Send SMS if line drops
out
Send Mail Alert if line
drops out
Active Mode and
Backup Type
After finished the above settings, click OK to save the settings.
D
e
t
a
i
l
e
D
e
t
a
i
l
e
To use 3G network connection through 3G USB Modem, please configure WAN3 interface.
Vigor2920 Series User's Guide
sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
Use the drop down list to choose one of the profiles which will
be used to notify the administrator when the network
connection is off.
Check the box to enable this function. When the network
connection is off, the system will send a mail alert to notify the
administrator.
Active Mode – Determine the WAN interface will be active for
always (Always On) or be treated as a backup WAN interface
(Backup Type).
Backup Type – Determine the role of such WAN interface. It
will be changed according to the Active Mode specified.
If you choose Always On as Active Mode, such interface will
be used for access into Internet all the time.
If you choose Backup as the Active Mode, you have to specify
which WAN interface will be selected to backup multiple
WANs. However, ignore this setting if you want to backup a
single WAN.
When any WAN disconnect – Such backup WAN will be
activated when any master WAN interface disconnects.
When all WAN disconnect – Such backup WAN will be
activated only when all master WAN interfaces disconnect.
d
S
e
t
t
i
n
g
s
f
o
r
W
A
N
d
S
e
t
t
i
n
g
s
f
o
r
W
A
N
3
I
n
t
e
r
f
a
c
e
(
v
i
a
U
S
3
I
n
t
e
r
f
a
c
e
(
v
i
a
U
S
100
B
)
