CONTENTS:
IMPORTANT SAFETY INSTRUCTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DAMAGE DURING SHIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DROP-IN FRYER COUNTER CUT-OUT/INSTALLATION . . . . . . . . 1
POSITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
VENTILATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
NATIONAL CODE REQUIREMENT . . . . . . . . . . . . . . . . . . . . . . . . . 2
GAS CONNECTORS & PIPE SIZE . . . . . . . . . . . . . . . . . . . . . . . . . 2
FLEXIBLE GAS CONNECTION
& QUICK DISCONNECT DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . 3
RESTRAINING DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ELECTRICAL CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LEVELING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PLACING YOUR KEATING FRYER IN OPERATION
FILLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LIGHTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Keep this manual for training new personnel.
p a r t # 0 3 8 1 4 2
Users Manual
INSTANT RECOVERY
SERIES 2009
READ AND SAVE THIS MANUAL FOR FUTURE REFERENCE.
RECORD THE MODEL AND SERIAL
. . . . . . . . . . . . . . . . i
®
GAS FRYER
SERIAL NO. ______________________________
®
MODEL NO. _____________________________
KEEP THESE NUMBERS FOR FUTURE REFERENCE.
SHUTDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TIMER PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
OIL BREAKDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CLEANING AND BOIL-OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
PREVENTIVE MAINTENANCE CHART . . . . . . . . . . . . . . . . . . . . . 11
HI-LIMIT CHECK BI-MONTHLY . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
THERMOSTAT CALIBRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
THERMOSTAT BULB POSITIONING . . . . . . . . . . . . . . . . . . . 11-12
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-15
ORDERING PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-30
WIRING DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-47
WARRANTY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
. . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-800-KEATING
www.keatingofchicago.com
g a s F r y e r 2 0 0 9
0 8 / 1 1
