Keating Of Chicago 2000 User Manual

Instant recovery gas fryer
Hide thumbs Also See for 2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
INSTANT RECOVERY
READ AND SAVE THIS MANUAL FOR FUTURE REFERENCE
Record the Model No. and Serial of this Instant Recovery® Gas Fryer in the space provided below.
IMPORTANT: Keep a copy of your bill of sale. The date on the bill establishes the warranty period should ser-
vice be required. If service is performed, it is in your interest to obtain and keep all receipts. Keating com-
mercial fryers are intended for other than household use.
Important Safety Instructions . . . . . . . . . . . . . . .i
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . .1
Damage During Shipment . . . . . . . . . . . . . . . . .1
Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
National Code Requirement . . . . . . . . . . . . . . .1
Gas Connectors & Pipe Size . . . . . . . . . . . . . .2
Flexible Gas Connection & Quick Disconnect
Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Restraining Devices . . . . . . . . . . . . . . . . . . . . .2
Electrical Connection . . . . . . . . . . . . . . . . . . . .2
Leveling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
PLACING YOUR KEATING FRYER IN OPERA-
TION
Filling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
This Owner's Guide provides specific operating instructions for your model. Use the Instant Recovery®
Fryer only as instructed in this Service Guide.
Si desea obtener usa copia en español de estes Manual del Usario, sirvase escribir la dirección que
se incluye a continuadión.
SERIES 2000 FRYER MANUAL
Serial No. __________________________
Model No. __________________________
Keep these numbers for future reference
CONTENTS:
Versión en español
1-800-KEATING
w w w. k e a t i n g o f c h i c a g o . c o m
GAS FRYER
®
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Oil Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . .6
Draining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Cleaning and Boil-Out . . . . . . . . . . . . . . . . . .6-8
Preventive Maintenance Chart . . . . . . . . . . . . .9
Hi-Limit Check Bi-Monthly . . . . . . . . . . . . . . . . .9
Thermostat Calibration . . . . . . . . . . . . . . . . . . .9
Thermostat Bulb Positioning . . . . . . . . . . . . . . .9
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Ordering Parts . . . . . . . . . . . . . . . . . . . . . . . . .11
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . .11-15
Wiring Diagrams . . . . . . . . . . . . . . . . . . . .15-18
Gas Fryer 2000
8
08/11

Advertisement

Table of Contents
loading

Related Manuals for Keating Of Chicago 2000

Summary of Contents for Keating Of Chicago 2000

  • Page 1: Table Of Contents

    SERIES 2000 FRYER MANUAL INSTANT RECOVERY READ AND SAVE THIS MANUAL FOR FUTURE REFERENCE Record the Model No. and Serial of this Instant Recovery® Gas Fryer in the space provided below. Serial No. __________________________ Model No. __________________________ Keep these numbers for future reference IMPORTANT: Keep a copy of your bill of sale.
  • Page 2 Purchaser should post in a prominent location instructions to be followed in the event the user smells gas. This information shall be obtained by consulting the local gas supplier. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly...

  • Page 3: Introduction

    INTRODUCTION Instructions in this manual should be read thoroughly before attempting to operate this Keating Gas Fryer. All installation and service on Keating equipment must be performed by qualified, certified, licensed and/or autho- rized installation or service personnel. Operating information for Keating equipment has been prepared for use by qualified and/or authorized per- sonnel.

  • Page 4: Gas Connectors & Pipe Size

    only on the type of gas specified by the user and indi- cated on the serial plate located inside the door. The gas may be natural, propane or manufactured. The type of gas cannot be converted to another gas fuel by turning or engaging a switch.

  • Page 5: Leveling

    receptacle. Do not cut or remove the grounding prong from this plug. (Model AA has no electric connection). LEVELING The Keating Gas Fryer will operate at its highest effi- ciency when properly leveled. Place a level on the fryer from side to side. For fryer on legs, the bottom foot of the leg is adjustable.
  • Page 6 AA CONTROL PANEL BB CONTROL PANEL 34×24 BB CONTROL PANEL 34×24 TS CONTROL PANEL TS CPU CONTROL PANEL AIR IN THE GAS SUPPLY LINE MAY REQUIRE A LONGER THAN NORMAL PERIOD OF TIME TO LIGHT YOUR FRYER DURING INITIAL INSTALLA- TION OR AFTER OVERNIGHT SHUTDOWN NOTE: Unless you have an AA model your fryer cannot be operated during a power failure.

  • Page 7: Cooking

    STEP 1. Set "MELT-IDLE-FRY" switch to "IDLE" posi- tion and thermostat to the "OFF" position. STEP 2. Turn "MAIN POWER" switch to the "ON" position. STEP 3. Hold the "PUSH TO LIGHT" switch in until the amber "PILOT ON" light comes on. STEP 4.

