Hoshizaki DSM-12CE Service Manual

Modular ice maker
Hide thumbs Also See for DSM-12CE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
NO.
24ME-431
ISSUED: APR. 28, 1997
REVISED: FEB. 15, 2011
HOSHIZAKI
MODULAR ICE MAKER
DSM-12CE
MODEL
SERVICE MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki DSM-12CE

Summary of Contents for Hoshizaki DSM-12CE

  • Page 1 NO. 24ME-431 ISSUED: APR. 28, 1997 REVISED: FEB. 15, 2011 HOSHIZAKI MODULAR ICE MAKER DSM-12CE MODEL SERVICE MANUAL...

  • Page 2: Table Of Contents

    [a] DSM-12CE [Auxiliary code V-1 and earlier] ---------------------------------------------1 [b] DSM-12CE [Auxiliary code V-2 and later] ------------------------------------------------2 2. SPECIFICATIONS ----------------------------------------------------------------------------------3 [a] DSM-12CE (CONT.) [Auxiliary code V-1 and earlier] ---------------------------------3 [b] DSM-12CE (UK) [Auxiliary code V-1 and earlier] --------------------------------------4 [c] DSM-12CE (CONT.) [Auxiliary code V-2 and later] ------------------------------------5 [d] DSM-12CE (UK) [Auxiliary code V-2 and later] -----------------------------------------6 II.
  • Page 3 VIII. REMOVAL AND REPLACEMENT OF COMPONENTS -------------------------------- 40 1. PANELS --------------------------------------------------------------------------------------------- 40 [a] FRONT PANEL ------------------------------------------------------------------------------- 40 [b] UNDER COVER ------------------------------------------------------------------------------ 40 [c] CABINET --------------------------------------------------------------------------------------- 40 [d] SIDE PANELS--------------------------------------------------------------------------------- 40 2. STORAGE BIN ------------------------------------------------------------------------------------ 41 3. SERVICE FOR REFRIGERANT LINES ---------------------------------------------------- 42 [a] SERVICE INFORMATION ----------------------------------------------------------------- 42 [b] REFRIGERANT RECOVERY ------------------------------------------------------------- 43 [c] EVACUATING AND RECHARGE -------------------------------------------------------- 44...

  • Page 4: Specifications

    I. SPECIFICATIONS 1. DIMENSIONS/CONNECTIONS [a] DSM-12CE [Auxiliary code V-1 and earlier]...

  • Page 5: [B] Dsm-12Ce [Auxiliary Code V-2 And Later]

    [b] DSM-12CE [Auxiliary code V-2 and later]...

  • Page 6: Specifications

    2. SPECIFICATIONS [a] DSM-12CE (CONT.) [Auxiliary code V-1 and earlier] AC SUPPLY VOLTAGE 1PHASE 220-240 V 50 Hz AMPERAGE 1.6 A (Ambient temp. 32°C, Water temp. 21°C) STARTING AMPERAGE 7.5 A ELECTRIC CONSUMPTION 260 W (Ambient temp. 32°C, Water temp. 21°C)

  • Page 7: [B] Dsm-12Ce (Uk) [Auxiliary Code V-1 And Earlier]

    [b] DSM-12CE (UK) [Auxiliary code V-1 and earlier] AC SUPPLY VOLTAGE 1PHASE 220-240 V 50 Hz AMPERAGE 1.6 A (Ambient temp. 32°C, Water temp. 21°C) STARTING AMPERAGE 7.5 A ELECTRIC CONSUMPTION 260 W (Ambient temp. 32°C, Water temp. 21°C) POWER FACTOR...

  • Page 8: [C] Dsm-12Ce (Cont.) [Auxiliary Code V-2 And Later]

    [c] DSM-12CE (CONT.) [Auxiliary code V-2 and later] AC SUPPLY VOLTAGE 1 PHASE 220-240V 50Hz AMPERAGE 1.6 A (Ambient temp. 32 °C, Water temp. 21°C) STARTING AMPERAGE 7.5 A ELECTRICAL CONSUMPTION 260 W (Ambient temp. 32°C, Water temp. 21°C) POWER FACTOR POWER SUPPLY CAPACITY 0.49 kVA (2.0 A)

  • Page 9: [D] Dsm-12Ce (Uk) [Auxiliary Code V-2 And Later]

