Private IP
Private IP Subnet Mask
Protocol
Use IP Alias
IP Alias
H o w t o a d d a n e w
H o w t o a d d a n e w
1. Open NAT>> Address Mapping.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Enable This Profile
WAN Profile
Private IP
will be applied to.
Display the private IP used for this entry.
Display the subnet mask used for this entry.
Display the protocol used for the entry.
Display the using status (enabled or disabled) for WAN IP
alias.
Display the selected WAN IP address.
A d d r e s s M a p p i n g
A d d r e s s M a p p i n g
Description
Type the name of the profile.
Check the box to enable the Address Mapping profile.
Choose a WAN profile for such entry.
Type the private IP used for this entry.
126
p r o f i l e
p r o f i l e
Vigor3900 Series User's Guide
