System • Front crash severity sensors. • Restraints control module with impact and safing sensors. • Restraint system warning light and backup tone. • The electrical wiring for the airbags, crash sensor(s), safety belt pretensioners, front safety belt usage sensors, driver seat position sensor, and indicator lights.
Page 48: Driver And Passenger Airbags
Supplementary Restraints System DRIVER AND PASSENGER AIRBAGS WARNING: Never place your arm or any objects over an airbag module. Placing your arm over a deploying airbag can result in serious arm fractures or other injuries. Objects placed on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury.
Page 49: Side Airbags
Supplementary Restraints System After all occupants have adjusted their seats and put on safety belts, it is very important that they continue to sit properly. Properly seated occupants sit upright, lean against the seat back, and center themselves on the seat cushion, with their feet comfortably extended on the floor. Sitting improperly can increase the chance of injury in a crash event.
Page 50 Supplementary Restraints System WARNING: Do not lean your head on the door. The side airbag could injure you as it deploys from the side of the seatback. WARNING: Do not attempt to service, repair, or modify the airbag, its fuses or the seat cover on a seat containing an airbag, as you could be seriously injured or killed.
Page 51: Safety Canopy Curtain Airbags
Supplementary Restraints System SAFETY CANOPY™ CURTAIN AIRBAGS WARNING: Do not place objects or mount equipment on or near the headliner at the siderail that may come into contact with a deploying curtain airbag. Failure to follow these instructions may increase the risk of personal injury in the event of a crash. WARNING: Do not lean your head on the door.
Page 52 Supplementary Restraints System The Safety Canopy will deploy during significant side crashes or when a certain likelihood of a rollover event is detected by the rollover sensor. The Safety Canopy is mounted to the roof side-rail sheet metal, behind the headliner, above each row of seats. In certain sideways crashes or rollover events, the Safety Canopy will be activated, regardless of which seats are occupied.
Page 53: Crash Sensors And Airbag Indicator
Supplementary Restraints System CRASH SENSORS AND AIRBAG INDICATOR WARNING: Modifying or adding equipment to the front end of your vehicle (including frame, bumper, front end body structure and tow hooks) may affect the performance of the airbag system, increasing the risk of injury. Do not modify the front end of your vehicle.
Page 54: Airbag Disposal
Supplementary Restraints System The fact that the safety belt pretensioners or airbags did not activate for both front seat occupants in a crash does not mean that something is wrong with the system. Rather, it means the restraints control module determined the accident conditions (for example, crash severity, belt usage) were not appropriate to activate these safety devices.
Page 55: Keys And Remote Control
Keys and Remote Control PRINCIPLE OF OPERATION The remote control allows you to: • remotely lock or unlock the vehicle doors • remotely open the power liftgate (if equipped) • remotely start or stop the engine (if equipped) • arm and disarm the anti-theft system (if equipped) •...
Page 56: Remote Control
Keys and Remote Control Intelligent Access (If Equipped) The system uses a radio frequency signal to communicate with your vehicle and authorize your vehicle to unlock when one of the following conditions is met: • You touch any button on the keypad. •...
Page 57 Keys and Remote Control Intelligent Access Key (If Equipped) Your intelligent access keys operate the power locks and the remote start system. The key must be in your vehicle to activate the push-button start system. The intelligent access key also contains a removable mechanical key blade that you can use to unlock the driver door.
Page 58 Keys and Remote Control Integrated Keyhead Transmitter 1. Twist a thin coin in the slot near the key ring to remove the battery cover (1). 2. Carefully peel up the rubber gasket (2) from the transmitter if it does not come off with the battery cover.
Page 59 Keys and Remote Control 4. Insert a new battery with the + facing downward. Press the battery down to make sure it is fully in the housing. 5. Snap the battery cover back onto the transmitter and install the backup key. Memory Feature (If Equipped) The memory feature allows you to recall the driver seat, power mirrors, power adjustable pedal and power steering column (if equipped) memory...
Page 60 Keys and Remote Control Car Finder Press the button twice within three seconds. The horn will sound and the turn signals will flash. We recommend you use this method to locate your vehicle, rather than using the panic alarm. Sounding a Panic Alarm Press the button to activate the alarm.
Page 61 Keys and Remote Control Remote Starting the Vehicle Note: You must press each button within three seconds of each other. Your vehicle will not remote start and the horn will not sound if you do not follow this sequence. The label on your transmitter details the starting procedure.
Page 62: Replacing A Lost Key Or Remote Control
Keys and Remote Control Turning the Vehicle Off After Remote Starting Press the button once. The parking lamps will turn off. You may have to be closer to your vehicle than when starting due to ground reflection and the added noise of the running vehicle. You can disable or enable the remote start system through the information display.
Page 63: Mykey
MyKey PRINCIPLES OF OPERATION MyKey allows you to program keys with restricted driving modes to promote good driving habits. All but one of the keys programmed to the vehicle can be activated with these restricted modes. Any keys that have not been programmed are referred to as administrator keys or admin keys.
Page 64: Creating
MyKey • Audio system maximum volume of 45% for some audio systems. A message will be shown in the display when you attempt to exceed the limited volume. Also, the speed-sensitive or compensated automatic volume control will be disabled. • Always on setting. When this is selected, you will not be able to turn off certain features.
Page 65: Clearing
MyKey CLEARING ALL MYKEYS You can clear all MyKeys within the same key cycle as you created the MyKey. If you switch your ignition off, however, you will need to use an admin key to clear your MyKeys. Note: When you clear your MyKeys, you remove all restrictions and return all MyKeys to their original admin key status at once.
Page 66: Remote Start, Mykey
MyKey is not compatible with non-Ford-approved aftermarket remote start systems. If you choose to install a remote start system, please see your Ford authorized dealer for a Ford-approved remote start system . Vehicles With Ford-approved Aftermarket Remote Start Systems When using a Ford-approved aftermarket remote start system, the vehicle recognizes the remote start system as an additional admin key.
Page 67 MyKey compatible with non-Ford-approved remote start systems, but may help you retain some MyKey functions. When using a non-Ford-approved remote start system, the vehicle may recognize the remote start system as an additional admin key with its associated privileges. If you restart the vehicle by inserting a key into the ignition cylinder and recycling the ignition completely, then you may retain some MyKey functions.
Page 68: Troubleshooting, Mykey
MyKey MYKEY TROUBLESHOOTING Condition Potential causes • The key or fob used to start the vehicle I cannot create a MyKey. does not have admin privileges. • The key or fob used to start the vehicle is the only admin key (there always has to be at least one admin key).
Page 69 MyKey Condition Potential causes • Purchase a new key from your authorized I lost the only admin key. dealer. • Program a spare key. See SecuriLock in the I lost a key. Security chapter. • The vehicle has a remote start system that I accidentally programmed all keys is recognized as an admin key.
Page 70: Locks
Locks LOCKING AND UNLOCKING You can use the power door lock control or the remote control to lock and unlock your vehicle. Power Door Locks A. Unlock B. Lock Remote Control You can use the remote control anytime your vehicle is not running. Unlocking the Doors (Two-Stage Unlock) Press the button to unlock the driver door.
Page 71 Locks Activating Intelligent Access (If Equipped) You must have the intelligent access key within 3 feet (1 meter) of your vehicle. At the Front Driver Door Press any number on the SecuriCode keyless entry keypad. After locking the doors with the lock sensor, there is a brief delay before you can unlock your vehicle.
Page 72 Locks • pressing the lock button on another intelligent access key When you open one of the front doors and lock your vehicle using the power door lock control, all doors will lock then unlock if: • the ignition is on, or •...
Page 73 Locks Illuminated Entry The interior lamps and select exterior lamps illuminate when you use the integrated keyhead transmitter, intelligent access key or the keyless entry keypad to unlock the vehicle. The system will turn off the lights if: • you switch the ignition on •...
Page 74 Locks LIFTGATE WARNING: Do not allow people to travel in any area of your vehicle that does not have seats and safety belts. Riding in a cargo area, inside or outside of the vehicle, is extremely dangerous. In a crash, people riding in these areas are more likely to be seriously injured or killed.
Page 75 Locks Power Liftgate (If Equipped) WARNING: Make sure all persons are clear of the power liftgate area before using the power liftgate control. WARNING: Keep keys out of the reach of children. Do not allow children to operate the power liftgate, or to play near an open or moving power liftgate.
Page 76 Locks If the liftgate reverses and starts to close after an open request, a fast continuous tone indicates excessive load on the gate or a possible strut failure. Have the system checked by an authorized dealer if you still have a fast tone after removing the load.
Page 77 Locks To open the liftgate window: Press the window release button B located inside the liftgate pull handle. Obstacle Detection When closing: The liftgate reverses to full open when it detects an obstacle. A chime sounds three times as the liftgate begins to reopen. Remove the obstacle to close the liftgate.
Page 78: Securicode™ Keyless Entry Keypad
Locks SECURICODE™ KEYLESS ENTRY KEYPAD (IF EQUIPPED) The keypad, located near the driver window, is invisible until touched and then it lights up so you can see and touch the appropriate buttons. Note: If you enter your entry code too fast on the keypad, the unlock function may not work.
Page 79 Locks Erasing a Personal Code 1. Enter the factory-set 5-digit code. 2. Press and release 1•2 on the keypad within five seconds. 3. Press and hold 1•2 for two seconds. This must be done within five seconds of completing Step 2. All personal codes are now erased and only the factory-set 5-digit code will work.
Page 80: Security
Security SECURILOCK® PASSIVE ANTI-THEFT SYSTEM Note: The system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Metallic objects, electronic devices or a second coded key on the same key chain may cause vehicle starting issues if they are too close to the key when starting your vehicle.
Page 81 Security Replacement Keys Note: Your vehicle may come with two integrated keyhead transmitters. The integrated keyhead transmitter functions as a programmed ignition key that operates all the locks and starts the vehicle, as well as a remote control. If your programmed transmitters or standard SecuriLock coded keys are lost or stolen and you do not have an extra coded key, you will need to have your vehicle towed to an authorized dealer.
Page 82 Security 6. Turn the ignition off and remove the second previously programmed coded key from the ignition. 7. After three seconds but within 20 seconds of turning the ignition off and removing the previously programmed coded key, insert the new unprogrammed key into the ignition.
Page 83: Anti-Theft Alarm
Security ANTI-THEFT ALARM The system will warn you of unauthorized entry to your vehicle. The turn signal lamps will flash and the horn will sound when: • any door or the hood is opened without using the key or the remote control •...
Page 84: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WHEEL WARNING: Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. Refer to Sitting in the Correct Position in the Seats chapter. Manual Adjust Steering Wheel (If Equipped) 1.
Page 85 Steering Wheel Power Adjust Steering Wheel (If Equipped) Use the control on the side of the steering column to tilt the position. Memory Feature The steering column positions are saved and recalled with the memory feature. Refer to the Seats chapter. Pressing the adjustment control during memory recall will cancel the operation.
Page 86: Steering Wheel Controls
Steering Wheel AUDIO CONTROL Type One A. Seek up or next B. Volume up C. Volume down D. Seek down or previous...
Page 87 Steering Wheel Type Two A. Volume up B. Seek up or next C. Media D. Seek down or previous E. Volume down Media Press the media button repeatedly to scroll through available audio modes. Seek, Next or Previous Press the seek button to: •...
Page 88 Steering Wheel VOICE CONTROL (IF EQUIPPED) Type One A. Phone mode B. Voice recognition Press OK to confirm selection. See the SYNC or Navigation System chapter.
Page 89 Steering Wheel Type Two A. Phone mode B. Voice recognition Press OK to confirm selection. See the SYNC or Navigation System chapter. CRUISE CONTROL See the Cruise Control chapter.
Page 90: Pedals
Pedals ADJUSTABLE PEDALS (IF EQUIPPED) WARNING: Never use the controls when your feet are on the accelerator or brake pedals, especially when the vehicle is moving. Note: Adjust the pedals only when your vehicle is in park (P). Depending on your vehicle and equipment level, the shape and location of your power-adjustable pedal control can vary.
Page 91: Wipers And Washers
Wipers and Washers WINDSHIELD WIPERS Note: Fully defrost the windshield before turning on the windshield wipers. Note: Make sure the windshield wipers are turned off before entering a car wash. Note: Clean the windshield and wiper blades if they begin to leave streaks or smears.
Page 92: Windshield Washers
Wipers and Washers Keep the outside of the windshield clean, especially the area around the interior mirror where the sensor is located, or sensor performance may be affected. WINDSHIELD WASHERS Note: Do not operate the wipers on a dry windshield. This may scratch the glass, damage the wiper blades or cause the wiper motor to burn out.
Page 93: Lighting
Lighting LIGHTING CONTROL A. Off B. Parking lamps, instrument panel lamps, license plate lamps and tail lamps C. Headlamps High Beams • Push the lever toward the instrument panel to switch on the high beams. • Pull the lever toward you to switch of the high beams.
Page 94: Autolamps
Lighting AUTOLAMPS WARNING: The daytime running lamps system does not activate the rear lamps and may not provide adequate lighting during low visibility driving conditions. Also, the autolamps switch position may not activate the headlamps in all low visibility conditions, such as daytime fog.
Page 95: Instrument Lighting Dimmer
Lighting INSTRUMENT LIGHTING DIMMER Use to adjust the brightness of the instrument panel and all applicable lit components in the vehicle during headlamp and parking lamp operation. • Tap the top or bottom of the control to brighten/dim all interior lit components incrementally, or •...
Page 96: Direction Indicators
Lighting DIRECTION INDICATORS • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Front Row Map Lamps (If Equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: •...
Page 97 Lighting Second Row Map Lamps (If Equipped) The second row map lamps are located in the headliner above the second row seats. The second row map lamp lights when: • any door is opened, • the instrument panel dimmer switch is rotated up until the courtesy lamps come on, and •...
Page 98: Windows And Mirrors
Windows and Mirrors POWER WINDOWS WARNING: Do not leave children unattended in your vehicle and do not let them play with the power windows. They may seriously injure themselves. WARNING: When closing the power windows, you should verify they are free of obstructions and make sure that children and pets are not in the proximity of the window openings.
Page 99: Exterior Mirrors
Windows and Mirrors Window Lock A. Unlock B. Lock Press the control to lock or unlock the rear and front passenger window controls. Accessory Delay You can use the window switches for several minutes after you switch the ignition off, or until you open either front door. EXTERIOR MIRRORS Power Exterior Mirrors WARNING: Do not adjust the mirror while your vehicle is in...
Page 100 Windows and Mirrors Power-Folding Mirrors (If Equipped) Note: Using the mirrors 10 or more times within one minute, or repeated folding and unfolding of the mirrors while holding the control down during full travel, may disable the system to protect motors from overheating.
Page 101: Interior Mirrors
Windows and Mirrors Auto-Dimming Feature (If Equipped) The driver’s side exterior mirror will automatically dim when the interior auto-dimming mirror is activated. Signal Indicator Mirrors (If Equipped) The rear-facing portion of the appropriate mirror housing will blink when the turn signal is activated. Blind Spot Information System (BLIS®) with Cross Traffic Alert (CTA) (If Equipped) Refer to Blind Spot Information System (BLIS®) with Cross Traffic...
Page 102 Windows and Mirrors CHILDMINDER MIRROR (IF EQUIPPED) On double bin overhead consoles, the conversation mirror allows the driver to view the rear seating area. WARNING: Do not use the childminder mirror to view rearward traffic, do not allow rear passengers to distract you from the driving task, and make sure the rear view mirror has a clear view of rearward traffic.
Page 103: Sun Visors
Windows and Mirrors SUN VISORS Rotate the visor toward the side window and extend it rearward for extra sunlight coverage. Illuminated Visor Vanity Mirror Lift the cover to switch on the lamp. MOONROOF (IF EQUIPPED) WARNING: Do not let children play with the moonroof or leave children unattended in the vehicle.
Page 104 Windows and Mirrors Opening and Closing the Moonroof Press and release the SLIDE control to open the moonroof. The moonroof will stop short of the fully opened position. Note: This position helps to reduce rumbling wind noise which may happen with the moonroof fully open.
Page 105: Instrument Cluster
Instrument Cluster Type 1 and 2 A. Tachometer B. Information display (Type 2 shown Type 1 similar) C. Speedometer D. Fuel gauge E. Engine coolant temperature gauge Information Display Odometer Located in the bottom of the information display. Registers the accumulated distance your vehicle has travelled.
Page 106 Instrument Cluster Fuel Gauge Note: The fuel gauge may vary slightly when your vehicle is moving or on a gradient. Switch the ignition on. The fuel gauge will indicate approximately how much fuel is left in the fuel tank. The arrow adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel filler door is located.
