Icom IC-FR4000 Service Manual page 4

SECTION 1 SPECIFICATIONS
Measurement method
Frequency range
Type of emission
Channel spacing
Frequency stability
Number of channels
Antenna connector
Power supply requirement
Current drain (approx.)
Operating temperature range
Dimensions (proj. not included)
Weight (approx.)
RF output power (High/Low)
Modulation system
Maximum frequency deviation
Spurious emissions
Adjacent channel power
Input impedance
Receive system
Intermediate frequencies
Sensitivity (typical)
Adjacent channel selectivity (typical)
Spurious response
Intermodulation (typical)
Audio output power
Audio output impedance
All stated specifications are subject to change without notice or obligation.
IC-FR4000
EIA/TIA-603
Low band ([L]; [USA1], [GEN1], [GEN5], [EUR1], [FRG1]): 400.000–430.000 MHz
Middle band ([M]; [GEN2], [GEN6]):
High band ([H]; [USA3], [GEN3], [GEN7], [EUR3], [FRG3]):450.000–480.000 MHz
Wide/Narrow ([USA1], [USA3], [GEN1]–[GEN7], [EUR1], [EUR3]): 25/12.5 kHz
Middle/Narrow ([FRG1], [FRG3]):
±2.5 ppm
[USA1], [USA3], [GEN1], [GEN2], [GEN3]:
AC
[GEN5], [GEN6], [GEN7], [EUR1], [EUR3], [FRG1], [FRG3]: 220–240 V
DC 13.6 V (negative ground)
20 A (at 50 W)
TX
RX
–30˚C to +60˚C (–22˚F to +140˚F)
410(W) × 110(H) × 360(D) mm; 16
50/10 W
Variable reactance frequency modulation
[Wide]: ±5.0 kHz, [Middle]: ±4.0 kHz, [Narrow]: ±2.5 kHz
70 dBc typical
[Wide], [Middle]: 70 dB, [Narrow]: 60 dB
Double-conversion superheterodyne system
0.5 µV at 12 dB SINAD
[Wide], [Middle]: 70 dB, [Narrow]: 60 dB
2.5 W typical at 10% distortion with a 4 Ω load
1 - 1
Wide (25 kHz): 16K0F3E
Middle (20 kHz): 14K0F3E
Narrow (12.5 kHz): 8K50F3E
Max. 32 channels
Type-N × 2 (50 Ω)
13.2 V (negative ground)
Max. audio: 2 A
Stand-by: 1 A
(W) × 4
5 11
/
32
12 kg; 26 15 / lb
32
0.25 µW ≤ 1GHz, 1.0 µW > 1 GHz
600 Ω
1st: 70 MHz, 2nd: 455 kHz
6 dBµV (emf) at 20 dB SINAD
70 dB
70 dB
4 Ω
IC-FR4100
ETS 300 086
430.000–450.000 MHz
20/12.5 kHz
±1.0 kHz
100–120 V
12 A (at 25 W)
–25˚C to +55˚C
(H) × 14
3
/ / (D) inch
32 16
25/5 W
