Icom IC-FR4000 Service Manual page 20

I
ADJUSTMENT MODE FREQUENCY LIST
[USA1], [GEN1], [GEN2], [GEN6]
CH [GEN5], [EUR1],
[FRG1] (MHz)
A01
429.925 (RX) 449.925 (RX)
400.275 (TX) 430.275 (TX)
A02
429.925 (RX) 449.925 (RX)
429.725 (TX) 449.725 (TX)
A03
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A04
400.075 (RX) 430.075 (RX)
400.275 (TX) 430.275 (TX)
A05
400.075 (RX) 430.075 (RX)
400.275 (TX) 430.275 (TX)
A06
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A07
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A08
400.075 (RX) 430.075 (RX)
400.275 (TX) 430.275 (TX)
A09
429.925 (RX) 449.925 (RX)
429.725 (TX) 449.725 (TX)
A10
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A11
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A12
415.075 (RX) 440.075 (RX)
415.275 (TX) 440.275 (TX)
A13
410.275 (RX) 435.275 (RX)
415.275 (TX) 440.275 (TX)
A14
410.275 (RX) 435.275 (RX)
415.275 (TX) 440.275 (TX)
[USA1], [GEN1], [GEN5], [EUR1], [FRG1]: 400–430 MHz version
[GEN2], [GEN6]: 430–450 MHz version
[USA3], [GEN3], [GEN7], [EUR3], [FRG3]: 450–480 MHz version
LCD display's detail as shown below. A number of 3 figures is a adjustment value (sample).
I LCD DISPLAY IN THE ADJUSTMENT MODE
[USA3], [GEN3],
[GEN7], [EUR3],
[FRG3] (MHz)
(MHz)
A01 LW TXREF 127
479.925 (RX)
450.275 (TX)
A02 LW HRTUN 115
479.925 (RX)
459.725 (TX)
A03 LW MRTUN 088
465.075 (RX)
465.275 (TX)
A04 LW LRTUN 055
450.075 (RX)
450.275 (TX)
A05 LW RPTSQL 150
450.075 (RX)
450.275 (TX)
A06 HW POWER 166
465.075 (RX)
465.275 (TX)
A07 LW M DEV 143
465.075 (RX)
465.275 (TX)
A08 LW LMODC 073
450.075 (RX)
450.275 (TX)
A09 LW HMODC 191
479.925 (RX)
479.725 (TX)
A10 LW CTCDEV 134
465.075 (RX)
465.275 (TX)
A11 LW DTCADJ 159
465.075 (RX)
465.275 (TX)
A12 LN CTCDEV 062
465.075 (RX)
465.275 (TX)
A13 LW RPTAF 141
460.275 (RX)
465.275 (TX)
A14 LN RPTAF 126
460.275 (RX)
465.275 (TX)
A01 LW TXREF 127
W/N
LCD DISPLAY
4 - 4
ADJUSTMENT
TVCO/RVCO adjustment.
W
Reference frequency adjustment.
NONE
W
RX sensitivity adjustment.
W
NONE
W
RPT SQL adjustment.
W
TX power adjustment.
W
TX modulation adjustment.
W
TX modulation adjustment.
W
TX modulation adjustment.
W
CTCSS modulation adjustment.
W
DTCS modulation adjustment.
W
CTCSS modulation adjustment.
N
RPT modulation adjustment.
W
RPT modulation adjustment.
N
Adjustment value
Adjustment item
Band width (WIDE)
TX power (LOW)
Adjustment frequency channel
(NARROW)
(WIDE)
(NARROW)
