Draytek Vigor3900 Series User Manual page 164

Item
Protocol
Source Port Start
Source Port End
Destination Port
Start
Destination Port
End
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new Service Type Object profile has been created.
Description
allowed to be typed here is 10.
Specify one of the protocols for such profile.
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting source port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending source
port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting destination
port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending
destination port.
Click it to save the configuration.
Click it to exit the dialog without saving anything.
156 Vigor3900 Series User's Guide