Page 107 Instrument Cluster WARNING: Never remove the coolant reservoir cap while the engine is running or hot. The hot coolant is under pressure and may cause serious burns. Type 3 A. Left Information Display B. Speedometer C. Right Information Display. See the MyTouch chapter for more information.
Page 108: Warning Lamps And Indicators
Instrument Cluster WARNING LAMPS AND INDICATORS The following warning lamps and indicators will alert you to a vehicle condition that may become serious. Some lamps will illuminate when you start your vehicle to make sure they work. If any lamps remain on after starting your vehicle, refer to the respective system warning lamp for further information.
Page 109 Instrument Cluster Cruise Control It will illuminate when you switch this feature on. Direction Indicator Illuminates when the left or right turn signal or the hazard warning flasher is switched on. If the indicators stay on or flash faster, check for a burned out bulb. Door Ajar Displays when the ignition is on and any door is not completely closed.
Page 110 Instrument Cluster High Beam It will illuminate when the headlamp high beam is switched on. It will flash when you use the headlamp flasher. Hill descent (if equipped) Illuminates when hill descent is switched on. Liftgate ajar It will illuminate when the ignition is on and liftgate is not completely closed.
Page 111 Instrument Cluster Service Engine Soon The service engine soon indicator light illuminates when the ignition is first turned to the on position to check the bulb and to indicate whether the vehicle is ready for Inspection/Maintenance (I/M) testing. Normally, the “service engine soon” light will stay on until the engine is cranked, then turn itself off if no malfunctions are present.
Page 112: Audible Warnings And Indicators
Instrument Cluster Illuminates momentarily when two-wheel drive high is selected. 4X4 High Illuminates when four-wheel drive high is engaged. 4X4 LOW Illuminates when four-wheel drive low is engaged. 4X4 AUTO Displays when using the 4x4 system. AUDIBLE WARNINGS AND INDICATORS Key In Ignition Warning Chime Sounds when the key is left in the ignition in the off or accessory position and the driver’s door is opened.
Page 113: Information Displays
Information Displays GENERAL INFORMATION WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 114 Information Displays Scroll up/down to highlight one of the categories, then press the right arrow key or OK to enter into that category. Press the left arrow key as needed to exit back to the main menu. Display Mode Use the arrow buttons to choose between the following display options. Display Mode Distance to E Digital Speedo...
Page 115 Information Displays Driver Assist In this mode, you can configure different driver setting choices. Note: Some items are optional and may not appear. Driver Assist Normal history used or Towing history DTE Calculation used Engine Hours Engine Hours XXXXX Engine Idle Hours Engine Idle Hours XXXXX Settings In this mode, you can configure different driver setting choices.
Page 116 Information Displays Settings Create MyKey Hold OK to create MyKey 911 Assist Always On or User Selectable Do Not Disturb Always On or User Selectable Traction Control Always On or User Selectable Max Speed 65 MPH (105 km/h), 70 MPH (110 km/h), 75 MPH (120 km/h), 80 MPH *MyKey...
Page 117 Information Displays Display Mode Use the arrow buttons to choose between the following display options. Display Mode Distance to Empty Digital Speedometer — Press OK to change units Gauge Detail (Oil pressure, Oil temperature and Transmission temperature) Engine Information (Oil life, Engine hours and Engine idle hours) Trip/Fuel Use the arrow buttons to choose between the following trip and fuel options.
Page 118 Information Displays Towing Use the arrow buttons to configure different towing setting choices. Towing No Trailer connected Active trailer name or Default Trailer Trailer Status Accumulated trailer miles Trailer brake gain Trailer Sway Control - check enabled or uncheck disabled Trailer Brake Mode Elect.
Page 119 Information Displays Off Road In this mode, you can view different off road information. Off Road Pitch, Steering Angle and Roll Settings In this mode, you can configure different driver setting choices. Note: Some items are optional and may not appear. Settings Driver Select Sport, Normal or Comfort...
Page 120 Information Displays Settings Autolamp Select time Lighting Delay interval Locks Autolock - check enabled or uncheck disabled Autounlock - check enabled or uncheck disabled Remote Driver’s Door Unlock or All Doors Vehicle Oil Life Remaining Life — Hold OK to Reset Power Enable or Disable switch...
Page 121 Information Displays Information Display Controls (Type 3) • Press the up and down arrow buttons to scroll through and highlight the options within a menu. • Press the right arrow button to enter a sub-menu. • Press the left arrow button to exit a menu.
Page 122 Information Displays Display Mode Use the arrow buttons to choose between the following display options. Display Mode Digital tachometer and fuel level gauge Digital tachometer, fuel level gauge and engine coolant temperature gauge Gauge Detail (Oil pressure, Oil temperature and Transmission temperature) Engine Hours (Engine hours and Engine idle hours) Oil Life...
Page 123 Information Displays Towing Use the arrow buttons to configure different towing setting choices. Towing No trailer connected Active trailer name or Default Trailer Trailer Status Accumulated trailer miles Trailer brake gain Trailer Sway Control - check enabled or uncheck disabled Trailer Brake Mode Elect.
Page 124: Off Road
Information Displays Off Road In this mode, you can view different off road information. Off Road Off Road Status (Pitch, Roll, Wheel Angle) Settings In this mode, you can configure different driver setting choices. Note: Some items are optional and may not appear. Settings Blindspot - check enabled or uncheck disabled Cross Traffic Alert - check enabled or uncheck disabled...
Page 125 Information Displays Settings Easy Entry / Exit - check enabled or uncheck disabled Lighting Autolamp Delay Select time interval Locks Autolock - check enabled or uncheck disabled Autounlock - check enabled or uncheck disabled Remote Unlock All Doors or Driver Oil Life Remaining Life XXX% —...
Page 126: Information Messages
Information Displays INFORMATION MESSAGES Note: Depending on the vehicle options equipped with your vehicle, not all of the messages will display or be available. Certain messages may be abbreviated or shortened depending upon which cluster type you have. Press the OK button to acknowledge and remove some messages from the information display.
Page 127 Information Displays Battery and Charging System Action / Description Messages Check Charging System Stop your vehicle as soon as it is safe to do so and switch off the ignition. Contact your authorized dealer. Turn Power Off to Save Battery Displays to warn of a low 12–volt battery condition.
Page 128 Information Displays Blind Spot Information System Action / Description Messages Vehicle Coming From X Displayed when the blind spot information system with cross traffic alert (CTA) system is operating and senses a vehicle. Brake System Messages Action / Description Brake Fluid Level Low Indicates the brake fluid level is low and the brake system should be inspected immediately.
Page 129 Information Displays Fuel Messages Action / Description Check Fuel Fill Inlet Displays when the fuel fill inlet may not be properly closed. Fuel Level LOW Displays as an early reminder of a low fuel condition. Keys and Intelligent Access Action / Description Messages No Key Detected Displayed if the intelligent access...
Page 130 Information Displays Keys and Intelligent Access Action / Description Messages Accessory Power Active Displayed when the vehicle is in the accessory ignition state. Starting System Fault This message is displayed when there is a problem with your vehicle’s starting system. See an authorized dealer for service.
Page 131 Information Displays MyKey® Messages Action / Description MyKey active Drive Safely Displays when MyKey is active. Speed Limited to xx MPH/km/h Displays when starting the vehicle and MyKey is in use and the MyKey speed limit is on. Near Vehicle Top Speed Displays when a MyKey is in use and the MyKey speed limit is on and the vehicle speed is approaching 80 mph...
Page 132 Information Displays Off Road Messages Action / Description For Hill Descent Reduce Speed Displayed when hill descent speed exceeds 20 MPH (32 KM/H). For Hill Descent Select Gear Displayed when hill descent control mode requires driver shift transmission into gear. Hill Descent Driver Resume Control Displayed when the hill control mode requires the driver to resume...
Page 133 Information Displays Power Steering Messages Action / Description Steering fault Service now The power steering system has detected a condition within the power steering system that requires service immediately. See an authorized dealer. Steering assist fault Service required The power steering system has disabled power steering assist due to a system error.
Page 134 Information Displays Tire Messages Action / Description Tire Pressure Sensor Fault Displays when a tire pressure sensor is malfunctioning, or your spare tire is in use. For more information on how the system operates under these conditions, see theWheels and Tires chapter. If the warning stays on or continues to come on, contact an authorized dealer.
Page 135 Information Displays Trailer Messages Action / Description Trailer Lighting Module Fault See There is a fault with your vehicle Manual trailer lighting module. See Towing a Trailer. Trailer Stop Lamps Fault Check There is a fault with your trailer Lamps stop lamp.
Page 136 Information Displays 4WD Messages Action / Description For 4X4 Low Shift to N Displayed when 4X4 LOW is selected and the vehicle is stopped. For 4X4 Low Slow To 3 MPH Displayed when 4X4 LOW is selected while the vehicle is moving.
Page 137: Climate Control
Climate Control MANUAL CLIMATE CONTROL WITH AUXILIARY CLIMATE CONTROL (TYPE 1) REAR REAR A. Front fan speed control: Controls the volume of air circulated in your vehicle. Adjust to select the desired fan speed. B. Temperature control: Controls the temperature of the airflow in your vehicle.
Page 138 Climate Control F. REAR (temperature control): Press to turn on the auxiliary climate control system and to set the desired rear temperature with the front control. The rear temperature is the same as the front temperature when only the center rear temperature light (REAR) is lit. The rear temperature is different from the front temperature when more than one rear temperature light (REAR) is lit.
Page 139 Climate Control MANUAL CLIMATE CONTROL WITH AUXILIARY CLIMATE CONTROL (TYPE 2) A. Front fan speed control: Controls the volume of air circulated in your vehicle. Adjust to select the desired fan speed. B. Heated rear window: Turns the heated rear window on and off. See Heated windows and mirrors later in this chapter for more information.
Page 140 Climate Control F. Recirculated air: Press the button to switch between outside air and recirculated air. When you select recirculated air, the air currently in the passenger compartment recirculates. This may reduce the time needed to cool the interior (when used with A/C) and may reduce unwanted odors from entering your vehicle.
Page 141: Dual Automatic Temperature Control
Climate Control AUTOMATIC CLIMATE CONTROL A. Power and Driver temperature control: Press the button to switch the system on and off. Switching off the climate control system prevents outside air from entering the vehicle. Turn to increase or decrease the air temperature for the driver side of the vehicle.
Page 142 Climate Control H. A/C: Press the button to switch the air conditioning compressor on or off. Use air conditioning with recirculated air to improve cooling performance and efficiency. I. MAX A/C: Press the button to maximize cooling. Recirculated air flows through the instrument panel vents, air conditioning automatically turns on, and the fan automatically adjusts to the highest speed.
Page 143 Climate Control AUXILIARY CLIMATE CONTROL (IF EQUIPPED) The auxiliary climate controls are on the rear of the center console. Depending on your vehicle and option package, you may not have all these controls on your auxiliary climate controls. A. Fan speed control: Controls the volume of air circulated in the rear of your vehicle.
Page 144 Climate Control GENERAL OPERATING TIPS General Hints Note: Prolonged use of recirculated air may cause the windows to fog Note: You may feel a small amount of air from the footwell air vents regardless of the air distribution setting. Note: To reduce humidity build-up inside your vehicle, do not drive with the system switched off or with recirculated air always switched on.
Page 145 Climate Control Heating the Interior Quickly Vehicle with manual climate Vehicle with automatic control climate control Adjust the fan speed to the Press the AUTO button. highest speed setting. Adjust the temperature control Adjust the temperature control to the highest setting. to the desired setting.
Page 146 Climate Control Recommended Settings for Cooling Vehicle with manual climate Vehicle with automatic control climate control Adjust the fan speed to the Press the AUTO button. center setting. Adjust the temperature control Adjust the temperature control to the midway point of the cold to the desired setting.
Page 147: Rear Window Defroster
Climate Control HEATED WINDOWS AND MIRRORS (IF EQUIPPED) Heated Rear Window Note: The vehicle must be running to use this feature. Press the control to clear the rear window of thin ice and fog. Press the control again within 15 minutes to switch it off. It turns off automatically after approximately 15 minutes, or when you switch off the ignition.
Page 148 Climate Control Automatic Settings In hot weather, the system is set to 72°F (22°C). The cooled seats are set to high (if available, and selected to AUTO in the information display). In moderate weather, the system either heats or cools (based on previous settings).
Page 149: Seats
Seats SITTING IN THE CORRECT POSITION WARNING: Sitting improperly out of position or with the seatback reclined too far can take off weight from the seat cushion and affect the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seatback, with your feet on the floor.
Page 150: Head Restraints
Seats HEAD RESTRAINTS WARNING: Fully adjust the head restraint before you sit in or operate your vehicle. This will help minimize the risk of neck injury in the event of a crash. Do not adjust the head restraint when your vehicle is moving. WARNING: The adjustable head restraint is a safety device.
Page 151 Seats Front Seat Head Restraints The head restraints consist of : A. An energy absorbing head restraint. B. Two steel stems. C. Guide sleeve adjust and release button. D. Guide sleeve unlock and remove button. Adjusting the Head Restraint Raise: Pull up the head restraint. Lower: 1.
Page 152 Seats Second row outboard seat head restraints – The outboard head restraints are non-adjustable, but you can fold them. The non-adjustable head restraints consist of: • A trimmed energy absorbing foam and structure (A). • A fold strap (B). 1. Pull the fold strap to fold the outboard head restraint. 2.
Page 153: Manual Seats
Seats MANUAL SEATS WARNING: Do not adjust the driver seat or seatback while your vehicle is moving. This may result in sudden seat movement, causing loss of control of your vehicle. WARNING: Rock the seat backward and forward after releasing the lever to make sure that it is fully engaged.
Page 154: Power Seats
Seats Manual Lumbar (If Equipped) The lumbar support control is located on the outboard side of the seat. Turn the control to adjust your support. POWER SEATS (IF EQUIPPED) WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 155 Seats Power Recline (If Equipped) Move the switch to recline the seatback forward or rearward. Note: On vehicles with memory seats, to prevent damage to the seat, the power seats are designed to set a stopping position just short of the end of the seat track.
Page 156: Memory Function
Seats MEMORY FUNCTION (IF EQUIPPED) This feature will save and recall the positions of the driver seat, power mirrors, power steering column and optional power adjustable pedals. The memory seat control is located on the left side of the driver seat. Programming Memory Positions 1.
Page 157 Seats Easy Entry and Exit Feature (If Equipped) The Easy Entry and Exit feature adjusts the position of the seat and steering column to allow easier exit and entry to the vehicle. The driver seat automatically moves 2 inches (5 centimeters) rearward when the transmission is in park (P) and you remove the key from the ignition or you switch the ignition off.
Page 158 Seats Cooled Seats The cooled seats will only function when the engine is running. To operate the cooled seats: Press the cooled seat symbol to cycle through the various cooling settings and off. Cooler settings are indicated by more indicator lights. If the engine falls below 350 RPM while the cooled seats are on, the feature will turn itself off.
Page 159: Rear Seats
Seats REAR SEATS Folding Down the Second Row 40% Seat System WARNING: Use caution when folding the seatback to the flat back position as the system will move forward when you lift the release handle. WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 160 Seats 2. Locate handle on the side of the seat cushion by the door. 3. Pull up on the handle and push the seat back forward toward the front of the vehicle. To return the seat to the upright position: 1.
Page 161 Seats Placing the Second Row Outboard 40% Seats in Cargo Mode WARNING: Use caution when folding the seatback to the flat back position as the system will move forward when you lift the release handle. WARNING: Always return the seat from the kneel position prior to raising the seatback.
Page 162 Seats Adjusting the Second Row Outboard 40% Seat for E-Z Entry WARNING: Always latch the vehicle seat to the floor, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. WARNING: After using the E-Z Entry feature make sure there are not any objects, cargo or the feet of a third row occupant under the second row seat when latching the seat to the floor.
Page 163 Seats To return the seat to a seating position: 1. Push the seat down and latch to the floor. 2. Bring the seatback to an upright position. The seatback should lock into position. Note: If the seatback will not return to the upright position, tumble the seat again and re-latch it to the floor.
Page 164 Seats Reclining the Second-Row Outboard 40% Seatback WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a crash. The release handle is located on the outboard side of the seat cushion.
Page 165 Seats 2. With the latch released the seatback can be lowered into the load floor position. 3. To return the seat to the upright position, lift the seatback until the latch is fully engaged. Adjusting the Second-Row Center 20% Seat (If Equipped) Note: Move this seat forward to keep a child in a child restraint close to the front seat occupants.
