  • Page 2 PURCHASER SHOULD POST IN A PROMINENT LOCATION. WARNING Burns Shock Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. Improper installation can cause damage, injury or death.

  • Page 3: Table Of Contents

    ELECTRIC FRYER - SERIES 2006  TABLE OF CONTENTS Oil Breakdown ..............8 Important Safety Instructions ..........i Limited Calibration ............. 8 - 9 INTRODUCTION .............. 1 INSTALLATION Thermostat Bulb Positioning ..........9 Damage During Shipment ..........1 SERVICE DIAGNOSIS Standard Features ............

  • Page 4: Standard Features

    STANDARD FEATURES CM Model: BB and TS Counter Model Fryers are equipped with all of the same features as the BB and • Highly polished stainless steel fryer vessel TS Models respectively, but take up less than three square feet of counter space. The 10x11CM Model •...

  • Page 5: Drop-In Fryer Counter Cutout/Installation

    ELECTRIC FRYER - SERIES 2006  DROP-IN FRYER FIRST STEPS COUNTER CUTOUT/INSTALLATION POSITIONING TYP. “A” 45° 5/8" The fryer must be placed under an exhaust hood with a fi re retardant system. Your ventilation hood, when installed, must conform to the current standards. ALL DETERMINED BY CUTTING TOOL connections and placement must comply with current...

  • Page 6: Restraining Devices

    RESTRAINING DEVICES NOTE: A hole has been punched in the rear of the fryer NOTICE cabinet for a cord or conduit exit. If a cord is used, the 1. Adequate means must be pro- National Electrical Code, ETL standards and most local vided to limit the movement of the codes require a bushing or strain relief (not provided appliance without depending on the...

  • Page 7: Melting

    ELECTRIC FRYER - SERIES 2006 Figure 2 OPERATION OF THIS FRYER SHOULD BE LIMITED Fill Level Line TO PERSONNEL WHO HAVE BEEN THOROUGHLY TRAINED IN OPERATING PROCEDURES. USE ONLY KEATING APPROVED BASKETS IN YOUR FRYER. NEVER OVERFILL FRY BASKETS. DO NOT BANG BASKETS ON BASKET HANGERS OR FRYER VESSEL.

  • Page 8: Shutdown

    8. When timer sounds, lift basket out of oil. Place Figure 3 on basket hanger (on splashback of fryer) to allow Operator in draining of excess oil. Safety Gear C. Basket-Lift Models 1. Fill fryer as described on page 4 - FILLING. 2.

  • Page 9: Cleaning And Boil-Out

    ELECTRIC FRYER - SERIES 2006 8. Dissolve 2/3 cup of Keating Sea Powder for every fi ve gallons of water and let soak for 1/2 hour. If UNDER NO CIRCUMSTANCES SHOULD YOU PERMIT there is a large build-up of carbonized grease, allow HOT OIL TO COME IN CONTACT WITH WATER OR fryer to soak overnight.

  • Page 10: Electronic Timers

    Figure 7 under warranty, needs repairs other than routine Electric Timer maintenance or cleaning, you are required to contact Keating of Chicago (at 1-800-KEATING) before calling a local service company. PREVENTIVE MAINTENANCE Preventive maintenance should be done in daily, PROGRAMMING weekly, monthly and yearly intervals as necessary.

  • Page 11: Thermostat Bulb Positioning

    ELECTRIC FRYER - SERIES 2006 You will need: One standard fl at blade screwdriver One accurate fryer thermometer 1. Set thermostat to desired frying temperature. 2. Allow thermostat to cycle three times. 2. Allow fryer to cycle three times. 3. Place an accurate thermometer in the oil. 4.

  • Page 12: Service Diagnosis

     SERVICE DIAGNOSIS The following diagnosis is only to be used as a guide to qualifi ed service personnel. Keating recommends that you use a qualifi ed & licensed service company. (Equipment still under warranty requires it.) Call 1-800-KEATING if you need assistance in locating a qualifi ed service company. A properly adjusted Keating Instant Recovery®...

  • Page 13: Ordering Parts

    ELECTRIC FRYER - SERIES 2006 PROBLEM PROBABLE CAUSE SOLUTION Oil in fryer vessel smokes a. Oil has begun to break down. a. Replace oil. b. High carbon content in oil. b. Filter oil completely, replace if necessary. c. Dirty fryer vessel. c.