    [d] DSM-12CE (UK) [Auxiliary code V-2 and later] AC SUPPLY VOLTAGE 1 PHASE 220-240V 50Hz AMPERAGE 1.6 A (Ambient temp. 32 °C, Water temp. 21°C) STARTING AMPERAGE 7.5 A ELECTRICAL CONSUMPTION 260 W (Ambient temp. 32°C, Water temp. 21°C) POWER FACTOR POWER SUPPLY CAPACITY 0.49 kVA (2.0 A)

  • Page 10: General Information

    II. GENERAL INFORMATION 1. CONSTRUCTION [a] LEFT SIDE VIEW WITH PANELS REMOVED Auxiliary code V-1 and earlier Insulation Mechanism Cover Evaporator Water Valve Agitating Plate Control Box Tray Bin Sensor Dispensing Switch Storage Bin Gear Motor Assembly Condenser Spout Fan Motor Auger Relay-4 Compressor...
  • Page 11 Auxiliary code V-2 and later Thermistor Insulation Mechanism Cover Evaporator Water Valve Agitating Plate Control Box Tray Bin Sensor Dispensing Switch Storage Bin Gear Motor Assembly Condenser Spout Fan Motor Auger Compressor Drain Cassette Power Supply Hot Gas Valve Cord Under Cover Air Filter Drain Pipe...

  • Page 12: [B] Control Box

    [b] CONTROL BOX Auxiliary code V-1 and earlier Defrost Thermostat Fuse Holder (250V/5A Fuse) Protective Thermostat Relay-1 Relay-2 Relay-3...
  • Page 13 Auxiliary code V-2 and later Power Transformer Fuse Holder (Transformer-1) Controller Board (250V/5A Fuse) Power Relay...

  • Page 14: [C] Mechanism Assembly

    [c] MECHANISM ASSEMBLY Auxiliary code V-1 and earlier Retaining Ring (S) Agitating Motor Shim (B) O-ring Ice Making Switch Bracket Shim (A) Motor Bracket Lever Spring, Collar Retaining Ring (L) Cam (B) Ice Making Switch E-ring Shim (C) Tilting Motor Cam (A) Water Supply Switch...
  • Page 15 Auxiliary code V-2 and later Retaining Ring (S) Agitating Motor Shim (B) O-ring Ice Making Switch Bracket Shim (A) Motor Bracket Lever Spring, Collar Retaining Ring (L) Cam (B) Ice Making Switch E-ring Shim (C) Tilting Motor Cam (A) Tilting Switch Mechanism Cover Guide...

  • Page 16: Installation Instructions

    III. INSTALLATION AND OPERATING INSTRUCTIONS WARNING 1. The installation must be carried out by qualified personnel, in accordance with current regulations, according to the manufacturer’s instructions. 2. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. 1.

  • Page 17: Location

    2) Remove shipping tapes holding the package of accessories, and check the contents: a) Installation Kit Inlet Hose Outlet Hose Rc1/2-G3/4 Nipple b) Brace c) Machine Screw d) Tapping Screw 3) Remove tapes holding the power cord. 2. LOCATION IMPORTANT 1.

  • Page 18: Installation

    3. INSTALLATION * Incorrect installation can cause harm to people, animals or things, for which the manufacturer cannot be held responsible. * Secure the ice dispenser to the counter table by using the brace, machine screws and tapping screws (accessory). See Fig. 2. Machine Screw Tapping Screw Brace...
  • Page 19 The correct replacement for the detachable fuse cover is identifiable from the manufacturer’s reference number stamped on the plug. Supply of replacement fuse covers can be obtained from Hoshizaki Parts/Service Centres. Fuses should be rated at 13A and approved to BS 1362.

  • Page 20: Water Supply And Drain Connections

    5. WATER SUPPLY AND DRAIN CONNECTIONS WARNING Connect to potable water supply only. * The connections to the mains water supply must be made in accordance with the countries’ current requirements of the Water Water Inlet G3/4 Supply or Water Fittings Regulations. * Water supply pressure should be minimum 0.05 MPa (0.5 bar) and maximum 0.78 MPa (8 bar).

  • Page 21: Operating Instructions

    a suitable sealing compound should be used to obtain a leak free joint. Note: Jointing compounds should be approved and suitable for potable water use. 4) Attach grey flexible outlet hose (accessory) to free end of Rc1/2-G3/4 nipple as indicated, confirming fitment of rubber washer before finally hand tightening the joint. This pipe can be cut to length as necessary to suit position of main drain.