Page 166 Seats Rear Heated Seats (If Equipped) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 167 Seats Folding Down the Third Row Seats to the Load Floor WARNING: To prevent possible damage to the seat or safety belts, make sure that the safety belts are not buckled when moving the seat to the load floor position. WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 168 Seats PowerFold™ Third-Row Seat (If Equipped) Note: The power fold down seats will operate for 10 minutes after the ignition switch is in off. The transmission must be in park (P) and the liftgate, or liftgate glass must be open. Similar to the battery saver feature, the power third row seat will be disabled 10 minutes after turning the vehicle off.
Page 169: Universal Garage Door Opener (If Equipped)
168 Universal Garage Door Opener (If Equipped) HOMELINK® WIRELESS CONTROL SYSTEM (IF EQUIPPED) WARNING: Make sure that the garage door and security device are free from obstruction when you are programming. Do not program the system with the vehicle in the garage. WARNING: Do not use the system with any garage door opener that does not have the safety stop and reverse feature as required by U.S.
Page 170 Universal Garage Door Opener (If Equipped) 169 Programming Note: Put a new battery in the hand-held transmitter. This will ensure quicker training and accurate transmission of the radio-frequency signal. 1. With your vehicle parked outside of the garage and your key in the ignition, turn the key so that the ignition is in the on position.
Page 171 170 Universal Garage Door Opener (If Equipped) After programming the HomeLink button, follow Steps 5 – 7 as listed below to program your garage door opener. Note: You may need a ladder to reach the unit and you may need to remove the cover or lamp lens on your garage door opener.
Page 172 Universal Garage Door Opener (If Equipped) 171 Programming HomeLink to a Genie Intellicode 2 garage door opener Note: The Genie Intellicode 2 transmitter must already be programmed to operate with the garage door opener. Programing the transmitters To program HomeLink to the transmitter you must first put the transmitter into programming mode.
Page 173 172 Universal Garage Door Opener (If Equipped) Programming HomeLink to the Genie Intellicode garage door opener motor Note: You may need a ladder to access the garage door opener motor. To program HomeLink to the garage door opener motor: 1. Press and hold the PROGRAM button on the garage door opener motor until both blue LED’s turn on.
Page 174: Auxiliary Power Points
Auxiliary Power Points AUXILIARY POWER POINTS WARNING: Do not plug optional electrical accessories into the cigarette lighter socket (if equipped). Improper use of the lighter can cause damage not covered by your warranty, and can result in fire or serious injury. Note: If used when the engine is not running, the battery will discharge.
Page 175 Auxiliary Power Points 110 Volt AC Power Point (If Equipped) WARNING: Do not keep electrical devices plugged in the power point whenever the device is not in use. Do not use any extension cord with the 110 volt AC power point, since it will defeat the safety protection design.
Page 176 Auxiliary Power Points The power point can switch to a fault mode when it is overloaded, overheated or shorted. Unplug your device and turn the ignition off then on for overloading and shorting conditions. Let the system cool off, then turn the ignition off then on for an overheating condition.
Page 177: Storage Compartments
Storage Compartments CENTER CONSOLE (IF EQUIPPED) Stow items in the cupholder carefully as items may become loose during hard braking, acceleration or collisions, including hot drinks which may spill. Available console features include: A. Cupholders B. Utility compartment, coin holder slots, tissue box holder, audio input jack and USB port C.
Page 178: Starting And Stopping The Engine
Starting and Stopping the Engine GENERAL INFORMATION WARNING: Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. WARNING: Do not park, idle, or drive your vehicle on dry grass or other dry ground cover.
Page 179: Ignition Switch
Starting and Stopping the Engine IGNITION SWITCH (IF EQUIPPED) A. Off: The ignition is off. Note: When you switch the ignition off and leave your vehicle, do not leave your key in the ignition. This could cause your vehicle battery to lose charge.
Page 180 Starting and Stopping the Engine Ignition Modes Off: Turns the ignition off. • Without applying the brake pedal, press and release the button once when the ignition is in the on mode, or when the engine is running but the vehicle is not in motion. Accessory: Allows some electrical accessories to operate while the engine is not running.
Page 181 Starting and Stopping the Engine Before starting the engine check the following: • Make sure all occupants have fastened their safety belts. • Make sure the headlamps and electrical accessories are off. • Make sure the parking brake is on. •...
Page 182 Starting and Stopping the Engine Fast Restart (Vehicles with Keyless Start) The fast restart feature allows you to restart the engine within 20 seconds of switching it off, even if a valid key is not present. Within 20 seconds of switching the engine off, press the brake pedal and press the button.
Page 183: Engine Block Heater
Starting and Stopping the Engine 2. If your vehicle has a keyless start system, move the transmission selector lever to position N and use the brakes to bring your vehicle to a safe stop. When your vehicle has stopped, move the transmission selector lever to position P and switch the ignition off by pressing and holding the button for one second, or pressing it three times within two seconds.
Page 184 Starting and Stopping the Engine We recommend that you do the following for safe and correct operation: • Use a 16-gauge outdoor extension cord that is product certified by Underwriter’s Laboratory or Canadian Standards Association. This extension cord must be suitable for use outdoors, in cold temperatures, and be clearly marked Suitable for Use with Outdoor Appliances.
Page 185: Fuel And Refueling
Fuel and Refueling SAFETY PRECAUTIONS WARNING: Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler inlet, do not refuel until the sound stops.
Page 186: Fuel Quality
Fuel and Refueling • Automotive fuels can be harmful or fatal if swallowed. Fuel, such as gasoline, is highly toxic and if swallowed can cause death or permanent injury. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent. The toxic effects of fuel may not be visible for hours.
Page 187 Fuel and Refueling • Fuels containing the octane booster additive, methylcyclopentadienyl manganese tricarbonyl (MMT). • Leaded-fuel (The use of leaded fuel is prohibited by law). Note: Use of any fuel other than recommended fuel can cause powertrain damage, impair the emission control system or cause loss of vehicle performance.
Page 188 Fuel and Refueling Refilling With a Portable Fuel Container WARNING: Do not insert the nozzle of portable fuel containers or aftermarket funnels into the Easy Fuel® system. This could damage the fuel system and its seal, and may cause fuel to run onto the ground instead of filling the tank, which could result in serious personal injury.
Page 189: Refueling
Fuel and Refueling REFUELING WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island. • Turn off your engine when you are refueling. •...
Page 190 Fuel and Refueling Easy Fuel® “No Cap” Fuel System WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler door, do not refuel until the sound stops. Otherwise, fuel may spray out, which could cause serious personal injury.
Page 191: Fuel Consumption
Fuel and Refueling FUEL CONSUMPTION Filling the Tank The advertised capacity is the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty. Empty reserve is the amount of fuel in the tank after the fuel gauge indicates empty.
Page 192 Information are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft® or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 193 Fuel and Refueling Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 194 Fuel and Refueling Readiness for Inspection/Maintenance (I/M) Testing Some state, provincial and local governments may have Inspection/Maintenance (I/M) programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. If the service engine soon indicator is on or the bulb does not work, the vehicle may need to be serviced.
Page 195: Transmission
Transmission AUTOMATIC TRANSMISSION WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. WARNING: Do not use the tow/haul feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control.
Page 196 Transmission R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 197 Transmission Tow/haul delays upshifts to reduce frequency of transmission shifting. Tow/haul also provides engine braking in all forward gears when the transmission is in the D (Drive) position; this engine braking will slow the vehicle and assist the driver in controlling the vehicle when descending a grade.
Page 198 Transmission Understanding your SelectShift Automatic® transmission This vehicle may be equipped with a SelectShift Automatic™ transmission (SST) gearshift lever. The SST is an automatic transmission with the ability for the driver to change gears up or down (without a clutch) as desired. The SST feature has two modes: PRS and M mode. M (Manual) Moving the gearshift lever from drive position D (Drive) to M (Manual) gives you the ability to manually change gears.
Page 199 Transmission Recommended shift speeds: Upshifts when accelerating Shift from: 1 – 2 15 mph (24 km/h) 2 – 3 25 mph (40 km/h) 3 – 4 40 mph (64 km/h) 4 – 5 45 mph (72 km/h) 5 – 6 50 mph (80 km/h) In order to prevent the engine from running at too low an RPM, which may cause it to stall, the SST will still automatically make some...
Page 200 Transmission Brake-shift interlock WARNING: Do not drive your vehicle until you verify that the brake lamps are working. WARNING: When doing this procedure, you will be taking the vehicle out of park which means the vehicle can roll freely. To avoid unwanted vehicle movement, always fully set the parking brake prior to doing this procedure.
Page 201 Transmission 6. Remove the three fasteners under the column that secure the lower shroud half to the column. 7. Pull the lock lever into the full unlocked position and remove the lower shroud cover by pulling the lever handle through the slot in the cover.
Page 202 Transmission WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the on position unless the brake pedal is pressed.
Page 203 Transmission If Your Vehicle Gets Stuck in Mud or Snow Note: Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Note: Do not rock the vehicle for more than a minute or damage to the transmission and tires may occur, or the engine may overheat.
Page 204: Four-Wheel Drive (If Equipped)
Four-Wheel Drive (If Equipped) USING FOUR-WHEEL DRIVE (4WD) (IF EQUIPPED ) WARNING: For important information regarding safe operation of this type of vehicle, see General Information in the Wheels and Tires chapter. Note: Do not use 4X4 mode on dry, hard surfaced roads. Doing so will produce excessive noise, increase tire wear and may damage drive components.
Page 205 Four-Wheel Drive (If Equipped) 4WD switch positions WARNING: Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns or abrupt maneuvers in these vehicles.
Page 206 Four-Wheel Drive (If Equipped) • 4L (4X4 LOW) provides electronically locked four-wheel drive when extra power at reduced speeds is required. The message center will display 4X4 LOW when this mode is selected. This mode is not recommended for use on dry pavement. Use this mode for off-road low-speed operation or when extra power is required, such as climbing steep grades, going through deep sand or pulling a boat out of the water.
Page 207 Four-Wheel Drive (If Equipped) How Your Vehicle Differs From Other Vehicles WARNING: Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 208 Four-Wheel Drive (If Equipped) Power is supplied to all four wheels through a transfer case. On 4WD vehicles, the transfer case allows you to select 4WD when necessary. Information on transfer case operation and shifting procedures can be found in this chapter. Information on transfer case maintenance can be found in the Maintenance chapter.
Page 209 Four-Wheel Drive (If Equipped) If your vehicle gets stuck WARNING: Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander. Note: Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 210 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 211 Four-Wheel Drive (If Equipped) When climbing a steep slope or hill, start in a lower gear rather than downshifting to a lower gear from a higher gear once the ascent has started. This reduces strain on the engine and the possibility of stalling. If you do stall out, do not try to turn around because you might roll over.
Page 212 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 213: Brakes
Brakes GENERAL INFORMATION Note: Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn out. Have them inspected by an authorized dealer. If your vehicle has continuous vibration or shudder in the steering wheel while braking, have your vehicle inspected by an authorized dealer.
Page 214: Hints On Driving With Anti-Lock Brakes
Brakes HINTS ON DRIVING WITH ANTI-LOCK BRAKES When the system is operating, the brake pedal will pulse and may travel further. Maintain pressure on the brake pedal. You may also hear a noise from the system. This is normal. The anti-lock braking system will not eliminate the risks when: •...
Page 215 Brakes Hill start assist keeps your vehicle stationary long enough to move your foot from the brake pedal to the accelerator pedal when your vehicle is on a slope. The brakes are released automatically once the engine has developed sufficient drive to prevent the vehicle from rolling down the slope. This is an advantage when pulling away on a slope, (for example from a car park ramp, traffic lights or when reversing uphill into a parking space).
Page 216: Traction Control
Traction Control PRINCIPLES OF OPERATION The traction control system helps avoid drive wheel spin and loss of traction. If your vehicle begins to slide, the system applies the brakes to individual wheels and, when needed, reduces engine power at the same time. If the wheels spin when accelerating on slippery or loose surfaces, the system reduces engine power in order to increase traction.
Page 217: Stability Control
Stability Control PRINCIPLES OF OPERATION WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction or wheel and tire size may change the handling characteristics of the vehicle and may adversely affect the performance of the AdvanceTrac® system. In addition, installing any stereo loudspeakers may interfere with and adversely affect the AdvanceTrac®...
Page 218: Advancetrac
Stability Control A Vehicle without AdvanceTrac with RSC skidding off its intended route. B Vehicle with AdvanceTrac with RSC maintaining control on a slippery surface. USING STABILITY CONTROL AdvanceTrac®With RSC™ The system automatically activates when you start your engine. You can turn off the electronic stability control and roll stability control portions of the system below 35 mph (56 km/h).
Page 219 Stability Control AdvanceTrac with RSC Features Stability Roll Electronic Traction Button control stability stability control functions OFF light control control system Button pressed and held for more than Flashes then 5 seconds at illuminated Disabled Disabled Disabled vehicle speed solid under 35 mph (56 km/h) Vehicle speed...
Page 220: Terrain Response
Terrain Response HILL DESCENT CONTROL™ (IF EQUIPPED) WARNING: Hill descent control cannot control descent in all surface conditions and circumstances, such as ice or extremely steep grades. Hill descent control is a driver assist system and cannot substitute for good judgment by the driver. Failure to do so may result in loss of vehicle control, crash or serious injury.
Page 221 Terrain Response Note: Noise from the ABS pump motor may be observed during hill descent control operation. This is a normal characteristic of the ABS and should be no reason for concern. Hill descent modes • At speeds below 20 mph (32 km/h): When the HDC button is pressed and HDC is active, HILL DESCENT CONTROL ACTIVE will appear in the message center for several seconds.
Page 222: Parking Aids
Parking Aids SENSING SYSTEM (IF EQUIPPED) WARNING: To help avoid personal injury, please read and understand the limitations of the system as contained in this section. Sensing is only an aid for some (generally large and fixed) objects when moving in reverse on a flat surface at parking speeds. Traffic control systems, inclement weather, air brakes, and external motors and fans may also affect the function of the sensing system;...
Page 223 Parking Aids The sensing system warns the driver of obstacles within a certain range of the bumper area. The system turns on automatically whenever the ignition is switched on. When receiving a detection warning, the radio volume is reduced to a predetermined level.
Page 224 Parking Aids Front Sensing System The front sensors are active when the gearshift is in any position other than P (Park) or N (Neutral) and the vehicle speed is below 8 mph (13 km/h). A. Coverage area of up to 27 inches (70 centimeters) from the front of the vehicle and about 6–9 inches (15–23 centimeters) to the side of...
Page 225: Rear-View Camera System
Parking Aids REAR VIEW CAMERA SYSTEM (IF EQUIPPED) WARNING: The rear view camera system is a reverse aid supplement device that still requires the driver to use it in conjunction with the interior and exterior mirrors for maximum coverage. WARNING: Objects that are close to either corner of the bumper or under the bumper, might not be seen on the screen due to the limited coverage of the camera system.
Page 226 Parking Aids Using the Rear View Camera System The rear view camera system displays what is behind your vehicle when you place the transmission in R (Reverse). The system uses two types of guides to help you see what is behind your vehicle: 1.
Page 227 Parking Aids Guidelines and the Centerline Note: Fixed guidelines are only available when the transmission is in R (Reverse). Note: The centerline is only available if fixed guidelines are on. A. Rear bumper B. Fixed guideline: Red zone C. Fixed guideline: Yellow zone D.
Page 228 Parking Aids Manual Zoom WARNING: When manual zoom is on, the full area behind the vehicle is not shown. Be aware of your surroundings when using the manual zoom feature. Note: Manual zoom is only available when the transmission is in R (Reverse).
Page 229: Cruise Control
Cruise Control PRINCIPLES OF OPERATION Cruise control lets you maintain a set speed without keeping your foot on the accelerator pedal. USING CRUISE CONTROL WARNING: Do not use cruise control in heavy traffic, on winding roads or when the road surface is slippery. This could result in loss of vehicle control, serious injury or death.
Page 230 Cruise Control Type Two Switching On Cruise Control The cruise controls are located on the steering wheel. Press and release ON. Setting a Speed 1. Accelerate to the desired speed. 2. Press and release SET+. 3. Take your foot off the accelerator pedal.
Page 231: Driving Aids
