A p p l i c a t i o n F i l t e r
A p p l i c a t i o n F i l t e r
Application Filter can integrate several application objects within one profile for restricting
the usage of application. For example, it can block people defined in IP object profile not
using IM application, not using P2P for file sharing, and not downloading files via certain
protocol.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Rename
Profile
Enable The Profile
Time Profile
Source IP
Description
Add a new group profile for Application filter.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Renew current web page.
Allow to modify the selected profile name.
Display the name of the application filter profile.
Display the status of the profile. False means disabled; True
means enabled.
If no time schedule is set, None will be shown in this field.
Display the source IP object profile selected for such group.
136 Vigor3900 Series User's Guide