  • Page 8: Shutdown

    C C A A U U T T I I O O N N OPERATION OF THIS FRYER SHOULD BE LIMITED TO PERSONNEL WHO HAVE BEEN THOROUGHLY TRAINED IN OPERATING PROCEDURES. Set thermostat to the desired frying temperature. C C A A U U T T I I O O N N CARE SHOULD BE TAKEN WHEN LOWERING BASKETS INTO FRYER TO PREVENT SPLASHING HOT OIL FROM FRYER VESSEL.
  • Page 9 C C A A U U T T I I O O N N A KEATING FRYER OR FILTER SHOULD BE DRAINED ONLY UNDER THE SUPERVISION OF PROPERLY TRAINED PERSONNEL. WHEN DISCARDING OIL, A COVERED RECEPTACLE APPROVED FOR USE WITH HOT OIL SHOULD BE USED.

  • Page 10: Operator Self Help Check List

    5. Open the discard valve located near the quick dis- connect in the filter cabinet. 6. The hose may now be used to pump the oil into the shortening handling system and discarded proper- 7. Remove oil container to a secure area to prevent accidental spillage.

  • Page 11: Preventative Maintenance

    PREVENTIVE MAINTENANCE Preventive maintenance should be done in daily, week- ly, monthly and yearly intervals as necessary. Following preventive maintenance procedures will help keep your fryer working efficiently. Proper care and servicing will lead to years of quality performance. PREVENTIVE MAINTENANCE CHART TIME OPERATOR/OWNER FRAME...

  • Page 12: Timer

    REQUIRED TEST EQUIPMENT: Multimeter (for testing continuity) CHECKING CONTINUITY WITH THE MULTIMETER 1. Rotate the thermostat shaft until an audible click is heard. 2. Rotate the thermostat shaft left and right ten times causing the switch to click on and off ten times, while using the Multimeter to verify continuity.

  • Page 13: Warranty Repairs

    STEP 2 PRESS all 3 buttons in sequence: left-center-right. The BEEPER will BEEP when each button is pressed. If BEEPER does not BEEP, the timer is defective. STOP TESTING. Reset procedure is completed when 1:00 appears on the digital dis- play.
  • Page 14 QTY. DESCRIPTION THERMOSTAT DIAL PLATE 375° THERMOSTAT KNOB GAS FRYER THERMOSTAT 14” 14CM and AA 10x11 18 and up SWITCH ROCKER WHITE ON/OFF SWITCH ROCKER MOMENTARY HIGH LIMIT (RESETTABLE) CONTROL PANEL BB GAS QTY.DESCRIPTION THERMOSTAT DIAL PLATE 375° THERMOSTAT KNOB GAS FRYER THERMOSTAT 14”...
  • Page 15 ELECTRICAL BOX ASSEMBLY GAS FRYER (TS and BB ONLY) QTY. DESCRIPTION TRANSFORMER 120V/240V TO 24V 2 PIN CONNECTOR 9 PIN CONNECTOR FAT MELT 24V POT ASSEMBLY 14AA GAS (Front Drain Shown) QTY. DESCRIPTION 3 FIN RADIANT POT WELDMENT 14” GAS UNI-POT BURNER DRAIN VALVE 1”...
  • Page 16 POT ASSEMBLY 18BB & 18TS GAS (Front Drain Shown) QTY. DESCRIPTION 3 FIN RADIANT POT 18” GAS WELDMENT BURNER DRAIN VALVE DRAIN VALVE 2” FRONT REAR DRAIN VALVE (NOT SHOWN) RUNNER PILOT ASSEMBLY GAS VALVE NAT. (FRONT DRAIN TS) LP. (FRONT DRAIN TS) GAS VALVE NAT.

  • Page 17: Wiring Diagrams

    AA2000 ELECTRICAL ASSEMBLY BB2000 ELECTRICAL ASSEMBLY...
  • Page 18 Electrical Assembly not shown to scale TS2000 ELECTRICAL ASSEMBLY Electrical Assembly not shown to scale BB ELECTRICAL ASSEMBLY WITH SE FILTER...
  • Page 19 TS ELECTRICAL ASSEMBLY WITH SE FILTER BASKET LIFT ELECTRICAL ASSEMBLY (ALL FRYERS)
  • Page 20 PROBLEM Fryer overshoots a. Thermostat bulb improperly temperature setting. placed. b. Thermostat out of calibration. Oil in fryer vessel smokes. a. Oil has begun to breakdown. b. High carbon content in oil. c. Dirty fryer vessel. d. Inferior grade of oil. e.

  • Page 22: Service Information

    DATE OF PURCHASE: ________________________________________________________________ INVOICE NUMBER: ____________________ SERIAL NUMBER: ________________________________________ REMARKS: ______________________________________________ I HAVE READ THE INSTALLATION AND OPERATION INSTRUCTIONS. SIGNED: __________________________________________________________________________________ DATE: __________________________ SERVICE INFORMATION KEATING OF CHICAGO, INC. www.keatingofchicago.com KEATING LIMITED WARRANTY CARD FRYER TOP-SIDE COOKER Serving Those Who Serve The Very Best...