Driving Aids BLIND SPOT INFORMATION SYSTEM (BLIS®) WITH CROSS TRAFFIC ALERT (CTA) (IF EQUIPPED) WARNING: To help avoid injuries, NEVER use the BLIS® as a replacement for using the interior and exterior mirrors and looking over your shoulder before changing lanes. BLIS® is not a replacement for careful driving.
Page 232 Driving Aids Using the Systems BLIS® turns on when the engine is started and the vehicle is driven forward above 3 mph (5 km/h); it remains on while the transmission is in D (Drive) or N (Neutral). If shifted out of D (Drive) or N (Neutral), the system enters CTA mode.
Page 233 Driving Aids Zone coverage also decreases when parking at shallow angles. Here, the left sensor is mostly obstructed; zone coverage on that side is severely limited. System Lights and Messages The BLIS® and CTA systems illuminate a yellow alert indicator in the outside mirror on the side of the vehicle the approaching vehicle is coming from.
Page 234 Driving Aids System Sensors WARNING: Just prior to the system recognizing a blocked condition and alerting the driver, the number of missed objects will increase. To help avoid injuries, NEVER use the BLIS® as a replacement for using the side and rear view mirrors and looking over your shoulder before changing lanes.
Page 235 Driving Aids Reasons for messages being displayed Heavy rainfall/snowfall No action required. The system automatically interferes with the resets to an unblocked state once the radar signals rainfall/snowfall rate decreases or stops. Do not use BLIS® and/or CTA in these conditions. System Limitations The BLIS®...
Page 236: Steering
Driving Aids Switching the Systems Off and On One or both systems can be switched off temporarily by using the information display control; refer to the Information Display chapter. When you switch off the Blind Spot Information System, you will not receive alerts and the information display will display a system off message.
Page 237: Auto Leveling Suspension
Driving Aids for you to steer. This occurs to prevent internal overheating and permanent damage to your steering system. If this should occur, you will neither lose the ability to steer the vehicle manually nor will it cause permanent damage. Typical steering and driving maneuvers will allow the system to cool and steering assist will return to normal.
Page 238: Load Carrying
For proper function of the roof rack system, loads must be placed directly on crossbars affixed to the roof rack side rails. Your vehicle may be equipped with factory-installed crossbars. Ford Genuine Accessory crossbars, designed specifically for your vehicle, are also recommended for use with your roof rack system.
Page 239: Vehicle Loading
Load Carrying LOAD LIMIT Vehicle Loading – With and Without a Trailer This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 240 Load Carrying WARNING: The appropriate loading capacity of your vehicle can be limited either by volume capacity (how much space is available) or by payload capacity (how much weight the vehicle should carry). Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available.
Page 241 Load Carrying Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 242 Load Carrying • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
Page 243 Load Carrying GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 244 Load Carrying WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lb.” on your vehicle’s placard. 2.
Page 245: Cargo Management System
Load Carrying calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight. In metric units, the calculation would be: 635 kg - (2 x 99 kg) - (12 x 45 kg) = 635 - 198 - 540 = -103 kg.
Page 246 Load Carrying Cargo Shelf and Divider (If Equipped) WARNING: Do not load any objects on the shelf that may obstruct your vision or strike occupants of the vehicle in the case of a sudden stop or collision. WARNING: Do not place people or pets on or under the parcel shelf.
Page 247 Load Carrying POWER DEPLOYABLE RUNNING BOARDS (IF EQUIPPED) WARNING: In extreme climates, excessive ice buildup may occur, causing the running boards not to deploy. Be sure that the running boards have deployed, and have finished moving before attempting to step on them. The running boards will resume normal function once the blockage is cleared.
Page 248 Load Carrying Automatic Power Deploy The running boards will extend down and out when the doors are opened. Automatic Power Stow The running boards will return to the stowed position after a two second delay when the doors are closed. Manual Power Deploy To manually operate the running boards, refer to the Information Displays chapter.
Page 249: Towing
Towing TOWING A TRAILER WARNING: Do not exceed the GVWR or the GAWR specified on the certification label. WARNING: Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of your vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury.
Page 250 TRAILER SWAY CONTROL WARNING: Turning off trailer sway control increases the risk of loss of vehicle control, serious injury or death. Ford does not recommend disabling this feature except in situations where speed reduction may be detrimental (such as hill climbing), the driver has significant trailer towing experience, and can control trailer sway and maintain safe operation.
Page 251 Towing Note: Certain states require electric trailer brakes for trailers over a specified weight. Be sure to check state regulations for this specified weight. The maximum trailer weights listed may be limited to this specified weight, as your vehicle’s electrical system may not include the wiring connector needed to use electric trailer brakes.
Page 252 Towing ESSENTIAL TOWING CHECKS Follow these guidelines for safe towing: • Do not tow a trailer until you drive your vehicle at least 1000 miles (1600 kilometers). • Consult your local motor vehicle laws for towing a trailer. • See the instructions included with towing accessories for the proper installation and adjustment specifications.
Page 253 Towing Hitches WARNING: The trailer hitch on this vehicle is part of the vehicle rear crash safety structure. Do not remove the trailer hitch. Failure to follow this warning could compromise vehicle crash structure and increase the risk of injury in a rear end crash. Do not use a hitch that clamps onto your vehicle’s bumper.
Page 254 Towing When hooking-up a trailer using a weight-distributing hitch, always use the following procedure: 1. Park your vehicle, without the trailer, on a level surface. 2. Measure the height of the top of your vehicle’s front wheel opening on the fender. This is H1. 3.
Page 255 Towing 5. Attach the trailer to your vehicle without the weight-distributing bars connected. 6. Make sure you securely attach and lock the trailer tongue to the hitch. 7. Install safety chains, lighting, and trailer brake controls as required by law or the trailer manufacturer. 8.
Page 256: Trailer Brake Controller-Integrated
Ford has tested the trailer brake controller to be compatible with several major brands of electric-over-hydraulic trailer brakes. Contact an authorized dealer for information on which brands you can use.
Page 257 Towing information display as follows: • TBC GAIN = XX.X NO TRAILER: Shows the current gain setting during a given ignition cycle and when adjusting the gain. This also displays if you use the manual control lever or make gain adjustments with no trailer connected.
Page 258 Explanation of Information Display Warning Messages Note: An authorized dealer can diagnose the trailer brake controller to determine exactly which trailer fault has occurred. However, your Ford warranty does not cover this diagnosis if the fault is with the trailer.
Page 259 The controller module and display turn on when you turn the ignition on. • The trailer brake controller is only a factory-installed or dealer-installed item. Ford is not responsible for warranty or performance of the controller due to misuse or customer installation.
Page 260 Towing Trailer Lamps WARNING: Never connect any trailer lamp wiring to the vehicle’s tail lamp wiring; this may damage the electrical system resulting in a fire. Contact an authorized dealer as soon as possible for assistance in proper trailer tow wiring installation. Additional electrical equipment may be required.
Page 261 Towing • If you are towing a trailer frequently in hot weather, hilly conditions, at the gross combined weight rating (or any combination of these factors), consider refilling your rear axle with synthetic gear lubricant (if the axle is not already filled with it). See the Capacities and Specifications chapter for the lubricant specification.
Page 262: Wrecker Towing
We recommend the use of a wheel lift and dollies or flatbed equipment to tow your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Vehicle damage may occur if towed incorrectly, or by any other means.
Page 263: Recreational Towing
Towing TOWING THE VEHICLE ON FOUR WHEELS Emergency Towing If your vehicle becomes inoperable (without access to wheel dollies, car-hauling trailer, or flatbed transport vehicle), it can be flat-towed (all wheels on the ground, regardless of the powertrain and transmission configuration) under the following conditions: •...
Page 264 Towing 7. Leave the transmission in position N. • If your vehicle has an ignition key, turn the ignition as far as it goes toward the off position (it does not turn fully off when the transmission is in position N.) You must leave the key in the ignition while towing.
Page 265 Towing 2. Press and hold the brake pedal. 3. Shift the transmission out of N and into any gear. 4. Release the brake pedal. • If completed successfully, the instrument cluster displays 4X2 and NEUTRAL TOW DISABLED. • If the indicator light and message do not display, you must perform the procedure again from the beginning.
Page 266: Driving Hints
Driving Hints BREAKING-IN You need to break in new tires for approximately 300 miles (480 kilometers). During this time, your vehicle may exhibit some unique driving characteristics. Avoid driving too fast during the first 1000 miles (1600 kilometers). Vary your speed frequently and change up through the gears early.
Page 267: Floor Mats
Driving Hints • Add particular accessories to your vehicle (e.g.; bug deflectors, rollbars or light bars, running boards, ski racks). • Drive with the wheels out of alignment. DRIVING THROUGH WATER WARNING: Do not drive through flowing or deep water as you may lose control of your vehicle.
Page 268 Driving Hints WARNING: Always make sure that the floor mats are properly attached to the retention posts in the carpet that are supplied with your vehicle. Floor mats must be properly secured to both retention posts to make sure mats do not shift out of position. WARNING: Never place floor mats or any other covering in the vehicle foot well that cannot be properly secured to prevent them from moving and interfering with the pedals or the ability to control the...
Page 269: Roadside Emergencies
• Winch out – available within 100 feet (30.5 meters) of a paved or county maintained road, no recoveries. • Towing – Ford eligible vehicles will be towed to an authorized dealer within 35 miles (56.3 kilometers) of the disablement location or to the nearest authorized dealer.
Page 270 1-800-241-3673. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest Ford dealership within 35 miles (56.3 kilometers). To obtain reimbursement information, United States Ford vehicle customers call 1-800-241-3673. Customers will be asked to submit their original receipts.
Page 271: Hazard Warning Flashers
WARNING: Failure to inspect and, if necessary, repair fuel leaks after a collision may increase the risk of fire and serious injury. Ford Motor Company recommends that the fuel system be inspected by an authorized dealer after any collision. In the event of a moderate to severe collision, this vehicle includes a fuel pump shut-off feature that stops the flow of fuel to the engine.
Page 272: Jump-Starting The Vehicle
Roadside Emergencies Note: When you try to restart your vehicle after a fuel shutoff, the vehicle makes sure that various systems are safe to restart. Once your vehicle determines that the systems are safe, then the vehicle will allow you to restart. Note: In the event that your vehicle does not restart after your third attempt, contact an authorized dealer.
Page 273 Roadside Emergencies Connecting the Jumper Cables WARNING: Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. Note: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
Page 274 Roadside Emergencies Jump Starting 1. Start the engine of the booster vehicle and run the engine at a moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 275: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 276 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading. In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 277 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126...
Page 278 BBB Auto Line dispute, and decision, are admissible in the court action. Should you choose to accept the BBB AUTO LINE decision, Ford is then bound by the decision, and must comply with the decision within 30 days of receipt of your acceptance letter.
Page 279 (CANADA ONLY) This pertains to vehicles delivered to authorized Canadian dealers. In those cases, where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation or arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 280 Puerto Rico, contact the nearest authorized dealer. If the authorized dealer cannot help you, contact: FORD MOTOR COMPANY Customer Relationship Center 1555 Fairlane Drive Fairlane Business Park #3 Allen Park, Michigan 48101 Telephone: (800) 841-FORD (3673) FAX: (313) 390-0804 Email: prcac@ford.com www.ford.com.pr...
Page 281 If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.
Page 282: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 283: Fuses
Fuses CHANGING A FUSE Fuses WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. If electrical components in your vehicle are not working, a fuse may have blown.
Page 284 Fuses The high-current fuses are coded as follows: Fuse or relay Fuse amp rating Protected circuits location — Rear washer relay — Starter relay — Blower motor relay — Rear wiper relay — Fuel pump relay — Electronic cooling fan —...
Page 285 Fuses Fuse or relay Fuse amp rating Protected circuits location 30A** Trailer brake 20A** Power point (console) 20A** 4x4 module relay 30A** Trailer tow module 30A** Passenger power seat — Air conditioner clutch relay — Trailer tow park lamp relay —...
Page 286 Fuses Fuse or relay Fuse amp rating Protected circuits location 40A** Trailer tow module — Not used 30A** Front wiper motor relay 40A** Rear window defroster and heated mirror relay 10A* Anti-lock brake system run/start feed Powertrain control module ISP Power steering —...
Page 287 Fuses Fuse or relay Fuse amp rating Protected circuits location 25A* Vehicle power 1 – powertrain control module 20A* Vehicle power 2 – powertrain control module 20A* Vehicle power 4 – ignition coils — Not used 15A* Vehicle power 3 – powertrain control module Rain sensor —...
Page 288 Fuses To reinstall the fuse box cover, place the top part of the cover on the fuse panel, then push the bottom part of the cover until you hear it click shut. Gently pull on the cover to make sure it is seated properly. The fuses are coded as follows: Fuse or relay Fuse amp rating...
Page 289 Fuses Fuse or relay Fuse amp rating Protected circuits location SYNC, power lift gate, electric finish panel, display Run accessory relay Passive entry/start module Interior lighting, puddle lamps Right turn and stop/turn signals Left turn and stop/turn signals Reverse lamp, center high mount stop lamp, EC mirror Right front low beam Left front low beam...
Page 290 Fuses Fuse or relay Fuse amp rating Protected circuits location Rear park assist, rear camera, BLIS, heated seat Climate module, O/D switch — Not used 4X4 module EC mirror, moonroof, DVD, AM/FM radio Left and right front high beams Rear park/tail lamps 7.5A Restraints control module —...
Page 291: Maintenance
Have your vehicle serviced regularly to help maintain its roadworthiness and resale value. There is a large network of Ford authorized dealers that are there to help you with their professional servicing expertise. We believe that their specially trained technicians are best qualified to service your vehicle properly and expertly.
Page 292: Opening And Closing The Hood
Maintenance Working with the Engine Off 1. Set the parking brake and shift to P (Park). 2. Turn off the engine and remove the key (if equipped). 3. Block the wheels. Working with the Engine On WARNING: To reduce the risk of vehicle damage or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 293: Under Hood Overview
Maintenance UNDER HOOD OVERVIEW 3.5L V6 EcoBoost® engine A. Windshield washer fluid reservoir B. Battery C. Engine oil filler cap D. Engine oil dipstick E. Brake fluid reservoir F. Engine coolant reservoir G. Air filter assembly H. Power distribution box...
Page 294: Engine Oil Dipstick
Maintenance ENGINE OIL DIPSTICK A. – MIN B. – MAX ENGINE OIL CHECK Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait 15 minutes for the oil to drain into the oil pan.
Page 295: Engine Coolant Check
1. Check the engine oil level. 2. If the engine oil level is not within the normal range, add engine oil that meets Ford specifications. See Capacities and Specifications for more information. Remove the engine oil filler cap and use a funnel to pour the engine oil into the opening.
Page 296 Maintenance Note: For best results, coolant concentration should be tested with a refractometer such as Robinair Coolant and Battery Refractometer 75240. We do not recommend the use of hydrometers or coolant test strips for measuring coolant concentrations. Note: Automotive fluids are not interchangeable; do not use engine coolant/antifreeze or windshield washer fluid outside of its specified function and vehicle location.
Page 297 Severe Climates If you drive in extremely cold climates: • It may be necessary to have a Ford authorized dealer increase the coolant concentration above 50%. • A coolant concentration of 60% will provide improved freeze point protection.
Page 298 Maintenance If you drive in extremely hot climates: • It may be necessary to have a Ford authorized dealer decrease the coolant concentration to 40%. • A coolant concentration of 40% will provide improved overheat protection. Engine coolant concentrations below 40% will decrease the corrosion/freeze protection characteristics of the engine coolant and may cause engine damage.
Page 299: Automatic Transmission Fluid Check
Maintenance When Fail-Safe Mode is Activated WARNING: Fail-safe mode is for use during emergencies only. Operate the vehicle in fail-safe mode only as long as necessary to bring the vehicle to rest in a safe location and seek immediate repairs. When in fail-safe mode, the vehicle will have limited power, will not be able to maintain high-speed operation, and may completely shut down without warning, potentially losing engine power, power steering assist,...
Page 300: Brake Fluid Check
Add fluid to fill the reservoir if the level is low. Only use a washer fluid that meets Ford specifications. See the technical specifications chart in the Capacities and Specifications chapter. Note: The front and rear washer systems are supplied from the same reservoir.
