LIMITATION OF DAMAGES To the maximum extent permitted by applicable law, in no event shall HTC or its providers be liable to user or any third party for any indirect, special, consequential, incidental or punitive damages of any kind in contract...
Table of Contents Contents 1. Welcome to the HTC Touch Pro2 Quick Start Guide ........4 2. Inside the Box ......................4 3. Get to Know Your HTC Touch Pro2 ..............5 4. Installing the SIM Card, Battery, and Storage Card ........7 5.
1. Welcome to the HTC Touch Pro2 Quick Start Guide Congratulations on your purchase of the HTC Touch Pro2. This Quick Start Guide will help you get started with your HTC Touch Pro2. This guide will walk you through the features we feel you will want to learn right away when you use your HTC Touch Pro2.
Quick Start Guide 5 3. Get to Know Your HTC Touch Pro2 Notification LED Earpiece POWER Second Hardware Camera Keyboard Light Sensor Microphone Touch Screen Zoom BACK START Sync Connector/ TALK/SEND Earphone Jack/TV Out VOLUME 3.2 Megapixel Microphone Camera MUTE...
Page 6
6 Quick Start Guide Opening the hardware keyboard To use the hardware keyboard, slide the screen panel to the right to reveal the keyboard. The screen orientation automatically switches to landscape mode when the keyboard is opened. Adjusting the LCD screen angle 50°...
Quick Start Guide 7 4. Installing the SIM Card, Battery, and Storage Card You need to remove the back cover before you can install the SIM card, battery and storage card. Also, make sure to always turn off the power before installing or replacing the SIM card and battery.
Page 8
8 Quick Start Guide To remove the SIM card Insert the tip of the stylus into the small hole above the SIM card slot, and then push the SIM card out with the stylus. Slide the SIM card out from the slot with your other thumb or finger.
Quick Start Guide 9 To charge the battery Connect the USB connector of the AC adapter to the sync connector at the bottom of your device. Plug in the AC adapter to an electrical outlet to start charging the battery. The battery will be fully charged after about 3 hours of charging.
10 Quick Start Guide 5. Get Started After installing and charging the battery, you can now power on and start using your device. Turning on the power Press the POWER button on the top panel of your device. On first time use, after customised settings are installed, if you have contact information stored on your SIM card, the SIM Card Changed screen appears.
Page 11
Quick Start Guide 11 You will find the following tabs that on the TouchFLO 3D Home screen: Home Messages Calendar Stock Music Settings People Mail Internet Photos Weather and Videos To display TouchFLO 3D in landscape view When you slide out the hardware keyboard, the Home screen automatically changes to landscape view and temporarily hides the tabs.
12 Quick Start Guide • Press and hold your finger on the active tab, and then slide your finger right or left over the tabs.. • Swipe left or right across the screen. • Press the right or left key on the hardware keyboard. Press the END button anytime to return to the Home tab.
The Zoom bar located below the touch screen is a handy zoom control that is unique in your HTC Touch Pro2. When you are viewing a web page in Opera Mobile or a photo in Album, you can zoom in by...
14 Quick Start Guide 6. Personalise Your HTC Touch Pro2 Personalise your HTC Touch Pro2 to suit your lifestyle. Date and time If you are a frequent traveler, you can easily set your device to display the date and time of your location.
Quick Start Guide 15 When downloading or copying a sound file, store the file to the /My Documents/ My Ringtones folder on your device. For a complete list of supported audio file formats, refer to the Appendix in the User Manual PDF. Profile You can select a profile for incoming calls.
16 Quick Start Guide Weather and stock information Set up the TouchFLO 3D Weather tab to display up-to-date weather conditions of frequently-visited locations. Up to 10 cities can be displayed on this tab. You can also get the most up-to-date stock information. Add up to 14 stock quotes or market indexes on the Stock tab.
Quick Start Guide 17 7. Add Contacts On the People tab, you can add up to 15 favourite contacts. This makes it quicker and easier for you to make calls, send text messages, and send e-mail messages to contacts who you most frequently communicate with. Creating new contacts Before you can add favourite contacts to the People tab, you need to create new contacts or import SIM contacts.
Page 18
18 Quick Start Guide Adding favourite contacts to the People tab Once you have created or imported contacts, you can add them as favourite contacts to the People tab. On the Home screen, slide to the tab. People Tap Add Favorite, or tap one of the plus (+) icons. On the Select a Contact screen, tap the name of the desired contact.
Quick Start Guide 19 8. Experience People-centric Communication Your HTC Touch Pro2 keeps all your communication at your fingertips in one convenient location. Quick access to favourite contacts Flip through the contact pictures on the People tab and then quickly call or send a message to a favourite contact.
Page 20
20 Quick Start Guide On the Details tab, choose On the Messages tab, view On the Email tab, view how to communicate with the exchanged text messages received e-mail messages contact or edit contact details. and quickly send a reply. from the contact.
Quick Start Guide 21 9. Make Calls When you start a call from the People tab or the Contacts list, the Phone screen opens and dials the call. You can also open the Phone screen anytime by pressing the TALK/SEND button ) on your device.
Page 22
22 Quick Start Guide The Phone screen then opens, with the sender’s phone number automatically filled in and ready to be dialled. Tap Talk or press TALK/SEND again to call the sender. • Open a received e-mail. You can tap the Talk icon ( ) that is displayed to the right of the sender name to call the sender, if this sender is a stored contact.
Quick Start Guide 23 10. Send Text and Multimedia Messages Create and send text or multimedia messages to your family, friends or business associates. To send a text message On the Home screen, slide to the Messages tab and tap In the To field, enter a mobile phone number, or tap To and select a contact from the Contacts list.