  • Page 14: Parts List

     PARTS LIST - ELECTRIC FRYER P/N 220V P/N 440V ITEM DESCRIPTION MODEL ELEMENT ELEMENT 10x11 34x24 Quantity Per Model HEATING ELEMENT 2500 W 004347 006342 3800 W 005623 004348 4350 W 004349 004350 6000 W 004353 004352 004353 004352 004355 022287 004355...

  • Page 15: Bb Control Panel Parts List

    ELECTRIC FRYER - SERIES 2006 BB CONTROL PANEL 208/240V & 480V Control Panel Front (not shown to scale) Detail Area Contactor Tray (Top View) Front Drain Unit Contactor Tray (Front View) Front Drain Unit ITEM DESCRIPTION 10x11 34x24 Quantity Per Model SWITCH TOGGLE SEALED ON-OFF 059141 INDICATING LIGHT CLEAR ROUND 28V...

  • Page 16: Ts Control Panel Parts List

    TS CONTROL PANEL 208/240V & 480V with ROCKER SWITCHES (not shown to scale) Control Panel Front Contactor Tray (Top View) Front Drain Unit Contactor Tray (Front View) Front Drain Unit ITEM DESCRIPTION 10x11 34x24 Quantity Per Model SWITCH ROCKER ON-OFF DPST 035030 SWITCH ROCKER SPDT WHITE 025726...
  • Page 17 ELECTRIC FRYER - SERIES 2006 TS CONTROL PANEL 208/240V & 480V with TOGGLE SWITCHES (not shown to scale) 059870 Detail Area Control Panel Front Contactor Tray (Top View) - Front Drain Unit Contactor Tray (Front View) - Front Drain Unit ITEM DESCRIPTION 10x11...

  • Page 18: Cpu Control Panel Parts List

    34x24 TS CONTROL PANEL 208/240V & 480V with TOGGLE SWITCHES (not shown to scale) Control Panel Front Detail Area Contactor Tray (Top View) - Front Drain Unit Contactor Tray (Front View) - Front Drain Unit ITEM DESCRIPTION 34x24 SWITCH TOGGLE SEALED ON-OFF 059141 INDICATING LIGHT CLEAR ROUND 28V 057863...
  • Page 19 ELECTRIC FRYER - SERIES 2006 34x24 CPU CONTROL PANEL 208/240V with TOGGLE SWITCH (not shown to scale) Control Panel Front Detail Area Contactor Tray (Top View) - Rear Drain Unit Contactor Tray (Front View) - Rear Drain Unit ITEM DESCRIPTION 34x24 SWITCH TOGGLE SEALED ON-OFF 059141...
  • Page 20 CPU CONTROL PANEL 208/240V with ROCKER SWITCHES (not shown to scale) 4, 5, 6, 7 Control Panel Front Contactor Tray (Top View) Spark Ignition Contactor Tray (Top View) Contactor Tray (Front View) Rear Drain Unit Spark Ignition Contactor Tray (Front View) Rear Drain Unit ITEM DESCRIPTION...

  • Page 21: Basket-Lift Housing And Roller Guide Parts

    ELECTRIC FRYER - SERIES 2006 BASKET LIFT POWER SUPPLY BOX & BASKET LIFT ASSEMBLY Basket Lift Power Supply Box Basket Lift Assembly Top View Side View Housing Top View Bottom View NOTES: 1. A minimum distance of 3/16" and maximum distance of 1/4" should be maintained when actuator is at full downward stroke.
  • Page 22 BASKET LIFT POWER SUPPLY BOX 2007 (CPU & NON-CPU) Top View Side View ITEM DESCRIPTION TRANSFORMER STEPDOWN 24VAC 100VA 058359 RELAY DPDT 24VAC 030844 RELAY DPDT 24VDC (CPU MODEL) 017673 RECTIFIER 24VDC 018321 BUSHING STRAIN RELIEF 5/8" HOLE 000470 BUSHING STRAIN RELIEF 3/4" HOLE 033800 NOTE: Circuit breaker is located under the control panel.

  • Page 23: Wiring Diagrams

    ELECTRIC FRYER - SERIES 2006  WIRING DIAGRAMS NOTE: A separate wiring diagram has been included with this manual and should be saved for troubleshooting and maintaining the fryer. The wiring diagrams in this section cover standard fryers which may or may not match the diagram sent with the fryer.