Page 301: Battery
Maintenance CHANGING THE VEHICLE BATTERY WARNING: Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 302: Checking The Wiper Blades
Maintenance If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush. You can neutralize the acid with a solution of baking soda and water. It is recommended that the negative battery cable terminal be disconnected from the battery if you plan to store your vehicle for an extended period of time.
Page 303: Changing The Wiper Blades
Maintenance CHANGING THE WIPER BLADES Replace wiper blades at least once per year for optimum performance. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at a right angle to the wiper arm. 2.
Page 304: Air Filter(S)
Maintenance 4. To attach the new wiper to the wiper arm, align the cross pin and keyway (denoted with the arrows) and firmly press the wiper blade into the wiper arm until an audible snap is heard. If you find this procedure too difficult, please see your dealer. AIR FILTER CHECK WARNING: To reduce the risk of vehicle damage and or personal burn injuries, do not start your engine with the air...
Page 305 Maintenance Changing the Air Filter Element 1. Locate the mass air flow sensor electrical connector on the air outlet tube. This connector will need to be unplugged. 2. Unlock the locking clip on the connector (connector shown from below for clarity), then squeeze and pull the connector off of the air outlet tube.
Page 306 Maintenance 5. Release the three clamps that secure the cover to the air filter housing. Push the air filter cover toward the center of the vehicle and up slightly to release it. 6. Remove the air filter element from the air filter housing. 7.
Page 307: Adjusting The Headlamps
Maintenance ADJUSTING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident, an authorized dealer should check the alignment of your headlamps. Vertical Aim Adjustment 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away.
Page 308: Changing A Bulb
Maintenance 5. Locate the vertical adjuster on each headlamp, then use a Phillips #2 screwdriver to turn the adjuster either counterclockwise or clockwise in order to adjust the vertical aim of the headlamp. The upper edge of the light pattern should line up to the horizontal line.
Page 309: Removing A Headlamp
Maintenance Replacing Headlamp Bulbs WARNING: Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated. 1.
Page 310 Maintenance Replacing Front Parking Lamp and Direction Indicator Bulbs 1. Make sure that the headlamp control is in the off position. 2. Open the hood. 3. At the back of the headlamp, remove the two headlamp assembly retainer bolts. 4. Slide headlamp assembly forward and off the retaining tab to expose the back of the headlamp assembly.
Page 311 Maintenance Replacing Tail, Stop, Turn Signal, Side Marker, and Backup Lamp Bulbs The tail, stop, turn signal, side marker and backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace any bulb: 1.
Page 312 Maintenance Replacing License Plate Lamp Bulbs The license plate bulbs are located above the license plate on the liftgate. To change the license plate bulbs: 1. Make sure the headlamp switch is in the off position. 2. Remove the license lamp screw from the assembly.
Page 313 To replace all instrument panel lights - see your authorized dealer * To obtain replacement approach lamp assembly bulbs, see your authorized dealer and reference Ford part no. 2L1Z–13B374–BB for the passenger side mirror and 2L1Z–13B375–BB for the driver side mirror.
Page 314: Vehicle Care
Vehicle Care GENERAL INFORMATION Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. CLEANING PRODUCTS For best results, use the following products or products of equivalent quality: Motorcraft Bug and Tar Remover (ZC-42)
Page 315 Vehicle Care • Immediately remove items such as gasoline, diesel fuel, bird droppings and insect deposits because they can cause damage to the vehicle’s paintwork and trim over time. Use Motorcraft Bug and Tar Remover. • Note: Suntan lotions and insect repellents can damage any painted surface;...
Page 316: Waxing
Vehicle Care WAXING Regular waxing is necessary to protect the paint on your car from the elements. We recommend that you wash and wax the painted surface once or twice a year. When washing and waxing, park your vehicle in a shaded area out of direct sunlight.
Page 317: Cleaning The Windows And Wiper Blades
Vehicle Care • Spray Motorcraft Engine Shampoo and Degreaser on all parts that require cleaning and pressure rinse clean. In Canada, use Motorcraft Engine Shampoo. • Never wash or rinse the engine while it is hot or running; water in the running engine may cause internal damage.
Page 318: Cleaning The Interior
Vehicle Care CLEANING THE INTERIOR WARNING: Do not use cleaning solvents, bleach or dye on the vehicle’s safety belts, as these actions may weaken the belt webbing. WARNING: On vehicles equipped with seat-mounted airbags, do not use chemical solvents or strong detergents. Such products could contaminate the side airbag system and affect performance of the side airbag in a collision.
Page 319: Cleaning The Instrument Panel And Instrument Cluster Lens
Vehicle Care CLEANING THE INSTRUMENT PANEL AND INSTRUMENT CLUSTER LENS WARNING: Do not use chemical solvents or strong detergents when cleaning the steering wheel or instrument panel to avoid contamination of the airbag system. Note: Follow the same procedure as cleaning leather seats for cleaning leather instrument panels and leather interior trim surfaces.
Page 320 Vehicle Care CLEANING LEATHER SEATS (IF EQUIPPED, EXCEPT FOR THE KING RANCH® EDITION) Note: For the King Ranch® Edition leather seats, refer to a separate section in this chapter. • Clean spills and stains as quickly as possible. • For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a mild soap and water solution.
Page 321: Cleaning The Alloy Wheels
Vehicle Care Scratches Natural Markings - Because the leather in the seat comes from genuine steer hides, there will be evidence of naturally occurring markings, such as small scars. These markings give character to the seating covers and should be considered as proof of a genuine leather product. In order to lessen the appearance of certain scratches and other wear marks, apply conditioner on the affected area following the same instructions as in the Conditioning section.
Page 322: Vehicle Storage
Vehicle Care • Industrial-strength (heavy-duty) cleaners, or cleaning chemicals, in combination with brush agitation to remove brake dust and dirt, could wear away the clearcoat finish over time. • Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. •...
Page 323 Vehicle Care Engine • The engine oil and filter should be changed prior to storage, as used engine oil contains contaminates that may cause engine damage. • Start the engine every 15 days. Run at fast idle until it reaches normal operating temperature.
Page 324 Vehicle Care Removing Vehicle from Storage When your vehicle is ready to come out of storage, do the following: • Wash your vehicle to remove any dirt or grease film build-up on window surfaces. • Check windshield wipers for any deterioration. •...
Page 325: Wheels And Tires
Wheels and Tires GENERAL INFORMATION Notice to Utility Vehicle, Van and Truck Owners WARNING: Utility vehicles have a significantly higher rollover rate than other types of vehicles. To reduce the risk of serious injury or death from a rollover or other crash you must: •...
Page 326 Wheels and Tires Power is supplied to all four wheels through a transfer case or power transfer unit. Four-wheel drive vehicles allow you to select different drive modes as necessary. You can find information on transfer case operation and shifting procedures in the Transmission chapter. You can find information on transfer case maintenance in the Maintenance chapter.
Page 327: Tire Care
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 328 Wheels and Tires Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear 1 ⁄ times as well on the government course as a tire graded 100.
Page 329 Wheels and Tires Glossary of Tire Terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 330 Wheels and Tires INFORMATION CONTAINED ON THE TIRE SIDEWALL Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall.
Page 331 Wheels and Tires E. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. F. 95: Indicates the tire’s load index. It is an index that relates to how much weight a tire can carry.
Page 332 Wheels and Tires H. U.S. DOT Tire Identification Number (TIN): This begins with the letters DOT and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 333 Wheels and Tires M. Maximum Inflation Pressure: Indicates the tire manufacturer’s maximum permissible pressure or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the vehicle manufacturer’s recommended cold inflation pressure, which can be found on the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or Tire Label which...
Page 334 Wheels and Tires Information on T Type Tires T type tires have some additional information beyond those of P type tires. These differences are described below. T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 335 You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 336 Wheels and Tires Maximum Inflation Pressure is the tire manufacturer’s maximum permissible pressure or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure, which can be found on the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or Tire Label which is located...
Page 337 Wheels and Tires Note: Some spare tires operate at a higher inflation pressure than the other tires. For T-type mini-spare tires, see the Dissimilar Spare Tire and Wheel Assembly Information section. Store and maintain at 60 psi (4.15 bar). For full-size and dissimilar spare tires, see Dissimilar Spare Tire and Wheel Assembly Information under Changing a Road Wheel in this chapter.
Page 338 Wheels and Tires Damage Periodically inspect the tire treads and sidewalls for damage (such as bulges in the tread or sidewalls, cracks in the tread groove and separation in the tread or sidewall). If damage is observed or suspected, have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended.
Page 339 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or the Tire Label...
Page 340 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
Page 341 Wheels and Tires WARNING: Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander. Driving habits have a great deal to do with your tire mileage and safety. • Observe posted speed limits. •...
Page 342 USING SNOW CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 343 Follow these guidelines when using snow tires and chains: • If possible, avoid fully loading your vehicle. • Use only cable type chains or chains offered by Ford/Lincoln as an accessory or equivalent. Other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
Page 344: Tire Pressure Monitoring System (Tpms)
Wheels and Tires TIRE PRESSURE MONITORING SYSTEM WARNING: The tire pressure monitoring system is NOT a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge. See Inflating Your Tires in this chapter. Failure to properly maintain your tire pressure could increase the risk of tire failure, loss of control, vehicle rollover and personal injury.
Page 345 Wheels and Tires telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. The tire pressure monitoring system complies with part 15 of the FCC rules and with RSS-210 of Industry Canada.
Page 346 Wheels and Tires When you believe your system is not operating properly The main function of the tire pressure monitoring system is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 347 Wheels and Tires Low tire Possible cause Customer action required pressure warning light Flashing warning Spare tire in use Repair the damaged road wheel and light tire and reinstall it on the vehicle to restore system function. For a description on how the system functions, see When your spare tire is installed in this section.
Page 348: Changing A Road Wheel
WARNING: The use of tire sealant may damage your tire pressure monitoring system and should only be used in roadside emergencies. If you must use a sealant, the Ford Tire Mobility Kit sealant should be used. The tire pressure monitoring system sensor and valve stem on the wheel must be replaced by an authorized dealer after use of the sealant.
Page 349 Wheels and Tires 2. Full-size dissimilar spare with label on wheel: This spare tire has a label on the wheel that states: THIS TIRE AND WHEEL FOR TEMPORARY USE ONLY When driving with one of the dissimilar spare tires listed above, do not: •...
Page 350 Wheels and Tires • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability • All-wheel driving capability (if applicable) • Load leveling adjustment (if applicable) When driving with the full-size dissimilar spare tire and wheel assembly, additional caution should be given to: •...
Page 351 Wheels and Tires WARNING: Always use the jack provided as original equipment with your vehicle. If using a jack other than the one provided as original equipment with your vehicle, make sure the jack capacity is adequate for the vehicle weight, including any vehicle cargo or modifications.
Page 352 Wheels and Tires Note: Pay close attention to the orientation of the bag, because it will have to be reinstalled after changing the tire. 3. Unsnap the wheel lug nut wrench, jack extension and handle from the plastic tray. 4. Remove the jack from the tray assembly. Removing the Spare Tire 1.
Page 353 Wheels and Tires 11. Position the jack according to the jack locator arrows found on the frame and turn the jack handle and extension tool assembly clockwise. Note: Use the frame rail as the jacking location point, not the control arm. 12.
Page 354 Wheels and Tires 17. Remove the jack and fully tighten the lug nuts in the order shown and reinstall the wheel cover. See Wheel Lug Nut Torque Specifications later in this chapter for the proper lug nut torque specification. 18. Unblock the wheels. 19.
Page 355: Technical Specifications
N•m M14 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. Note: Inspect the wheel pilot hole and mounting surface prior to installation. Remove any visible...
Page 356: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 3.5L V6 EcoBoost Cubic inches Fuel Minimum 87 octane Firing order 1–4–2–5–3–6 Ignition system Coil on plug Spark plug gap 0.030–0.033 inch (0.75 – 0.85 mm) Compression ratio 10.0:1 DRIVEBELT ROUTING 1. The short drivebelt is on the first pulley groove closest to engine. 2.
Page 357 Capacities and Specifications...
Page 358 Capacities and Specifications...
Page 359 Capacities and Specifications...
Page 360 Capacities and Specifications...
Page 361: Part Numbers
WW-1612 (rear) Motorcraft replacement parts are recommended for scheduled maintenance and are available at your Ford or Lincoln dealer or at fordparts.com. These parts meet or exceed Ford Motor Company’s specifications, and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions, and durability.
Page 362: Vehicle Identification Number
Capacities and Specifications VEHICLE IDENTIFICATION NUMBER The vehicle identification number is located on the driver’s side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: A.
Page 363: Vehicle Certification Label
Capacities and Specifications VEHICLE CERTIFICATION LABEL The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label shall be affixed to either the door hinge pillar, the door latch post, or the edge of the door near the door latch,...
Page 364: Accessories
•Remote start •Vehicle security systems •Back up alarm* •Wheel locks •Locking gas plug for capless fuel •Warning sensors system •Vehicle cover* *The accessory manufacturer designs, develops and therefore warrants Ford Licensed Accessories, and does not design or test these accessories...
Page 365 • If you or an authorized Ford dealer add any non-Ford electrical or electronic accessories or components to your vehicle, you may adversely affect battery performance and durability. In addition, you may also adversely affect the performance of other electrical systems in the vehicle.
Page 366: Extended Service Plan
SERVICE PLANS (U.S. Only) More than 32 million Ford owners have discovered the powerful protection of Ford Extended Service Plan. It is the only extended service plan backed by Ford Motor Company, and provides peace of mind protection beyond the New Vehicle Limited Warranty coverage.
Page 367 • Destination assistance for taxi, shuttle, rental car coverage and emergency transportation Transferable Coverage If you sell your vehicle before your Ford Extended Service Plan coverage expires, you can transfer any remaining coverage to the new owner. Whenever you sell your vehicle, prospective buyers may have a higher degree of confidence that vehicle was properly maintained with Ford ESP, thereby improving resale value.
Page 368 Ford ESP has to offer while paying over time. You are pre-approved with no credit checks, no hassles! To learn more, call our Ford ESP specialists at 800-367-3377. Ford ESP P.O.
Page 369: Audio System
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Note: Do not insert CDs with homemade paper (adhesive) labels into the CD player as the label may peel and cause the CD to become jammed.
Page 370 Audio System MP3 Track and Folder Structure Audio systems capable of recognizing and playing MP3 individual tracks and folder structures work as follows: • There are two different modes for MP3 disc playback: MP3 track mode (system default) and MP3 folder mode. •...
Page 371: Myford™ System
Audio System AM/FM/CD/SYNC/SIRIUS WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 372 Audio System B. Number block: • In radio mode, store your favorite stations for later access. When tuned to any station, press and hold a preset button until sound returns. • In CD mode, press a button to select a track. •...
Page 373 Audio System L. PHONE: Press this button to access the phone features of the SYNC system. See the SYNC chapter for more information. M. MENU: Press this button to access different audio system features. See Menu structure later in this section. N.
Page 374 Audio System SIRIUS Scan Select for a brief sampling of all available channels. Show ESN Select to view your satellite radio electronic serial number (ESN). You need this number when communicating with Sirius to activate, modify or track your account. Select to view available satellite radio Channel Guide channels.
Page 375 Audio System Audio Settings Speed Compensated Automatically adjusts the volume to Volume compensate for speed and wind noise. You can set the system between 0 and +7. Sound Select to adjust settings for Treble, Middle, Bass, Fade and Balance. Select to optimize sound quality for the chosen Occupancy Mode seating position.
Page 376 Audio System AM/FM/CD SONY AUDIO SYSTEM WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 377: Rear Seat Controls
Audio System E. VOL and Power: • Press this button to switch the system off and on. • Turn it to adjust the volume. F. Eject: Press this button to eject a CD. G. CD Slot: Insert a CD. REAR AUDIO CONTROLS Your vehicle is equipped with rear seat audio controls.