  • Page 22: Preparing The Icemaker For Long Storage

    2. PREPARING THE ICE DISPENSER FOR LONG STORAGE 1) Dispense all ice from the storage bin. 2) Close the water tap. Remove the inlet hose from the water tap, and drain the hose. 3) Unplug the machine from power socket. 4) Replace plug in the power socket and after 30 seconds unplug it again.
  • Page 23 [3] Drain Cassette At least once a week, pull out the drain cassette and clean it with warm water and a neutral cleaner. [4] Condenser Check the condenser once a year, and clean if required by using a brush or vacuum cleaner.
  • Page 24 11) Mix 5 litres of water with 18 ml of 5.25% sodium hypochlorite solution in a suitable container. 12) Soak a clean sponge or cloth with the solution, and wipe the storage bin, tray, auger and mechanism cover liner. 13) Replace the removed parts in their correct position. 14) Plug in the ice dispenser.

  • Page 25: Technical Information

    VI. TECHNICAL INFORMATION 1. WATER CIRCUIT AND REFRIGERANT CIRCUIT Water Solenoid Valve Accumulator Evaporator Tray Capillary Tube Fan Motor Hot Gas Drier Compressor Solenoid Valve Strainer Condenser Water Circuit Refrigerant Circuit...

  • Page 26: Wiring Diagram

    2. WIRING DIAGRAM [a] Auxiliary code V-1 and earlier...
  • Page 27 [b] Auxiliary code V-2 and later...

  • Page 28: Timing Chart

    3. TIMING CHART [a] Auxiliary code V-1 and earlier Start Up Freeze Cycle Defrost Cycle Freeze Cycle Defrost Cycle Michroswitch-2 Michroswitch-3 Michroswitch-4 Michroswitch-5 Relay-1 Relay-2 Relay-3 Relay-4 WARM Thermostat-1 COLD Synchronous Motor-1 Synchronous Motor-2 Fan Motor Water Solenoid Valve Hot Gas Sole- noid Valve Compressor Bin Control...

  • Page 29: [B] Auxiliary Code V-2 And Later

    [b] Auxiliary code V-2 and later Defrost Part Name Start Up Freeze Cycle Defrost Cycle Freeze Cycle Cycle Full 6°C ▲ ▲ Thermistor 0°C ■ ■ ● ● Ice Making Switch (Micro Switch-3) Compressor Power Relay Hot Gas Solenoid Valve 15sec.

  • Page 30: Sequence

    4. SEQUENCE 1) When the water supply tap is opened and the unit Evaporator is energized, the compressor starts and the tilting motor (synchronous motor-1) operates to move the tray into the horizontal position. Meanwhile the water valve opens to supply ice making water into the tray. When the tray reaches the horizontal, the water valve closes to start a freeze cycle.
  • Page 31 4) As the unit repeats the above freeze and defrost cycles, the storage bin is gradually filled with ice. When ice reaches a certain level, a tilt of the tray Bin Control moves the bin control activator at the bottom of the Switch tray to operate the bin control switch [*4] so that the ice making mechanism will stop.

  • Page 32: Performance Data

    5. PERFORMANCE DATA Ambient Temp. (°C) Water Temp. (°C) Ice Production (kg/d) 13.5 Freeze Cycle Time 6’57” 7’51” 10’16” 13’27” 16’41” Defrost Cycle Time 2’56” 2’23” 1’58” 1’44” 1’37” Head Pressure (bar) 13.4 15.5 Water Consumption (lit/d) Electric Consumption (W)

  • Page 33: Ice Dispensing Capacity

    6. ICE DISPENSING CAPACITY Ice Production Per Day: 13 kg Storage Capacity: 3 kg Ambient Temperature: 10°C Water Temperature: 10°C Cycle Time: 9.5 min. Ice Production Per Cycle: 85 g 50Hz Dispensing Minimum Dispensing Maximum Continuous Dispensing Capacity Amount Time With No Ice With Full Ice Storage (3 kg) Storage (0 kg) Per Cup...
  • Page 34 Ice Production Per Day: 10 kg Storage Capacity: 3 kg Ambient Temperature: 21°C Water Temperature: 15°C Cycle Time: 12 min. Ice Production Per Cycle: 85 g 50Hz Dispensing Minimum Dispensing Maximum Continuous Dispensing Capacity Time With No Ice Amount With Full Ice Storage (3 kg) Per Cup Storage (0 kg) 111**...