  • Page 24: Bb Wiring Diagram

    10x11, 14, 18 & 20 BB 2000 208240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER CONTACTOR 24VAC...
  • Page 25 ELECTRIC FRYER - SERIES 2006 10x11 BB 2006 208-240V & 480V 1 PHASE FRONT DRAIN WIRE COLOR CODES: - BLACK - BROWN - BLUE - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER CONTACTOR 24VAC POWER DISTRIBUTION BLOCK FAT MELT TIMER SWITCH GRD -...
  • Page 26 14, 18, 20 BB 2006 208-240V & 480V 1 PHASE FRONT DRAIN WIRE COLOR CODES: - BLACK - BROWN - BLUE - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER CONTACTOR 24VAC POWER DISTRIBUTION BLOCK FAT MELT TIMER SWITCH GRD - GROUNDING LUG...
  • Page 27 ELECTRIC FRYER - SERIES 2006 14, 18, 20 BB 2006 208-240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 28 24 BB 2006 208-240V & 480V 3 PHASE with REAR DRAIN and SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER CONTACTOR 24VAC POWER DISTRIBUTION BLOCK...

  • Page 29: Ts Wiring Diagram

    ELECTRIC FRYER - SERIES 2006 34x24 BB 2006 208-240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 30 10x11 TS 2006 208-240V & 480V 3 PHASE with REAR DRAIN WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER CONTACTOR 24VAC POWER DISTRIBUTION BLOCK FAT MELT TIMER SWITCH GRD - GROUNDING LUG...
  • Page 31 ELECTRIC FRYER - SERIES 2006 14 TS 2006 WITH BASKET-LIFT 208-240V & 480V 3 PHASE FRONT DRAIN WIRE COLOR CODES: - BLACK - BROWN B/R - BLACK/RED - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 32 14 TS 2006 with BASKET-LIFT 208-240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN B/R - BLACK/RED - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 33 ELECTRIC FRYER - SERIES 2006 18, 20 TS 2006 208-240V & 480V 3 PHASE with BASKET-LIFT FRONT DRAIN WIRE COLOR CODES: - BLACK - BROWN B/R - BLACK/RED - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 34 18, 20 TS 2006 with BASKET-LIFT 208-240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN B/R - BLACK/RED - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...
  • Page 35 ELECTRIC FRYER - SERIES 2006 24 TS 2006 208-240V & 480V 3 PHASE with REAR DRAIN and SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...

  • Page 36: Cpu Wiring Diagram

    34x24 TS 2006 208-240V & 480V 3 PHASE WITH REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: OVER MAX TEMP LIGHT (RED) CIRCUIT BREAKER POWER SWITCH...
  • Page 37 ELECTRIC FRYER - SERIES 2006 34x24 CPU 2007 208-240V & 480V 3 PHASE with REAR DRAIN & SAFE & EASY® FILTER WIRE COLOR CODES: - BLACK - BROWN - BLUE - GRAY - GREEN - ORANGE - RED WH - WHITE - YELLOW COMPONENT CODES: CIRCUIT BREAKER...

  • Page 38: Bb Models

     KEATING FRYER SPECIFICATIONS BB MODELS: 10x11 BB 14 BB AMPS PER LINE - AMPS AMPS PER LINE - AMPS VOLTS THREE PHASE SINGLE VOLTS THREE PHASE SINGLE PHASE PHASE 11.7 13.1 15.5 15.5 • 3 ELEMENTS (2500W EACH) • 3 ELEMENTS (4350W EACH) 18/20 BB 24 BB AMPS PER LINE -...

  • Page 39: Ts Models

    ELECTRIC FRYER - SERIES 2006 TS MODELS: 10x11 TS 14 TS AMPS PER LINE - AMPS AMPS PER LINE - AMPS VOLTS THREE PHASE SINGLE VOLTS THREE PHASE SINGLE PHASE PHASE 10.2 17.4 11.4 19.5 13.6 23.2 13.6 23.2 • 3 ELEMENTS (3800W EACH) •...
  • Page 41 CUSTOM PASTA FILTER SYSTEM TOP-SIDE COOKER HOTPLATE I HAVE READ THE INSTALLATION AND OPERATING INSTRUCTIONS. SIGNED: DATE: KEATING OF CHICAGO, INC. 1-800-KEATING 8901 West 50th Street PHONE: 708-246-3000 McCook, IL 60525-6001 FAX: 708-246-3100 Serving Those Who Serve the Very Best...