Page 378 Audio System HD RADIO™ INFORMATION (IF AVAILABLE) Note: HD Radio broadcasts are not available in all markets. HD Radio technology is the digital evolution of analog AM/FM radio. Your system has a special receiver that allows it to receive digital broadcasts (where available) in addition to the analog broadcasts, it already receives.
Page 379 Audio System HD Radio Reception and Station Troubleshooting Potential reception issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength. If you are listening to HD1, the system switches back to the analog broadcast until the digital broadcast is available again.
Page 380 HD Radio™ Technology manufactured under license from iBiquity Digital Corp. U.S. and foreign patents. HD Radio™ and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology.
Page 381: Satellite Radio Information
Audio System SATELLITE RADIO INFORMATION (IF EQUIPPED) Satellite Radio Channels Sirius broadcasts a variety of music, news, sports, weather, traffic and entertainment satellite radio channels. For more information and a complete list of Sirius satellite radio channels, visit www.siriusxm.com in the United States, www.sirius.ca in Canada, or call Sirius at 1–888–539–7474.
Page 382 Note: Sirius reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 383 Audio System Radio display Condition Possible action Invalid Channel The channel is no Tune to another longer available. channel or choose another preset. Unsubscribed Channel Your subscription does Contact Sirius at not include this 1–888–539–7474 to channel. subscribe to the channel, or tune to another channel.
Page 384: Auxiliary Input Jack
Audio System AUXILIARY INPUT JACK WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 385: Usb Port
Audio System 3. Switch the radio on. Select either a tuned FM station or a CD. 4. Adjust the volume as desired. 5. Switch your portable music player on and adjust its volume to half its maximum level. 6. Press AUX until LINE or LINE IN appears in the display. You should hear music from your device even if it is low.
Page 386 Audio System MEDIA HUB The media hub is located in the center console and has the following features: A. Auxiliary input jack B. USB ports C. SD card slot For more information, see the MyFord Touch chapter.
Page 387: Sync
SYNC® SYNC is an in-vehicle communications system that works with your Bluetooth-enabled cellular phone and portable media player. This allows you to: • Make and receive calls. • Access and play music from your portable music player. • Use 911 Assist, Vehicle Health Report and SYNC Services (Traffic, Directions &...
Page 388 SYNC® GENERAL INFORMATION Make sure you review your device’s manual before using it with SYNC. Support The SYNC support team is available to help you with any questions you cannot answer on your own. Monday-Saturday, 8:30am-9:00pm EST. Sunday, 10:30am-7:30pm EST. In the United States, call: 1–800–392–3673.
Page 389 Master Reset to erase all stored information. System data cannot be accessed without special equipment and access to the vehicle’s SYNC module. Ford Motor Company and Ford of Canada do not access the system data for any purpose other than as described...
Page 390 SYNC® USING VOICE RECOGNITION This system helps you control many features using voice commands. This allows you to keep your hands on the wheel and focus on what is in front of you. Initiating a Voice Session Push the voice icon; a tone sounds and Listening appears in the display.
Page 391 SYNC® Adjusting the Interaction Level Push the voice icon; when prompted, say “Voice settings”, then any of the following: When you say: The system: “Interaction mode standard” Provides more detailed interaction and guidance. “Interaction mode advanced” Provides less audible interaction and more tone prompts.
Page 392 SYNC® • Speak naturally, without long pauses between words. • At any time you can interrupt the system while it is speaking by pressing the voice icon. USING SYNC WITH YOUR PHONE Hands-free calling is one of the main features of SYNC. While the system supports a variety of features, many are dependent on your cellular phone’s functionality.
Page 393 SYNC® Depending on your phone’s capability and your market, the system may prompt you with questions such as setting the current phone as the primary phone (the phone SYNC automatically tries to connect with first upon vehicle start-up), downloading your phone book, etc. Pairing Subsequent Phones Note: To scroll through the menus, press the up and down arrows on your audio system.
Page 394 SYNC® “PHONE” “Call <name> at home” “Call <name> at work” OR “Call <name> in office” “Dial” “Phone book <name>” “Phone book <name> at work” OR “Phone book <name> at office” “Call history incoming” “Connections” “Go to privacy” “Hold” These commands do not require you to say “Phone” first. These commands are not available until phone information is completely downloaded using Bluetooth.
Page 395 SYNC® “DIAL” “411” (four-one-one), “911” (nine-one-one) “700 (seven hundred)” (seven hundred) “800 (eight hundred)” (eight hundred) “900 (nine hundred)” (nine hundred) “#” (pound) “<number> 0–9” “Asterisk” (*) “Clear” (deletes all entered digits) “Delete” (deletes one digit) “Plus” “Star” Note: To exit dial mode, press and hold the phone button or press MENU to go to the PHONE menu.
Page 396 SYNC® To access: 1. Press MENU during an active call. 2. When Active Call Menu is selected, press OK. 3. Scroll to cycle through the following options: When you select: You can: Mute the call. Mute Call? Switch a call from an active hands-free Privacy environment to your cellular phone for a more private conversation.
Page 397 SYNC® When you select: You can: Access your call history log. Call History 1. Press OK to select, then scroll through your call history options (incoming, outgoing or missed). 2. Press OK when the desired selection appears in the display. 3.
Page 398 SYNC® When you select: You can: Allows you to access your downloaded Phonebook phonebook. 1. Press OK to confirm and enter. If your phonebook has fewer than 255 listings, they appear alphabetically in flat file mode. If there are more, they are organized into alphabetical categories.
Page 399 SYNC® Text Messaging Note: This is a phone-dependent feature. SYNC allows you to receive, send, download and delete text messages. The system can also read incoming text messages to you so that you do not have to take your eyes off the road. Receiving a Text Message Note: This is a phone-dependent feature.
Page 400 6. Press OK when the contact appears and press OK again to confirm when the system asks if you would like to send the message. Each text message is sent with the following signature: “This message was sent from my <Ford or Lincoln>”. Pre-defined text message options Can’t talk right now...
Page 401 SYNC® Pre-defined text message options I need more directions I love you Too funny Can’t wait to see you I’m stuck in traffic Accessing Your Phone Settings These are phone-dependent features. Your phone settings allow you to access and adjust features such as your ring tone, text message notification, modify your phone book and also set up automatic download.
Page 402 SYNC® When you select: You can: Modify the contents of your phone book Modify Phonebook (such as add, delete, download). Press OK to select and scroll between: Add Contacts: Press OK to add more contacts from your phone book. Push the desired contact(s) on your phone.
Page 403 SYNC® System Settings System Settings provide access to your Bluetooth Devices and Advanced menu features. Use the arrow buttons to scroll through the menu options. The Bluetooth Devices menu allows you to add, connect, delete and set a phone as primary as well as turn your Bluetooth feature on and off. The Advanced menu allows you to access and set prompts, languages, defaults, perform a master reset, install an application and view system information.
Page 404 SYNC® If you select: You can: Set Bluetooth On/Off Turn the Bluetooth feature on and off. Press OK and scroll to toggle between On and Off. When the desired selection is chosen, press OK. Note: Turning Bluetooth off disconnects all Bluetooth devices and deactivates all Bluetooth features.
Page 405 SYNC® If you select: You can: Choose between English, Espanol and Languages Francais. Once selected, all of SYNC’s radio displays and prompts are in the selected language. 1. Press OK to select and then scroll through the languages. 2. Press OK when the desired selection appears in the display.
Page 406: Assist
SYNC® SYNC APPLICATIONS AND SERVICES (IF EQUIPPED) Note: In order for the following features to work, your cellular phone must be compatible with SYNC. To check your phone’s compatibility, visit www.SYNCMyRide.com, www.SYNCMyRide.ca or www.syncmaroute.ca. • SYNC Services (if equipped, United States only): Provides access to traffic, directions and information such as travel, horoscopes, stock prices and more.
Page 407 SYNC® If a crash deploys an airbag (excludes knee airbags and rear inflatable safety belts [if equipped]) or activates the fuel pump shut-off, your SYNC equipped vehicle may be able to contact emergency services by dialing 911 through a paired and connected Bluetooth-enabled phone. For more information about 911 Assist, visit www.SYNCMyRide.com, www.SYNCMyRide.ca or www.syncmaroute.ca.
Page 408 SYNC® In the Event of a Crash Not all crashes deploy an airbag or activate the fuel pump shut-off (which would activate 911 Assist); however, if 911 Assist is triggered, SYNC tries to contact emergency services. If a connected phone is damaged or loses connection to SYNC, SYNC searches for, and tries to connect to, any available previously paired phone and tries to make the call to 911.
Page 409: Vehicle Health Report
SYNC® Vehicle Health Report WARNING: Always follow scheduled maintenance instructions, regularly inspect your vehicle, and seek repair for any damage or problem you suspect. Vehicle Health Report supplements, but cannot replace normal maintenance and vehicle inspection. Vehicle Health Report only monitors certain systems that are electronically monitored by the vehicle and will not monitor or report the status of any other system, (such as brake lining wear).
Page 410 Certain versions or updates to Vehicle Health Report may also collect additional vehicle information. Ford may use the vehicle information it collects for any purpose. If you do not want to disclose your cellular phone number or vehicle information, do not run the feature or set up your Vehicle Health Report profile at www.SYNCMyRide.com.
Page 411 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect the vehicle travel information or other information identified in the Terms and Conditions, do not activate or use the service.
Page 412 SYNC® Connecting to SYNC Services Using Voice Commands 1. Press the voice button. 2. When prompted, say “Services”. This initiates an outgoing call to SYNC Services using your paired and connected Bluetooth-enabled cellular phone. 3. Once you are connected to the service, follow the voice prompts to request the desired service, such as “Traffic”...
Page 413 SYNC® 3. While on an active route, you can select or say “Route summary” or “Route status” to view the Route Summary turn list or the Route Status ETA. You can also turn voice guidance on or off, cancel the route or update the route.
Page 414 SYNC® SYNC AppLink™ Note: You must pair and connect your smartphone to SYNC to access AppLink. Note: iPhone users need to connect the phone to the USB port in order to start the application. We recommend you lock your iPhone after starting an application.
Page 415 SYNC® 7. Select SYNC-Media by pressing OK. 8. Scroll until <App Name> Menu is displayed (such as, Pandora Menu), then press OK. From here, you can access an application’s features, such as Thumbs up and Thumbs down. For more information, please visit www.SYNCMyRide.com.
Page 416 SYNC® 5. Depending on how many digital media files are on your connected device, Indexing may appear in the radio display. When indexing is complete, the screen returns to the Play Menu. 6. Press OK and scroll through selections of: •...
Page 417 SYNC® “USB” “Play playlist <name>” “Play previous folder” “Play previous track” “Play song <name>” “Play track <name>” “Refine album <name>” “Refine artist <name>” “Refine song <name>” “Refine track <name>” “Repeat off” “Repeat on” “Search album <name>” “Search artist <name>” “Search genre <name>” “Search song <name>”...
Page 418 SYNC® Voice command guide “Search/Play Genre” The system searches all the data from your indexed music and, if available, begins to play the chosen type of music. You can only play genres of music which are present in the GENRE metadata tags that you have on your digital media player.
Page 419 SYNC® Media Menu Features The media menu allows you to select your media source, how to play your music (by artist, genre, shuffle, repeat, etc.), and also to add, connect or delete devices. 1. Press AUX and then MENU to enter the Media Menu. 2.
Page 420 SYNC® When you select: You can: Choose to shuffle or repeat your music and Media Settings select your Autoplay settings. Once these selections are turned on, they remain on until turned off. Press SEEK to play the previous or next track. Note: Some digital media players require both USB and line in ports to stream data and music separately.
Page 421 SYNC® Accessing Your Play Menu This menu allows you to select and play your media by artist, album, genre, playlist, track, similar music or even to explore what is on your USB device. 1. Make sure that your device is plugged into the USB port and is turned on.
Page 422 SYNC® When you select: You can: Sort indexed music by genre (category) type. Genres SYNC lists the genres alphabetically in flat file mode. If there are more than 255, SYNC automatically organizes them into alphabetical categories. Press OK to select and then scroll to select the desired genre and press OK.
Page 423 SYNC® When you select: You can: Similar Music Play music similar to what is currently playing from the USB port. The system uses the metadata information of each song to compile a playlist for you. Press OK to select. The system creates a new list of similar songs and begins playing.
Page 424 SYNC® 4. Press OK and then scroll to select from: When you select: You can: Add Bluetooth Allows you to pair additional devices to the system. Device 1. Press OK to select and press OK again when Find SYNC appears in the display. 2.
Page 425 SYNC® Advanced Menu Options This menu allows you to access settings such as prompts, language, performing a master reset as well as returning to factory defaults. 1. Press AUX and then MENU to access the Media Menu. 2. Scroll until System Settings appears and select OK. 3.
Page 426 SYNC® When you select: You can: Completely erase all information stored on Master Reset SYNC (all phonebook, call history, text messages and all paired devices) and return to the factory default settings. Application Download new software applications (if available) and then load the desired applications through your USB port.
Page 427 SYNC® Phone issues Issue Possible Possible solution(s) cause(s) • This is a • Go to the website to review SYNC is not able to download my phone-dependent your phone’s compatibility. • Try turning off the device, phonebook. feature, OR • Possible phone resetting the device or removing malfunction.
Page 428 SYNC® Phone issues Issue Possible Possible solution(s) cause(s) • This is a • Go to the website to review I am having trouble phone-dependent your phone’s compatibility. • Try turning off the device, connecting my feature, OR • Possible phone phone to SYNC.
Page 429 SYNC® USB and media issues Issue Possible Possible solution(s) cause(s) • Try turning off the device, I am having Possible device trouble connecting malfunction. resetting the device or removing my device. the device’s battery, then trying again. • Make sure you are using the manufacturer’s cable.
Page 430 SYNC® Vehicle Health Report and SYNC Services (Traffic, Directions and Information) issues Issue Possible Possible solution(s) cause(s) • Your account • This is a free feature, but you I received a text that the Vehicle may not be must first register online to use it. •...
Page 431 SYNC® Voice command issues Issue Possible Possible solution(s) cause(s) • You may be • Review the Phone voice SYNC does not understand what using the wrong commands and the Media voice I am saying. voice commands, commands at the beginning of their respective sections.
Page 432 SYNC® Voice command issues Issue Possible Possible solution(s) cause(s) • You may be • Review the phone voice SYNC does not understand or is using the wrong commands at the beginning of calling the wrong voice commands, the phone section. •...
Page 433 • Some apps require you to register or login on the app on the phone before using them with AppLink. Also, some may have a Ford SYNC setting, so check the app’s settings menu on the phone.
Page 434 SYNC® AppLink issues Issue Possible Possible solution(s) cause(s) • Closing and restarting apps My phone is Sometime apps connected, my do not properly may help SYNC find the app(s) are close and re-open application if you cannot running, but I still their connection discover it inside the vehicle.
Page 435 SYNC® AppLink issues Issue Possible Possible solution(s) cause(s) My Android There is a Reset the Bluetooth on your phone is bluetooth bug on phone by turning it off and then connected, my some order turning Bluetooth back on. If app(s) are versions of the you are in your vehicle, SYNC running, I...
Page 436 SYNC to find. If AppLink apps limited number of the app has a Ford SYNC running on my bluetooth ports setting, disable that setting in phone listed in apps can use to the app’s settings menu on the...
Page 437: Myford Touch® (If Equipped)
MyFord Touch® (If Equipped) GENERAL INFORMATION WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 438 MyFord Touch® (If Equipped) This system uses a four-corner strategy to provide quick access several vehicle features and settings. The touchscreen provides easy interaction with your cellular phone, multimedia, climate control and navigation system. The corners display any active modes within those menus, such as phone status or the climate temperature.
Page 439 MyFord Touch® (If Equipped) SETTINGS Press to select any of the following: • Clock • Display • Sound • Vehicle • Settings • Help HOME Press to access your home screen. Depending on your vehicle’s option package and software, your screens may vary in appearance from the descriptions in this section.
Page 440 MyFord Touch® (If Equipped) Using the Touchscreen To turn a feature on and off, just touch the graphic with your finger. To get the best performance from the touch-sensitive controls: • Make sure your hands are clean and dry. • Press firmly on the center of a control graphic or menu item. •...
Page 441 MyFord Touch® (If Equipped) Cleaning the Touchscreen Display Use a clean, soft cloth such as one used for cleaning glasses. If dirt or fingerprints are still visible, apply a small amount of alcohol to the cloth. Do not pour or spray alcohol onto the display. Do not use detergent or any type of solvent to clean the display.