  • Page 35: Service Diagnosis

    VII. SERVICE DIAGNOSIS 1. Auxiliary code V-1 and earlier PROBLEM POSSIBLE CAUSE REMEDY [1] The ice a) Power supply 1. Open circuit. 1. Replace. dispenser will cord 2. Loose connection. 2. Reconnect. not start. 3. Unplugged. 3. Plug in. b) Fuse 1.
  • Page 36 PROBLEM POSSIBLE CAUSE REMEDY [6] Water supply a) Water supply 1. Water supply pressure 1. Get recommended never stops or is line too high or too low. pressure. too much. b) Water valve 1. Clogged with foreign 1. Replace. matter. c) Microswitch-4 1.
  • Page 37 PROBLEM POSSIBLE CAUSE REMEDY [11] Tray starts to a) Thermostat-1 1. Fused contacts. 1. Replace. go up with 2. Thermostat bulb out of 2. Fix on evaporator. remaining ice. position. b) Relay-2 1. Fused contacts. 1. Replace. 2. Coil winding opened. 2.
  • Page 38 PROBLEM POSSIBLE CAUSE REMEDY [16] (Continued) c) Storage bin 1. Little ice storage. 1. A small amount of remaining ice cannot be dispensed. Wait for enough ice storage. 2. Ice bridges. 2. Long suspension of ice dispensing may cause ice bridges.

  • Page 39: Auxiliary Code V-2 And Later

    2. Auxiliary code V-2 and later PROBLEM POSSIBLE CAUSE REMEDY [1] The ice a) Power supply 1. Open circuit. 1. Replace. dispenser will cord 2. Loose connection. 2. Reconnect. not start. 3. Unplugged. 3. Plug in. b) Fuse 1. Blown out. 1.
  • Page 40 PROBLEM POSSIBLE CAUSE REMEDY [5] (Continued) b) Water circuit 1. Water leaks from 1. Repair. connections. 2. Clogged with foreign 2. Clean. matter. c) Water valve 1. Clogged filter. 1. Clean. 2. Coil winding opened. 2. Check for proper voltage and replace.
  • Page 41 PROBLEM POSSIBLE CAUSE REMEDY [9] (Continued) f) Cam (B) 1. Obstructed. 1. Remove obstacles (capillary tubes or refrigerant lines). g) Agitating motor 1. Gear broken. See [19]. 1. Replace. (synchronous motor-2) h) See [11]. [10] Hot gas will a) Connector (7P) 1.
  • Page 42 PROBLEM POSSIBLE CAUSE REMEDY [15] Defective ice a) Tray 1. Deformed or damaged. 1. Replace. 2. Obstructed from 2. Remove obstacles (capillary horizontal position. tubes or refrigerant lines). b) Refrigeration 1. Undercharged or gas 1. Check for leaks by leakage circuit leaks detector.

  • Page 43: Removal And Replacement Of Components

    VIII. REMOVAL AND REPLACEMENT OF COMPONENTS 1. PANELS [a] FRONT PANEL Cabinet 1) Unplug the ice dispenser. Front Panel 2) Pull out the drain cassette. 3) Remove the screws behind the drain cassette. 4) Unhook the front panel by lifting it up, and pull it toward you.

  • Page 44: Storage Bin

    3) Remove the screws on the front and rear. Note: Be careful not to lose the tooth washer provided on the screw at the front. 2. STORAGE BIN 1) Dispense all ice from the storage bin. 2) Unplug the ice dispenser. 3) Close the water supply tap.

  • Page 45: Service For Refrigerant Lines

    14) Disconnect the hoses and terminals from the water valve. 15) Disconnect the hose from the drain pipe. 16) Slightly lift up the evaporator, and remove the storage bin. 3. SERVICE FOR REFRIGERANT LINES [a] SERVICE INFORMATION 1) Allowable Compressor Opening Time and Prevention of Lubricant Mixture [R134a] The compressor must not be opened more than 30 minutes in replacement or service.

  • Page 46: [B] Refrigerant Recovery

    6) Replacement Copper Tubing [R134a] The copper tubes currently in use are available for R134a. But do not use them if oily inside. The residual oil in copper tubes should be as little as possible. (Low residual oil type copper tubes are used in the shipped units.) 7) Evacuation, Vacuum Pump and Refrigerant Charge [R134a] Never allow the oil in the vacuum pump to flow backward.

