Item
Add
Edit
Delete
Refresh
Profile
Enable This Profile
Protocol
Source IP Address
Source Mask
Destination IP Address
Destination Mask
Destination Port Start
Destination Port End
Load Balance Pool
H o w t o
H o w t o
1. Open VPN and Remote Access >>VPN TRUNK Management and click the Load
Balance Rule tab.
2. Simply click the Add button.
Vigor3900 Series User's Guide
Description
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Display the name of the profile.
Display the status of the profile. False means disabled; True
means enabled.
Display the protocol configured by such profile.
Display the source IP address specified for this profile.
Display the subnet mask address specified for the source IP
of this entry.
Display the destination IP address specified for this entry.
Display the subnet mask address specified for the destination
IP of this entry.
Display the start point specified in the Dest Port Range for
this entry.
Display the end point specified in the Dest Port Range for
this entry.
Display the selection of load balance pool.
a d d a L o a d B a l a n c
a d d a L o a d B a l a n c
e R u l e p r o f i l e
e R u l e p r o f i l e