Page 442 MyFord Touch® (If Equipped) Speed-restricted Features Some features of this system may be too difficult to use while your vehicle is moving so they are restricted from use unless your vehicle is stationary. • Screens that are too crowded with information, such as Point of Interest reviews and ratings, Sirius Travel Link sports scores, movie times and ski conditions.
Page 443 Master Reset to erase all stored information. System data cannot be accessed without special equipment and access to the vehicle’s SYNC module. Ford Motor Company and Ford of Canada do not access the system data for any purpose other than as described...
Page 444: Voice Recognition
MyFord Touch® (If Equipped) Note: If your vehicle is not equipped with Navigation, Compass appears in the display instead of Navigation. If you press the right arrow to go into the Compass menu, you can see the compass graphic. The compass displays the direction in which the vehicle is traveling, not true direction.
Page 445 MyFord Touch® (If Equipped) How to Use Voice Commands with Your System Press the voice icon. After the tone, speak your command clearly. These commands can be said at any time. “Cancel” “Exit” “Go back” “List of commands” “Main menu” “Next page”...
Page 446 MyFord Touch® (If Equipped) Accessing a List of Available Commands • If you use the touchscreen, press the Settings icon > Help > Voice Command List. • If you use the steering wheel control, press the voice icon. After the tone, speak your command clearly.
Page 447 MyFord Touch® (If Equipped) Confirmation Prompts: The system uses these short questions to confirm your voice request. If turned off, the system simply makes a best guess as to what you requested. The system may still occasionally ask you to confirm settings. Phone/Media Candidate Lists: Candidate lists are lists of possible results from your voice commands.
Page 448: Listening To Music
MyFord Touch® (If Equipped) ENTERTAINMENT A. AM 1 and AM AST B. FM 1, FM 2 and FM AST C. SIRIUS D. CD E. USB F. Touch this button to scroll down for more options, such as: • SD Card •...
Page 449 MyFord Touch® (If Equipped) Browsing Device Content When listening to audio on a device, you can browse through other devices without having to change sources. For example, if you are currently listening to audio on an SD card, you can browse all the artists that are stored on your USB device.
Page 450 MyFord Touch® (If Equipped) device, then want to switch to a satellite radio channel, simply press the voice button on the steering wheel controls and say the name of the Sirius station (such as, “the Highway”). The following voice commands are available at the top level of the voice session no matter which current audio source you are listening to (such as a USB device or Sirius satellite radio).
Page 451 MyFord Touch® (If Equipped) Options Sound Settings allows you to adjust settings for: • Bass • Midrange • Treble • Balance and Fade • DSP (Digital Signal Processing) • Occupancy Mode • Speed Compensated Volume. Note: Your vehicle may not have all these sound settings. Set PTY for Seek/Scan allows you to select a category of music you would like to search for.
Page 452 MyFord Touch® (If Equipped) When HD Radio is on and you tune to a station broadcasting HD Radio technology, you may notice the following indicators on your screen: HD) logo is grey when acquiring a digital station, and then changes to orange when digital audio is playing. When this logo is available, you may also see Title and Artist fields on-screen.
Page 453 MyFord Touch® (If Equipped) HD Radio Reception and Station Troubleshooting Potential Reception Issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength.
Page 454 HD Radio Technology manufactured under license from iBiquity Digital Corp. U.S. and foreign patents. HD Radio and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology.
Page 455 MyFord Touch® (If Equipped) Radio Voice Commands If you are listening to the radio, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to the radio, press the voice button and, after the tone, say “Radio”, then any of the commands in the following chart.
Page 456 MyFord Touch® (If Equipped) Sirius Satellite Radio (If Activated) Press the lower left corner of the touchscreen, then select the SIRIUS tab. Presets Save a channel by pressing and holding one of the memory preset areas. There is a brief mute while the radio saves the channel. Sound returns when finished.
Page 457 Note: Sirius does not support the Alert feature on all channels. Ford Motor Company shall not be responsible for Alert feature variation. Electronic Serial Number (ESN) is required when you need to activate, modify or track your satellite radio account.
Page 458 MyFord Touch® (If Equipped) Satellite Radio Voice Commands If you are listening to Sirius satellite radio, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to Sirius satellite radio, press the voice button and, after the tone, say “Sirius”, then any of the commands in the following chart.
Page 459 Note: Sirius reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 460 MyFord Touch® (If Equipped) Sirius troubleshooting tips Radio display Condition Possible action Acquiring... Radio requires more No action required. This than two seconds to message should produce audio for the disappear shortly. selected channel. Sat Fault/SIRIUS There is an internal If this message does not system failure.
Page 461 MyFord Touch® (If Equipped) Press the lower left corner of the touchscreen, and then select the CD tab. You can also advance and reverse the current track or current folder, if applicable. Repeat Touch this button to repeat the currently playing track, all tracks on the disc or turn the feature off if already on.
Page 462 MyFord Touch® (If Equipped) CD Voice Commands If you are listening to a CD, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to a CD, press the voice button and, after the tone, say “CD”, then any of the commands in the following chart.
Page 463 MyFord Touch® (If Equipped) USB Port The ports are located either in the center console or behind a small access door in the instrument panel. To access and play music from your device, press the lower left corner of the touchscreen, and then select the USB tab.
Page 464 MyFord Touch® (If Equipped) Browse allows you to view the contents of the device. It also allows you to search by categories, such as genre, artist or album. If you want to view song information such as Title, Artist, File, Folder, Album, and Genre, touch the on-screen album art.
Page 465 MyFord Touch® (If Equipped) “USB” or “SD CARD” “Play podcast <name>” “Help” “Play podcast episode <name>” If you have said you would like to browse your USB or SD card, the system prompts you to specify what you would like to browse. When prompted, see the following “Browse”...
Page 466 MyFord Touch® (If Equipped) If your indexed media files contain no information embedded in these metadata tags, SYNC may classify the empty metadata tags as Unknown. In order to playback video from your iPod® or iPhone®, (if compatible), you MUST have a special combination USB/RCA composite video cable (which you can buy from Apple®).
Page 467 MyFord Touch® (If Equipped) WARNING: Store the portable music player in a secure location, such as the center console or the glove box, when your vehicle is in motion. Hard objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. The audio extension cable must be long enough to allow the portable music player to be safely stored while your vehicle is moving.
Page 468: Phone Features
MyFord Touch® (If Equipped) PHONE A. Phone B. Quick Dial C. Phonebook D. History E. Messaging F. Settings Hands-free calling is one of the main features of SYNC. Once you pair your phone, you can access many options using the touchscreen or voice commands.
Page 469 MyFord Touch® (If Equipped) Pairing Your Phone for the First Time WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
Page 470 MyFord Touch® (If Equipped) 4. When prompted on your phone’s display, confirm that the PIN provided by SYNC matches the PIN displayed on your cellular phone. 5. The display indicates when the pairing is successful. SYNC may prompt you with more phone options. For more information on your phone’s capability, see your phone’s user guide and visit the website.
Page 471 MyFord Touch® (If Equipped) Phonebook Touch this button to access and call any contacts in your previously downloaded phone book. The system places the entries in alphabetical categories summarized at the top of the screen. To turn on contact picture settings, if your device supports this feature, press Phone >...
Page 472 MyFord Touch® (If Equipped) Composing a Text Message Note: This is a speed-dependent feature. It is unavailable when your vehicle is traveling at speeds over 3 mph (5 km/h). Note: Downloading and sending text messages using Bluetooth are phone-dependent features. 1.
Page 473 MyFord Touch® (If Equipped) • Dial to call the contact. • Ignore to exit the screen. Note: If you select View and your vehicle is traveling over 3 mph (5 km/h), the system offers to read the message to you instead of allowing you to view it while driving.
Page 474 MyFord Touch® (If Equipped) Roaming Warning Touch this button to have the system alert you when your phone is in roaming mode. Phone Voice Commands Press the voice button on the steering wheel control. After the tone, say any of the following commands: “PHONE”...
Page 475: Information Menu
Note: SYNC Services varies by trim level and model year and may require a subscription. Traffic alerts and turn-by-turn directions available in select markets. Message and data rates may apply. Ford Motor Company reserves the right to change or discontinue this product service at any time without prior notification or incurring any future obligation.
Page 476 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your vehicle travel information or other information identified in the Terms and Conditions, do not subscribe or use the service.
Page 477 MyFord Touch® (If Equipped) Connecting to SYNC Services Using the Touchscreen If your vehicle is equipped with Navigation, touch the i (Information) button to access these features. If your vehicle is not equipped with Navigation, touch the corner of the touchscreen with the green tab.
Page 478 MyFord Touch® (If Equipped) If you miss a turn, SYNC automatically asks if you want the route updated. Just say, “Yes” when prompted and the system delivers a new route to your vehicle. If your vehicle is equipped with Navigation, SYNC Services downloads your requested destination to the navigation system.
Page 479 Note: Visit www.siriusxm.com/traffic# and click on Coverage map and details for a complete listing of all traffic areas covered by Sirius Travel Link. Note: Neither Sirius nor Ford is responsible for any errors or inaccuracies in the Sirius Travel Link services or its use in vehicles.
Page 480 MyFord Touch® (If Equipped) When you subscribe to Sirius Travel Link, it can help you locate the best gas prices, find movie listings, get current traffic alerts, view the current weather map, get accurate ski conditions and see scores to current sports games.
Page 481 MyFord Touch® (If Equipped) Sirius Travel Link Voice Commands Note: In order to use Sirius Travel Link, your vehicle must be equipped with navigation and your navigation SD card must be in the SD card slot. Press the voice button on the steering wheel controls and, when prompted, say any of the following: Travel Link voice commands “5–day weather forecast”...
Page 482 MyFord Touch® (If Equipped) “TRAVEL LINK” “College basketball “Motor sports order” “NHL schedule” schedule” “College basketball “Motor sports “NHL scores” scores” schedule” “College football “Movie listings” “Traffic” headlines” “College football “My team headlines” “Weather” schedule” “College football “My teams schedule” “Weather map”...
Page 483 MyFord Touch® (If Equipped) 911 Assist® (If Equipped) WARNING: Unless the 911 Assist setting is set on before a crash, the system will not dial for help, which could delay response time, potentially increasing the risk of serious injury or death after a crash.
Page 484 MyFord Touch® (If Equipped) Setting 911 Assist On If your vehicle is equipped with Navigation, touch the i (Information) button to access these features. If your vehicle is not equipped with Navigation, touch the corner of the touchscreen with the green tab. Press Apps >...
Page 485 MyFord Touch® (If Equipped) 911 Assist May Not Work If • Your cellular phone or 911 Assist hardware sustains damage in a crash. • The vehicle’s battery or SYNC system has no power. • The phones(s) previously paired or connected to the system are thrown from the vehicle.
Page 486 “Vehicle health report”. Vehicle Health Report Privacy Notice When you create a Vehicle Health Report, Ford Motor Company may collect your cellular phone number (to process your report request) and diagnostic information about your vehicle. Certain versions or updates to Vehicle Health Report may also collect more vehicle information.
Page 487: Settings
MyFord Touch® (If Equipped) SETTINGS A. Clock B. Display C. Sound D. Vehicle E. Settings F. Help Under this menu, you can set your clock, access and adjust the display, sound and vehicle settings as well as access settings for specific modes or the help feature.
Page 488 MyFord Touch® (If Equipped) Display You can adjust the touchscreen display through the touchscreen or by pressing the voice button on your steering wheel controls and when prompted, say, “Display settings”. Press the Settings icon > Display, to access and make adjustments using the touchscreen.
Page 489 MyFord Touch® (If Equipped) Sound Press the Settings icon > Sound, then select from the following: Sound Settings Bass Midrange Occupancy Mode Treble Speed Compensated Volume Set Balance and Fade If equipped. Vehicle Press the Settings icon > Vehicle, then select from the following: •...
Page 490 MyFord Touch® (If Equipped) Camera Settings This menu allows you to access settings for your rear view camera. Press the Settings icon > Vehicle > Camera Settings, then select from the following settings: • Enhanced Park Aids. • Rear Camera Delay. Enable Valet Mode Valet mode allows you to lock the system.
Page 491 MyFord Touch® (If Equipped) System Keyboard Layout Have the touchscreen keyboard display in QWERTY or ABC format. Install Applications Install any downloaded applications or view the current software licenses. Select to restore factory defaults. This erases Master Reset all personal settings and personal data. Voice Control Press the Settings icon >...
Page 492 MyFord Touch® (If Equipped) Media Player Press the Settings icon > Settings > Media Player, then select from the following: Media player Autoplay When this feature is on, the system automatically switches to the media source upon initial connection. This allows you to listen to music during the indexing process.
Page 493 MyFord Touch® (If Equipped) Navigation Press the Settings icon > Settings > Navigation, then select from the following: Navigation Map Preferences Turn breadcrumbs on and off. Have the system display your turn list top to bottom or bottom to top. Turn the Parking POI notification on and off.
Page 494 MyFord Touch® (If Equipped) Navigation Traffic Preferences Have the system display areas where roadwork occurs. Have the system display incident icons. Have the system display areas where difficult driving conditions may occur. Have the system display areas where snow and ice on the road may occur. Have the system display any smog alerts.
Page 495 MyFord Touch® (If Equipped) Phone Settings Press the Settings icon > Settings > Phone, then select from the following: Phone Bluetooth Devices Connect, disconnect, add or delete a device, as well as save it as a favorite. Bluetooth Turn Bluetooth on and off. Do Not Disturb Have all calls go directly to your voice mail and not ring inside your vehicle.
Page 496 MyFord Touch® (If Equipped) Wireless & Internet Your system has a Wi-Fi feature that creates a wireless network within your vehicle, thereby allowing other devices (such as personal computers or phones) in your vehicle to speak to each other, share files or play games.
Page 497 MyFord Touch® (If Equipped) Wireless & Internet USB Mobile Instead of using Wi-Fi, your system can also Broadband use a USB mobile broadband connection to access the internet. (You must turn on your mobile broadband device on your personal computer before connecting it to the system.) This screen allows you to set up what is your typical area for your USB mobile broadband connection.
Page 498 MyFord Touch® (If Equipped) Help Press the Settings icon > Help, then select from the following: Help View your vehicle’s current location, if your Where Am I? vehicle is equipped with navigation. If your vehicle is not equipped with navigation, nothing displays.
Page 499: Climate Features
MyFord Touch® (If Equipped) CLIMATE Touch the lower right corner on the touchscreen to access your climate control features. Depending on your vehicle line and option package, your climate screen may look different from this screen. Note: You can switch temperature units between Fahrenheit and Celsius. See Settings in this chapter.
Page 500 MyFord Touch® (If Equipped) C. Fan speed: Touch + or - to increase or decrease the volume of air circulated in your vehicle. Note: When the system is controlling the fan speed automatically, all the fan speed indicators turn off. D.
Page 501 MyFord Touch® (If Equipped) I. Heated rear window: Turns the heated rear window on and off. See Heated windows and mirrors in the Climate Control chapter. J. Defrost: Touch the button to distribute air to the windshield vents and de-mister. Air distribution to instrument panel and footwell vents turn off.
Page 502 MyFord Touch® (If Equipped) There are additional climate control commands but in order to access them, you have to say “Climate” first, then when the system is ready to listen, you may say any of the following commands: Additional climate control voice commands “Automatic”...
Page 503: Navigation System
MyFord Touch® (If Equipped) NAVIGATION SYSTEM (IF EQUIPPED) Note: The navigation SD card must be in the SD card slot to operate the navigation system. If you need a replacement SD card, see your authorized dealer. Note: The SD card slot is spring-loaded. To remove the SD card, just push the card in and release it.
Page 504 MyFord Touch® (If Equipped) You can cancel the route or have the system demo the route for you. Select Route Prefs to set route preferences like avoiding freeways, tollroads, ferries and car trains as well as to use or not use high-occupancy vehicle lanes.
Page 505 MyFord Touch® (If Equipped) To expand these listings, press the + in front of the point of interest listing. When programming a point of interest destination, the system allows you to sort the resulting lists alphabetically, by distance or by cityseekr listings (if available).
Page 506 MyFord Touch® (If Equipped) Food & Drink Nightlife Attraction This icon appears when your selection exists in multiple categories within the system. When you are viewing more information for hotels, cityseekr also tells you if the hotel has certain services and facilities using icons. Hotel services and facilities Restaurant 24 Hr Room Service...