  • Page 47: [C] Evacuating And Recharge

    [c] EVACUATION AND RECHARGE 1) Attach charging hoses, a service manifold and a vacuum pump to the system. 2) Turn on the vacuum pump. 3) Allow the vacuum pump to pull down to a 760 mmHg vacuum. Evacuating period depends on pump capacity. 4) Close a low-side valve on the service manifold.

  • Page 48: Brazing

    4. BRAZING DANGER 1. Refrigerant R134a itself is not flammable, explosive and poisonous. However, when exposed to an open flame, R134a creates phosgene gas, hazardous in large amounts. 2. Always recover the refrigerant and store it in a proper container. Do not discharge the refrigerant into the atmosphere.

  • Page 49: Drier

    5. DRIER IMPORTANT Always install a new drier every time the sealed refrigeration system is opened. Do not replace the drier until after all other repair or replacement has been made. 1) Unplug the ice dispenser. 2) Remove the panels. 3) Recover the refrigerant and store it in a proper container.

  • Page 50: Compressor

    6. COMPRESSOR 1) Unplug the ice dispenser. 2) Remove the panels. 3) Remove the terminal cover on the compressor, and disconnect the compressor wiring. 4) Recover the refrigerant and store it in a proper container. 5) Unsolder and disconnect the discharge and suction pipes from the compressor. 6) Remove the hold-down bolts, washers and rubber grommets.

  • Page 51: Hot Gas Valve

    7. HOT GAS VALVE 1) Unplug the ice dispenser. 2) Remove the panels. 3) Remove the screw securing the hot gas valve. 4) Remove the screw securing the coil to the valve body, and pull off the coil. If the coil does not require replacement, go to 7). 5) Cut the coil leads at the wire connectors.

  • Page 52: Evaporator

    8. EVAPORATOR 1) Unplug the ice dispenser. 2) Remove the panels. 3) Remove the storage bin. 4) Recover the refrigerant and store it in a proper container. 5) Sandpaper and disconnect the brazing connection. Remove the evaporator using brazing equipment. 6) Detach the two brackets from the removed evaporator, and attach them to the new evaporator.

  • Page 53: Water Valve

    6) Assemble the removed parts in the reverse order of which they were removed. 7) Plug in the ice dispenser. 10. WATER VALVE 1) Unplug the ice dispenser. 2) Close the water supply tap. 3) Remove the front panel and cabinet. 4) Plug in and run the ice dispenser.

  • Page 54: Gear Motor

    11. GEAR MOTOR IMPORTANT Do not reuse the spring pin. To prevent excessive strain, fix the gear motor shaft when installing the spring pin. 1) Unplug the ice dispenser. 2) Remove the front panel. 3) Cut the gear motor leads at the wire connectors. 4) Remove the gear motor assembly from the mechanism cover.

  • Page 55: Control Box

    12. CONTROL BOX IMPORTANT Every time the mechanism cover or tray is removed, check the ice size after assembling the removed parts. [a] Auxiliary code V-1 and earlier 1) Unplug the ice dispenser. 2) Remove the front panel. 3) Disconnect all the connectors from the control box. If the thermostats require replacement, go to 6).

  • Page 56: [B] Auxiliary Code V-2 And Later

    [b] Auxiliary code V-2 and later 1) Unplug the ice dispenser. 2) Remove the front panel. 3) Disconnect the three connectors from the control box. 4) Remove the four screws securing the control box, and remove the control box. 5) Remove the two screws securing the cover. 6) Replace the applicable parts.

  • Page 57: Controller Board [Auxiliary Code V-2 And Later]

    13. CONTROLLER BOARD [Auxiliary code V-2 and later] [a] CONTROLLER BOARD LAYOUT Power Transformer (Transformer-1) Power Relay (Compressor) Hot Gas OUTPUT Solenoid Valve Power Relay (Synchronous Motor-2) Fan Motor Illuminates (energized) Flashes (bin full) Tilting Motor OUTPUT (Synchronous Motor-1) Motor Valve Agitating Motor (Synchronous Motor-2)

  • Page 58: Fuse [Auxiliary Code V-0 And Earlier]

    14. FUSE [Auxiliary code V-0 and earlier] 1) Unplug the ice dispenser. 2) Remove the front panel. 3) Insert a flat blade screwdriver or the like into the square hole on the fuse holder (side or top). Push and unhook the fuse holder cap with the fuse. 4) Pull out the cap, and remove the fuse.