24 Quick Start Guide 11. Set Up and Use E-mail On the Home screen, slide to the Mail tab and set up your personal e-mail account such as Yahoo! Mail Plus or AOL and your Outlook work e-mail account. If this is your first time to set up an e-mail account, tap New Account. If you are setting up subsequent accounts, tap Menu >...
Quick Start Guide 25 To create and send an e-mail message E-mail accounts are displayed as small e-mail icons at the right side of the Mail tab. Select an e-mail account that you want to use. to create a new e-mail. Tap To and select a contact that has a stored e-mail address.
26 Quick Start Guide 13. Straight Talk™ Your HTC Touch Pro2 features Straight Talk™, a technology that integrates messaging, voice, and conference calling, allowing you to seamlessly transition from a message to a single call or multi-party conference call. With dual microphone and speaker that enhance voice quality and reduce noise, Straight Talk turns your device into a conference room speakerphone system.
Page 27
Quick Start Guide 27 Slide open the hardware keyboard so that your device will display the Conference Room screen. Tap the photo of the first participant. When the first call is connected, tap the photo of the second participant to dial the second call. The first call is automatically put on hold.
Page 28
28 Quick Start Guide To break away from the conference call During the conference call, you can talk in private with a certain participant and put the others in the conference on hold. Tap the participant’s photo and then tap Private. To swap between a private call and the conference call, tap the dim area or tap Swap.
Quick Start Guide 29 14. Experience Internet Without the Wait Set up push Internet on your device so that you can have frequently-visited web pages pre-delivered and ready for display on the Opera Mobile browser anytime. To add a push web page to the Internet tab On the Internet tab, tap Add a new push page.
30 Quick Start Guide 15. Use the Camera Whether you are travelling on business or leisure, you can use the built-in 3.2 megapixel camera to take high-quality photos or capture video clips of your trip and encounters. To take a photo On the Home screen, slide to the Photos and Videos tab and then tap the camera icon ( Touch the area on the viewfinder screen that you want to focus on.
Page 31
Quick Start Guide 31 To capture a video clip On the Home screen, slide to the Photos and Videos tab and then tap the video icon ( Point the camera at your subject. Touch the Virtual Camera button ( ) to activate auto-focus. When focus is set, the camera automatically starts capturing video.
ActiveSync Select this mode when you need to sync information and files between your device and your computer. For more information, see “Synchronise Your HTC Touch Pro2 with Your Computer” in this Quick Start Guide.
Page 33
Quick Start Guide 33 Disk Drive This mode is available for selection only when there is a microSD card installed on your device. Select this mode when you want to quickly copy files between the storage card and your computer. Internet Sharing When you do not have Internet access on your notebook or desktop computer, you can select this mode to use your device as a modem for your computer.
34 Quick Start Guide 17. Synchronise Your HTC Touch Pro2 with Your Computer You can take information from your computer wherever you go by synchronising it to your HTC Touch Pro2. Setting up synchronisation software on your computer Depending on your computer’s operating system, you need to install either Microsoft ActiveSync®...
Quick Start Guide 35 18. Maintain the Performance of Your Device If you experience some sluggishness with your device, try a soft reset to shut down all programs and restart your device. To perform a soft reset Pull out the stylus. Remove the back cover.
• For more information, you can also visit HTC’s support web site. On the support web site, select your device model and refer to the “FAQs”. The device heats up when I’m charging the battery or when I’m making long duration calls.
Data and/or Documentation will be error-free, or implied warranties arising from course of dealing or course of performance. Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your use or misuse of the Weather Information, Stock Data, Data and/or Documentation or the results from such use.
38 Quick Start Guide Pictograms and Graphic Symbols Read this manual’s Safety Do not use while Information and General re-fuelling Precautions. Do not use hand-held while This device may produce a Read the Safety Information Section of this manual Do not use while re-fueling driving bright or flashing light For body-worn operation...
Quick Start Guide 39 Important Health Information and Safety Precautions When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages. Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.
Page 40
40 Quick Start Guide WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (140° F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.
Page 41
Pressure Level requirement laid down in the applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1. • Earphone, manufactured by HTC, Model HS S300. SAFETY IN AIRCRAFT Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most...
Page 42
42 Quick Start Guide local laws and regulations restricting the use of wireless devices while driving. Limiting exposure to radio frequency (RF) fields For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice: Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones.
Quick Start Guide 43 Your mobile device is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organisation ICNIRP and include safety margins designed to assure the protection of all persons regardless of age and health. The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR.
Page 44
44 Quick Start Guide from the body. **Note: The 1g SAR value is measured at GSM/GPRS/EGPRS 850/1900 MHz and WCDMA/HSDPA Band II & Band V. The Body SAR value of 0.499 w/kg @1g has been tested with back of the device kept at 1.5cm away from the body.
Quick Start Guide 45 To assure optimal phone performance and ensure human exposure to RF energy is within the Antenna location guidelines set forth in the relevant standards, always use your device only in its normal-use position. Contact with the antenna area may impair call quality and cause your device to operate at a higher power level than needed.
Page 46
46 Quick Start Guide • Device getting warm after prolonged use When using your device for prolonged periods of time, such as when you’re talking on the phone, charging the battery or browsing the web, the device may become warm. In most cases, this condition is normal and therefore should not be interpreted as a problem with the device.
Page 47
Quick Start Guide 47 NOTICE: When taking the device from low-temperature conditions into a warmer environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power. • Avoid pushing objects into product Never push objects of any kind into cabinet slots or other openings in the product.
48 Quick Start Guide • Operating machinery Full attention must be given to operating the machinery in order to reduce the risk of an accident. • Electrostatic discharge (ESD) Do not touch the SIM card’s metal connectors. • Seizures/Blackouts This phone is capable of producing bright flashing lights. •...
Quick Start Guide 49 Hearing Aids Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives. Other Medical Devices If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy.