Page 507 MyFord Touch® (If Equipped) Setting Your Navigation Preferences Select settings for the system to take into account when planning your route. Press the Settings icon > Settings > Navigation. Map Preferences Breadcrumbs displays your vehicle’s previously traveled route with white dots. Turn this feature ON or OFF. Turn List Format allows you to choose to have the system display your turn list Top to Bottom or Bottom to Top.
Page 508 MyFord Touch® (If Equipped) Traffic Preferences Avoid Traffic Problems allows you to choose how you want the system to handle traffic problems along your route. • Automatic: Have the system reroute you to avoid traffic incidents that develop and impact the current route. The system does not provide a traffic alert notification.
Page 509 MyFord Touch® (If Equipped) Change the appearance of the map display by repeatedly pressing the arrow button in the upper left corner of the screen. It toggles between three different map modes: Heading up, North up, and 3D. Heading up (2D map) always shows the direction of forward travel to be upward on the screen.
Page 510 MyFord Touch® (If Equipped) Auto Zoom Press the green bar to access map mode, then select the + or - zoom button to bring up the zoom level and Auto buttons on the touchscreen. When you press Auto, Auto Zoom turns on and Auto displays in the bottom left corner of the screen in the map scale.
Page 511 MyFord Touch® (If Equipped) Starting point indicates the starting point of a planned route. Waypoints indicates the location of a waypoint on the map. The number inside the circle is different for each waypoint and represents the position of the waypoint in the route list. Destination symbol indicates the ending point of a planned route.
Page 512 MyFord Touch® (If Equipped) View/Edit Route Access these features when a route is active: • View Route • Edit Destination/Waypoints • Edit Turn List • Detour • Edit Route Preferences • Edit Traffic Preferences • Cancel Route. Nokia is the digital map provider for the navigation application. If you find map data errors, you may report them directly to Nokia by going to http://mapreporter.navteq.com.
Page 513 MyFord Touch® (If Equipped) Navigation system voice commands “Destination nearest POI” “Show turn list” “Destination play nametags” “Voice guidance off” “Destination POI” “Voice guidance on” “Destination POI category” “Where am I?” “Destination previous destination” “Zoom in” “Destination street address” “Zoom out” “Detour”...
Page 514 MyFord Touch® (If Equipped) “NAVIGATION” “Zoom state” “Zoom street” “Zoom to <distance>” “Help” If you have said, “Destination”, you may say any of the commands in the Destination chart. One-shot Destination Street Address When you say either “Navigation destination street address” or “Destination street address”, the system asks you to say the full address.
Page 515 MyFord Touch® (If Equipped) Phone issues Issue Possible Possible solution(s) cause(s) • This is a • Go to the website to review SYNC is not able to download my phone-dependent your phone’s compatibility. • Try turning off the device, phonebook. feature, OR •...
Page 516 MyFord Touch® (If Equipped) Phone issues Issue Possible Possible solution(s) cause(s) • This is a • Go to the website to review I am having trouble phone-dependent your phone’s compatibility. • Try turning off the device, connecting my feature, OR •...
Page 517 MyFord Touch® (If Equipped) USB and media issues Issue Possible Possible solution(s) cause(s) • Try turning off the device, I am having Possible device trouble connecting malfunction. resetting the device or removing my device. the device’s battery, then trying again. •...
Page 518 MyFord Touch® (If Equipped) Vehicle Health Report and SYNC Services (Traffic, Directions and Information) issues Issue Possible Possible solution(s) cause(s) • Your account • This is a free feature, but you I received a text that the Vehicle may not be must first register online to use it.
Page 519 MyFord Touch® (If Equipped) Voice command issues Issue Possible Possible solution(s) cause(s) • You may be • Review the Phone voice SYNC does not understand what using the wrong commands and the Media voice I am saying. voice commands, commands at the beginning of their respective sections.
Page 520 MyFord Touch® (If Equipped) Voice command issues Issue Possible Possible solution(s) cause(s) • You may be • Review the phone voice SYNC does not understand or is using the wrong commands at the beginning of calling the wrong voice commands, the phone section.
Page 521: Appendices
SYNC® End User License Agreement (EULA) • You have acquired a device (“DEVICE”) that includes software licensed by FORD MOTOR COMPANY from an affiliate of Microsoft Corporation (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“MS SOFTWARE”) are protected by international...
Page 522 Neither FORD MOTOR COMPANY nor its suppliers shall be liable for any damages arising out of errors in the speech recognition process.
Page 523 SOFTWARE after the date you obtain your initial copy of the SOFTWARE (“Supplemental Components”). If FORD MOTOR COMPANY or third party software and services suppliers provide or make available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply.
Page 524 DEVICE. UPGRADES AND RECOVERY MEDIA: If the SOFTWARE is provided by FORD MOTOR COMPANY separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labeled “For Upgrade Purposes Only” or For Recovery Purposes...
Page 525 For additional information, see http://www.microsoft.com/exporting/. TRADEMARKS: This EULA does not grant you any rights in connection with any trademarks or service marks of FORD MOTOR COMPANY, MS, Microsoft Corporation, third party software or service providers, their affiliates or suppliers.
Page 526 End user notice Microsoft® Windows® Mobile for Automotive Important Safety Information This system Ford SYNC contains software that is licensed to Manufacturer FORD MOTOR COMPANY by an affiliate of Microsoft Corporation pursuant to a license agreement. Any removal, reproduction, reverse engineering or other unauthorized use of the software from this system in violation of the license agreement is strictly prohibited and may subject you to legal action.
Page 527 Appendices General Operation Voice Command Control Functions within the Windows Automotive-based system may be accomplished using only voice commands. Using voice commands while driving allows you to operate the system without removing your hands from the wheel. Prolonged Views of Screen Do not access any function requiring a prolonged view of the screen while you are driving.
Page 528 Appendices Route Safety Do not follow the route suggestions if doing so would result in an unsafe or illegal maneuver, if you would be placed in an unsafe situation, or if you would be directed into an area that you consider unsafe. The driver is ultimately responsible for the safe operation of the vehicle and therefore, must evaluate whether it is safe to follow the suggested directions.
Page 529 Appendices otherwise require your undivided attention, and you therefore agree to comply with the following when using the Telenav Software: (a) observe all traffic laws and otherwise drive safely; (b) use your own personal judgment while driving. If you feel that a route suggested by the Telenav Software instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or directs you into an area that you consider to be unsafe, do not follow such instructions;...
Page 530 Appendices names, logos, patent or copyright notices, or other notices or markings; (d) distribute, sublicense or otherwise transfer the Telenav Software to others, except as part of your permanent transfer of the Telenav Software; or (e) use the Telenav Software in any manner that (i) infringes the intellectual property or proprietary rights, rights of publicity or privacy or other rights of any party, (ii) violates any law, statute, ordinance or regulation, including but not limited to laws and regulations...
Page 531 Appendices DAMAGES (INCLUDING IN EACH CASE, BUT NOT LIMITED TO, DAMAGES FOR THE INABILITY TO USE THE EQUIPMENT OR ACCESS DATA, LOSS OF DATA, LOSS OF BUSINESS, LOSS OF PROFITS, BUSINESS INTERRUPTION OR THE LIKE) ARISING OUT OF THE USE OF OR INABILITY TO USE THE TELENAV SOFTWARE, EVEN IF TELENAV HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 532 Appendices terms and conditions of this Agreement. Any such sale, assignment or transfer that is not expressly permitted under this paragraph will result in immediate termination of this Agreement, without liability to Telenav, in which case you and all other parties shall immediately cease all use of the Telenav Software.
Page 533 Appendices 9. Other Vendors Terms and Conditions The Telenav Software utilizes map and other data licensed to Telenav by third party vendors for the benefit of you and other end users. This Agreement includes end-user terms applicable to these companies (included at the end of this Agreement), and thus your use of the Telenav Software is also subject to such terms.
Page 534 Appendices License Limitations on Transfer: Your limited license does not allow transfer or resale of the Data, except on the condition that you may transfer the Data and all accompanying materials on a permanent basis if: (a) you retain no copies of the Data; (b) the recipient agrees to the terms of this End-User License Agreement;...
Page 535 Appendices OF THE NATURE OF THE CAUSE OF THE CLAIM, DEMAND OR ACTION ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT, WHICH MAY RESULT FROM THE USE OR POSSESSION OF THIS DATA; OR FOR ANY LOSS OF PROFIT, REVENUE, CONTRACTS OR SAVINGS, OR ANY OTHER DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF YOUR USE OF OR INABILITY TO USE THIS DATA, ANY DEFECT IN THIS...
Page 536 Appendices Government End Users: If the Data is being acquired by or on behalf of the United States government or any other entity seeking or applying rights similar to those customarily claimed by the United States government, this Data is a “commercial item” as that term is defined at 48 C.F.R.
Page 537 Appendices The software from Gracenote (the “Gracenote Software”) enables this device to do disc and music file identification and obtain music-related information, including name, artist, track, and title information (“Gracenote Data”) from online servers (“Gracenote Servers”), and to perform other functions. You may use Gracenote Data only by means of the intended End User functions of this device This device may contain content belonging to Gracenote’s providers.
Page 538 Appendices CONTENT. GRACENOTE COLLECTIVELY AND SEPARATELY RESERVE THE RIGHT TO DELETE DATA AND/OR CONTENT FROM THE COMPANIES’ RESPECTIVE SERVERS OR, IN THE CASE OF GRACENOTE, CHANGE DATA CATEGORIES FOR ANY CAUSE THAT GRACENOTE DEEMS SUFFICIENT. NO WARRANTY IS MADE THAT EITHER GRACENOTE CONTENT OR THE GRACENOTE SOFTWARE OR GRACENOTE SERVERS ARE ERROR-FREE OR THAT THE FUNCTIONING OF THE GRACENOTE SOFTWARE OR GRACENOTE...
Page 539: Scheduled Maintenance
Parts installed at your dealership carry a nationwide 24-month or unlimited miles (kilometers) parts and labor limited warranty. If you do not use Ford authorized parts they may not meet our specifications and depending on the part, it could affect emissions compliance.
Page 540 Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
Page 541 It is critical that systems are flushed only with new fluid that is the same as that required to fill and operate the system, or using a Ford-approved flushing chemical. Owner Checks and Services Certain basic maintenance checks and inspections should be performed every month or at six month intervals.
Page 542 In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help make sure your vehicle keeps running great.
Page 543 Scheduled Maintenance...
Page 544: Normal Scheduled Maintenance And Log
Scheduled Maintenance NORMAL SCHEDULED MAINTENANCE AND LOG Intelligent Oil-Life Monitor® Your vehicle is equipped with an Intelligent Oil-Life Monitor that determines when the engine oil needs to be changed based on how your vehicle is used. By using several important factors in its calculations, the monitor helps reduce the cost of owning your vehicle and reduce environmental waste at the same time.
Page 545 Scheduled Maintenance Normal scheduled maintenance At every oil change Change engine oil and filter. interval as indicated by Rotate tires, inspect tire wear and measure the information display tread depth. Perform multi-point inspection (recommended). Inspect automatic transmission fluid level (if equipped with dipstick).
Page 546 Scheduled Maintenance Other maintenance items Every 30000 miles Replace climate-controlled (heated and (48000 km) cooled) seat filter (if equipped). Replace engine air filter. At 100000 miles Change engine coolant. (160000 km) Every 100000 miles Replace spark plugs. (160000 km) Inspect accessory drive belt(s). Every 150000 miles Change automatic transmission fluid and filter.
Page 547 Scheduled Maintenance Maintenance Schedule Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS...
Page 548 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 549 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 550 Scheduled Maintenance SPECIAL OPERATING CONDITIONS If you operate your vehicle primarily in any of the following conditions, you need to perform additional maintenance as indicated. If you occasionally operate your vehicle under any of these conditions, it is not necessary to perform the additional maintenance. For specific recommendations, see your dealership service advisor or technician.
Page 551 Scheduled Maintenance Extensive idling or low-speed driving for long distances as in heavy commercial use (such as delivery, taxi, patrol car or livery) As required Change engine oil and filter as indicated by the information display and perform services listed in the Normal Scheduled Maintenance chart.
Page 552 Scheduled Maintenance Off-road operation Inspect frequently, Inspect steering linkage, ball joints and service as required U-joints. Lubricate if equipped with grease fittings. Replace engine air filter. Every 5000 miles Change engine oil and filter. (8000 km) or six Inspect wheels and related components for months abnormal noise, wear, looseness or drag.
Page 553 Scheduled Maintenance Special Operating Condition Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
Page 554 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 555 Normal vehicle axle maintenance: Rear axles and power take-off units with synthetic fluid and light-duty trucks equipped with Ford-design axles are lubricated for life; do not check or change fluid unless a leak is suspected, service is required or the assembly has been submerged in water.
Page 556 Scheduled Maintenance ENGINE COOLANT CHANGE RECORD Initial change Six years or 100000 miles (160000 km) (whichever comes first) After initial change Every three years or 50000 miles (80000 km) Engine Coolant Change Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS...
Page 557: Index
Index 911 Assist™ ......405, 482 All Wheel Drive (AWD), driving off road ......203 Ambient mood/lighting .....488 Ambulance packages ....15 ABS (see Brakes) .....212 AM/FM ........449 Accessing and using your USB port ........461 Antifreeze (see Engine coolant) ....294 Accessing call history/phone book during active call .....394 Anti-lock brake system (see Brakes) ......212...
Page 558 Cross Traffic Alert ....230 Cargo management system ..244 Cruise control ......228 CD ........370, 375 Customer Assistance ....268 CD player ......368, 460 Ford Extended Service CD voice commands ....461 Plan ..........365 Cell phone use ......16 Getting roadside assistance ...268 Getting the service you Changing a tire ......347...
Page 559 Index specifications ......356 Event data recording ....12 Defrost .......136, 138, 140 Exhaust fumes ......182 rear window ......146 Dipstick automatic transmission fluid ..........298 Fail safe cooling ......297 engine oil .........293 Fleet MyKey programming ..62 Display settings ......487 Floor mats .........266 Driving under special conditions ....202, 208–209 Fluid capacities ......356 sand .........208...
Page 560 Index Hazard flashers ......270 Jack ..........347 positioning .......347 HD Radio™ .......450 storage ........347 Headlamps Joining two calls aiming ........306 (multiparty/conference call) ..394 autolamp system ....93–94 bulb specifications ....312 Jump-starting your vehicle ..271 checking alignment ....306 flash to pass ......92 high beam .........92 replacing bulbs .......308 Keyless entry system Head restraints ......149...
Page 561 Index Locks autolock ........71 Octane rating ......186 childproof ........34 doors ..........69 Lubricant specifications ...356 Lug nuts ........354 Pairing other phones ..392, 468 Pairing your phone ....468 Pairing your phone for the first time ......391, 468 Making and receiving calls ..469 Parental MyKey programming ...62 MAP DVD - Loading and Unloading ........469...
Page 562 Index fluid, refill capacity ....356 Roof rack ........237 fluid, specifications ....356 Route preferences ....506 Power Windows ......97 Privacy information ..388, 442 Push button start system ..178 Safety Belt Maintenance ....43 Putting a call on/off hold ..394 Safety belts (see Safety restraints) ....37 Safety defects, reporting ..281 Quick touch buttons ....510 Safety information ....387, 440...
Page 563 Index SecuriCode keyless entry Sun visor ........102 system ..........77 Supplemental Restraint System SecuriLock passive anti-theft (SRS) (see airbags) ....47 system ..........79 Supported media file types ..464 Selecting your media source Supported player, media (USB, Line in, BT audio) ..418 formats and metadata Sending new text messages ..471 information ........464 Setting a destination ....502...
Page 564 Index tire grades .......327 treadwear ......327, 336 Vehicle health report ..408, 484 Touchscreen features (climate) ........498 Vehicle Identification Number Towing .......248, 261 (VIN) ..........361 recreational towing ....262 Vehicle loading ......238 Trailer Brake Controller-Integrated ....255 Ventilating your vehicle ...182 trailer towing ......248 wrecker ........261 Voice commands in media mode ..........415...

Ford 2015 EXPEDITION Owner's Manual

Table of Contents

Table of Contents

Table of Contents

Table of Contents

Introduction

Child Safety

Safety Belts

Supplementary Restraints System

Keys and Remote Control

Mykey

Locks

Security

Steering Wheel

Pedals

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays

Climate Control

Seats

Universal Garage Door Opener (if Equipped)

Auxiliary Power Points

Storage Compartments

Starting and Stopping the Engine

Fuel and Refueling

Transmission

Four-Wheel Drive (if Equipped)

Brakes

Traction Control

Stability Control

Terrain Response

Parking Aids

Cruise Control

Driving Aids

Load Carrying

Towing

Driving Hints

Roadside Emergencies

Customer Assistance

Fuses

Maintenance

Vehicle Care

Wheels and Tires

Capacities and Specifications

Accessories

Extended Service Plan

Audio System

Sync

Myford Touch® (if Equipped)

Appendices

Scheduled Maintenance

Index

Quick Links

Related Manuals for Ford 2015 EXPEDITION

Summary of Contents for Ford 2015 EXPEDITION