  • Page 59: Mechanism Assembly

    15. MECHANISM ASSEMBLY IMPORTANT Every time the mechanism cover or tray is removed, check the ice size after assembling the removed parts. [a] ARM 1) Unplug the ice dispenser. Note: The mechanism assembly will be easily removable if the unit is stopped just after a defrost cycle starts.

  • Page 60: [C] Tilting Motor

    8) Remove the securing screw, and take off the agitating motor (synchronous motor-2). If the shim (B) and O-rings do not require replacement, go to 10). 9) Remove the retaining ring (S), and disassemble the above parts. 10) Replace the parts as required. 11) Assemble the removed parts in the reverse order of which they were removed.

  • Page 61: [D] Ice Making Switch [Auxiliary Code V-1 And Earlier]

    10) Assemble the removed parts in the reverse order of which they were removed. 11) Plug in the ice dispenser. [d] ICE MAKING SWITCH [Auxiliary code V-1 and earlier] 1) Unplug the ice dispenser. 2) Remove the front panel, control box, arm and lever. 3) Disconnect the connectors from the ice making switch (michroswitch-5).
  • Page 62 Projection (Mandrel) Evaporator Agitating Plate 23 mm DIA or less 9) Use the hexagon head screw and screw (A) to secure the ice making switch and the bracket on the cover. Position the ice making switch bracket around its original Tray location.

  • Page 63: Tray

    16. TRAY IMPORTANT Every time the mechanism cover or tray is removed, check the ice size after assembling the removed parts. 1) Dispense all ice from the storage bin. 2) Unplug the ice dispenser. 3) Remove the front panel, gear motor, control box, arm, lever and mechanism cover. 4) Remove the tray from the evaporator bracket openings.

  • Page 64: Relay-4 (Compressor) [Auxiliary Code V-1 And Earlier]

    17. RELAY-4 (COMPRESSOR) [Auxiliary code V-1 and earlier] 1) Unplug the ice dispenser. 2) Remove the front panel, cabinet, under cover and left side panel. 3) Disconnect the terminals from the relay-4. 4) Remove the relay bracket from the base. 5) Remove the relay-4 from the relay bracket.

  • Page 65: Thermistor [Auxiliary Code V-2 And Later]

    18. THERMISTOR [Auxiliary code V-2 and later] [a] REMOVAL AND REPLACEMENT 1) Unplug the ice dispenser. 2) Remove the front panel and cabinet. 3) Remove the control box. 4) Disconnect the two closed end connectors of the thermistor leads. 5) Remove the ties, insulation, thermistor holder and thermistor in this order. 6) Remove the old sealant from the thermistor holder and suction pipe.

  • Page 66: [B] Defrost And Low Water Control

    9) Cover the parts with the insulation and secure them with the ties. Note: 5. After the thermistor holder is fitted, do NOT pull the thermistor leads to move the thermistor. 10) Cut the new thermistor leads at the bottom of the connector and connect it with a closed end connector.

  • Page 67: Transformer

    Temperature (°C) Resistance (kΩ) 10.61 6.00 3.87 2.47 19. TRANSFORMER 1) Unplug the ice dispenser. 2) Remove the front panel, cabinet, under cover and side panels. 3) Remove the terminal cover on the compressor, and disconnect the compressor wiring. 4) Remove the start capacitor and starter. 5) Cut the transformer leads at the wire connectors.

  • Page 68: Adjustment Of Ice Size

    IX. ADJUSTMENT OF ICE SIZE When a certain size of ice forms on the evaporator, ice obstructs the agitating plate located inside the tray and moved up and down by the agitating mechanism. The cam (B) rotates and pushes down itself to hit the ice making switch located below, which signals to end a freeze cycle.

  • Page 69: Adjustment

    2. ADJUSTMENT [a] Auxiliary code V-1 and earlier Note: Adjustment exceeding the proper ice size range will cause ice bridges and result in a failure. 1) Check the current ice size before adjusting the ice making switch. 2) Unplug the ice dispenser. 3) Remove the front panel and cabinet.

  • Page 70: [B] Auxiliary Code V-2 And Later

    [b] Auxiliary code V-2 and later 1) Unplug the ice dispenser. 2) Remove the front panel and cabinet. 3) Check and remember the location of the ice making switch bracket from the square Projection (Mandrel) Evaporator Agitating Plate hole in the left side of the control box. 23 mm DIA or less 4) Use a spanner (7 mm) from the square hole in the left side of the control box to Tray...
